Plastizising Unit Engel 25mm

ENGEL

Condition: excellent (used), Year of construction: 2011, operating hours: 80,000 h, functionality: fully functional, clamping force: 1,200 kN, screw diameter: 40 mm, displacement volume: 201 cm³, total length: 5,245 mm, total width: 1,525 mm, total height: 2,300 mm, overall weight: 7,200 kg, input frequency: 50 Hz, input voltage: 400 V, The machine comes from the current series production of a plastics processor and, according to the previous owner, is fully functional. An inspection at the production facility is possible after scheduling an appointment. Key data (according to manufacturer's specifications ENGEL) • Clamping force 1,200 kN (120 t), tie-barless clamping unit • Platen dimensions 790 × 790 mm (Wide Platen), minimum tool size 350 × 350 mm • Tool installation height min. 400 mm, opening stroke 506 mm, max. platen distance 900 mm • Ejector 130 mm stroke, 39.8 kN • Injection unit 1 (330H, horizontal): screw Ø 40 mm, displacement volume 201 cm³, specific injection pressure 1,221 bar / increased 1,667 bar • Injection unit 2 (80W, angled position): displacement volume 38 cm³ (screw Ø 22 mm) or 49 cm³ (Ø 25 mm) [CHECK 09/25: which screw] • Hydraulics: pump drive 30 kW, oil capacity 300 l • Connection 3 × 400 V, 50 Hz, 139 kW / 220 A • Control system ENGEL CC 200 [CHECK 09/25] • Operating hours 87,300 h (as of 09/2026); plasticizing cylinder Ø 40 mm from 2021 with 20,300 h (according to the previous owner) Your advantages • Tie-barless: The tool space is free from tie bars. Large and bulky tools with core pulls can be accommodated, for which a larger clamping force class would often be required in tie-bar machines. • Short setup times: Tools are installed from the side without tie-bar removal. • Automation: Robots travel horizontally into the tool space – smaller cell, lower hall height, shorter cycles. • Tool-friendly: Platen parallelism via the patented ENGEL Flex-Link system (according to the manufacturer). • Hydraulic connections for core pulls, parallel movements programmable (according to the previous owner) – for tools with sliders, undercuts and thread cores. • Combi version with space for a rotary table or indexing plate (according to the manufacturer). • Main injection unit with a newer plasticizing cylinder (2021). • Second injection unit, according to the previous owner, was not used in operation, therefore minimal wear. [CHECK 09/25: unit available + free injection test] Typical applications 2K hard/soft and two-color: handles with TPE zone, housings with molded-in seal, switches and operating elements, connectors with seal, rollers with soft tread, closures with sealing lip, cable glands, medical components, two-color design parts. Single-component: technical precision parts and parts with inserts. Scope of supply • Injection molding machine as described [CHECK 09/25: with both injection units] • ENGEL data sheet, layout plan, platen drawing Not included in the scope of supply: the peripherals visible in the photos (removal/automation with protective enclosure, temperature control units, material handling and drying, mobile switch cabinet) and tools. Ljdpfxoz Eimfj Agrert Terms and conditions • Price on request • Available presumably from week 48/2026 • Payment 100% advance payment • Transport throughout Europe on request Note: The technical specifications are based on the manufacturer's documentation and the information provided by the previous owner. They are for informational purposes only and do not constitute an agreement on the condition or a warranty within the meaning of §§ 434, 443 BGB. We will confirm individual values during the inspection or upon request. Offer subject to change, prior sale reserved.

