Condition: excellent (used), number of straightening rollers: 19, straightening roller diameter: 18 mm, leveller ARKU RM 1825 with the dimensions: 250 x 2 mm - also till 5 mm thickness possible if you have got smaler material, 19 rolls, diam. of the rolls 18 mm Dusdpfxezb Eg Dj Abfju

Condition: excellent (used), functionality: fully functional, number of straightening rollers: 23, straightening roller diameter: 47 mm, leveller UNGERER Typ 1500/3,00/23 - dimensions: 1500 x 0,50 - 3,00 mm, 23 rolls, diam. of the rolls 47 mm Duedpfx Aezb Ef Tobfsu

Condition: good (used), sheet thickness steel (max.): 3 mm, product width (max.): 200 mm, - Capacity: 200 × 3 mm - Manual operation - Automatic operation - Clockwise and counterclockwise rotation - Infinitely adjustable speed - Emergency stop Dusdpezb Afkofx Abfeu - 380V

Condition: used, Year of construction: 2001, sheet width 1650 mm plate thickness 0,5- 3 mm number of rolls 21 straightening feed 0- 60 m/min straightening roll diameter 50 mm adjustment 30 mm weight of the machine ca. 24,5 t dimensions of the machine ca. 4,5x 2 x 2,8 m voltage 400 V passage width 1720 mm number of support rolls 18 main drive motor 45 kW run-in height 1250 mm 6 HI High-performance straightening machine with 21 rolls for fine straightening work of steel or non-ferrous metals. Machine has 23 intermediate Duedpozafi Nefx Abfsu rolls and 18 support points. Working rolls are adjustable with DRO in 0,01 mm. Main Gearbox was renewed in 2021.

Condition: ready for operation (used), Year of construction: 2013, Offered is a precision sheet metal straightening machine. Material width: 1500mm, material thickness: 1-2mm, suitable for: aluminum, control: Siemens Simatic OP177B. Equipped with roller conveyor discharge frame. Additionally available spare parts: Siemens Control Unit 24V DC (6SL3040-1NB00-0AA0), Siemens compact asynchronous motor 15kW (1PH7133-2DF02-0BA0), Siemens synchronous servo motor (1FK7042-5AK71-1KG0), Siemens Sinamics Basic Line Module (6SL3130-1TE22-0AA0), Siemens Simatic Panel OP177B, INA cam rollers. Weight: approx. 6700kg, overall dimensions X/Y/Z: approx. 2400mm/1600mm/1800mm. Inspection possible by arrangement. Dodpfxjy Uyfvo Abfeuu

Condition: used, Year of construction: 1987, material width 800 mm material thickness 0,4 - 2,5 mm no. of straightening rolls 8 straightening roll diameter 53 mm number of draw-in rolls 2 diameter of draw-in rolls 160 mm material thickness at 800 mm material width (Niro) 0,6 mm Dsdpfey Ruttsx Abfouu material thickness at 800 mm material width (steel 1,0 mm material thickness at 150 mm material width (Niro) 2,5 mm material cross-cut 975 mm² speed - 35 m/min power requirement 2,1 kW weight 7,0 t dimensions (WxDxH) 2,0 x 2,0 x 2,3 m Straightening machine RM 8-53/160-800 with infinitely varibale drive, motoric driven straightening rolls, supporting rolls, hydraulic lifting of the roller cassette, motorized adjustment of the rolls, hydraulic threading wedge, side guidance at the inlet

Condition: good (used), Year of construction: 2012, Ref. -No.: 10469 Manufacturer: JAESPA Type: Comfort 420 A Year of construction: 2012 Storage location: Halberstadt Machine-No.: 233XXXXX Weight Of The Machine Ca.: 2500 kg Machine length: 2400 mm Machine width: 2800 mm Machine Height: 1700 mm Bending capacity square tube: 420 x 420 mm Dsdpfx Aboy Ed D Djfouu Bending capacity round bar: 420 mm Bundle min.: 215 x 65 mm Bundle max.: 420 x 170 mm Flat: 420 x 420 mm Roll diameter: 590 mm Saw band dimensions: 4100 x 1300 x 4780 mm Belt speed: 15 - 100 m/min. Operating pressure: 50 bar Flow rate: 6,5 l/min Tank capacity: 40 liter Coolant content: 50 liter Material support height: 800 mm Saw motor: 5,5 kW hydraulic motor: 0,75 kW coolant pump: 0,12 kW Chip brush: 0,09 kW Chip conveyor: 0,18 kW Measurement standard: DIN EN 23746

