Tenoning machine

HOFMANN

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, power: 7.5 kW (10.20 HP), planing width: 625 mm, tool diameter: 125 mm, number of blades: 4, rotational speed (min.): 5,000 rpm, overall weight: 1,000 kg, 4-knife TERSA cutter head for planer Motor power 7.5 kW Positioning control for the thickness table Segmented infeed roller Segmented pressure bar Feed speeds of 7 + 14 m/min Table extension Planing width 625 mm, chip removal up to 8 mm, planing height 3.5-305 mm Thickness table mounted on four support spindles and with 4-point guidance. Heavily ribbed cast iron table, finely planed Modern control panel ergonomically positioned. Electric thickness table adjustment with LED display. Buttons for adjusting in rapid or slow mode, Adjustment accurate to 1/10 mm; integrated operating hour counter. Electronic starting and braking system. Electronic, wear-free brake for safe stopping of the cutter head. Infeed roller in rubber and two rubber outfeed rollers (high quality, low wear) Segmented pressure bar, rotary knob with scale, for adjusting the pressure (preload) of the outfeed pressure bar Kdodjz Dkftopfx Akwot Two feed speeds 7 + 14 m/min; electrically switchable, also during planing Thickness hood with carpet support, can be used as a storage area for wood. Dust extraction port Ø 160 mm, to the left (can also be on the right – can be easily converted on site) Air velocity 22 m/s Integrated tool storage compartment for operating tools and planing knives Electrical equipment according to VDE/EN 60204 with main switch, emergency stop button and 2nd emergency stop button on the discharge side, winding protection, undervoltage protection, contact for controlling the dust extraction, accessories: 1 set of knives installed, operating tools, grease gun, operating manual Weight: approx. 1000 kg CE-compliant, BG-Holzstaubgeprüft No. HM 23001 Workplace-related emission values dB(A) according to DIN 45635 Part 1650 Idle noise approx. 69 dB(A), operating noise approx. 79 dB(A) Workplace-related dust emission value: 0.44 mg/m³

Condition: excellent (used), Year of construction: 1995, Combined surfacing and thicknessing planer from Hofmann, featuring the legendary Leitz-Wigo spiral cutterhead, very robust construction in a compact design. Special feature of this machine: The surfacing table does not need to be folded up for thicknessing, so no conversion is necessary. Equipped with a "genuine" spiral cutterhead. Planing width approx. 620 mm Thickness table electrically adjustable with digital display, fine adjustment via handwheel Grooved steel infeed roller Rubberized outfeed roller, new Planing height approx. 4 - 240 mm 2 feed speeds 7 + 14 m/min Table length 2520 mm Drive motor 5.5 kW with automatic motor brake 2-knife cutterhead with spiral-shaped, re-sharpenable HSS knives Two sets of spiral knives are included, each mounted in matching pressure blocks. Re-sharpening is done by a sharpening service, and the sharpened knife sets can then be easily screwed into the cutterhead without any adjustment work. Slotted table lips Cutterhead guard Suvamatic Fence swivels with guide strip Concave and pointed edge setting for the surfacing tables Rod for hanging the dust extraction hood Dust extraction port 2 x 160 mm Only a few touch-up spots V-belt renewed Knives sharpened Rubber outfeed roller renewed Operating manual CE marking No scratches on the tables. Thickness table with two adjustable table guide rollers Dimensions approx. 2520 x 1200 x 1200 mm (L x W x H). Weight approx. 1300 kg. The machine can be demonstrated on site by appointment. We only offer machines that are ready for demonstration and are in our warehouse; see "other offers from this supplier". Kdsdpjztkyxefx Akwet

Condition: good (used), functionality: fully functional, Manufacturer: HOFMANN Type: NG-1 Kdedpfszzlnmex Akwjt Machine No.: 922472 Max. disc diameter: 320 mm Max. loading weight: 20 kg

Condition: used, Year of construction: 1996, Second-hand machine Year of manufacture: 1996 Features and technical specifications: - The basic principle of Hofmann machines is their tried-and-tested cast iron construction - Grey cast iron is by far the leader in vibration damping, compressive strength and load-bearing capacity - Milling spindle 30 mm with clockwise and anti-clockwise rotation - Milling stop with stop jaws, central adjustment and single-sided fine adjustment of the jaws - Manual height adjustment with digital display and zero-reset button - Table dimensions: 1200 x 820 mm - Table height: 890 mm - Motor power: 5.0/6.2 kW - Spindle speeds: 3,000/4,000/5,000/6,000/8,000/10,000 rpm - Height adjustment: 125 mm - Chip extraction connection: 110/120 mm - with Holz Her 2-roller feed mechanism Weight: 850 kg Kdodszk Nnpopfx Akwot Availability: by arrangement Storage location: 63934 Röllbach

Condition: used, Year of construction: 1979, Used Machine Year of manufacture: 1979 Features and technical specifications: - Planing table width: 500 mm - Planing table length: 2,650 mm - Cutter shaft: 2x strip planer blades Kjdpfx Aezk Nmxokwodt - Motor: 3 kW - Planing guide can be tilted up to 90° The machine does not have a motor brake and can therefore only be sold for spare parts! Availability: Immediate Location: 63934 Röllbach

