CNC 5-axis portal milling machine

Fidia GTF32

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 30214501, turning length: 2,000 mm, total length: 12,000 mm, WFL Millturn M60/2000 WORKING RANGE center distance mm 2000 swing over bed, turning diameter mm 690 MAIN DRIVE AC-drive with 2 gear steps drive power 100% duty cycle kW 40 max. speed min-1 3300 max. torque at the spindle 100% duty cycle Nm 1830 TAILSTOCK quill diameter mm 140 quill travel mm 160 quill force (adjustable) N 3500-31000 quill with installed live center MK 5 TOOL HOLDER (single tool holder, turning-boring-milling unit) AC-drive drive power 100% duty cycle kW 30 Nwodpfju Hl R Tox Abzoi speed range max. min-1 6000 max. torque at the spindle 100% duty cycle Nm 315 travel vertical to the X/Z-plane (Y-axis) mm 300[-125/+175] pivot capability of the milling spindle (B-axis) ° -110/+90 spindle head acc. DIN 69893 HSK-A100 spindle diameter in front bearing mm 100 DIMENSIONS length (max. tool magazine) m 11 width/height m 3,9/3,3

Condition: good (used), total width: 3,500 mm, total length: 19,000 mm, total height: 2,100 mm, workpiece weight (max.): 6,000 kg, grinding diameter: 850 mm, grinding length: 6,000 mm, center height: 425 mm, Cylindrical grinder Schmaltz - RM 82/6000 MACH-ID 9492 Make: Schmaltz Type: RM 82/6000 Centre height: 425mm Grinding Ø: 850mm Grinding length: 6000mm Grinding stone dimensions:1100 x 80 x 560mm Grinding stone speeds: 700Rpm Table inclasement: -5 to +5° Tailstock: 160 x 100Mk Length: 19000mm Nedpjy Dr Eaofx Abzowi Width: 3500mm Height: 2100mm Weight: 31000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 3,150 mm, travel distance Y-axis: 1,850 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 24 m/min, spindle speed (max.): 24,000 rpm, torque: 87 Nm, Fidia C20 CNC WORKING AREA X-axis longitudinal travel: mm 3,150 Y-axis transverse travel: mm 1,850 Z-axis vertical travel: mm 1,000 MAX AXIS SPEEDS X, Y axis feed rate: m/min 30 Z axis feed rate: m/min 24 WORK TABLE Clamping surface: mm 3,000 x 1,600 Maximum permissible load: kg/m² 5,000 T-slots: • Longitudinal 8 H12 + 1 H8 • Width mm 22 • Pitch mm 160 ELECTROSPINDLE Maximum power (S6 60%): kW 55 Spindle speed range: rpm 240 ÷ 24,000 Constant power range: rpm 6,000 ÷ 24,000 Maximum torque: Nm 87.5 Tool holder: HSK-A63 C-axis travel: ± 200° C-axis speed: °/min 2,000 C-axis offset from spindle axis: mm 75 A-axis travel: +95° / -110° A-axis speed: °/min 2,000 Max distance spindle nose – table surface: mm 1,175 Machine equipped with: Njdpfxeyw Tddj Abzswi • 24-position tool magazine • Remote electronic handwheel • HMS system for head calibration • Various equipment included with the machine • User and maintenance manual and CE declaration of conformity

Condition: good (used), Year of construction: 1997, Ref. -No.: 10620 Manufacturer: SKODA Type: W 200 T Year of construction: 1997 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 Storage location: Halberstadt Country of origin: Germany Nodpfx Asyagidsbzjwi X-Travel: 16000 mm Y-Travel: 5150 mm Z-Travel: 1600 mm W-Axis: 2100 mm V-axis: 2000 mm B-Axis: 0 - 360 ° Spindle Diameter: 200 mm Table Load: 80.000 kg Tool Taper: SK 60 / SK 50 Turning Speeds: 1000 RPM Rotary table diameter: 3500 x 3000 mm Further information: Including angle head Machine can be inspected under power.

