Working platform semitrailer

FAYMONVILLE MAX Trailer MAX210 Telesattel Megatrailer

You can find our complete stock of vehicles, including those available immediately or at short notice, on our website.

Excerpt from the equipment. Full equipment details available upon request.

Loading Platform
* Double extendable version with pneumatically operated locking mechanism
* 2 pairs of recessed lashing rings (LC 5,000 daN)
* 1 pair of recessed lashing rings (LC 10,000 daN)
* 7 pairs of outward-folding lashing rings (LC 5,000 daN)
* 3 pairs of outward-folding lashing rings (LC 10,000 daN)
* Cut-outs in the outer frame of the loading platform for hooking in tension belts (LC 2,000 daN)

Landing Legs
* JOST landing legs (mechanical) with 2-speed gearbox, approx. 24 t lifting capacity (approx. 50 t test load)

Tyres
* 235/75 R 17.5 3PMSF

Axles
* BPW axles hydro-mechanically forced steered
* Air suspension with lift and lower valve

Braking System
* According to EU regulations, with EBS-E (2S2M), without connection lines to the tractor unit

Steel Construction
* Made of high-strength fine-grain steels. Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)

Paintwork
* Premium and durable corrosion protection for the standard shot-blasted welded frame provided by a 2-component (2K) zinc-rich primer
* High-quality 2-component (2K) top coat, single color in RAL 3002 carmine red
* Rear section metallized and painted in RAL 9010 (pure white)
* Rims in silver

Including Accessories
* Remote steering from front and rear via cable remote control with push buttons, with single-track control (no installation in tractor unit)
* Electro-hydraulic power unit
* 4 wheel chocks with holder mounted on the front wall
* 2-inch kingpin
* Yellow-red air couplings on the galvanized connection strip at the front
* Yellow reflective tape according to EU regulations on the sides, extension, and rear of the trailer
* European reflective signs (red-yellow) on the trailer's rear
* One mudflap on the trailer's rear
* Manual and instructions on USB stick
* Loading platform with robust hardwood floor
* 10 pairs of stake pockets for 100 x 50 mm plug-in stakes on the outer frame of the loading platform
* Mounting bracket for a revolving beacon on the trailer's rear
* Galvanized supports under the inclined section of the loading platform
* Mounting bracket for a revolving beacon on the trailer's rear
* Hook-in rail for ALU access ramps at the rear of the vehicle
* 80 km/h speed stickers on the rear and both sides
* Load gauge for determining axle loads including load chart
* One galvanized steel front wall (EN12642-XL), approx. 1,600 mm high
* Central lubrication system with 2 BEKAMAX (Pico) pumps with standard grease NLGI-2 and removable pump protection cover
* Spiral cable supplying the electro-hydraulic unit and/or the electric winch (approx. 35 mm², approx. 3.5 m long, max. 250 A) between trailer and tractor unit with connector (NATO-NATO)
* Coated sand layer on the central beam as anti-slip protection
Fjdpfx Ajk Ugacoa Njgi
* 6 pairs of WADER container pockets in the loading platform, for 1 x 20' container, 2 x 20' containers or 1 x 40' container, an additional locking point is provided in the extension for a 45' container
* 5 pairs of crosswise stake pocket rails mounted in the loading platform, for 100 x 50 mm plug-in stakes
* Storage for up to 9 pairs of plug-in stakes, approx. 100x50 mm, inside on the front wall
* One INOX toolbox, approx. 1,500 x 390 x 810 mm, mounted under the loading platform left and right in the direction of trav

The listing was translated automatically. Translation errors are possible.