Condition: ready for operation (used), Strip width: 300 mm Strip thickness: 0.4 - 2.5 mm at maximum strip width Number of straightening rollers: 11 pcs Number of feeder rollers: 2 pcs Number of exit rollers: 2 pcs Roller diameter: 60 mm All upper rollers manually adjustable Dusdpfx Aboyztzdofju All lower rollers interconnected by gears Variable speed, manually adjustable via handwheel Loop control via touch arm Strip guide at inlet Roller basket at outlet

Condition: used, Year of construction: 1989, number of straightening rollers: 21, straightening roller diameter: 80 mm, sheet thickness steel (max.): 10 mm, product width (max.): 1,250 mm, Sheet width: 1250 mm Sheet thickness: 10 mm Number of rollers: 21 pcs Roller diameter: 80 mm Belt speed: 12 m/min Adjustable cross-section: 5700 mm² Total power requirement: 60 kW Equipment: Working direction: left to right Strip infeed: left Belt speed control: three-phase motor Duodpfx Asyykyhjbfou Measuring device: digital display Roll stand adjustment: motorized Positioning control: TWIN-Control Quick-change system: hydraulic

Condition: used, Year of construction: 1987, material width 120 mm Djdpfx Ajynmpasbfsuu material thickness 0,2 - 4,0 mm no. of straightening rolls 19 straightening roll diameter 24 mm material cross-cut 2 - 120 mm² 40 mm bending speed 5 - 25 m/min power requirement 2,5 kW weight 0,85 t dimensions (WxDxH) 1,2 x 1,7 x 1,6 SPECIAL DEAL as is where is, IN NEED OF OVERHAUL WITHOUT putting into operation / WITHOUT additional work free loaded to truck

Condition: used, Year of construction: 1966, 5 weight 5 t . Dujdpfxsx U A Nkj Abfou

Condition: excellent (used), Year of construction: 1990, number of straightening rollers: 23, roller diameter: 80 mm, Number off straightening rolls 23 units Roll diameter 80 mm Minimum thickess 0,5 mm Maximum thickness 12 mm Digital readout system position rolls Fine adjustment down feed   Rolling width: 1450mm Rolling thickness 3x toproll Ø:12mm Rolling thickness 5x toproll Ø:16mm Top Roll Ø: 80mm Dusdpfx Abjxyhhajfju Bottom Roll Ø: 80mm Number of rolls: 23 Rolling speed: 3,75 - 15 M/Min Adjustiment lower roll: 26mm/min. Power: 30kW Length: 3000mm Width: 4000mm Height: 2400mm Weight: 28000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 1991, functionality: fully functional, number of straightening rollers: 9, total length: 1,550 mm, straightening roller diameter: 30 mm, total height: 1,820 mm, total width: 2,500 mm, sheet thickness (max.): 2 mm, Kohler straightening unit 30.180 / 9-300.1 consisting of: Djdpfswrx R Sjx Abfjuu Straightening machine KRM 30.180 / 9 Uncoiling reel 300.1 Strip guide