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,600 mm, Travel ranges: Longitudinal (X): 4000 mm Vertical (Z): 1600 mm Lateral (Y): 1300 mm Rotary table: Diameter: 1600 mm Maximum speed: 250 min⁻¹ Drive power (100% duty cycle): 53 kW Maximum transport load (positioning): 8000 kg Maximum transport load (rotation): 3000 - 8000 kg Work table: Length: 4000 mm Width: 1240 mm Height of work table: 760 mm Automatically indexing milling head: Tool interface: ISO 50, DIN 69871 AD Automatic tool clamping: Clamping force 20000 N Spindle speed range: Spindle speed: 20 - 5000 min⁻¹ Full power from 340 min⁻¹ Torque at 32 kW/S1: 900 Nm Main drive: Drive power: 43 kW Maximum rapid traverse rate: X-axis 45000 mm/min Y- and Z-axis 35000 mm/min Maximum feed force: X, Y and Z-axis 16000 N Automatic tool changer Magazine positions in M version: Maximum tool positions: SK 50 40 positions Maximum tool positions: Capto C8 20 positions Machine weight: approx. 32,100 kg Equipment: - Work table 4000 x 1240 x 760 mm with integrated rotary table Ø 1600 mm - Swiveling control panel with telescopic arm with HEIDENHAIN TNC 640 HSCI (6 axes + spindle) control, including 19" flat screen, metallic keyboard with integrated mouse and USB interface on the control panel. Processor speed 0.5 ms including HEIDENHAIN smarT.NC. - Interpolative turning with HEIDENHAIN TNC 640 HSCI consisting of CAM system, HEIDENHAIN postprocessor, software adaptation for C-axis (spindle). Nedpfx Aszi S E Uobzewi - Portable electronic hand-held unit HEIDENHAIN HR 520 with 5 m cable. - Automatically indexing milling head / 2 levels with 2.5° x 2.5° division and a tool clamping force of 20,000 N (H200), 32 kW / 900 Nm, tool interface ISO 50 - DIN 69871 AD. Mounting flange with Hirth gearing for adapting turning tool holders, grinding spindles or additional milling heads and a protective ring to cover the Hirth gearing; not required if H205 is selected. - Spindle drive 43 kW at 100% duty cycle via water-cooled HEIDENHAIN inline motor with direct power transmission. The motor is integrated into the milling slide. - Turning tool holder with Capto C8 interface (manual tool clamping) for turning operations incl. Hirth gearing and SK 50 interface according to DIN 69871 AD for adaptation to SORALUCE milling heads. (Semi-automatic changing with additional manual fastening by 8 x M8 screws); not required with fully automatic changing of the turning tool holder. - Pneumatically adjustable pick-up station (travel 500 mm) in the tool changer area for the turning tool holder and protective ring for semi-automatic changing. - Work table with integrated NC rotary table Ø 1,600 mm, for turning operations and for positioning operations with hydraulic clamping. - Rack and pinion drive in the X-axis via two servomotors controlled in a master-slave process.

Condition: ready for operation (used), Year of construction: 2015, operating hours: 61,469 h, controller manufacturer: TRUMPF, controller model: TASC 6000, This TRUBEND Cell 5000 with TruBend 5085 extended version (2720 mm x 850 kN) and BendMaster 60 was manufactured in 2015. World's first bending automation with image recognition for maximum flexibility. Sheet metal parts up to 40 kg, 6-axis backgauge sensor technology. Maximum repeat accuracy thanks to angle sensor technology (ACB) in automated operation. It features a stable all-steel frame, electro-hydraulic top drive, and a modern block hydraulic system. The control unit is a TRUMPF TASC 6000 with a 15-inch touchscreen and network capabilities. Ideal for precise bending operations, consider the opportunity to buy this TRUMPF TruBend Cell 5000 press brake. Contact us for more information about this machine. • Machine: TruBend 5085 (2720 mm x 850 kN) with BendMaster 60 • Stable all-steel machine frame • Press beam with spherical bearing and tilt adjustment • Electro-hydraulic top drive with 4-cylinder technology • Generous edge clearance • Flat front covers • Modern block hydraulics • Electronic pressure balance • Measuring system with glass scale and spring compensation • Hydraulic oil in the machine (lifetime lubrication) • Oil cooler • Control cabinet cooling via air-to-air heat exchanger • Modern machine design • Stop/Backgauge • Stop system • Backgauge system: 2 axes (X and R) • Tool clamping • Upper tool holder, manual clamping, hardened • Lower tool holder, hydraulic clamping, hardened • Lower tool shift, 2 positions, pneumatic • Crowning • Manual crowning • Control • TRUMPF TASC 6000 • Graphical workshop programming • Windows XPe (embedded), Pentium 4, 2.8 GHz • 2 GB RAM • 15-inch touchscreen • Network-enabled • Teleservice via modem • Operation • Control panel with LCD keypad and foot switch • Communication rail • Safety • Standard safety devices • BendGuard safety device for upper tools up to 390 mm • CE marking Additional equipment • TRUMPF BendMaster automation (standard features) Njdpfx Absx Imqljzswi • Robot/Handling • Stable base and manipulator in die-cast aluminum • Load capacity 60 kg (workpiece plus gripper) • Low-profile welded floor track • Sheet metal sensor for contour detection • Rotary feedthrough for easy gripper change • Gripper coupling on the BendMaster • Sensors for 4-axis backgauge system • Electric drives • Double sheet detection • NC gripper transfer station • Vacuum generation for suction grippers • Control • TRUMPF PC control with operator terminal • Teleservice via modem • Operation via screen, mouse, and keyboard • Safety • Safety fence with access doorWorld's first bending automation with image recognition for maximum flexibility Sheet metal parts up to 40 kg, 6-axis backgauge sensor technologyMaximum repeat accuracy thanks to angle sensor technology (ACB) in automated operationTruBend 5085 (2720 mm x 850 kN) with BendMaster 60

