Ergotech 200-50 Compact

DEMAG

Condition: used, Demag Ergotech 3300-840, Demag injection molding machine, used machine Manufacturer : Demag, Sumitomo Model: Ergotech 3300-840 Overall dimensions : Length x Width x Height: 6.5 x 2.0 x 2.2 meters Net weight (without oil): 13 800 kg Fodpfx Akex Sqi Hohjgf TECHNICAL DATA (BY SCREW DIAMETER) ----- Description Unit "A" "B" "C" ----- Screw diameter: [mm] 45 50 60 L/D ratio: [-] 20 20 20 Injection pressure (at 400 °C): [bar] 2402 1946 1351 Shot volume: [cm3] 358 442 636 Shot weight (PS): [g] 320 400 570 Barrel heating power: [kW] 13.0 14.8 23.1 Installed electrical power*: [kW] 58/68 60/70 68/78 ----- * Note: Values are higher with electric screw drive (WA). INJECTION UNIT FEATURES ----- Max. dosing stroke: 225 mm Max. nozzle retraction: 470 mm Nozzle immersion depth: 40 mm (SVO) / 30 mm (SPI) Nozzle contact force: 80 kN Electric screw drive (WA): 20.5 kW Material hopper capacity: 75 liters GENERAL AND HYDRAULIC DATA ----- Hydraulic oil tank capacity: 700 liters Pump unit power: 45 / 55 kW Dry cycle (EUROMAP 6a): 1440 / 1600 h-1 Dry cycle (without nozzle movement): 1890 / 2100 h-1 Continuous noise level: 74 dB (A)

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: TD2002/2360, DEMAG KBK overhead crane system with approximate dimensions of 3x4m (4m span) This crane is available in multiple units! Other sizes are also available – please inquire! Load capacity / lifting capacity: 800 kg - 0.8 tons Technical data of the system: Crane system with Demag KBK2 rails The system is delivered complete: KBK rails, rail connectors, trolleys, end plates, supports/hangers, etc. The crane has internal power supply Includes 800 kg Demag DKES chain hoist (infinitely variable) - lifting height approx. 3m The crane is disassembled and immediately available Very good condition, see pictures The item is located in 75053 Gondelsheim Shipping by freight forwarder or collection only by appointment Fodpjztut Njfx Akhogf Demag KBK1, KBK2 and KBK3 rails are in stock! Other KBK systems are also available. Load capacity 125 kg - 1600 kg Please request a non-binding quote for your overhead crane system, specifying the load capacity and dimensions.

Condition: excellent (used), functionality: fully functional, Year of construction: 2013, machine/vehicle number: TD2002/0365, DEMAG KBK overhead crane, span approximately 4x4m – expandable upon request! Load capacity / lifting capacity: 500 KG - 0.5 tons Technical data of the system: Fgedpfx Aoztutvskhsf Overhead crane track made of Demag KBK2 rails The system is delivered complete: KBK rails, rail connectors, trolleys, end plates, supports/hangers, etc. Includes Dalmec manipulator PFS 120KG NL Articulating boom, rotatable 360 degrees, with approximately 3m reach The crane is disassembled and immediately available Very good condition, see pictures The item is located in 75053 Gondelsheim Shipping via freight forwarder or collection only by prior appointment Demag KBK1, KBK2, and KBK3 rails are in stock! Other KBK systems are also available. Load capacity 125KG - 1600KG Please inquire about your overhead crane with the required load capacity and dimensions.

Condition: good (used), Crane system with two fixed (l= ~14.000 mm) and three running rails (l= ~6.000 mm) with trolleys which allow the mounting of log clamps with hoist. Tilt prevention system allows smooth and perfectly parallel displacing of the running rails. Max weight per rail = 1.000 kg. Mounted from ceiling (no supporting steel structure included). Power supply via integrated conductor line inside the rails (no external wires). Compressed air with outside air pipes (not inside the rails). Fsdpfx Aeg Dgg Rekhjgf Option: chain hoist with log clamp to lift logs from a pallet onto a stream feeder.

Condition: good (used), Crane system with two fixed (l= ~7.000 mm) and three running rails (l= ~6.000 mm) with trolleys which allow the mounting of log clamps with hoist. Max weight per rail = 1.000 kg. Fjdeg Dgdvspfx Akhegf Mounted from ceiling (no supporting steel structure included). Power supply via integrated conductor line inside the rails (no external wires). Compressed air with outside air pipes (not inside the rails). Option: chain hoist with log clamp to lift logs from a pallet onto a stream feeder.

