Used Hbm Drilling And Milling M/C for sale (98,819)

Condition: new, neu ca. 12 - 14 Wochen ab Auf Spanien 50410 € 952.75 € 35 mm MK 4 390 mm 94- 2.225 (16) 50 Hz 113 U/min Ibodpfxeynmtxs Anmja M35 1660 mm 1510 mm 2600 mm 910 kg 180 mm 190 - 650 mm 1310 mm 125 mm 400 x 420 mm 0,10 - 0,18 - 0,24 (3) mm/min 750 - 1.500 U/min ERLO (MADE IN SPAIN) FOR DEMANDING WORKSHOP USE drilling and milling machine automatic feed precision electromagnetic clutches geared drive cross table fixed base and displaceable headstock control panel cooling equipment with electric motor pump hand wheel for fine tuning clamping device for tools adjustable stop drill guard OPTIONAL EQUIPMENT (PRICES ON REQUEST): Digital read out for drilling depth Tapping device Motorized longitudinal and/or transverse feed Digital read out for table axes and/or drill head height adjustment

Condition: used, Year of construction: 1985, bore capacity in steel (diameter) 30 mm x-travel 850 mm y-travel 435 mm Control HEIDENHAIN TNC 150 total power requirement 16 kW weight of the machine ca. 3500 kg dimensions of the machine ca. m F E H L M A N N (Switzerland) CNC-Controlled High Precision Drilling and Milling Machine with HEIDENHAIN CNC-Control Model TNC 150 Model PICOMAX 100 CNC – 2 + A * Year 1985 Serial No. 16 085 109 _____ Table travel: Longitudinal ( X-Axis) 850 mm Cross (Y-Axis) 435 mm Milling/Boring head travel vertical ( Z-Axis) 210 mm Table size /Clamping area 500 x 1.570 resp. 390 x 1.280 mm Mounting height below spindle, approx. 140 / 690 mm Height adjustment of Milling head max. 540 mm Distance between spindle and column 450 mm Spindle taper SF 32 Spindle quill travels 210 mm Drilling Capacity approx.. 30 mm Ibsdpfx Aot Hxa Hjnmea Spindle speeds steplessly adjustable 50 – 2,500 rpm Feeds steplessly adjustable 1 – 8.000 mm/Min. Quick feed 8.000 mm/Min. Spindle drive, approx. 6 kW Total electrical load 16 kW - 400 V - 50 Hz Weight, approx. 3,500 kg Accessories / Special Features: * HEIDENHAIN – CNC Path Control System Model TNC 150 with colour Screen Grafik, Subroutines, cycles, Threading cycles, Milling Cycles, etc. Mobile Control unit with electronic handwheel. Ideal for quick set-up and approach to the workpiece. * The quill movement can be actuated manually or also by the CNC-Control, * The Drilling depth can be presetted by a 12 fold turret drum for different quillstops and with a digital display of the values on monitor. * The complete Milling/Drilling head can be positioned in 3 different heights and with automatic clamping. * Hi Precision Coordinate table controlled by the XY – CNC axis with hardened ball screw spindles. * With quick change tool holders, chucks, millers, etc. and with coolant device. Condition : Very Good to excellent - Machine under power, ideal for small batch production Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 1971, Technical details: max. diameter of face turning: ca. Ø 900 mm revolution per minute: Spindel: 12,5 - 00 / 24 step U/min revolution per minute: Planscheibe: 8 - 190 / 12 step U/min feed steps: Planscheibe: 0,03 - 3 / step rapid traverse: alle Bewegungen: 2000 / 4000 m/min tool taper: der Arbeitsspindel: ISO 50 / SK50 table clamping surface:: 700 x 800 table rotating: 360° Grad drill table adjustment: quer: 800 mm max. table load: 1500 kg total power requirement: ca. 11,0 kW weight of the machine ca.: 7800 kg dimension machine xH: 3,0 x 2,0 x 2,6 m dimensions electric cabinet: 1800 x 400 x 1950 mm Ibedpfx Asu Idtponmsa Ø of the face plate 420mm Movement of the face slide 180mm largest Ø during facing approx. 900mm Longitudinal movement of the column 700mm Vertical movement of the headstock 700mm Feed drive of column, headstock and clamping table: -for spindle operation=0,20 - 10 mm/rev with 34 speeds -for operation with faceplate= 0,16 - 16 mm/rev with speeds Equipment: optical fine measuring device/measuring system for axes X/Y/Z/B-axis hydraulics machine feet/footplates control panel with boom *