Condition: excellent (used), Year of construction: 2020, travel distance X-axis: 8,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 2,500 mm, rapid traverse X-axis: 35,000 m/min, rapid traverse Y-axis: 40,000 m/min, rapid traverse Z-axis: 40,000 m/min, total width: 5,800 mm, total height: 4,500 mm, total length: 13,500 mm, table length: 10,000 mm, table width: 1,250 mm, Travelling Column High performance, precision and machining power Linear guiding of RAM combined with Hydrostatic Guiding HDS ACD2 Milling head with 5000 Rpm and 1400 Nm torq Aitek ATC chain 60 position with L=400 and 250 diameter x 35 Kg Filtration with IKZ 15 Bar Chip conveyor BLUM 3D Measuring probe Wide bed linear guided in X-Travel W=930 mm Rotary table driver prepared in E-Cabinet X-Axis: 8000mm Y-Axis: 1300mm Z-Axis: 2500mm Table Length: 10000mm Nsdpfxjyr Dmdo Abzjwi Table Width: 1250mm Power on spindle: 40kW Spindle speeds: 5000Rpm Spindle Taper: 40ISO/Bt/Mk Feed rate X-Axis: 35000mm/min. Feed rate Y-Axis: 40000mm/min. Feed rate Z-Axis: 40000mm/min. Millinghead auto-index:0.001 x 0.001 Gr° Working hours: 3800H Length: 13500mm Width: 5800mm Height: 4500mm Weight: 45000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Nwjdpexgu R Isfx Abzoi Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 1,700 h, functionality: fully functional, machine/vehicle number: MP7/5/P, travel distance X-axis: 730 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 400 mm, feed length X-axis: 585 mm, feed length Y-axis: 250 mm, feed length Z-axis: 400 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 50 m/min, spindle speed (min.): 1 rpm, spindle speed (max.): 42,000 rpm, rapid traverse X-axis: 80 m/min, rapid traverse Y-axis: 80 m/min, rapid traverse Z-axis: 80 m/min, type of input current: three-phase, table load: 60 kg, workpiece weight (max.): 60 kg, overall weight: 8,000 kg, MP7-5 Axis with integrated pallet changer 5-axis with rotary/swivel axis Travel range X/Y/Z 585x250x400 mm Travel range B +/- 105 degrees Njdoxlctbspfx Abzjwi Travel range C continuous Workpiece weight 60 kg Distance machine table to spindle nose 450 mm Machine dimensions (W x D x H) 2845 x 2370 x 3000 mm Machine weight 8000 kg Spindle speed 42,000 rpm Equipment: Control: Heidenhain TNC640 Main spindle: HVC140 HSK-E40 with rotary union for internal media supply - Max. speed 42,000 rpm - Milling power S1/S6 10 kW / 13 kW - For internal coolant supply, air and emulsion Oil mist extraction for oil/emulsion Dust extraction: L-CUT Machine-integrated workpiece changer for 36x EROWA ITS50 or 18x EROWA ITS115 Hand-held control unit with electronic handwheel and enabling switch Measuring probe system: Renishaw OMP400 Aerosol DRY LUBRICATION (ADL) - Precise dosage of media externally and through the tool Rotary table chuck: EROWA PowerChuck P on 5-axis Blum laser: LC50 Media distributor: MHT Tool changer 90 positions, HSK E40 Warranty: 12 months Transport Initial commissioning on site Training

Condition: used, Year of construction: 2013, Technical details: faceplate diameter: 800 mm power requirement: 110 kW weight of the machine ca.: 37.000 / total 52.000 t transport measurements machine: 5,07 x 2,98 x 3,90 m clamping diameter: 800 mm Njdpeuyp Enofx Abzswi : Ø 800 x 720 mm Tool bore: Capto C6 tools in tool magazin: 2 x 80 With C-Axis *