Condition: used, Year of construction: 2005, operating hours: 124,424 h, functionality: fully functional, machine/vehicle number: 155134, clamping force: 1,500 kN, total length: 5,196 mm, total width: 1,704 mm, total height: 2,189 mm, overall weight: 9,500 kg, Equipment: documentation/manual, Technical condition: operational, used until the end of its production run. Regularly serviced and maintained. This machine is ideally suited for the production of plastic components. It features a robust design from a reputable manufacturer, ensuring reliable and precise operation. Additional information: The machine can be viewed by prior appointment. Technical documentation is available. Assistance with arranging loading is provided. Lrodez Eiafjpfx Agret Price: 35,000 PLN net / the price includes an ENGEL ERC 13/1-F robot, serial no. 155243, manufactured in 2005, installed on the machine.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, clamping force: 1,800 kN, screw diameter: 55 mm, displacement volume: 510 cm³, mold height (min.): 300 mm, ejector force: 80,000 N, ejector stroke: 180 mm, total length: 6,200 mm, total width: 1,800 mm, total height: 2,200 mm, overall weight: 12,900 kg, Clamping force: 180t Year of manufacture: 2014 Injection unit 1050 Screw diameter: 55 mm Specific injection pressure: 1615 bar Injection volume: 510 ccm Pump motor power: 30 kW Cylinder heating band power: 16.3 kW Tool closing unit 1800 Clamping force: 180 t Ljdpfxjz Eacwe Agrert Tool plate dimensions: 880 x 830 mm Ejector force: 80 kN Ejector stroke: 180 mm Tool height: from 300 mm Opening stroke: 750 mm Maximum platen distance: 1050 mm Weight: 12900 kg Dimensions (m) L x W x H: 6.2 x 1.8 x 2.2 m Technical data: - Clamping force 1,800 kN (180 t) - Injection unit 1050, screw diameter 55 mm - Max. injection volume 510 cm³ - Injection pressure 1,615 bar, holding pressure up to 2,050 bar - Injection rate 255 cm³/s - Metering stroke 215 mm, max. screw speed 230 rpm - Opening stroke 750 mm, min. mold height 300 mm - Max. platen distance 1,050 mm - Mounting plates 880 x 830 mm - Max. mold weight 2,250 kg - Ejector: stroke 180 mm, force 80 kN - 6 mold cooling circuits at 10 l/min - Dry cycle time 2.0 s at 250 mm - Oil tank 540 l - Machine weight 12.9 t, dimensions 6.2 x 1.8 x 2.2 m

Condition: good (used), Year of construction: 2011, functionality: fully functional, clamping force: 1,000 kN, screw diameter: 35 mm, injection pressure: 1,600 bar, total length: 4,000 mm, total width: 1,300 mm, total height: 1,900 mm, overall weight: 4,400 kg, warehouse no.: 503730 manufacturer: ENGEL type: e-max 310-100 controller: LC 200 A01 year of construction: 2011 clamping force: 1000 kN distance between tie-bars h x v: 460 x 410 mm size of mould plates h x v: 650 x 600 mm min. mould height: 150 mm max. mould height: 450 mm max. open daylight: 800 mm opening stroke: 350 mm screw diameter: 35 mm swept volume: 135 ccm injection pressure: 1600 bar equipment included incl. Spruepicker screen text german core pulling hydraulically 1x Anti vibration mounts mould heating 8x handling type: Angussentnahmegerät manufacture: ENGEL controller: ER-USP 5 year of construction: 2011 measures of machine l x w x h: 4m x 1.3m x 1.9m total weight: 4400KG Lodpfx Agsz Eabtsrort

Condition: good (used), Year of construction: 2011, operating hours: 78,000 h, functionality: fully functional, clamping force: 2,200 kN, screw diameter: 55 mm, injection pressure: 1,615 bar, total length: 5,700 mm, total width: 1,700 mm, total height: 2,200 mm, overall weight: 12,200 kg, warehouse no.: 503731 manufacturer: ENGEL type: Victory 1050-220 spex controller: CC 200 A02 year of construction: 2011 operation hours: 78000 h clamping force: 2200 kN size of mould plates h x v: 880 x 830 mm min. mould height: 300 mm max. open daylight: 1050 mm opening stroke: 750 mm screw diameter: 55 mm injection volume: 510 ccm Spritzdruck: 1615 bar equipment included: screen text german core pulling hydraulically 2x machine incl. Handling Anti vibration mounts mould heating 8x technical data robot-system Lrjdpfxjz D U Ilo Agrjt handling type: Linear manufacture: ENGEL controller: Viper 6 year of construction: 2011 measures of machine l x w x h: 5.7m x 1.7m x 2.2m total weight: 12200KG

