Slideway grinding machine

GIORIA 2600x12000

Condition: good (used), Year of construction: 1979, Single column vertical turning lathe BERTHIEZ TM500 SP Manufacturer: Berthiez (France) Model: TM500 SP Year of manufacture: 1979 Main technical data: Kedsx A U Raopfx Ahasnc Table diameter: 6300 mm Maximum turning diameter: 15000 mm Maximum usable height: 4000 mm Arm travel: 3600 mm Main motor power: 100KW Maximum allowable load on faceplate: 80 t Ram size: 360x360 mm Machine weight: approx. 230 tons The machine is capable of both turning and milling operations. Do not hesitate to contact us for any additional information.

Year of construction: 1978, condition: ready for operation (used), A Haeusler CNC large-format 4-roll plate bending machine is available. Number of rolls: 4, Roll width: 3050mm, Max. prebending plate width: 3000mm, Max. prebending plate thickness: 60mm, Max. rolling capacity at max. plate width and 3500mm bending diameter: 70mm, Roll diameter top/bottom/side: 620mm/600mm/500mm, Max. top roll load: 12000kN, Operating speed: 4m/min, Connected load: 132kW, Weight: approx. 85t. Including cone bending device. Documentation available. An on-site inspection is possible. Knodpfxezka H Ao Ahaoc

Condition: new, For sale, a pipe straightener from the German manufacturer SMS MEER, the machine is brand new, it was dismantled from a plant that collapsed during the delivery and assembly of the machine. The machine has two Siemens 200 kW drive motors each. Straightening rollers have a length of 460mm, diameter on the sides 400mm, diameter in the middle 300mm. The weight of the machine itself is 44 tons, the total weight is 55 tons. Kodem H Unhopfx Ahaenc I can send a lot of photos before dismentling.

Condition: excellent (used), Year of construction: 1970, functionality: fully functional, I am selling this machine, it is connected and can be tested. A video of the machine can be sent via WhatsApp. Diameter over the bed: 1250 mm Diameter over the carriage: 900 mm Turning length: 6000 mm Knjdpjxwqk Eefx Ahaec Workpiece weight between centers: 14,000 kg

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, overall weight: 120,000 kg, total height: 5,600 mm, pressing force: 1,250 t, air pressure: 6 bar, distance between side stands: 1,200 mm, distance between stands: 1,400 mm, stroke length: 500 mm, table length: 1,850 mm, table width: 1,600 mm, Straight-sided eccentric press ERFURT type PKZe 1250 Superb working condition, after full, professional overhaul. After - newer used. Specification: Capacity: 1250 ton force Slide stroke: 500 mm Kedpsubyrxofx Ahasnc Slide adjustment: 215 mm Maximum shut height between bolster plate and slide (stroke down, adjustment up): 860 mm Bed area (width x depth): 1600x1850 Slide area (width x depth): 1300x1400 mm Opening in the bed (width x depth): 1100x1100 mm Main motor rating: 90 kW at 1478 RPM Ram adjusting motor rate: 7.5 kW at 1450 RPM Number of single strokes: 8 min-1 Cushion capacity: 200 ton force Cushion stroke: 200 mm Height above floor: 7900 mm Press weight: 130 000 kg.

Condition: good (used), Manufacturer: INNOCENTI Type: PM 325 FT Year of construction: 2012 Specifications: Metric Metric US Standard Table length 4250 mm Table width 4250 mm Table load 130.000 V-axis feed 3000 mm B-axis rotation 360.000 ° High-speed rotation B-axis 0.16 - 34.5 Omw/min. Knodpfxetwllfo Ahaoc Dimensions (estimate) length 8000 mm width 4250 mm height 2000 mm weight 62500 kg Please note: The information on this page is given in good faith and to the best of our knowledge, and where possible, has been obtained from the manufacturer, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 700 mm, spindle speed (max.): 2,000 rpm, table length: 1,100 mm, table width: 842 mm, X axis: mm 1.000 Y axis: mm 700 Spindle travel: mm 300 Table dimensions: mm 1.100 x 842 Spindle speed: rpm 40 – 2.000 Spindle cone: MT 4 Max power: kW 10 Max loading on table: ton 1 Machine weight: ton 15 Kjdszizgbepfx Ahaonc EQUIPPED WITH A LOT OF ACCESSORIES

Condition: good (used), Center height: 1,000 mm Distance between centers: 15,600 mm Maximum diameter allowed above the bed: 2,019 mm Maximum diameter allowed above the carriage: 1,625 mm Diameter of the faceplate: 1,800 mm Maximum clamping between chucks: 1,500 mm Maximum load: 75 tons Spindle motor power: 82 Approximate dimensions: Length = 21,570 mm, Width = 4,765 mm Accelerated carriage travel: 2,000 mm/min Metric thread possibilities: from 2 to 25 mm Knedpozbt S Ijfx Ahaoc Maximum thread length: 800 mm Minimum distance from faceplate to tool: 2,000 mm Accessories: 2 faceplates with a diameter of 1,100 mm on a traveling steady rest 2 steady rests, 150 to 450 mm 2 steady rests, 450 to 750 mm 2 steady rests, 750 to 1,000 mm (on a traveling steady rest) Videos available.

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, For sale: this lathe. Swing diameter over bed: 1,000 mm. Turning length: 4,000 mm. Sinumerik 840D control. Knodoxzr Rbepfx Ahasc

Condition: excellent (used), Year of construction: 2003, operating hours: 18,847 h, functionality: fully functional, machine/vehicle number: nº Serie 1151, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Trevisan DS200 is a Machining Center featuring an integrated turning device (U-axis/facing head), enabling turning with the workpiece stationary and the tool rotating (cylindrical, conical, spherical, threading, facing) and, within the same setup, milling, drilling, and reaming with the main spindle. It is equipped with two independent spindles (milling head + U-axis facing head) and automatic tool change, thus functioning as a combined "lathe + machining center" in a single unit, reducing cycle times and errors due to re-clamping. Typical Architecture of the DS200 Series • Structure: bed and columns made of high-rigidity cast iron. • Contouring head (U-axis): various diameters with a radial travel of 70 mm, multi-tool tool holder, and constant surface speed for high-quality turning with the workpiece stationary. • Table/palletization: 1 pallet with a table size of 1200x600 mm. • Capacities: up to Ø350 mm. Kjdpfx Ahjxrb Ukjaonc Focus on the Trevisan DS200/70 The DS200/70 belongs to the "Small/Compact" family, designed for medium-sized parts requiring precision turning and milling/drilling operations in a single setup. According to Trevisan nomenclature, “200/70” indicates a facing head diameter of 200 mm with U-axis travel of 70 mm. Indicative Configuration and Capabilities • Type: Trevisan DS200 turning-milling center • Facing/contouring head (U-axis): Ø ≈ 200 mm, U-axis travel ≈ 70 mm, suitable for cylindrical, conical, spherical, threading, facing operations with the workpiece fixed. • Basic travels (DS200/70 class): X ≈ 520 mm. • Single-setup processes: turning (fixed workpiece) + milling/boring with main spindle → reduced cycle time and improved coaxiality between turned and machined surfaces. Typical Use Cases • Valve bodies, covers, flanges, and pump components where turned internal/external profiles (spherical, conical) and multiple precision drilling/milling operations are required.
