Vertical Machining Centre

HAAS VF-4SS

Condition: excellent (used), Year of construction: 2012, Haas Vf4SS Year of manufacture 2012 Gjdjxnpuwjpfx Afpeuh 12,000 rpm BT 40 40+1 tool changer With 4th axis Renishaw Very good condition! Videos available.

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, rotational speed (max.): 12,000 rpm, spindle nose: BT 40, number of slots in tool magazine: 24, WORK AREA: Longitudinal X: 1.270 mm Transverse Y: 508 mm Gedpfjxiv T Asx Afpsuh Vertical Z: 635 mm Distance between spindle nose and table: 102-737 mm TABLE: Dimensions: 1.321 x 457 mm Maximum weight on table: 1.588 kg T-slot width: 16 mm T-slot center distance: 80 mm SPINDLE: Spindle connection taper: BT 40 Rotation speed: 12.000 rpm TOOL CHANGE: Magazine capacity: 24 Tool taper: BT 40 Machine complete with: • High pressure through the spindle • Remote electronic handwheel

Condition: good (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, The machine is in good technical condition, with testing possible by agreement. 4th axis included in the price. Prepared for 5th axis. X-axis travel: 1270 mm Y-axis travel: 508 mm Z-axis travel: 635 mm Machine weight: 5950 kg Max. spindle speed: 12,000 rpm Max. power: 22.4 kW Through-spindle cooling: YES Gjdpfsxlr Izsx Afpjuh

Condition: ready for operation (used), Year of construction: 2007, Haas VF-4SS HE Milling Machine with HRT310 Year of manufacture: 2007 X-axis: 1270 mm Y-axis: 508 mm Z-axis: 635 mm Table size: 1,321 x 457 mm Maximum table load: 794 kg Spindle taper: ISO SK 40 Godpfxoxit Nuo Afpouh Spindle: 12,000 rpm with 22.4 kW Through-spindle coolant (IKZ): 21 bar Programmable coolant nozzle Additional filter Chip conveyor spiral 24+1 tool changer High-speed machining Portable control panel VQC-V programming support G/M codes RS-232 and USB interfaces Coordinate system / scaling User-defined macros 4th axis preparation HRT 310 CNCB HTS9 manual tailstock Machine weight approx. 6.3 t The machine can be inspected under power by arrangement near Bielefeld. Loading can be provided. Buyer is responsible for transport. Technical data, accessories, and machine descriptions are non-binding.

Condition: ready for operation (used), Year of construction: 2018, Control Unit Brand HAAS Model na Main Drive Tool taper BT40 Number of axis 4 Movement X-Axis Movement 1250 mm Y-Axis Movement 508 mm Guedpfx Afexd H Umepeh Z-Axis Movement 635 mm This 4-axis HAAS VF-4SS was manufactured in 2018, featuring a working area of 1250 × 508 × 635 mm and a spindle speed of 12,000 rpm. It includes a 24 + 1 tool magazine and a BT40 taper. If you are looking to get high-quality milling capabilities, consider the HAAS VF-4SS machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 22 [kW] - Spindle speeds : 12000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 1270/508/635 [mm] - Rapid traverses rates (X/Y/Z) : 35.6/35.6/35.6 [m/min] - Cutting feed rates (X/Y/Z) : 21 [m/min] - Distance table / spindle nose (min./max.) : 742 [mm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 30 TABLE - Table dimensions : 1321/495 [mm] - Maximum weight upon table : 794 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 30 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3870/2510 [mm] - Machine height : 2690 [mm] - Machine weight : 6260 [kg] MACHINE HOURS - Number of hours under power : 1138 [h] EQUIPMENT - CNC : HAAS - Interface : Ethernet / RS232 / USB / PCMCIA - Interactive programming - Electronic handwheel - Rigid tapping - Type of divisor : 4e axe CNC intégré * manufacturer : HAAS * model : HRT210 Gusdpfsxfcabsx Afpoh * clamping diameter : 203 [mm] * tightening type : Manuel - Coolant tank - Predisposition Coolant through spindle - Chips conveyor - Tool probe - Electric transformer - Tool-holders

