Condition: new, 9D715US crankshaft balancing machine is adapted for balancing crankshafts of various designs, including crankshafts of V6, V8, V10 and V12 engines, with balancing weights on the connecting rod pins: - Balancing of crankshafts of any design - Shaft weight up to 300kg - Shaft length up to 1400mm - Drilling module for unbalance correction The machine design allows balancing crankshaft separately, as well as crankshaft complete with flywheel and clutch, which guarantees minimum unbalance during engine operation. MACHINE HIGHLIGHTS • Hard-bearing supports - safe operation with high initial unbalance at low speeds. • Roller cassettes with large diameter spherical rollers and provide the required accuracy for balancing heavy shafts. • Replaceable antifriction prismatic V-blocks allow balancing of crankshafts with low mass or with special bearing journals. • Narrow support stands of the machine allow balancing of crankshafts with complex configuration and with “narrow” bearing journals. The 9D715US machine has a cassette width of 27 mm, which is the best in its class. • For balancing V-shaped crankshafts, the machine can be equipped with counterweights (variable weight) to simulate the weight of connecting rods. • A vertical drilling module mounted on its own guides allows unbalance in the crankshaft counterweights to be corrected directly on the machine. • The frequency converter drive provides smooth acceleration and deceleration of the electric motor and infinitely variable speed control of the rotor. MEASUREMENT AND CONTROL • We make balancing easier - the main advantage of our balancing systems. • The balancing process is displayed in real time and the unbalance behaviour of the rotor is monitored on the screen to achieve the best possible result. • Measuring balancing system has additional necessary functions for crankshaft balancing: Fgedpowk Ittefx Afpjh - recalculates the unbalanced mass to the drilling depth, taking into account the drill diameter and the permissible drilling depth. - It recalculates the unbalance on several correction planes, so that unbalance can be corrected in neighboring crankshaft counterweights. SPECIFICATIONS Weight range of balanced rotors 3 - 300 kg Maximum rotor diameter (above the bedding) 1100 mm Diameter of rotor support journals 20 - 140 mm Distance between centres of rotor journals 150 – 1350 mm Support type Rollers / V-blocks Transmission element for rotor rotation Belt Minimum achievable residual specific unbalance 0.4 g.mm/kg Rotor speed range 300 – 1500 rpm Electric motor power 2.2 kW Parameters of the supply network 380V, 3 Ph, 50Hz VTM Group balancing machines will allow you to do your job well and get positive feedback and attract more customers. Do you need a machine for a different load capacity, diameter or length? We manufacture balancing machines for every needs. Please contact us to get the best offer! 👇

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, SERDI Valve seat milling machine for cylinder head - used machine, in very good condition, ready to use Technical details: Dimensions (L x W x H): 1690 x 1050 x 2170 mm Fgodpfx Asv Ild Sofpoh Net weight approx.: 1085 kg Max. cylinder head dimensions (L x W x H): 1200 x 500 x 450 mm Crosswise work piece tilting: +42° to - 15° Min-max machining capacity: 16 - 70 mm Workhead travel: lengthwise: 930 mm crosswise: 40 mm sphere-cylinder travel (radius): 9 mm Spindle: max. spindle inclination degrees: 5 travel: 200 mm motor power: 1200 W rotation speed: 100 - 1200 RPM Connections: electric supply: 2.5KVA - 230V - 1Ph-50/60Hz air pressure supply: 6 bars air volume supply: 300 l noise level at 400 rpm 72 DBA, at 1200 rpm 82 DBA If you are interested, please contact me! More machines for sale: A-M, Serdi, Comec, AMC, Carmec, Kwik-Way, Serdi, PEG Crankshaft grinding, surface grinding, valve grinding, valve seat milling, pressure testing, parts washing, line boring, valve guide presses, vacuum tester

Condition: new, functionality: fully functional, ADMA100 A-M Connecting rod cap and face grinding machine - new machine Technical details: 1 Phase 220V - 50 Hz Max. outside dimension of cap: Φ 275 mm Max. thickness of the connecting rod: 100 mm Motor power: 0,75 Kw L x W x H: 920 x 750 x 350 mm Packing dimensions: L x W x H: 1360 x 890 x 620 mm Net weight: 150 kg Gross weight: 180 kg Fgedpfx Afevrz Unepoh If you are interested, please contact me! More machines for sale: A-M, Serdi, Comec, AMC, Carmec, Kwik-Way, Serdi, PEG Crankshaft grinding, surface grinding, valve grinding, valve seat milling, pressure testing, parts washing, line boring, valve guide presses, vacuum tester

Condition: new, Year of construction: 2024, functionality: fully functional, VSM3.0DRO A-M Valve seat milling machine - new machine. Digital display valve seat milling machine. High precision valve seat milling machine specifically designed for multi-valve cylinder heads. Machining capacity from 16 mm to 90 mm. Variable speed from 100 to 1200 RPM. Fjdpjvmpnlefx Afpogh Max. cylinder head width: 500/19,7 mm/inch Max. cylinder head height: 450/17,7 mm/inch Tilt degree of cylinder head: +42°- -42° Max. tilt degree of spindle: 5° Travel: -Cross: 930/37 mm/inch -Longitudinal: 40/1,6 mm/inch -Spindle: 200/8 mm/inch Spindle power: 1.8 kw Max. rotation speed of spindle: 0-1000 RPM Power supply: 380V/50Hz 3ph vagy 220V/60Hz 3ph Air compressor supply: 6/87 Bar/psi Noisy level: at 400 RPM 72dBA; at 1200 RPM 82dBA Weight: 1050/2310 kg/lb Dimension (L x W x H): 1040 mm x 1050 mm x 2170 mm