Condition: good (used), Crane system with two fixed (l= ~6.000 mm) and three running rails (l= ~6.000 mm) with trolleys which allow the mounting of log clamps with hoist. Max weight per rail = 1.000 kg. Mounted from ceiling (no supporting steel structure included). Fedpfx Aeg Dgh Iokhsgf Power supply via integrated conductor line inside the rails (no external wires). Compressed air with outside air pipes (not inside the rails). Option: chain hoist with log clamp to lift logs from a pallet onto a stream feeder.

Condition: good (used), Crane system with two fixed (l= ~7.000 mm) and three running rails (l= ~5.000 mm) with trolleys which allow the mounting of log clamps with hoist. Tilt prevention system allows smooth and perfectly parallel displacing of the running rails. Fedpfxog Dghco Akhegf Max weight per rail = 1.000 kg. Mounted from ceiling (no supporting steel structure included). Power supply via integrated conductor line inside the rails (no external wires). Compressed air with outside air pipes (not inside the rails). Option: chain hoist with log clamp to lift logs from a pallet onto a stream feeder.

Condition: used, functionality: fully functional, machine/vehicle number: 001655U, load capacity: 6,300 kg, For sale Used Demag single-girder overhead crane, 20,440 mm span x 6,300 kg capacity. Ref. 001655U * Stored in a dry environment * Technically 100% operational and inspected All our new and used cranes, which we supply with installation, come with a warranty! Fgjdpfx Akszilafshsf We can optionally supply our cranes including: * Adjustment of length and/or height and possible repainting * Power rail / conductor bar * Radio control * Tandem control * Installation and inspection You can also contact Jan Reiling B.V. for: * New lifting equipment * Parts for your lifting equipment * Swing cranes * KBK X/Y systems * Chain hoists * Wire rope hoists * Service and maintenance * Inspection of your lifting equipment In addition, we have our own stock of approximately 15,000 Demag parts. For more information, see the Jan Reiling B.V. website. Cranes, crane, gantry crane, workshop crane, warehouse crane, hoist, cranes, hall crane, bridge crane, workshop crane, storage crane, lifting equipment. Overhead crane. Single-girder. Chain hoist.

Condition: used, functionality: fully functional, machine/vehicle number: 001654U, load capacity: 6,300 kg, For sale Used Demag single-girder overhead crane, 20,440 mm span x 6,300 kg capacity. Ref. 001654U * Stored in a dry environment * Technically 100% in order and inspected Fgsdpfjzik Stjx Akhjf All our new and used cranes, which we supply with installation, come with a warranty! We can supply our cranes with the following options: * Adjustment of length and/or height, and repainting if required * Power rail / conductor bar system * Radio remote control * Tandem control * Installation and inspection You can also contact Jan Reiling B.V. for: * New lifting equipment * Spare parts for your lifting equipment * Swing cranes * KBK X/Y systems * Chain hoists * Wire rope hoists * Service and maintenance * Inspection of your lifting equipment In addition, we have our own stock of approximately 15,000 Demag parts. For more information, please visit the website of Jan Reiling B.V. Cranes, overhead crane, workshop crane, warehouse crane, hoist, cranes, hall cranes, bridge cranes, workshop cranes, storage cranes, lifting equipment, universal crane, hoist. Overhead crane. Single-girder. Chain hoist.

Condition: used, Year of construction: 2005, operating hours: 67,553 h, functionality: fully functional, clamping force: 500 kN, screw diameter: 30 mm, clearance between the columns: 355 mm, displacement volume: 106 cm³, injection weight: 96 g, mold height (min.): 210 mm, opening stroke: 400 mm, plate width: 480 mm, plate height: 480 mm, installation height: 400 mm, heating capacity: 8.3 kW (11.28 HP), power: 11 kW (14.96 HP), Machine DEMAG Ergotech Extra 50-200 with SEPRO Axess S3 handling robot. Ready for production and available for inspection at any time. 2 pneumatic cascades, 1 AS core pull, 6 integrated hot runner zones. Fgodpjx Ex R Eefx Akhef
