Universal machining center

DMG MORI DMU 60 EVO Linear

Condition: used, Year of construction: 2008, x-travel 630 mm y-travel 560 mm z-travel 560 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 10 / 15 kW max. Torque 130 / 87 Nm tool taper HSK-A63 swivellable NC: ° table surface area 1.000 x 600 mm T-slots 9x 14 x H7 max. table load 700 kg number of toolpositions 60 pos. tool taper HSK-A63 total power requirement 49,7 kVA weight of the machine ca. ca. 11,0 t dimensions of the machine ca. 4,5 x 4,5 x 3,5 m CNC - MachiningCenter Universal DECKEL MAHO - DMU 60 monoBLOCK - 4 axes (+ NC dividing head) Rjdpfx Anjx A H Rlopew - Swivel-Millinghead - Spindle refurbished - NEW X, Y, Z guideways - NEW ball screws - NEW X-axis bellows

Condition: good (used), Year of construction: 2010, Machine is in good condition. Parts shown by hand not come. Rsdpfsx N Atfjx Anpjw

Condition: good (used), Year of construction: 1997, Ref. -No.: 10620 Manufacturer: SKODA Rodpfjyagidex Anpow Type: W 200 T Year of construction: 1997 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 Storage location: Halberstadt Country of origin: Germany X-Travel: 16000 mm Y-Travel: 5150 mm Z-Travel: 1600 mm W-Axis: 2100 mm V-axis: 2000 mm B-Axis: 0 - 360 ° Spindle Diameter: 200 mm Table Load: 80.000 kg Tool Taper: SK 60 / SK 50 Turning Speeds: 1000 RPM Rotary table diameter: 3500 x 3000 mm Further information: Including angle head Machine can be inspected under power.

Condition: excellent (used), Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,800 mm, spindle diameter: 130 mm, overall weight: 32,450 kg, year of last overhaul: 2014, The machine is in very good technical condition, equipped with a Heidenhain iTNC 530 CNC control system. Specifications: Spindle diameter: 130 mm X-axis travel: 3000 mm Y-axis travel: 1800 mm Rsdsx Hfk Ijpfx Anpjw Taper in spindle: ISO 50 Spindle extension: 1120 mm Horizontal spindle head extension: 450 mm Total installed motor power: 50 KVA Dimensions (L x W x H): 10100 x 4380 x 5250 mm Weight: 32,450 kg

Condition: excellent (used), Year of construction: 2007, • Maximum possible drilling depth: 1200 mm • Maximum hole diameter: 32 mm • Minimum drilling diameter: 6 mm • Longitudinal travel (X-axis) table: 1800 mm • Cross travel (Z-axis) column: 1700 mm • Cross travel (W-axis) drilling head: 1150 mm • Vertical travel (Y-axis) drilling head: 1200 mm • Clamping surface NC table: 1500 x 1000 mm • Maximum table load: 10 t • Rotary axis (B-axis) rotary table: 360° • Rotary axis (A-axis) drilling head: -25°/+15° • Feed rate: 1-15 m/min (Y-axis: 1-10 m/min) • Rapid traverse speed in all axes: 15 m/min (Y-axis: 10 m/min) • Maximum spindle speed: 6000 rpm • Minimum spindle speed: 60 rpm • Tool holder: SK 40 • Tool clamping: OTT • Rated power main drive (100% ED, S1/40% ED, S6): 9/13 kW • Coolant tank capacity: 1000 l Rsdoxyf E Nspfx Anpow • Maximum coolant pressure: 100 bar • Low-pressure external and high-pressure internal coolant supply • Power supply: 3x 400 V; 50 Hz • Required installation space (L x W x H): 6550 x 5350 x 4130 mm • Machine weight: 12,000 kg Deep Hole Drilling Machine Equipment • CNC control: HEIDENHAIN iTNC 530 • Interpolated rotary table with minimal backlash, dimensions 1500 x 1000 mm • Swiveling drilling head +15°/-25° • Shank drilling head • Handwheel HR520 • Fixed supports (2 units) • Tool magazine: ELB tools: 12 pcs (max. diameter: 32 mm / max. length: 1550 mm) Standard tools: 12 pcs (max. diameter: 140 mm / max. length: 400 mm) • Direct measurement and positioning system in X, Y, and Z axes • Collision monitoring system for supports and drill sleeves • Oil cooler • Coolant flow control system • Adjustable coolant nozzles • Cooling unit for electrical cabinet • Enclosed upper cover (roof) • Drip tray for machine and tank facility (tray height 30 mm) • Extraction system • Infrared touch probe • Drilling depth extension 1200 mm (retrofit) • Chip conveyor

Condition: used, Year of construction: 1999, Pallet size 800 x 800 mm X/Y/Z - 1250/1000/850 mm Spindle taper BT 50 Spindle speeds 5000 rpm Tool changer w/80 stations Control: Redpfx Asv Rntujnpow Fanuc 18 i-M Equipped with: 2 pcs. pallets

Condition: used, Year of construction: 1990, spindle diameter 150 mm x-travel 4000 mm y-travel 3000 mm z-travel 1000 mm w-travel 1500 mm Table area 2000x2000 mm Table load 30 t Feed 3-3500 mm/min Rapid movement 5000 mm/min transmission ratio 2 spindle power 37 kW voltage 380 V frequency 50 Hz Control Heidenhain type ITNC mm The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Rodpfx Aeyqtf Tjnpow Your Markus Hirsch Team

