SBZ122

elumatec SBZ122

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 12200991016, rotational speed (min.): 24,000 rpm, overall weight: 1,635 kg, tool weight: 2,900 g, input voltage: 400 V, For economical and efficient machining of aluminium, plastic and thin-walled steel profiles All machining processes such as milling, drilling and thread cutting take place on a stationary profile, protecting the profile surface Improved work results thanks to the use of intelligent control technology Fast positioning of the machining unit at up to 60 m/min thanks to the use of dynamic servo drives Itsdpfx Aswgmyqeqcol Thread cutting without compensating chuck Automatic clamp recognition and positioning Automatic tool magazine with four tool shelves (without tools) Modern, 3-axis control Ergonomic work thanks to the use of a modern inclined bed No need for a reference movement of the axes thanks to the use of absolute encoder-based systems Collision avoidance thanks to automatic clamp recognition and positioning Power-Torque milling motor with closed speed control ensures short start-up and deceleration times spindle Certified, drive-integrated safety functions Low power consumption thanks to intelligent control technology Increased energy efficiency thanks to the connection of axis drives between circuits Uninterruptible power supply (UPS) Windows operating system 15.6" Panel PC, i3 processor, USB ports and network interface Easy and convenient program entry via eluCam on the operator panel, even during machining Remote online maintenance Machine equipment Air-cooled 8 kW milling spindle, S1 Cabin for operator protection Four horizontal pneumatic clamps for clamping the material Material stop, left side HSK-F63 tool holder Minimum quantity lubrication High-performance coolant Manual control panel Depth gauge Options Tools Tool holders Automatic tool magazine for up to four standard tools Automatic tool magazine for angle head Rotating head HSK-F63 angle for two tools Green-line cooling unit for control cabinet with reduced energy consumption Barcode scanner Protective cabin, optionally with all-round closure Four clamps as standard. Expandable to eight clamps Right reference material stop for placing workpieces with overlength processing Additional stop for overlength processing on the left Length measurement on both sides Double clamp and additional accessories upon request Panel PC 18.5", i5 processor Panel PC 21.6", i7 processor Note holder Sound-absorbing hood Chip disposal using chip trays

Year of construction: 2009, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 3,850 mm Itodpfx Aqsyqyaqjcel Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Windows control with USB connections Speed continuously adjustable up to 22,000 RPM handheld control unit minimum quantity spraying Tool changer with 2 magazines (total 10 places plus angle head) tensioner detection and tensioner displacement 2 light barrier ranges and 2 material stops, enabling pendulum operation A total of 8 material clamps Spindle in good condition, spindle-insertion force: 12 kN Weight: approx. 2,000 kg

Year of construction: 2018, operating hours: 5,750 h, condition: used, functionality: fully functional, overall weight: 3,800 kg, total length: 7,650 mm, total width: 2,180 mm, total height: 3,000 mm, milling spindle speed (max.): 20,000 rpm, number of spindles: 1, type of cooling: water, machine/vehicle number: 1220099569, operating hours of spindle: 5,720 h, number of slots in tool magazine: 12, number of axes: 5, Elumatec SBZ 122/75, a 5-axis machining center for aluminum profiles. Due to a change in production to a tube laser system, we are selling our fully functional Elumatec SBZ 122/75. Service was performed by Elumatec in March 2026 (see attached maintenance report), and we have not used the machine since then. Interested parties are welcome to view and test the machine at any time. Special equipment (see also the attached invoice): - Length measurement on both sides - 2 additional, automatically positionable material clamps - 1 additional material stop on the right side, allowing for the processing of oversized lengths - Control cabinet cooling Technical data (see also the attached brochure): - X-axis travel: 4176mm - Y-axis travel: 1040mm - Z-axis travel: 540mm Itodpfxjzz Tbhs Aqcel - A-axis swivel angle: -120° to +120° freely programmable - C-axis swivel angle: -220° to +220° freely programmable - Max. machining length without end-face machining: 3851mm - Max. machining length with end-face machining: 3525mm - Tool changer with 12 positions - Saw blade diameter: 180mm - 6 material clamps - Tool holder: HSKF63 - Spindle power: 7kW / 20000 rpm, water-cooled - 2-layer machining - Minimum quantity lubrication - Central lubrication This very fast and agile machine with a 5-axis head leaves nothing to be desired. The machine is available immediately. Space requirements can be found in the layout in the appendix. You can also find the transport instructions in the appendix; please contact us if you have any questions. Dismantling, loading and transport should preferably be organized by the buyer due to the subsequent reassembly. Various auxiliary tools can be made available upon request, if available. All information and dimensions have been provided to the best of our knowledge and belief; however, no guarantee can be given for completeness and accuracy! The sale is made as is, without any guarantee, return policy or similar. Subject to prior sale.

