Machining center
HERMLE C 1200U

Name: HERMLE C 1200U
Brand: HERMLE
Availability: InStock

Year of construction

2001

Condition

Used

Location

Lidköping

Show map

Machine data

Machine type:: Machining center

Manufacturer:: HERMLE

Model:: C 1200U

Year of construction:: 2001

Condition:: good (used)

Price & Location

Location:: Lidköping, Sverige

Call

Technical details

Travel distance X-axis:: 1,200 mm

Travel distance Y-axis:: 800 mm

Travel distance Z-axis:: 500 mm

Workpiece weight (max.):: 1,000 kg

Equipment:: chip conveyor

Details about the offer

Listing ID:: A186-64676

Update:: 07.03.2025

Description

TECHNICAL MACHINE BENEFITS:
- RAPID TRAVERSE IN ALL AXES 30 M/MIN
- CHIP-TO-CHIP TIME 6.5 S
- NC SWIVEL ROTARY TABLE
- CLAMPING SURFACE: Ø 800 MM
- SWIVEL RANGE: +15°/-97°
- SPEED DRIVE POWER/TORQUE/TOOL CONSUMPTION
- 10000 1/MIN 25 KW/159 NM (40% ED) / SK 40/HSK A 63
- 16000* 1/MIN 15 KW/130 NM (40% ED) / SK 40/HSK A 63
- 24000* 1/MIN 23 KW/79 NM (40% ED) / HSK A 63
- 30 SEATS
QUALITATIVE MACHINE BENEFITS:
- INTERNAL COOLANT SUPPLY 40 BAR
- HEIDENHAIN MEASURING PROBE WITH RADIO
- ELECTRIC HEAT COMPENSATION
- ELECTRONIC MANUAL CONTROL MODULE
- OIL MIST EXTRACTION
- CHIP CLEANING GUN
- BLOW-OFF DEVICE
- SEALING AIR FOR STANDARDS
- A AXIS +15º / -97º C AXIS 360º
- C AXIS 360º
Dcedov Hxifspfx Advec

The listing was translated automatically. Translation errors are possible.

Seller

Registered since: 2024

7 listings online

Call

Send inquiry

Telephone & Fax

+46 72 50... show
