Drilling and Milling M/C

HBM BF 30 DRO big

Condition: new, Guide and pull spindle lathe Bernardo Standard 165 D Technical specifications Tip width: 1000 mm Tip height: 175 mm Circulation diameter over bed: 350 mm Circulation diameter over crumpling*: 450 mm Orbit diameter via flat slide: 190 mm Bed width: 180 mm Spindle bore: 40 mm Spindle holder: DIN 55029, D1-4 Speed range: (8) 70 - 2000 rpm Range of longitudinal feeds: (40) 0.053 - 1.29 mm/U Area of plan feeds: (40) 0.013 - 0.31 mm/U Metric threads: (32) 0.4 - 7 mm Inch Thread: (36) 4 - 60 Gg/1" Pinole path: 110 mm Pinole holder: MK 3 Engine power: S1 100% 1.5 kW (400 V) Motor recording power: S6 40% 2.2 kW (400 V) Machine dimensions (W x D x H) 1730 x 700 x 1340 mm Weight approx. 514 kg * Bed length removable Delivery • 3-axis i200 digital display with LCD display • 3-jaw chuck DK11-160 mm / D4 • Flat disc 200 mm / D4, according to DIN 55029 • Fixed bezel - pass diam. max. 60 mm • Running bezel - pass diam. max. 60 mm • Clamping disc 250 mm • Quadruple steel holder • Shaft fixing device • Protective device for steel holders • Slip clutch • Micrometer longitudinal stop • Coolant device • Extendable chip newfir Dcodpfx Ahed Ri Ezj Ied • Motor with magnetic brake according to CE standard • Foot pedal with brake function according to CE • Spray wall • Threaded watch • LED machine light • Reducing sleeve • Interchangeable wheels • 2 centering tips • Base • Operating tool

Condition: new, WMD25LV - 230V / 1F Drilling capacity steel ----- 25 mm Milling capacity steel ----- 20 mm Flute cutters ----- 63 mm Motor ----- Brushless 750W Spindle speed stepless 50 - 3000 rpm Spindle stroke ----- 50 mm Spindle mounting ----- MK3 Work table ----- 700 x 180 mm Cross travel ----- 150 mm Dsdpfxsga T Eie Ah Iscd Longitudinal displacement ----- 490 mm T-slots ----- 3x12 mm Unloading ----- 170 mm Distance spindle - table ----- 325 mm Weight ----- 160 KG STANDARD ACCESSORIES * Drill head incl. drill chuck * Digital depth stop * Digital spindle display * Fine adjustment * Left / Right switch * Milling head left / right 90 degrees rotatable * Box with various tools OPTION * Support box € 249,00 ex vat

Condition: new, Year of construction: 2025, Heavy, solid cast iron design High running smoothness due to ground gear wheels running in an oil bath Right/left hand rotation Automatic quill feed with manual fine feed Motorized positioning of the Z-axis Motorized table feed of the X-axis Coolant device Machine lamp Gear head can be swivelled ± 60 Adjustable wedge bars Solid dovetail guide of the column, hand-scraped, for highest stability and greatest possible precision Height-adjustable, large-dimensioned protective disk with microswitch Drilling depth stop Digital position indicator DRO 5 Drilling / tapping function Massive and large dimensioned cross table, precisely surface machined with T-slots and adjustable taper bars Solid cast iron machine base with chip channel Single-stage quality industrial electric motor Wide speed range from 60 - 2,760 min-1 due to 2 infinitely variable speeds Dimensions and weights Length approx. 1600 mm Width/depth approx. 930 mm Height approx. 2110 mm weight approx. 495 kg Drilling/milling capacity cutter head size max. 63 mm Djdpfxeg U Uv Uo Ah Ijcd shank cutter size max. 26 mm Drilling capacity steel (S235JR) 24 mm Continuous drilling capacity steel (S235JR) 20 mm Electrical data Supply voltage 230 V Mains frequency 50 Hz Electrical connection Total connected load 1.5 kW Horizontal milling table length 800 mm width 240 mm Distance vertical spindle - milling table max. 420 mm T-slots size 14 mm T-slots number 3 T-slots distance 80 mm Standards and approvals Standard DIN EN 55011 EMC class C2 Travel X-A

Condition: new, diameter 200 mm height 105/265 mm centre height 105 mm Dedpfeupxd Rox Ah Iecd weight of the machine ca. 41 kg dimensions of the machine ca. 400 x 330 x 310 m