Condition: excellent (used), Year of construction: 2015, ENGEL victory 650/120 tech (25.109 h) (S&P 3793) Manufacture year: 2015 Operating hours: 25,109 Stunden Screw: 35 mm Injection pressure: 2400 bar Stroke volume: 192 cm³ Clamping Force: 120 t Tie bar distance: 740 x 680 mm Mould installation height min.: 300 mm Lredoz D Uthepfx Agrot Plate distance max.: 800 mm Dimensions: 5100 x 1500 x 2350 mm Eeight: 7000 kg Connected load: 22 kW Automatic door, Corepuller 1x, Airvalve, Hotrunner, price when new 122.000,- € etc... Price: on request contact: Mr. Ralf Schulz

Condition: excellent (used), Year of construction: 2004, Engel Victory 1350/220 Tech, clamping force 220 tonnes, year of manufacture 2004. Clamping plate dimensions (W x H): 860x830 mm. Screw diameter: 55 mm, volume: 618 cm³, center distance: 200 mm. Minimum mold height: 250 mm, maximum: 730 mm. Lrsdpfexu Rlkox Agrst

Condition: excellent (used), Year of construction: 2001, Engel ES 500/110 HL Clamping force: 110 tonnes Year of manufacture: 2001 Screw diameter: 45 mm Lrodpfx Ajxu Rldsgrst Injection volume: 318 cm³ Enlarged clamping platen Platen dimensions: 730x600 mm

Condition: ready for operation (used), Year of construction: 2004, clamping force: 1,600 kN, screw diameter: 45 mm, Hydraulic injection moulding machine manufactured in 2004. This Engel Victory 750/180 Power features a clamping force of 1,600 kN and a maximum injection volume of 259 cm³. It includes a screw diameter of 45 mm and a maximum injection pressure of 1,600 Bar. If you are looking to get high-quality injection moulding capabilities, consider the Engel Victory 750/180 Power machine we have for sale. Contact us for further details regarding this machine. • Space between columns: 520 x 520 mm • Maximum mold height: 585 mm Ljdpjz Dvd Iofx Agrsrt • Minimum mold height: 275 mm • Maximum injection volume: 259 cm³ • Maximum injection pressure: 1,600 bar • Centering ring: 160 mm • Hot runners in the machine: 8 • Core puller: 1 • Pneumatic valves: 2 • Programmable inputs: 2 Additional equipment • Robot: Wittmann W818 (MY: 2015)

Condition: ready for operation (used), Year of construction: 2013, operating hours: 65,265 h, clamping force: 1,600 kN, screw diameter: 35 mm, overall weight: 8,700 kg, controller manufacturer: ENGEL, controller model: CC200, Hydraulic injection moulding machine manufactured in 2013. This Engel Victory 500/160 tech features a clamping force of 1600 kN and an injection unit of 500. It includes a patented tiebarless clamping system and a highly abrasion-resistant cylinder. If you are looking to get high-quality injection moulding capabilities, consider the Engel Victory 500/160 tech machine we have for sale. Contact us for further details. • Injection unit: 500 • L/D ratio: 20 • Hydraulics: ECODRIVE SHV1 (high-dynamic servo pump) • Electrical connection: 3 x 400 V + N + PE, 50 Hz • Nominal connected load: approx. 102 kW • Clamping system: Patented tiebarless, fully hydraulic ENGEL clamping system • Centering: 160 mm • Ejector: Central ejector • Hydraulic core pulls: 2 on moving platen • Pneumatic mold valve control: 2-fold FESTO, up to 16 bar • Mold heating: 8 control zones • Cylinder/screw execution: M3 abrasion/corrosion-resistant cylinder (up to 350 °C), hardened screw S8 (Ø 35 mm, L/D 20), non-return valve R9b • Open nozzle: Flange thread M28 x 1.5, radius 15 mm, bore 4 mm • Mold temperature control: Flow regulator 0–10 l/min with 12 circuits (2 x 6 circuits) • Hydraulic tank capacity: Main approx. 330 l; suction approx. 130 l Lsdjz Dgvzjpfx Agrert • Interfaces: Coloring device interface; RS-485 for temperature control units; Euromap 67 / AN-146 robot interface; interface for Priamus PDDI 8903D1 and 8903E2 • Languages: Czech and German
