SINGLE SIDE EDGE BANDER (Left)

HOMAG KAL 310 / 8 / A20 / S2

Condition: used, Year of construction: 2005, Single-sided edge bander designed for precise and stable edging of solid wood and panel components (chipboard, MDF, laminate). The machine is conceived as a compact yet fully equipped solution for small- and medium-batch production, with an emphasis on edge processing quality. A robust cast iron frame ensures high rigidity and long-term geometric stability of the machine. It features a classic continuous conveyor with a pressure belt and a complete set of machining units for finishing the edge in a single pass. Technical configuration of the machine: Dujdpfjyfw Syjx Aamjp - Pre-milling unit - Material pre-heating - Automatic EVA glue application - EVA glue roller - Front and rear end trimming saws - Rough trimming unit - Corner rounding unit - Radius scraper - Glue scraper - Grooving unit - Brushing unit - Return conveyor

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, Biesse Rover A 1542 CNC Machining Center Working area X: 4140 mm Working area Y: 1560 mm Working area Z: 245 mm 5-axis electrospindle, HSK-F63 interface Vertical drilling heads: 17 Horizontal drilling heads in X: 6 Horizontal drilling heads in Y: 4 Grooving saw blade 25-position tool changer Worktable with 8 beams Dujdpfeyh Nd Rsx Aamop

Condition: used, Year of construction: 2008, Used machine Year of manufacture: 2008 Condition: well-maintained, serviced regularly (last service by Homag in 11/2024) Features and technical specifications: Minimum workpiece thickness: 12 mm Maximum workpiece thickness: 60 mm Minimum workpiece size (L×W): 240 × 55 mm (with 22 mm thickness) / 100 mm (with 60 mm thickness) Minimum edge thickness: 0.3 mm (roll material) / 0.4 mm (strip material) Maximum edge thickness: 3 mm (roll material) / 20 mm (strip material) Feed speed: infinitely variable, 18–25 m/min (frequency-controlled) Type of glue: EVA hot-melt adhesive Glue application (pot / cartridge / nozzle): melting unit with granulate hopper Glue volume / cartridge size: granulate hopper, melting capacity 18–35 kg/h, level-controlled Heat-up time: approx. 8–10 min Edge magazine (slots): 2 rolls (automatic roll change) Automatic edge change: yes (automatic via PC22, can be switched manually) Pre-milling: 2 × 1.5 kW, 200 Hz, 12,000 rpm, pneumatically adjustable Pressure zone: 1 pre-press roller Ø 150 mm + 6 post-press rollers Ø 70 mm, automatic adjustment End trimming: HL84 trimming unit, 2 × 0.8 kW, pneumatically adjustable (bevel / straight) Flush milling: via pre-milling unit, pneumatically adjustable Radius milling: FK13 contour routing unit, automatic 8-position tool changer (R = 2 mm) Bevel/profile milling: yes, via FK13, pneumatically adjustable Scraper: integrated in multi-finishing unit MN21 Polishing: buffing unit in finishing module FA11 Jointing unit: jointing milling unit KAL310/A20/S2, 2 × 3 kW Workpiece pre-heating: available Release agent spraying device: top / bottom, type 2929 (F.01) Extraction ports: multiple Ø 100 mm (individual extraction per unit) Control: power control PC22 (industrial PC, woodCommander on Win XP embedded) Operating voltage: 400 V, 50 / 60 Hz CE / Standards: CE-compliant according to EU Directive 98/37/EC Dimensions / required space: approx. 8,000 × 1,400 × 1,600 mm Weight: approx. 3,000 kg The return conveyor system visible in the pictures is not included in the scope of supply! Availability: short-term Location: 63934 Röllbach Dusdpfx Aajwx Aaqemjp

