Vertical cnc lathe

EMAG VSC 500

Condition: used, Year of construction: 1999, turning diameter 500 mm swing diameter 520 mm x-travel 1000 mm z-travel 400 mm spindle head DIN 55026 - Size 11 turning speeds max. 4000 U/min rapid traverse x + z axis 45 / 30 m/min Dwsdpfozn Agmjx Akhea feeding force 11 kN total power requirement 71 kW weight of the machine ca. 13,5 t dimensions of the machine ca. 9,5 x 4,5 x 3 m

Condition: used, Year of construction: 2012, turning diameter 400 mm swing diameter 420 mm x-travel 850 mm z-travel 315 mm spindle head DIN 55026 - Size 11 spindle bearing diameter 140 mm turning speeds max. 4000 U/min tool turret 12 times C5 Capto rapid traverse x + z axis 45 / 30 m/min feeding force 11 kN total power requirement 58 kW weight of the machine ca. 9 t dimensions of the machine ca. 9,5 x 4,5 x 3 m Hard turning Dsdpfx Asvxwx Aekhewa Dry machining Chip conveyor Promot Portal and Cellmaster No clamping device available No tools available no Cellmaster accessories available

Condition: like new (used), Year of construction: 2021, Offered is a double spindle pick up turning machine VSC 500 DUO. The machine is equipped with 2 independent working spindles and 2 EMAG turrets. The machine can produce 2 identical workpieces with the same machining operation, as well as one workpiece in two successive machining operations. The machine can be equipped with various periphery (chip conveyor, coolant system, external automation, etc.), depending on requirements. COTROL Siemens 840 Dsl TECHNICAL DATA workpiece diameter: max. 440 mm Dwedpfx Aet Du Tdjkhoa workpiece height: max. 250 mm chuck diameter: 450 mm swing diameter: 550 mm X-stroke: 925 mm Z-stroke: 400 mm TOOL CARRIER 2x EMAG disc turrets, 12x CDI 68, with driven tools Price, delivery time and equipment of the machine on request.

Condition: ready for operation (used), Year of construction: 2022, operating hours: 6,000 h, functionality: fully functional, spindle speed (max.): 4,000 rpm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 30 m/min, turning diameter: 450 mm, total length: 8,720 mm, total height: 3,888 mm, total width: 4,325 mm, type of input current: three-phase, torque: 585 Nm, overall weight: 18,000 kg, controller model: Siemens 840 D sl, For sale: a Hessapp DVT400, manufactured in 2022. Equipped with a Siemens 840 D sl control system. Features: - Powered tools on the left turret - Infeed and outfeed conveyor - Chip conveyor (discharge on the right) Dwsdpsw D Apcofx Akhoa - 2x tool holders, 12x VDI50 The machine is operational and can be inspected.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Line 1 – Hessapp Line 1 consists of 3 Hessapp lathes integrated with gantry loading. Following the turning operations, the line includes: • 2 twin-spindle multi-operation machining centers, make SW BA400, for drilling operations • 1 gear machining machine, make Unisign Univers 6 • Complete robot automation including infeed and outfeed conveyors Line 2 – Maus Dedpfxey S Ty Uj Akhowa Line 2 consists of 3 Maus lathes integrated with gantry loading. Following the turning operations, the line includes: • 2 twin-spindle multi-operation machining centers, make SW BA400, for drilling operations • 1 gear machining machine, make Unisign Univers 6 • Complete robot automation including infeed and outfeed conveyors Line 3 – EMAG / Diedesheim / Unisign Line 3 consists of: • 2 EMAG VSC 500 DB machines • 2 Diedesheim VDM55-11 machines • 1 Unisign Univers 6 for gear machining • Complete robot automation including infeed and outfeed conveyors

Condition: used, Year of construction: 2020, turning diameter max. 3.800 mm diameter of spindle flange 1.900 mm max. swing diameter 3.800 mm control 840 D sl Siemens turning speed range - main spindle max. 100 min/-1 power capacity - main spindel 200 kW max. Torque 67.000 Nm gear box 1:30 tool taper Capto C8 swivellable B: 0 - 270 ° Spindle speed - driven tool pos. max. 6.000 min -1 max. Torque 120 Nm tool taper Capto C8 number of toolpositions 41 pos. max. tool weight 20 kg max. tool length 400 mm max. tool diameter 120 mm 0 125 mm tool taper Capto C8 number of toolpositions 25 pos. workpiece diameter at full load 150 mm max. tool weight 20 kg max. tool length 400 mm x-axis 1: 2.800 mm x-axis 2: 3.200 mm z-axis 1.000 mm rapid traverse X: 32 / Z: 20 m/min feed power X/Z: 22 kN total power requirement 280 kVA weight of the machine ca. 155 t dimensions of the machine ca. 10,4 x 6,3 x 5,7 m CNC Vertical Turning Machine PITTLER - PV 4000 Dedpoyrhl Defx Akhswa - Control Expansion / Software SINUMERIK 828D/840D SL ProgramSYNC Software Option - 12-Jaw Compensating Chuck by RÖHM - Retractable Step Guards - Coolant Circulation - Coolant Conditioning - Oil Hose Skimmer - SIEMENS Safety Integrated - Network Interface / Data Transfer DNC Option - Remote Diagnostics for NC Functionality - Teleservice for Integrated PLC of the Sinumerik 840D - Ethernet Connection in the Control Cabinet - Variable Speed ??Range to Reduce Vibration - Air Purifier, Electrostatic Discharge - Probe for In-Process Workpiece Measurement - Walk-in Work Area

Condition: used, TECHNICAL DETAILS - axes number : 3 CAPACITY - machining diameter : 250 [mm] Dwsdpfxeuhbfys Akhoa - travels (X/Z) : 1600 / 300 [mm] - rapid feeds (X/Z) : 60 / 30 [m/min] SPINDLE - spindle nose : DIN55026 - size 6 - power : 18 / 22 [kW] - torque : 202 / 250 [Nm] - speeds : 0 - 6.000 [rpm] - indexing precision axis C : 0,001 [°] TURRET - number of positions : 12 - tool holders : VDI40 - number of rotary positions : 12 - rotary tools speed : 6.000 [rpm] - rotary tools power : 8,5 [kW] MILLING HEAD - number of spindles : 6 - 5 HSK 50 spindles upon Ø : 107,95 [mm] - 1 HSK40 spindle : at center ELECTRICAL SUPPLY - voltage : 400 [V] - installed power : 45 [kW] DIMENSIONS - floor space : 4.550 x 2.810 [mm] - height : 3.600 [mm] - weight : 10.000 [kg] EQUIPMENT - control CNC SIEMENS 840D-sl - 3 colors status lamp - linear scales : HEIDENHAIN - automatic part loader with conveyor - chips conveyor - coolant tank * with pump 10 bars * with washing gun - coolant through spindle - IFS mist separator - collection of parts supports - collet chuck - 3 live tool-holders
