Pneumatic cylinder

Festo DN-40-600-PPV

Condition: excellent (used), Year of construction: 1983, - Turning diameter over bed [mm]: - 1000 - Turning diameter over support [mm]: - 630 - Turning diameter in the bridge recess [mm]: - 1230 - Spindle bore [mm]: - 120 - Center distance [mm]: - 2000 - Rotation speed range [rpm]: - 5 ÷ 500 - Maximum workpiece weight in the chuck: 1300 kg - Machine weight: 10000 kg Kjdpfx Akeytnt Dswsdt

Condition: used, Year of construction: 1971, turning diameter over bed 1250 mm turning diameter over slide rest 900 mm turning length 5000 mm faceplate 1250 mm workpiece weight in steadies max. 20000 kg workpiece weight 16000 kg Kjdpfx Akjy D A Edjwsdt weight of the machine ca. 22 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Bezel, stick, lynette Ksdpfjd Nhivjx Akwjdt -Max. Diameter: 325 mm -Tip height: 405 mm -Edition: ball bearings -Drawing: in the photos -Dimensions: 780/140/H845 mm -Weight: 97 kg

Condition: repair required (used), Year of construction: 1969, functionality: not functional, machine/vehicle number: 41526, spindle bore: 95 mm, turning length: 8,000 mm, spindle speed (max.): 710 rpm, spindle speed (min.): 14 rpm, type of input current: three-phase, Manufacturer: Meuser Machine type: Lead screw/feed spindle lathe Condition: Damage to the lamellar clutch Distance between centers: 8000 mm Swinging diameter over bed: 470 mm Swinging diameter over cross slide: 360 mm Spindle bore: 95 mm Spindle speed: 14 - 710 rpm Motor power: 15 kW Supply voltage: 380 V Cross slide travel: 630 mm Kdedpfxezxpf Ro Akwst Top slide travel: 190 mm Tailstock travel: ~8000 mm Tailstock spindle diameter: - Tailstock spindle stroke: 230 mm Tailstock mounting: MK6 Bed width: 390 mm / 530 mm Digital measuring system: X-axis, Z0-axis

Condition: used, Year of construction: 2016, Coolant cleaning system Manufacturer: Zyklomat Type: ZKR 14/350 Year of manufacture: 2016 For cleaning grinding emulsions Supply of max. approx. 250 L/min. at approx. 3.5 bar water pressure Transfer to the filter system is carried out by the customer, air and foam-free. Maximum temperature: 50°C Cleaning capacity: 350 L/min. Recirculation from the clean tank to the dirty tank: 100-350 L/min. Machine supply max.: 250 L/min. Filtration principle: ZYKLOMAT high-performance hydrocyclone Z1B-9/3 Separation particle size: approx. 5 µm Medium: Emulsion 3-6% Operating temperature: Ambient temperature Solid particle content: approx. 5.14 m3 Operating volume max.: approx. 4.58 m3 Operating volume min.: approx. 3.60 m3 Process sequence: fully automatic full-flow filtration Kedpfxezwccmo Akwedt Sludge discharge: fully automatic, with consistent consistency The dirty liquid is fed via customer-provided lifting stations. The chips and fine sludge produced during grinding (grinding debris, scale, corundum) are discharged via a scraper conveyor. In the upper scraper section, the sludge is pre-dried. Filtration takes place via ZYKLOMAT high-performance hydrocyclones. The system operates fully automatically. Maintenance: annual maintenance Availability: 10-2026 Double scraper tank for discharging grinding sludge Type: KR 1.75-5.1 Total volume: approx. 5.14 m3 Maximum volume: approx. 4.58 m3 Length: approx. 4,000 mm, including 70 mm reinforcement Width: approx. 1,890 mm, including 140 mm reinforcement Height: approx. 1,105 mm, including 100 mm bottom profile Neck height: approx. 2,300 mm Theoretical maximum discharge volume: 15 kg/h Function: Coolant storage tank with integrated clean tank, sedimentation and flotation tank with fully automatic sludge discharge. 1 bevel gear motor Voltage 400 V, 50 Hz, IP 54 as scraper drive 3 connection nozzles for return lines from three machines 1 clean liquid tank, integrated at the rear into the scraper tank. Oil-tight welded, with internal circumferential bevel gear, various cover plates (non-walkable plates screwed onto angle frame), without ladder, without handrail, without internal access rungs Maximum volume: approx. 0.55 m3 9926ä

Condition: good (used), Pneumatic cylinder, air cylinder, pneumatic piston, air piston -Type: DNC-50-700-PPV-AQ Kdsdpfx Ajd Nhimokwot -Pressure: max. 12 bar -Stroke distance: 700 mm -Piston diameter: 50 mm -Dimensions: 885/65/65 mm -Weight: 5.5 kg

Condition: used, Gear motor, electric motor, electric gear motor -Speed: 19.5 rpm -Power: 0.55 kW -Construction: B5 -Diameter shaft: 35 mm -Protection class: IP 65 -Hole circle: 210 mm -Recess: 180 mm -Dimensions: 550/250 / H265 mm Kodpjcmtnaefx Akwjdt -Weight: 45 kg

Condition: used, Year of construction: 2018, functionality: fully functional, machine/vehicle number: SN 018-0212, travel distance X-axis: 4,000 mm, travel distance Y-axis: 580 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 2,200 rpm, spindle speed (min.): 140 rpm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 6 m/min, controller model: Penta-Tec, overall weight: 6,000 kg, nominal power (apparent): 12 kVA, number of slots in tool magazine: 10, We are offering this used BAUER Bohrmax Z40 vertical machining center, manufactured in 2018, for sale. Manufacturer: BAUER Model: Bohrmax Z40 Year of manufacture: 2018 SCOPE OF DELIVERY / TECHNICAL DATA: • Spindle speed range: 140-2200 rpm • Drive for X, Y, Z axes: servo motor • Rapid traverse X-axis: 20 m/min • Rapid traverse Y-axis: 6 m/min • Rapid traverse Z-axis: 6 m/min • Distance from top of table to bottom of tool holder: 700 mm • Tool holder: SK40 • Tool changer for 10 tools • T-slots: M12 • Drilling diameter: 3-32 mm • Thread drilling: M4 - M24 • Tolerance X-axis: ± 0.1 mm • Tolerance Y and Z axes: 0.06 mm • Drive motor for spindle: 7.5 kW • Light curtain at the front • Control: Touchscreen 18” • Chip conveyor with slat conveyor additional integrated equipment: • Automatic tool length measurement • Handheld control unit RCS01 • Software extension for pendulum operation + DXF package Kdsdpozlp T Ijfx Akwjt • Universally controllable hydraulic clamping system with 8 clamping points (manufacturer Polund - Pro-Clamp Systems) If you have any questions or require further information, please send us a message or call us.

Condition: used, Pneumatic cylinders, air cylinders, standard cylinders, clamping cylinders -Stroke: 20 mm -Piston diameter: 16 mm -Piston rod: 6 mm -Price: per piece -Number: 7x pieces -Dimensions: 92/32/H21 mm -Weight: 0.15 kg/piece Kjdpfofbbttox Akwsdt

Condition: used, Pneumatic cylinders, air cylinders, standard cylinders, clamping cylinders -Manufacturer: Festo -Type: DC-100-100-PPV -Piston: Ø 100 mm Kdedpfxsdk I T Ej Akwot -Stroke: 100 mm -Pressure: max. 12 bar -Pneumatic damping: adjustable on both sides -Number: 1x available -Price: per piece -Dimensions: 138/H395 mm -Weight: 5.75 kg