Condition: new, bore capacity in steel (diameter) 25 mm throat 185 mm bore stroke 50 mm spindle taper MK 3 spindle turning speed range 50 - 2500 U/min 178 mm 480 mm table surface area 700 x 180 mm connected load frequency 230 V Ibodpfx Aed Sb Aysnmja total power requirement 0,75 kW weight of the machine ca. 160 t dimensions of the machine ca. 0,75 x 0,8 x 0,9 m domestic equipments • Digital depth gauge • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional.

Condition: new, bore capacity in steel (diameter) 13,0 mm x-travel 300 mm y-travel 130 mm turning speeds 100 - 2500 U/min throat 165 mm spindle taper MT 3 MK Ibedpfx Aoxabb Hsnmsa table-size 490 x 120 mm diameter of hob 30,0 mm motor 230 Volt total power requirement 0,75 kW weight of the machine ca. 50 kg. dimensions of the machine ca. 520x500x740 mm Scope of delivery: - Key chuck 1 - 13 mm / B 16 - Drill chuck arbor MK 3 / B 16 - tightening spindle M 12 - Height-adjustable protective cover - operating key

Condition: new, bore capacity in steel (diameter) 40 mm throat 290 mm bore stroke 130 mm spindle taper SK 40 spindle turning speed range 75 - 3200 U/min 500 mm 230 mm table surface area 720 x 210 mm connected load frequency 400 V diameter of hob max. 80 mm total power requirement 1,1 kW weight of the machine ca. 0,35 t dimensions of the machine ca. 1,1 x 0,9 x 1,2 m Iodpfsfv H Husx Anmsba domestic equipments • Digital display • Digital depth gauge for quill • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional.

Condition: new, bore capacity in steel (diameter) 40 mm throat 275 mm bore stroke 120 mm spindle taper MK 4 turning speed range 75 - 3200 U/min 190 mm 490 mm table surface area 730 x 210 mm connected load frequency 400 V boring feeds: 0,1 - 0,18 - 0,26 mm/U total power requirement 1,1/1,5 kW weight of the machine ca. 0,35 t dimensions of the machine ca. 0,8 x 0,75 x 1,85 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° Ibjdpfxsupw T Do Anmoa - Feed via hand crank

Condition: new, bore capacity in steel (diameter) 45 mm quill stroke 125 mm 560 mm 230 mm table surface area 800 x 240 mm spindle turning speed range 75 - 3200 U/min max. milling cutter diameter 80 mm spindle taper ISO 30 max. distance between table and spindle-nose 460 mm throat 230 mm Isdjupxrnspfx Anmeba connected load frequency 400 V total power requirement 1,5 kW weight of the machine ca. 580 Kg dimensions of the machine ca. 1,2 x 1,0 x 2,1 m Equipment: All axes with 3-digital display. Quill travel has separate digit display. Automatic feed in X-axis and quill. Motorized Z-axis. tapping device. coolant system. machine base. Collet set, SK tool holder. Further machine accessories in box.

Condition: new, bore capacity in steel (diameter) 50 mm throat 360 mm bore stroke 150 mm Iodpfxefg U S Ue Anmeba spindle turning speed range 120 - 3000 U/min spindle taper SK 40 650 mm 320 mm vertical adjustment 500 mm table surface area 1000 x 300 mm connected load frequency 400 V diameter of hob max. 80 mm total power requirement 2,2 kW weight of the machine ca. 0,85 t dimensions of the machine ca. 1,25 x 1.5 x 2,3 m New Model Industrial Drilling and Milling Machine with Manual Transmission and High Speed Range. The prism guide in the Z-axis ensures a high degree of precision even in the most difficult milling jobs. Domestic equipments: • automatic feed in X-axis • 3-axis digital display • motorized Z-axis • Feed in quill • Left-right-run high • tapping attachment • Gear head swiveling • Coolant system

