Gear grinding machine

HÖFLER Helix 400 CNC

Condition: used, Year of construction: 2007, max. wheel diameter 380 mm gear width 540 mm max. module 7 Duedpfxjyt Rvhe Ag Hou Control SINUMERIK 840 D Axial travel 600 mm table diameter 317 mm table speeds 100 U/min milling head -swivable + / - 35 Grad milling spindle drive 27,00 kW milling spindle speeds (infinitely variable) 1500 U/min diameter of hob 160 mm cutter length max. 330 mm cutter speeds max. 3000 1/min hob dia. - max. 160 mm swarf cutter lenght - max. 330 mm tangential travel max. 300 mm 10.000 mm/min tangential speed max. 3000 mm/min 7.500 mm/min oil volume 100 l coolant capacity 780 l Counterholder movement 540 mm total power requirement 50,00 kW weight of the machine ca. 16,00 t dimensions of the machine ca. 6,00 x 4,50 x H3,50 m for the following processes: axial hobbing, individual part milling, Worm wheel milling, roofing, deburring; NC tailstock

Year of construction: 1980, condition: good (used), A used very well preserved cycle controlled lathe from Weisser Heilbronn with SIEMENS control. Duedpfegyy I Asx Ag Hsu centre distance 2000 mm centre height 295 mm Swing over bed 600 mm Swing over cross slide 260 mm Swing diameter in the bend 800 mm Total length of the crank 375 mm Bed width 450 mm Plan travel X-axis 350 mm Longitudinal travel Z-axis 1850 mm Spindle nose DIN 55022 size 8 Spindle speed Number 18 14 - 1400 rpm spindle bore 71,5 mm Diameter of front bearing 110 mm feed range 0,01 - 40,95 mm/rev rapid traverse 8 m/min Direct current drive 15 kW 400V 50Hz Max. permissible torque at the spindle 2500 Nm Tailstock quill 80 mm quill stroke 250 mm inner taper quill MK 5 Length x width x height Weight of the machine 5500 kg Accessories Tailstock Pneumatic three-jaw chuck with interchangeable jaws 315mm Quick change holder "MULTIFIX "in front of the center size "C Quadruple turret behind the center Tool holder Coolant device Pneumatic steady rest Technical data and dimensions: Errors excepted. Videoconference via whatsapp possible by appointment

Condition: ready for operation (used), A surface grinding machine ELB-Schliff with position display is available. Magnetic chuck dimensions X/Y: 900mm/450mm, grinding length: 900mm, grinding width: 450mm. Documentation available. An on-site inspection is possible. Djdpfeya Hw Iex Ag Hjuu

Condition: used, cone distance min./max. 0-108 mm Pitch angle min/max 5°/84° Control GE Fanuc Series 0-GC Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm Knife spindle - Speed range 41-121 U/min working spindle speed range 0-33.33 U/min weight 9025 kg dimensions of the machine ca. 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: - 18-piece cutter set - Chip conveyor Duodpfx Agjyh Rmme Hju - Technical documentation

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Dujdpertrvysfx Ag Hou Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: good (used), Year of construction: 1971, functionality: fully functional, machine/vehicle number: 12.02-37-31, grinding wheel width: 250 mm, grinding wheel diameter: 500 mm, grinding diameter: 125 mm, grinding length: 200 mm, type of input current: three-phase, overall weight: 5,000 kg, workpiece diameter (max.): 125 mm, nominal power: 28 kW (38.07 HP), The machine was used exclusively for grinding piston rods with a diameter of 10 mm. Dusdpfx Agow E D Eus Heu

Condition: good (used), Year of construction: 2009, Traverses XYZ 850 x 700 x 750 mm, Pallet size 500 x 500mm, pallet load 500 kgs, Dedpfxowq Iwxo Ag Houu 60 ATC, BT40 spindle taper, Fanuc 31i- control. Spindle power 22Kw, B axis 0.001 Degrees, 14000 rpm spindle, swarf conveyor, Through Spindle Coolant.

Condition: good (used), Year of construction: 2007, max. wheel diameter 1200 mm gear width 260 mm max. module 16 min. module 0,5 stroke 270 mm distance between table/spindle 920 mm taper of shaper cutter SK control Liebherr LH 90 table diameter 900 mm min. workpiece diameter-at internal hobbing 1200 mm strokes - infinitely variable 50-1000 Hub/min spindle diameter 125 mm table hole 320 mm Distance of shafts Min/Max 0-820 power requirement Stosskopf 30 KW total power requirement 72 KVA Duodpfx Agswzmp Is Hou weight of the machine ca. 24 t dimensions of the machine ca. 6,5x2,9x4 m Liebherr LH 90 control, 9 axis CNC, top condition.

Condition: good (used), Year of construction: 1998, spindle diameter 90 mm control Siemens SINUMERIK 840 C voltage 400 V stroke position adjustment 100 mm table hole 150 mm no. of strokes 100-1200 Hub/min weight of the machine ca. 8,0 t Key data Normal module: 6 mm Max. workpiece pitch circle diameter: 250 mm Max. tooth width (straight teeth): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance workpiece/jigging spindle: –80 mm to +320 mm Stroke position, stroke length Max. stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Stroke drive Stroke rates infinitely variable Standard: 100 to 1200 DH/min Motor for stroke drive: 9 kW Maximum cutting speed: 150 m/min Feeds Rotation axes (tool C1, workpiece C2 axis): Feed stepless relative to 100 mm pitch circle diameter: 1.0 to 9420 mm/min Radial axis (column slide X1 Duedpfx Agoxyadtj Heu axis): Feed continuously variable: 1.0 to 9420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / weight Total connected load: 26 kVA Total weight (standard version): approx. 9,000 kg

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : HSK63 - Spindle power : 22 / 26 [kW] - Spindle speeds : 100 - 10.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 800 x 600 x 800 [mm] - Rapid traverses rates (X/Y/Z) : 40 [m/min] B ROTARY AXIS - Travel : 360 [°] - Indexing precision : 0,001 [°] - Rapid traverse rate : 13,88 [rpm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 60 - Tool exchange time : 2,2 [sec] PALLET CHANGER - Pallet changing device type : Rotopalette Djdpfx Agouhb D No Houu - Pallet size : 630 x 500 [mm] - Pallets number : 2 - Maximum weight upon pallet : 900 [kg] - Distance table / spindle axis (min./max.) : 43 - 643 [mm] - Distance table center / spindle nose (min./max.) : 145 - 945 [mm] - Maximum workpiece diameter : 740 [mm] - Maximum workpiece height : 550 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 56 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5.244 x 3.305 [mm] - Machine height : 3.345 [mm] - Machine weight : 10.000 [kg] MACHINE HOURS - Number of working hours : 9.095 [h] EQUIPMENT - CNC : Fanuc 0i-MD - Interface : Ethernet / RS232 / USB / PCMCIA - Interactive programming : Manual guide - Electronic handwheel - Linear scales - Rigid tapping - 3 colors status lamp - Coolant tank : 700 [l] * with oil separator * with high-pressure pump : 40 [bars] * Coolant through spindle * with paper filtering unit * With washing gun * With cabin washing - Parts hydraulic clamping : prepared - Hydraulic counter balance : upon Y axis - Chips conveyor - Spindle cooling unit - Tool-holders : 35