Condition: ready for operation (used), machine/vehicle number: 0-200-03-8334, functionality: fully functional, workpiece height (max.): 60 mm, feed rate X-axis: 24 m/min, controller model: Power Control Pc 22, TECHNICAL DETAILS Panel height: 60 mm Solid wood: 20 mm PVC / ABS: 3 mm Dedpfxoydiymo Aamsup Feed speed: 24 m/min MACHINE DETAILS Control system: Power Control PC 22 Supply voltage: 480 V Frequency: 60 Hz Phases: 3~ + N Operating current: 51 A Fusing: 63 A Phase circuit: 3~ Control voltage: 24 V EQUIPMENT Electronically adjustable working height via CNC Powered, rubberized conveyor belt with increased pressure Panel support guide Lateral roller conveyor with idler rollers for panel support Sanding unit Infrared lamps for panel edge preheating Six-position coil holder magazine with automatic edge change via CNC EVA hot-melt gluing unit with premelter and glue pot Edge pressing unit for straight profiles with electronically adjustable pressure rollers via CNC End trimming unit with two motors and automatic tilt adjustment Overlapping cut-off / milling unit with two motors Glue / milling unit with two tiltable motors, electronically adjustable via CNC Multifunctional 4-motor corner rounding unit (smoothing + rounding) with CNC control, automatic adaptation Provision for integrating an additional working station Edge scraping unit Oscillating brush unit

Condition: ready for operation (used), Year of construction: 2006, This HOMAG Brandt Profiline KDF - 780 was manufactured in 2006. It features a swiveling control panel, durable keypad, and a color graphic flat screen. The edgebander handles edge thickness from to mm and workpiece thickness up to 60 mm. Variable feed rate is 20 m/min. Overall length is 7360 mm. Contact us for more information about this machine. • Edge thickness: mm • Roller diameter max.: 3 x 45 mm or 0.8 x 65 mm • Workpiece thickness: 8 - 60 mm • Variable feed rate: 20 m/min • Electrical connection: 400 V - 3 Ph. - 50 Hz • Pneumatic connection: 6 bar • Swiveling control panel at the machine inlet • Durable short-stroke membrane keypad • Color graphic flat screen • Industrial PC with CompactFlash disk for mass storage • Aggregate function keys with LED status indicator Dodsx Enkbepfx Aamoup • Operator guidance via color pictograms • Online language switching between various foreign languages • Overall length: 7360 mm • The control system had a boot and lost your stored data. In 2014, the machine had 1,911 hours. In 2016, the machine had 2,642 machine had an average running time of 300-350 hours per year. This means that the current total number of hours is approximately 5,900 hours.

Condition: used, Power Control Pc 22 Dedpfx Aasgiyn Iemeup Panel height 60 mm Solid wood mm 20 Pvc / Abs mm 3 Feed speed up to mt / min 24 Working height electronically adjustable by C.N. Motorized rubber belt with higher pressure Panel support guide Side roller conveyor with idle wheels for panel support Grinding group Lamps to heat the edge of the panel 6-position reel holder magazine with automatic edge change from C.N. Gluing unit for EVA hot melt glue with pre-melter and glue pot Edge pressure group on straight profiles with electronically adjustable pressure rollers by C.N. End trimming unit with 2 motors with automatic inclination adjustment Overlapping trimming unit with 2 motors Gluing unit with 2 tilting motors electronically adjustable by C.N. Multifunction 4-motor rounding unit (gleaner + rounder) with numerical control adjustment in automatic Free space for the possible insertion of another work group Edge scraper group Oscillating brush group

Condition: good (used), Year of construction: 2018, machine/vehicle number: 1000028154, functionality: fully functional, Equipment: rotational speed infinitely variable, The machine was commissioned in 2019, single owner. It has seen very little use. Description Useful working area, 5-axis configuration: X=3280mm, Y=1600mm Axis travel: X=3706mm, Y=2294mm, Z1=515mm, Z2=371mm Axis traverse speed: X=80m/min, Y=60m/min, Z=30m/min Electrospindle: HSD, 5 axes 11 kW, with continuous 360° rotation on B and C axes, enabling high-precision machining of complex shapes liquid-cooled Drilling head: HSD 20 vertical spindles 4 horizontal spindles grooving discs on X-axis grooving discs on Y-axis Djdjxdl H Uopfx Aamoup Work table: 6 cross beams Isbjwhypnjni Itxtobb 4 suction cups per beam preparation for uniclamp Tool magazines: 16-position revolver-type tool changer Vacuum system: Vacuum pump with a capacity of 250 m³/h, ensuring firm clamping of the parts during processing

Condition: ready for operation (used), Year of construction: 2009, Edgebander manufactured in 2009. This HOMAG PROFI KAR310/11/A20/S2 features a work piece return system BARBARIC. Consider the opportunity to buy this HOMAG PROFI KAR310/11/A20/S2 edgebander. Contact us for further details. • Condition: Used Additional equipment Djdjyhqi Dspfx Aamjup • BARBARIC workpiece return system