Condition: new, bore capacity in steel (diameter) 40 mm throat 290 mm bore stroke 130 mm spindle taper SK 40 spindle turning speed range 70 - 3200 U/min 520 mm Ibjdpfxefv H Hqs Anmoa 230 mm table surface area 730 x 210 mm connected load frequency 400 V total power requirement 1,1/1,5 kW weight of the machine ca. 0,32 t dimensions of the machine ca. 1,1 x 0,9 x 1,15 m domestic equipments • Digital depth gauge • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional.

Condition: new, bore capacity in steel (diameter) 40 mm throat 290 mm bore stroke 115 mm spindle taper SK 40 spindle turning speed range 70 - 3200 U/min 350 mm 130 mm table surface area 590 x 190 mm connected load frequency 400 V diameter of hob max. 80 mm feed 0,1 - 0,18 - 0,26 mm/U Ibedpfx Anjf Nb E Hemja total power requirement 1,1 kW weight of the machine ca. 0,4 t dimensions of the machine ca. 0,7 x 0,95 x 1,75 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank

Condition: new, bore capacity in steel (diameter) 45 mm throat 230 mm bore stroke 125 mm spindle taper ISO 30 spindle turning speed range 75 - 1600 U/min max. milling cutter diameter 80 mm 560 mm 230 mm table surface area 800 x 240 mm max. distance between table and spindle-nose 460 mm connected load frequency 230 V total power requirement 1,1 kW weight of the machine ca. 320 Kg dimensions of the machine ca. 1,0 x 0,8 x 1,45 m Features: Iodpjfg U S Tefx Anmsba Drill chuck with ISO-30 mount Digital depth gauge Left/right switch Emergency stop Swivel drill head Spindle guard Feed via handwheel Small tool case Machine stand optional

Condition: new, bore capacity in steel (diameter) 40 mm throat 275 mm bore stroke 120 mm spindle taper MK 4 turning speed range 75 - 3200 U/min 190 mm 490 mm table surface area 700 x 210 mm connected load frequency 400 V diameter of hob max. 80 mm total power requirement 1,1/1,5 kW weight of the machine ca. 0,35 t Isdpfoupw Uzex Anmoba dimensions of the machine ca. 0,8 x 0,75 x 1,85 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank

Condition: new, bore capacity in steel (diameter) 25 mm throat 170 mm bore stroke 50 mm 16 mm spindle taper MK 3 spindle turning speed range 50 - 3000 U/min 280 mm 155 mm table surface area 500 x 180 mm connected load frequency 230 V Ibjdpovdldwsfx Anmsa max. distance between table and spindle-nose max. 320 mm total power requirement 0,8 kW weight of the machine ca. 150 Kg dimensions of the machine ca. 670 x 550 x 910 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content

Condition: new, bore capacity in steel (diameter) 16 mm throat 170 mm bore stroke 50 mm 16 mm spindle taper MK2 spindle turning speed range 50 - 2250 U/min 320 mm 145 mm table surface area 500 x 140 mm connected load frequency 230 V total power requirement 0,5 kW weight of the machine ca. 90 Kg dimensions of the machine ca. 0,5 x 0,45 x 0,84 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head Ibsdpfx Anoupxmrjmja - Feeds via hand crank - Tool case with content but without digital display !!