Condition: like new (used), Haas VF4SS Year of Manufacture: 2015 Toolchanger: 24 + 1 positions, BT40 TSC 1000: High-pressure spindle coolant 63 bar 360-liter coolant tank Chip Auger: Spiral chip conveyor HRT 210: 4th axis 210mm incl. tailstock WIPS R: Wireless intuitive probe system Renishaw OTS toolsetter Renishaw probe IPS: Intuitive programming screen P-Cool: Programmable coolant nozzle Low hours, excellent condition! Godpfx Ajxc Nbasfpjuh

Condition: ready for operation (used), Year of construction: 2019, General Data Measurements width 2600 mm Measurements depth 3870 mm Measurements height 2770 mm Machine weight 6260 kg Control Unit Brand HAAS Model na Main Drive Spindle speed range 12000 rpm Spindle motor power 224 kW Tool taper CT40 / BT40 / HSK-A63 Number of axis 3 Movement X-Axis Movement 1270 mm Y-Axis Movement 508 mm Z-Axis Movement 635 mm Table Tslots size 80 mm Number of tslots 5 Table load 794 kg Tools Max weight 5.4 kg Max tool length 330 mm Additional Equipment Technical manuals and documentation Chip conveyor Optional tools included Loading at our facility available General Data Measurements width 2600 mm Measurements depth 3870 mm Measurements height 2770 mm Machine weight 6260 kg Control Unit Brand HAAS Model na Main Drive Spindle speed range 12000 rpm Spindle motor power 224 kW Tool taper CT40 / BT40 / HSK-A63 Number of axis 3 Movement X-Axis Movement 1270 mm Gusdpfxow R E I To Afpoh Y-Axis Movement 508 mm Z-Axis Movement 635 mm Table Tslots size 80 mm Number of tslots 5 Table load 794 kg Tools Max weight 5.4 kg Max tool length 330 mm Additional Equipment Technical manuals and documentation Chip conveyor Optional tools included Loading at our facility available This 3-axis HAAS VF4SS vertical machining center was manufactured in 2019. It features a spindle with a maximum speed of 12,000 rpm and a power of 22.4 kW. The machine offers a travel range of X=1270 mm, Y=508 mm, Z=635 mm, and a rapid feedrate of 35.6 m/min on all axes. The table can support up to 794 kg. Consider the opportunity to buy this HAAS VF4SS vertical machining center. Contact us for more information. Application Types Milling

Condition: ready for operation (used), Year of construction: 2012, operating hours: 18,699 h, functionality: fully functional, machine/vehicle number: 1095132, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, table width: 457 mm, table length: 1,321 mm, TECHNICAL DETAILS Travel X-axis: 1,270 mm Y-axis: 508 mm Z-axis: 635 mm Table Length: 1,321 mm Width: 457 mm Max. load: 794 kg Spindle Speed: 12,000 rpm Drive system: Inline Direct Drive Power: 22.4 kW Max. torque: 122 Nm at 2,000 rpm Feeds Rapid traverse X / Y / Z: 35.6 m/min Max. cutting feedrate: 21.2 m/min Tool Changer Gjdpfx Asxb Uhiefpeuh Capacity: 24+1 Type: CT 40 Max. tool diameter: 76 mm Tool-to-tool time: 1.6 s Chip-to-chip time: 2.2 s MACHINE DETAILS Dimensions Height: 3,023 mm Width: 3,886 mm Depth: 2,667 mm Operating Hours Cycle start time: 18,699 h Power-on time: 23,179 h EQUIPMENT 40 + 1 position tool changer, BT40 High-pressure spindle coolant 63 bar (TSC 1000) Coolant tank 360 liters Chip conveyor, spiral type 4th axis HRT 210, 210 mm including tailstock Wireless Intuitive Probe System (WIPS R) Renishaw OTS tool setter Renishaw measuring probe Intuitive Programming Screen (IPS) Programmable coolant nozzle (P-Cool) Approx. 15 tool holders

Condition: ready for operation (used), Year of construction: 2012, General Data Machine weight 6350 kg Control Unit Gsdsw R E I Hjpfx Afpouh Brand HAAS Main Drive Spindle speed range 12000 rpm Number of axis 4 Movement X-Axis Movement 1270 mm Y-Axis Movement 508 mm Z-Axis Movement 635 mm Tools Type of tool holder BT 40 This 4-axis HAAS VF-4SS was manufactured in 2012. It features a BT 40 tool holder and a maximum spindle speed of 12,000 rpm, suitable for a variety of machining tasks. Consider the opportunity to buy this HAAS VF-4SS vertical machining centre. Contact us for more information. Application Types Milling
