Guidance and lathe
Emco Emcomat 17 D

Name: Emco Emcomat 17 D
Brand: Emco
Availability: InStock

Condition

New

Location

Mindelheim Germany

Machine data

Machine type:: Guidance and lathe

Manufacturer:: Emco

Model:: Emcomat 17 D

Condition:: new

Price & Location

Seller location:: Biberkopfstraße 4, 87719 Mindelheim, Germany

Call

Details about the offer

Listing ID:: A322-6977

Update:: 09.01.2025

Description

Machine according to DIN 8605: Lathe with increased accuracy.

Distance between centers: 700 mm
Distance between centers: 170 mm
Swinging diameter over bed: Ø 340 mm
Swinging diameter over carriage: Ø 190 mm
Bed width: 260 mm
Travel of longitudinal slide: 600 mm
Travel of cross slide: 220 mm
Travel of top slide: 110 mm
Carriage length: 410 mm
Carriage width: 150 mm
Guide length of bed carriage: 380 mm
Lathe tool shank cross-section: 20x20 mm
Distance from lathe center to top slide: 34 mm
Swiveling range of top slide (rest): 60/120°
Kjdpjdctnbsfx Akwsdt

Main spindle:
Spindle mount DIN 55029 (camlock): S 5
Spindle bore: Ø 50 mm
Internal taper according to DIN 7178: 1:22
Spindle diameter in the front bearing: Ø 70 mm
Max. chuck diameter: Ø 200 mm
Max. faceplate diameter: Ø 200 mm
Spindle speeds: 40-3000 RPM
Speed control: Stepless
Mechanical speed steps: 4

Main drive:
Power at 40% duty cycle: 5.3 kW
Max. rated torque at main spindle: 640 Nm

Feed:
20 (28) longitudinal feeds Z: 0.045-0.787 mm/rev
20 (28) cross feeds X: 0.023-0.406 mm/rev

Threads:
20 (28) metric threads (standard equipment): 0.4 - 7.0 mm
32 inch threads (with optional gear set D3Z200): 56 - 4 TPI
28 module threads (with optional gear set D3Z200): 0.2 - 3.5
32 diametral pitch threads (with optional gear set D3Z200): 112 - 8

Tailstock:
Arbor diameter: Ø 50 mm
Internal taper of arbor: MK 3
Arbor travel: 120 mm
Lateral adjustment: ± 13 mm

Permissible workpiece weights
Suspended: 50 kg
Supported by tailstock: 150 kg

Further standard equipment (standard accessories):
Includes machine stand and integrated 3-axis digital display, German language, with color display
1 length stop
1 center, taper 1:22, DIN 7178
1 center MK3
1 chuck key
1 key part
1 grease gun
3 hexagon head screws M16x60 - DIN 933
3 hexagon nuts M16-8 DIN 934
1 simple tool holder
1 key A13x17 DIN 837
1 open-end wrench SW 19
1 open-end wrench SW 22
1 hexagon screwdriver SW 5
1 hexagon screwdriver SW 6
1 hexagon screwdriver SW 8
3 shear pins
1 box wrench
1 operating manual incl. parts list
1 electrical documentation
1 test report
Packaging (for truck transport with pallet and plastic cover)
Machine according to CE

Note: Illustrations show special equipment / accessories, among other things!

The listing was translated automatically. Translation errors are possible.