Condition: used, Year of construction: 1993, Price: On request Coil feed line system, straightener, decoiler Manufacturer: ARKU Year: 1993 Decoiler Type: AH 5000/500/MSG-4Q Capacity: 5000kg Working width: 50-500mm Speed: 50 m/min Max coil-diameter: 1800mm Straightener Type: RM 3060.4/9 Number of rolls: 9 Diameter rolls: 30 Capacity: 0,5-6mm Working width: 50-600mm Speed: 50 m/min Needs new PLC (controller in cabinet). Is taken by previous owner for programm. - Year: 1993 - Documentation available: No - CE certificate present: No - Min. sheet thickness [mm]: 0.5 - Max. sheet thickness [mm]: 6 - Max. working width [mm]: 600 - Number of rolls [pcs]: 9 - Roll diameter [mm]: 30 - Rolling speed [m/min]: 50 Financial information Duedpfx Abowng Ukjfeu VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: ready for operation (used), functionality: fully functional, Sheet straightening machine, 2100 mm,Sheet Metal Straightening, Plate Leveler Machine 2100 mm Dodpfx Abev Tpv Nofeuu Used machine Maximum Sheet Width: 2100 mm (2100x8 mm) Maximum Sheet Thickness: 10 mm (1500x10 mm) Number of Rolls: 11 pcs Roll Diameter: 95 mm Electric Motor: Adjustable speed and direction Electrical Data: 400 V, 50 Hz, 36 A, 22.5 kW Includes a roller conveyor.

Condition: used, Year of construction: 1996, material width 500 mm material thickness 0,3 - 3,0 mm no. of straightening rolls 5 straightening roll diameter 40 mm number of draw-in rolls 2 diameter of draw-in rolls 80 mm Dodpfxovuum No Abfeuu material cross-cut 600 mm² material thickness at 500 mm material width 1,2 mm material thickness at 200 mm material width 3,0 mm power requirement 4,0 kW weight 2,0 t dimensions (WxDxH) 1,5 x 1,5 x 1,9 m with motor, upper straightening rolls individually manually adjustable, neumatic adjustment of the infeed rolls, coil loop control via ultrasonic sensor

Condition: used, Year of construction: 1984, material width 250 mm material thickness 0,2 - 2,0 mm no. of straightening rolls 7 straightening roll diameter 60 mm run-in height 1250 mm speed 5 - 30 m/min power requirement 2,2 + 1,3 kW Weight 0,65 t dimensions (WxDxH) 1,05 x 1,25 x 1,5 m SPECIAL DEAL as is where is WITHOUT putting into operation / WITHOUT additional work free loaded to truck Duedpfovuk Sbox Abfsu

Condition: used, Year of construction: 1982, material width 250 mm material thickness 0,4 - 5,0 mm no. of straightening rolls 9 straightening roll diameter 60 mm speed 3 - 15 m/min material thickness at 250 mm material width 3,5 mm Dsdpfx Abevuk Nysfeuu material thickness at 100 mm material width 5,0 mm power requirement 1,8 kW weight 0,9 t dimensions (LxWxH) 1,45 x 1,4 x 1,55 m SPECIAL DEAL as is where is, WITHOUT additional work free loaded to truck

Condition: refurbished (used), Tube Straightener VRM60/75, made by KIESERLING Dedpfx Asvtpghsbfjuu Tube diameter : 8 – 60 or 14 - 75 mm Tube length : Depending on accessories (loading table, channels). Minimum 0.5m The ratio diameter/thickness depends on the yield. Strength Example: - 300 N/mm2 = Max. 6.5mm - 400 N/mm2 = Max. 5.7mm - 500 N/mm2 = Max. 5.1mm - 600 N/mm2 = Max. 4.7mm *The first 4 photos are examples of revamping of similar machines that we can offer in case of interest. The following are pictures of the machine in its current state. Tube diameter: 8 – 60 or 14 - 75 mm Tube length: Depending on accessories (loading table, channels). Minimum 0.5m

Condition: used, Technical details: plate width: 1000 mm Djdpfx Abevgbgaefjuu plate thickness: 3,0 mm smallest sheet thickness: 0,5 mm distance between columns: 920 mm Number of Straightening rolls: oben 4x unten 4x Stück / pieces roll diameter: ca. 75 mm number of rollers: 2 oben und 2 unten St. weight of the machine ca.: 6,5 t dimensions L x W x H: 3,8 x 2,2 x 2,1 m This is a sheet metal straightening machine with hydraulic feed. Further features: 4 straightening top rolls Ø 75 x 830 mm, stroke 20 mm, hydraulic 4 straightening bottom rolls Ø 75 x 830 mm, fixed, hydraulic 4 pull-out rollers Ø 110 x 480 mm, 2x top adjustable approx. 20 mm and 2x bottom, hydraulic Roller support Infeed height 1400 mm Hydraulic system equipment Operated externally Recommendation: complete conveyor system (decoiler + loading device + straightener with hydraulic feed) for sale with optional stock no. 0100572. *