Year of construction: 2008, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Itsdpfx Aozx Dz Teqcel Max. travel X-axis: 3,850 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control E 550 Speed continuously adjustable up to 24,000 rpm Handheld control unit Minimal量 sprühung tensioner detection and tensioner displacement Profile length measurement at the head Barcode scanner 5 pneumatic material clamps light barrier Additional material stop on the left for long profiles Spindle in like-new condition, spindle feeding force: 16 kN Weight: approx. 2,000 kg

Year of construction: 2006, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 3,850 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Iodjx Ecfkspfx Aqcetl Control E 550 Stepless speed control up to 21,000 rpm Manual control device Minimal quantity spray Automatic tool changer with magazine (4 slots plus angle head) Spanner measurement and clamp displacement 4 pneumatic material clamps Light barrier Weight: approx. 2,000 kg

Year of construction: 2007, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 280 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 21,000 rpm, working length: 3,750 mm, TECHNICAL DETAILS Machining length with bar support: 3,750 mm Machining length without bar support: 3,500 mm Travel range X-axis: 3,500 mm Travel range Y-axis: 280 mm Travel range Z-axis: 300 mm Positioning speed: 30 m/min Positioning accuracy: ±0.1 mm Spindle power: 6 kW Spindle speed: 21,000 rpm Spindle interface: HSK F63 Tool positions: 5 Max. tool diameter (manual): 200 mm Max. tool diameter (automatic): 92 mm Max. saw blade diameter: 500 mm MACHINE DETAILS Air consumption: approx. 50 l/cycle Compressed air requirement: > 7 bar Power supply: 400 V, 3-phase Itsdpsznczkofx Aqcjl Note: The machine's operating hour counter is defective and cannot be read. The machine was only used in a single-shift operation.

Year of construction: 2022, operating hours: 141 h, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 4,176 mm, travel distance Y-axis: 1,040 mm, travel distance Z-axis: 540 mm, saw blade diameter: 180 mm, milling spindle speed (max.): 20,000 rpm, machine/vehicle number: 122000029, Machine with only 141 operating hours! TECHNICAL DETAILS Travel range X-axis: 4,176 mm Travel range Y-axis: 1,040 mm Travel range Z-axis: 540 mm Traverse speed X-axis: max. 120 m/min Traverse speed Y-axis: max. 60 m/min Traverse speed Z-axis: max. 30 m/min Machining length without end-face machining: max. 3,851 mm Machining length with end-face machining: max. 3,525 mm Maximum bar diameter: 180 mm Tool storage locations in the automatic magazine: 12 Disc cutter diameter: 120 mm Saw blade diameter: 180 mm Tool length: max. 150 mm Itjdpjzgfvbsfx Aqcol Milling spindle speed: max. 20,000 rpm Milling spindle power: 7 kW S1 (water-cooled) Tool holder: HSK-F63 MACHINE DETAILS Voltage: 400 V Frequency: 50/60 Hz Power: 17.5 kW Current consumption: 25 A Maximum motor current consumption: 20 A Short-circuit resistance (Ik/SCCR): 5 kA Compressed air pressure: 7 bar Dimensions & Weight Dimensions (L x W x H): 7,643 x 2,171 x 3,000 mm Weight: 3,800 kg EQUIPMENT Automatic tool changer eluCam software Autonomous clamping jaw movement Premium clamping jaw with linear guide A-axis, infinitely adjustable from -120° to +120° C-axis, infinitely adjustable from -220° to +220° Note: Further technical details regarding the machine can be found in the attached document.

Year of construction: 2010, condition: used, 3-axis machining center with automatic tool change for aluminum or PVC profiles Max. travel X-axis: 6,700 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control Windows 10 with a new computer in 2023 Speed continuously adjustable up to 24,000 rpm handheld control unit minimum quantity spraying Tool changer with 2 magazines (total 10 places plus angle head) tensioner detection and tensioner displacement 2 pneumatically folding material stops and 2 light barrier areas, thus pendulum operation possible A total of 8 material clamps Iedpswwukxsfx Aqcotl Spindle in very good condition, spindle pull-in force: 12.5 kN Safety fence dismantled, a demonstration is still possible by arrangement Weight: approx. 3,500 kg

Year of construction: 2010, operating hours: 11,200 h, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 12222321222, Equipment: type plate available, Elumatec SBZ122/33 profile machining center, year 2010 Technical data: Working area: X - 3850 mm, Y - 350 mm, Z - 280 mm Electrospindle 10 kW - max. 20,000 rpm (overhauled in 2023) (RF-HSK-F63 125/125x430 24/6.5) Tool holder HSK-63 F Tool changer Work table with 4 clamps with automatic positioning Pneumatic clamping operation Photoelectric safety barrier Isdsw Rv A Uepfx Aqcotl Operator handheld terminal Control panel workstation USB connection Operating software: Windows 7 system Production software: EluSoft, EluCAM Numerical control: Ferrocontrol Protective fencing with doors (laser safety barrier) Automatic and central lubrication of linear guides Weight: 1,940 kg Total connected load: approx. 14 kW Machine dimensions: 4,670 x 2,000 x 2,540 mm Required space: 5,165 x 3,000 x 2,540 mm Machine used for aluminum profile processing. Serviced and ready for operation.
