Jig Boring Machine - Double Column

HAUSER M 5

Condition: excellent (used), Year of construction: 1990, machine/vehicle number: 30216 & 30277, feed length X-axis: 1,000 mm, travel distance X-axis: 1,000 mm, Universal tool milling machine Make: MAHO Model: MH 1000 2x available! x-way 1000 mm tool holder SK 40 digital display . Head tiltable +/- . Table tilt and swivel +/- . Quill stroke . - 3-axis digital display - Universal table 1.250 x 740 mm (T-slot 16 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - 6 autom. quill feeds Tsdpfxep S Sche Ahmsc 0,02/0,03/0,05/0,08/0,12/0,20 mm/Umdr. - central lubrication, manually operated The machine can be inspected with pleasure. Immediately ready for use Free loading, transport no problem.

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm Tedpfx Ahou Nc Riomec y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: used, Technical details: Todpfx Asxt El Aehmsc spindle diameter: 120 mm x-travel: 1250 mm y-travel: 1250 mm z-travel: 800 mm W-axis (spindle longitudinal): 600 mm Speed of boring spindles: 1- 2000 U/min. spindle taper ISO: 50 table surface area: 1000 x 1000 mm total power requirement: 55 kW weight of the machine ca.: 18 t with CNC HEIDENHAIN TNC 426 autom. toolchnager 40-pockets coolant attachment *

Condition: good (used), Year of construction: 2008, turning length: 12,000 mm, spindle motor power: 60,000 W, total height: 3,800 mm, total length: 23,000 mm, total width: 7,600 mm, swing diameter over cross slide: 1,520 mm, turning diameter over bed slide: 1,140 mm, workpiece weight (max.): 20,000 kg, overall weight: 58,000 kg, Equipment: documentation/manual, CNC Lathe Giuseppe Giana - GGH 1100/760 x 12.000 CNC MACH-ID 9439 Make: Giuseppe Giana Type: GGH 1100/760 x 12.000 CNC Control: Siemens 840 D-SL Year: 2008 3 bed way construction Bed width 1100 mm 3 x C-Type Steady rest on lower base with in feed 2 x Fixed steady rest 300 - 800 mm with 5 ton 2 x Chip conveyor 4 Chuck 1000 mm Barafuldi 4 way turret head Swing over bed Ø: 1520mm Swing over cross slide Ø:1140mm DBC Turning Length: 12000mm Spindle bore: 155mm Spindle power: 60kW Bed width: 1100mm Tailstock spindle Ø: 310Ø Stroke pinole: 300mm Spindle taper: 1:4 taperMk Workpiece weight: 20000 Power: 80A Speeds / ranges: 0-800Rpm Feed rate X-Axis: 0-8000mm/min. Tsdpfxjyl Uh Sj Ahmsc Feed rate Z-Axis: 0-8000mm/min. Length: 23000mm Width: 7600mm Height: 3800mm Weight: 58000kg

Condition: excellent (used), Year of construction: 2011, TECHNICAL DETAILS CNC control: MSX-501III X axis mm: 560 Y axis mm: 560 Z axis mm: 660 B axis deg.: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X,Y,Z: 60,000 Max. rapid traverse m/min X,Y,Z: 50 Spindle speed rpm: 12,000 Spindle power kW: 15 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Tool changer positions: 60 Max. tool diameter mm: 70 Tjdpfx Aoxfka Nohmsc Max. tool diameter with adjacent positions empty mm: 170 Max. tool length mm: 450 Max. tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant (high-pressure): Yes EQUIPMENT Double chip conveyor ISO-40 taper High-pressure through-spindle coolant with pump Tool breakage detection probe Part measuring probe RENISHAW MACHINE DIMENSIONS Length mm: 3,755 Width mm: 2,300 Height mm: 2,610 Weight kg: 7,600

Condition: used, Year of construction: 2014, Technical details: x-travel: 760 mm y-travel: 760 mm z-travel: 760 mm b-axis: 360.000 x 0.001 ° spindle drive: 26 / 18,5 (40% / 100%) kW spindle turning speed range: 50 - 15000 U/min Tool bore: KSK-A63 max. table loading capacity: 500 kg total power requirement: 43 kW weight of the machine ca.: 11,5 t Tsdoxrwpdspfx Ahmoc dimensions of the machine ca.: 2,7 x 4,73 x 2,87 m

Condition: new, For sale, a pipe straightener from the German manufacturer SMS MEER, the machine is brand new, it was dismantled from a plant that collapsed during the delivery and assembly of the machine. The machine has two Siemens 200 kW drive motors each. Straightening rollers have a length of 460mm, diameter on the sides 400mm, diameter in the middle 300mm. The weight of the machine itself is 44 tons, the total weight is 55 tons. I can send a lot of photos before dismentling. Tsdpfem H Unhox Ahmoc

Condition: good (used), Year of construction: 1983, Machine number: 316204/22 Type / Model: FSS 315/E Travel ranges x-y-z: 850 – 280 – 355 mm Table: 1,200 x 370 mm Clamping area: 1,060 x 260 mm Speed range: 28 to 1,400 rpm Spindle mount: SK 50 Quill stroke: 80 mm Tjdpsfli Afofx Ahmsc Feeds for x and y axes: 16 to 800 mm/min Feed for z axis: 5 to 250 mm/min Power: 8 kW Accessories/Equipment: Head swivels Condition: good Weight: 4 t Dimensions: 2,000 x 2,000 x 2,400 mm

Condition: good (used), Year of construction: 1990, CNC milling machine, manufacturer: TOS, type: FGS40CNC Control system: Heidenhain TNC 355, year of manufacture: 1990 Travel distances: X 1000 mm, Y 500 mm, Z 500 mm Todpfxsdtfhqo Ahmec Spindle mount: ISO 50.

Year of construction: 1978, condition: ready for operation (used), A Haeusler CNC large-format 4-roll plate bending machine is available. Number of rolls: 4, Roll width: 3050mm, Max. prebending plate width: 3000mm, Max. prebending plate thickness: 60mm, Max. rolling capacity at max. plate width and 3500mm bending diameter: 70mm, Roll diameter top/bottom/side: 620mm/600mm/500mm, Max. top roll load: 12000kN, Operating speed: 4m/min, Connected load: 132kW, Weight: approx. 85t. Including cone bending device. Documentation available. An on-site inspection is possible. Tsdpfszka H Aox Ahmec