Condition: used, Technical details: band width: 80 mm plate thickness: 1,5 mm number of rolls: 5 total power requirement: 1,2 kW weight of the machine ca.: 150 t space requirements approx. LxWxH: 1,1 x 0,7 x 1,4 m straightening rolls: - 2 upper rolls, 3 lower rolls - material feed is performed via two compressed air controlled rolls - compressed air connection is not mounted i.D. * Djdpfx Absu Ic E Rjfjuu

Condition: used, Technical details: sheet width: 250 mm plate thickness: 2 mm number of rolls: 11 straightening feed: 5...30 m/min infeed height: 1250 mm total power requirement: 4,0 kW weight of the machine ca.: 620 kg dimensions of machine: 1,15x1,02x1,5 mm dimensions electric cabinet LxWxH: 0,66x0,53x0,32 m Band Leveling Machine with feed Dsdpfx Aju Ic Ewjbfjuu equipment: - sideways band guidance rolls model: - band intake height horizontal:1250mm - tiltable: positiv 30°; negativ 15° *

Condition: used, Technical details: material width: 200 mm material thickness: 1,5 mm Dusdpfx Abeu Ic D Tefeu Number of Straightening rolls: 5x oben/upper/arriba no. of rolls: 6x unten/ lower/abajo throughput speed: nicht bekannt/ unknown/desconocido m/min current: 220/50 A/Hz total power requirement: 1,5 kW weight of the machine ca.: 0,447 t space requirements of the machine approx.: L:0,88xB:0,76xH:1,26 m description: machine does have 11 rolls upper roll: width: 210mm, dia. approx. 60mm, driven adjustable lower roll: width: 210mm, dia. approx.60mm, driven, not adjustable *

Condition: used, Technical details: material width: 400 mm material thickness: 2 mm Number of Straightening rolls: oben/upper/arriba: 5x Number of Straightening rolls: unten/lower/abjo: 6x roll width: 410 mm throughput speed: 9-20 m/min total power requirement: 5,5 kW Weight approx.: 1,3 t space requirement of the machine approx.: L:2,1xB:1,0xH:1,35 m description: - upper rolls adjustable around 14mm, not driven - lower rolls not adjustable, driven - each 1 intake/output roll (dia 35x410mm) equipment: - drum intake (L:1,2xW:0,7xH:1,16m), with 4 pcs rolls and guidance waggon - 2 intake limits / output limits Dsdpfxju Ic Dyj Abfeuu This straightening machine must be electrically integrated by the customer! *

Condition: used, Technical details: plate width: 800 mm coil weight: 12 t sheet width - max.: 800 mm sheet width - min.: 300 mm thickness of strip/band: max. 5,0 mm band speed: 4,5 / 25 m/min work height max.: 1700 mm Payload: 12,0 to (Coil) Weight approx.: 7,3 + 6,62 t dimensions of coil: 3,2 x 1,9 x 2,7 m dimension machine xH: 2,5 x 2,6 x 2,45 m Decoiler with loading device Can optionally be sold together with stock no. 0100571. straightening unit: Infeed rollers: 2 x Ø 144 x 850mm Straightening rolls: 3 x bottom rolls, rigid, Ø 100 x 850mm, 30mm adjustable 3 x top rollers, Ø 110 x 850mm; 30 mm adjustable Coil unwinding machine: Dujdpfxou Ic Ave Abfou Outer Ø 1.500mm Strip width max. 800mm Load capacity max. 12 to Clamping Ø 470 - 630 / 570 - 730mm Transport unit LxWxH: 1700 x 1500 x 1000mm; crosswise running, with prism support 1000 x1000mm Machine will be offered and sold with Stock no. 0100521 as a decoiling and streightening line. *