Condition: new, ACM321-K Cylinder head MAN 18.440 complete, spring mounted, new cylinder head Fedpfjt Siv Aex Afpegh Producer: A-M Brand: MAN Model: TGA; TGS; TGX Engine code: D2066; D2676 CC: 10.5D; 12.4D Year: 2004; 2005; 2006; 2007; 2008; 2009; 2010; 2011; 2012; 2013; 2014; 2015; 2016 Number of cylinders: 6 EURO4, EURO5, EURO6 ACM321-K cylinder head includes: Cylinder head Valve collets Valve spring plates Valve springs Valve stem seals Valves If you are interested, please contact me! Our webshop has hundreds of other products.

Condition: new, Year of construction: 2025, functionality: fully functional, CCT1600L A-M Pressure tester for cylinder head and block – new machine. Hydraulic tray lifting, motorized tray rotation. Technical details: Fsdpfx Afjncd Ecopjgh Max. cylinder head capacities: Lenght x Width x Height: 1350 x 425 x 300 mm Capacity of stainless steel tank: 500 liter Heating elements: 2 x 4,5 kw Hydraulic tray lifting Motorized tray rotation Hydraulic hoist: 0,75 kw Gear-motor: 0,25 kw Up and down travel time: 600 mm in 10 sec Thermostat: 0-90°C Power supply: 16kva-3x230v-ac-50/60hz Net weight approx: 600 kg Space requirements: Lenght x Width x Height: 2100 x 1050 x 1700 mm If you are interested, please contact me! More machines for sale: Berco, Comec, Sunnen, Carmec, Kwik-Way, Serdi, PEG Valve grinder, head and block resurfacer, valve seat milling, pressure tester, parts washer machines

Condition: new, functionality: fully functional, Comec RV516.ASM Valve refacing machine – new machine With standard equipment and variable valve speed device. Technical details: Valve stem diameter: 4-16 mm Valve stem length: 55-230 mm Valve head diameter: 114 mm Face angles: 0° - 60° Grinding wheel speed: 2800 RPM Main grinding wheel diameter: 215 mm Voltage – Hz – phases: 400V/50Hz/3 Fázis Main dimensions: W x L x H: 700 x 600 x 700 mm Weight: 142 kg If you are interested, please contact me! Fgsdpfsnbdlmex Afpoh More machines for sale: Berco, Comec, Sunnen, Carmec, Kwik-Way, Serdi, PEG Valve grinder, head and block resurfacer, valve seat milling, pressure tester, parts washer machines

Condition: new, Year of construction: 2025, functionality: fully functional, Kwik-Way SVS2 Deluxe Valve grinder machine - new condition With rocker arm grinder. Fgodpsnacu Dofx Afpsh Technical details: Precision 6-ball chuck Accuracy: 0,005 mm Minimum valve stem diameter: 4 mm Maximum valve stem diameter: 14 mm Minimum valve stem length (approx): 85,73 mm Maximum valve head diameter: 100 mm Valve grinding wheel diameter: 178 mm Surface wheel diameter: 76 mm Spindle drive motor (H.P.): 0,37 kW Chuck drive motor (H.P.): 0,06 kW Coolant capacity: 3,8 ltr Chuck R.P.M. (approx.): 100 - 300 Grinding angles: 13° - 62° Main dimensions: W x L x H: 940 x 559 x 406 mm Weight: 141 kg If you are interested, please contact me! More machines for sale: Berco, Comec, Sunnen, Carmec, Kwik-Way, Serdi, PEG Valve grinder, head and block resurfacer, valve seat milling, pressure tester, parts washer machines

Condition: as good as new (ex-display), functionality: fully functional, Surface grinder. New condition Taiwanese machine. The machine run a few hours, just it was tested. Fedpfxem Tv U Tj Afpjgh Standard accessories: Grinding wheel Wheel flange Flange extractor Wheel balancing arbor Wheel balancing base Wheel dresser with diamond Leveling screw & plates Tool box & tools Manual Optional accessories: 3 HP Spindle motor (siemen brand) instead of 2 HP Longitudinal by sensor & solenoid valve Electro magnetic chuck, 150 x 450 mm (Fine pole) Coolant system (Capacity 52L, 1/8 HP) Auto crossing stroke adjustment Crisscross grinding Power rapid up/down system (AC motor, 1/5 HP) Wheel flange (extra) Back water splash shield Led lamp instead of halogen lamp Spindle motor inverter 3 HP (Taiwan made) Digital readout (lu, cross: 300 mm + vertical: 450 mm; 2 axes monitor) Auto. demagnetizer for chuck 5A If you are interested, please contact me! More machines for sale: Berco, Comec, Sunnen, Carmec, Kwik-Way, Serdi, PEG Valve grinder, head and block resurfacer, valve seat milling, pressure tester, parts washer machines