Condition: good (used), functionality: fully functional, Year of construction: 2007, operating hours: 1,153 h, DYNO-MILL KD 6 Agitator Bead Mill (2007) Rsdpox Tdyzefx Anpow For sale is a DYNO-MILL KD 6 horizontal agitator bead mill, manufactured by Willy A. Bachofen AG (WAB). This machine is a premium Swiss-made unit designed for the continuous dispersion and wet-grinding of pumpable products, ranging from low to high viscosity. This unit was manufactured in 2007 and decommissioned in fully functional, running condition with no known faults. It is distinguished by its exceptionally low usage history, having logged only 1’153 operating hours. It comes equipped with a high-wear-resistant Silicon Carbide (SiSiC) inner cylinder and hardened stainless steel discs. It is sold as a complete bundle, including a peristaltic pump, a tool kit, the original electric cabinet and yttrium-stabilized zirconium balls (used). Highlights • Low Usage: Only 1'153 operating hours—internal mechanics are in excellent condition. • High-End configuration: Fitted with a ceramic Silicon Carbide (SiSiC) inner cylinder (6mm wall thickness) and hardened stainless steel discs for durability and contamination control. Sintered Silicon Carbide (SSiC) prevents product overheating significantly better than Zirconium or Steel liners. • Ready to Run: Sold as a complete package including the Electric Cabinet and a Peristaltic Product Pump. • Features the industry-standard WAB dynamic gap separator and pressure-balanced mechanical seal. • Voltage: Fitted with a modern Danfoss VLT frequency converter featuring wide-range input (380-480V, 50/60Hz), making the machine immediately compatible with both European (400V) and US (480V) power grids without modification Technical Specifications • Manufacturer: Willy A. Bachofen AG (WAB), Switzerland • Model: KD 6 • Grinding Chamber Volume: 6.0 Liters (Net volume ~5.7 Liters) • Throughput: approx. 50 – 200 kg/h (dependent on product/viscosity) • Main Drive: 11 kW Motor (440V / 60Hz rated) • Separation System: Dynamic gap separator (Tungsten Carbide rotor/stator) with adjustable gap width (0.15–1.0 mm) • Shaft Seal: Double mechanical seal (DGD) with integrated pressure rinsing circuit • Cooling: Forced water cooling jacket for the grinding cylinder • Weight: 695 kg
 Scope of Delivery • Mill: DYNO-MILL KD 6 base unit • Grinding System: Silicon Carbide (SiSiC) Inner Cylinder & Hardened Stainless Steel Discs • Feed Pump: Peristaltic Pump included • Controls: Original Electric Cabinet included • Grinding Media: Ceramic Beads, Zirconia Partially Stabilized with Yttria, four sizes, each approx. 25Kg (0.4 - 0.6 mm / 0.8 - 1.0 mm / 1.2 - 1.4 mm / 1.6 - 1.8mm) • Documentation: Operating instructions and wiring diagrams Condition • Mechanical: Excellent, running condition with no known faults at the time of decommissioning. • Cosmetic: The machine is clean but shows minor cosmetic wear (see pictures for visual details) • Last application: Food Typical Applications • Ideal for fine particle size reduction in industries such as: • Paints, Inks, and Coatings • Agrochemicals and Chemicals • Life Sciences and Microbiology • Food and cosmetics We ship worldwide. If you are interested or have any questions, please get in touch! Can be inspected in Liestal, Switzerland.

Condition: good (used), Year of construction: 2006, operating hours: 93,050 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 12 m/min, feed rate X-axis: 4 m/min, feed rate Y-axis: 4 m/min, feed rate Z-axis: 4 m/min, controller manufacturer: Fanuc, controller model: 15i, workpiece weight (max.): 5,000 kg, table width: 1,000 mm, table length: 1,000 mm, table load: 5,000 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 8,000 rpm, coolant supply: 30 bar, number of spindles: 1, number of slots in tool magazine: 120, tool length: 470 mm, tool diameter: 380 mm, tool weight: 15,000 g, Equipment: chip conveyor, documentation/manual, Horizontal machining center 4 axes / 4th axis resolution 0.001mm Spindle speed 8000 rpm 2 gear stages ATC with 120 tool pockets Rjdpfx Anexxt Ucepow Tool holder: MAS BT50 / pull stud Mitsui Direct measuring systems X / Y / Z / B Coolant supply: external / internal / Niagara Rigid tapping function Travel paths: X=2000mm Y=1500mm Z=1200mm Interference circle: 2000mm Scraper belt conveyor Knoll type 340 K-1 Filter system Knoll type SF1000/Turbo 2 Filter system footprint: 2500 x 1400 x 2400mm

Condition: used, Year of construction: 2001, Technical details: x-travel: 2000 mm y-travel: 1600 mm z-travel: 1140 mm b-axis: 0.0001° x 360° ° number of pallets: 4 table surface area: 1000 x 1450 mm max. table load: 6.000 kg turning speed range: 4 - 10000 U/min Rjdoxc E H Eepfx Anpsw power capacity at 100 % load: 40 kW kW tool taper: HSK100 DIN69893A machine weight ab.: 63.000 kg space required L x W X H: 12320 x 11000 x 4700 mm incl. 50 x HSK100 tool tapers *