Condition: new, Thickness planer HOFMANN, model D 636 - new Kdodpfx Aozylvuekwst TERSA cutterhead with 4 knives 5.5 kW motor, 400 V, 50 Hz, electronic start and brake unit Modern control panel ergonomically positioned. Electric adjustment of the thickness table with push buttons for adjustment in rapid or slow mode, as well as adjustment to within 1/10 mm, integrated operating hour counter. Thickness table on four support spindles and with 4-point guidance. Rubber infeed roller and 2 rubber outfeed rollers. Segmented pressure bar, rotary knob for pre-tensioning the outfeed pressure bar Dust extraction port Ø 160 mm, to the left. Integrated tool storage compartment including options: - Motor power 7.5 kW instead of 5.5 kW - Stepless feed rate 4-22 m/min, instead of the 2 feed speeds - Positioning control for D 636 with 250 memory slots

Condition: new, Year of construction: 2026, HOFMANN, type AD 635, new surface planer/thicknesser - TERSA cutterhead with 4 knives, Kdjdpfxozyf Tye Akwet - Thickness table adjustment with buttons for rapid or slow feed adjustment, as well as adjustment to within 1/10 mm accuracy, integrated operating hour counter, - Thickness table supported by 4 lead screws and guided on 4 sides - Rubber infeed and outfeed rollers including options: - Motor power 7.5 kW - Continuously variable feed rate of 4-22 m/min, instead of the 2 feed speeds - Positioning control for AD 635 including sensor monitoring via light barrier - Extension table 630 mm, L = 1000 mm - Telescopic push stick

Condition: new, Year of construction: 2026, HOFMANN TFS 107 Table milling machine with swivel adjustment +/- 45.5° 7.5 kW motor, 400 V, 50 Hz, Table size 1,200 x 815 mm, heavy-duty ribbed cast iron table, with table rings Electronic start and braking system Electric height and swivel adjustment in rapid and slow mode accurate to 1/10, height adjustment approx. 145 mm, Swivel adjustment +/- 45.5° 4 speeds 3,000/4,500/6,000/9,000 Milling fence type 2601, efficient with multiplex fence jaws Fixed milling spindle Ø 30 mm with quick-release nut "fix" Left/right rotation, machine socket, arc milling guard type TAPOA, Hofmann "Centrex". Includes options: - Table size 2000 x 815 mm with extendable support by 480 mm, instead of standard table - Stepless speed control TFS 107 from 1,500 to 10,000 rpm incl. 7.5 kW motor, - HOFMANN milling fence type 2620, including quick-release system for the fence jaws, digital display - 2 cast iron fence jaws 500/500 mm - Control panel moved upwards - Tool compartment for TFS 107 Kjdpfx Ajzyf Ikekwodt

Condition: used, Year of construction: 1999, total length: 1,000 mm, total width: 2,040 mm, total height: 1,710 mm, Colour: Grey Empty weight: 900 kg - Year: 1999 - Documentation available: No - CE certificate present: No - Serial number: 126-02049 - Main motor power [kW]: 7.8 - Spindle diameter [mm]: 40 - Table length [mm]: 1990 - Max. tool diameter milling head [mm]: 180 - Feeding device present: Yes - Brand: Holz-her - Number of wheels [pcs]: 3 - Number of speeds: 2 - Voltage [V]: 380 - Current consumption [A]: 12 - Power [kW]: 6.2 - Transport dimensions: 1000mm x 2040mm x 1710mm (l x w x h) - Transport weight [kg]: 900kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Kjdpfx Ajwnigcskwedt Yorick Diebels

Condition: used, mileage: 263,069 km, power: 154 kW (209.38 HP), gearing type: mechanical, fuel type: diesel, color: orange, overall weight: 16,000 kg, empty load weight: 9,840 kg, number of seats: 3, first registration: 06/2002, Year of construction: 2002, operating hours: 10,533 h, Equipment: additional headlights, cabin, hydraulics, Road marking machine: + Hofmann Kjdpfx Asxal A Ujkwedt + H75-1000 + Thermoplastic + Electric heater (400V) + Thermoplastic tank with gas heater and hydraulic agitator + Paint and bead spray left / right + Line segment computer + Rear and front warning system + CompAir DLT 0404 compressor with Deutz diesel engine (9,513 operating hours) + Kubota Diesel V1505 drive engine (22,975 operating hours) + Renault Midlum 210 chassis + First registered: 10.06.2002 + 263,069 km; 10,533 operating hours + 3-seater + Manual transmission with reduction gear + Hand throttle Unladen weight: 9,840 kg; permissible total weight: 16,000 kg + 813 cm x 250 cm x 325 cm (LxWxH) Receive all newly listed vehicles by email – sign up for our NEWSLETTER! Errors and omissions excepted, subject to prior sale!