Condition: new, bore capacity in steel (diameter) 16 mm throat 180 mm Isdpsupxcyjfx Anmsba bore stroke 85 mm spindle taper MK 2 spindle diameter 47 mm spindle turning speed range 320 - 3300 U/min 230 mm 100 mm table surface area 420 x 155 mm connected load frequency 230 V 900 x 600 x 300 cm total power requirement 0,75 kW weight of the machine ca. 8o Kg dimensions 0,7 x 0,7 x 0,8 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank

Condition: new, bore capacity in steel (diameter) 25 mm throat 175 mm bore stroke 50 mm 16 mm spindle taper MK 3 spindle turning speed range 50 - 3000 U/min 380 mm 175 mm table surface area 700 x 180 mm connected load frequency 230 V max. distance between table and spindle-nose max. 320 mm total power requirement 0,75 kW weight of the machine ca. 150 Kg dimensions of the machine ca. 670 x 550 x 910 m Drilling and milling machine with large table Ibjdjupxtfspfx Anmsa Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° spindle protection. incl. tool box with various tools

Condition: new, bore capacity in steel (diameter) 30 mm throat 200 mm bore stroke 70 mm 16 mm spindle taper MK3 spindle turning speed range 50 - 3000 U/min 565 mm 220 mm table surface area 840 x 210 mm connected load frequency 400 V Isdpfx Anoupxt Eomsba max. distance between table and spindle-nose max. 470 mm total power requirement 1,1 kW weight of the machine ca. 230 Kg dimensions of the machine ca. 0,75 x 1,05 x 1,3 m Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° Recording MC 3 - B16. Drill chuck 3 - 16 mm. spindle protection. Machine stand otional ( 199 Euro) incl. tool box with various tools

Condition: new, bore capacity in steel (diameter) 35 mm throat 230 mm bore stroke 125 mm spindle taper ISO 40 spindle turning speed range 115 - 1750 U/min 560 mm 175 mm table surface area 1000 x 240 mm max. distance between table and spindle-nose 375 mm connected load frequency 400 V total power requirement 0,85/1,5 kW Ibodpfxju Imkds Anmea weight of the machine ca. 0,95 t dimensions of the machine ca. 1,3 x 1,2 x 2,1 m Domestic equipments: automatic feed and handwheel. Drill chuck with MK4 holder Digital depth display Left / right switch. Emergency stop switch Pivot head swiveling Spindle protection. Small toolbox Machine base and X-axis feed optional.

Condition: new, bore capacity in steel (diameter) 32 mm throat 200 mm bore stroke 70 mm 16 mm spindle taper MK3 spindle turning speed range 50 - 3000 U/min 220 mm 425 mm table surface area 700 x 210 mm max. distance between table and spindle-nose 470 mm total power requirement 1,5 kW Ibedpfx Asupxlbjnmoa weight of the machine ca. 230 Kg dimensions of the machine ca. 0,75 x 1,05 x 1,2 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content

Condition: new, bore capacity in steel (diameter) 16 mm throat 185 mm bore stroke 50 mm 20 mm spindle taper MK 2 spindle diameter mm spindle turning speed range 100-1500 / 200-3000 U/min 175 mm 280 mm table surface area 500 x 180 mm connected load frequency 230 V total power requirement 0,85 kW weight of the machine ca. 0,12 t Iedeurznwopfx Anmjba dimensions of the machine ca. 0,86 x 0,6 x 0,9 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank

Condition: like new (used), Year of construction: 1987, Used Giddings and Lewis Model MC 50 Twin Pallet Horizontal Machining Centre with Live Spindle, 60 ATC and G&L 8000A Control System. Serial # 445-1052.Year of Manufacture: 1987 Machine Formerly Installed at Rolls Royce Plc In Derby UK. Immediately for Sale and now Located in Belgium where it can be Inspected. Spindle Diameter - 130 MM Spindle Taper - 50 ISO Spindle Travel (Z Axis) - 915 MM Spindle Speeds (4 Ranges) - 5 to 1500 RPM Main Motor - 30 HP Pallet Size - 1219 x 1245 MM Pallet Rotation Increments - 0.001 DEG (360,000 POSITIONS) Pallet Changer Max Load - 5000KGS Pallet Max Load Without APC - 9000 KGS Longitudinal Travel (W) - 1700 MM Vertical Travel Of Head (Y) - 1500 MM Cross Travel (X) - 1800 MM Feed Rates Per Minute - 1.00MM/MIN TO RAPID RATE Rapid Traverse Rate Per Minute (X And Y) - 4500 MM / MIN Rapid Traverse Rate Per Minute (Z And W) - 3000 MM / MIN Auto Tool Changer - 60 POSITIONS Electrical Supply - 415V, 3PH, 50HZ FEATURES AND EQUIPMENT High Pressure (25 Bar) Through Spindle Coolant, High Tolerance Machine. Accurate Machine which was well Maintained and Regularly Calibrated by Manufacturer. Renishaw Probing. Ibodpsu Dahnjfx Anmea Length - 11679 MM Width - 6502 MM Height - 4423 MM Weight - 40329 KGS

Condition: used, Year of construction: 2007, Technical details: spindle diameter: 160 mm x-travel: 6500 mm Iodszuy Sgjpfx Anmoba y-travel: 3000 mm W-axis (spindle longitudinal): 1000 mm dimension of the ram: 400 x 420 mm ram stroke: 1000 mm bore spindle turning speed range: 1 - 2000 U/min spindle taper ISO: 50 feed speeds: 2 - 6000 - 8000 mm/min rapid speed: 8/10 m/min total power requirement: 100 kW weight of the machine ca.: 76 t dimensions of the machine ca.: 12 x 4 x 7,5 ( 5,4 ü.F. ) m with CNC Steuerung HEIDENHAIN iTNC 530 autom. toolchanger 40-pockets autom. Pickup Station for universal milling head, and facing head rotary table 2500 x 2500 mm , max load 25 to. 1500 mm longitudinal movement floor plate 4000 x 2000 mm measuring probe, chip conveyor and coolant attachment *

Condition: used, Year of construction: 1998, x-travel 6000 mm y-travel 4000 mm z-travel 1250 mm w-axis 1500 mm Control Fidia max. workpiece weight 60000 kg Control unit for tool magazine/tool changer Siemens turning speeds 6,3 - 4000 U/min surface area 2500 x 4500 mm 48 St. tool taper SK50 daylight between the side columns 3700 mm rapid traverse 30000 m/min Ibedpfeu I E Emsx Anmsa total power requirement 63 kW weight of the machine ca. 150 t required space 16,8 x 10,3 x 7,9 m

Condition: excellent (used), Year of construction: 1995, x-travel 14000 mm y-travel 5000 mm z-travel 1500 mm w-axis 3000 mm column daylight 4000 mm column: max. dist. table - spindle nose 4500 mm workpiece weight 100 t table dimension - longitudinal 9000 mm table dimension - cross 3000 mm spindle taper ISO SK 50 spindle turning speed range 2-2500 U/min spindle motor 113 kW spindle diameter 200 mm max. torque on the spindle 9500 Nm feed in x - axis 1-10000 mm/min feed in y - axis 1-10000 mm/min feed range Z-direction 1-10000 mm/min rapid traverse 20000 mm/min height over floor 8600 mm control SIEMENS 840C weight of the machine ca. 360 t ATTACHMENTS angular milling head yes autom. tool clamping yes ball spindles yes guideway covers yes coolant unit yes high pressure cooling syst. (through spindle) yes closed cabin yes chip conveyor yes Ibodpfovwgm Hjx Anmoa TECHNICAL DESCRIPTION 2 portal milling centres, each with 3 table pallets 9000 x 3000 mm: - Tool changer with 420 tools - Head pick-up system - Video monitoring via camera - High pressure lubrication unit for inner cooling 70bar AVAILABLE HEAD UNITS: - Fixed angle head HS800C600 105 Kw 600 long - Fixed angle head HSD350C850 50 Kw 850 long - Fixed angle head HSD 40C880 12 Kw 880 long - Fixed angle head HSD 190C1000 30 Kw 1000 long - Vertical spindle unit VS800C 105 Kw 900 long - Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time - Angle spindle unit SO800C905 - 22,5° fix - Angle spindle unit HSE1200CS -25° fix - Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth --> 1.350 1/min , B-Achse 0,5 Grad Hirth One additional drilling extension SE 350C plus 1 SE500C. DESCRIPTION OF CONDITION In 2011/2012 these 2 identical machines were retrofitted The milling length was extended to 14meters and an automatic changing system for table pallets was installed. Both machines can be seen under power by prior appointment.
