Squaring/Edgebanding Lines

IMA + MEINERT COMBIMA/II/650/A/R3

Condition: excellent (used), Angular sawing plant Numerical Control OSI Plus - Software Optiplanning N. 2 Pre-loading roller tables (mm) approx. 4500 x 2200 each Lifting table (mm) 4500 x 2200 1° Rear-pusher, with No. 5 clamps/grippers Turning device (rotating unit) at 90° 1° Panel saw (longitudinal) max. cutting width (mm) 4500 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 ( Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min Cutter for shredding trimmings 2° Rear-pusher, with No. 10 clamps/grippers 2° Panel Saw - Max cutting width mm 2200 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 (Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min No. 2 Front supporting tables with Air blowing system mm 2200 x 1500 Automatic unloader (bridge) for cut panels "RBO (BIESSE)" Mod. Lifter with 6 stacking stations Pjdpsukhd Aefx Aflsgp

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Pgodoihfiiepfx Afljp Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Rubber-coated vertical rollers as fence and feeders during workpieces process In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Separate electric and command cabinet Total installed power (Kw) 35 WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Condition: excellent (used), Flexible N.C. automatic line for drilling, routing and inserting (hardware). Numerical control with Albatros software. Consisting of: Pgodoidmkrepfx Aflop KZ2046) Infeeder with hedgehog (buffer) store (18 positions) KZ2047) Transfer with motorised conveyoring belt KZ2048) CNC Mod. Vector GLR-X 30-13 KZ2049) Transfer with motorised conveyoring belt KZ2050) CNC Mod. Vektor XK 40-13 KZ2051) Transfer with motorised conveyoring belt KZ2052) CNC Mod. Idrak 3 KZ2053) Transfer with motorised carpet with 90° inclination on a rollers table KZ2054) Rollers conveyor with also motorised belts (to move panels at 180° to the assembly lines)

Condition: excellent (used), Flexible N.C. line for drilling, routing and "hardware" insertion. Numerical Control "TPA" Albatros. Composed by: 1) Hedgehog loader, with 12 positions (for 12 panels), vertical panel introduction. 2) CNC Drilling and routering machine Mod. Over 25.13 with inserter (for bushes, shelf support and base). - N. 1 operating head (estimated KW 5,5) with tool storing revolver (10 positions) - N. 1 boring head with 24 independent spindles (X axis) - N. 1 boring head with 2 independent spindles (Y axis) - N. 1 boring head with 5 independent spindles (Z axis) - N. 1 insertion unit (bushing screwing) - N. 1 insertion unit (shelf support pressure) Psdpfxehvagke Afljgp - N. 1 storage and feeding tank 3) Unloader (90° side-deplacement), with motorized conveyor for vertical outfeed of the panel. 4) Unloader - tilting (0°-90) moves the panel from vertical to horizontal, with motorized conveyor

Condition: used, machine/vehicle number: 007857, Position 1: Horizontal Storage Systems IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 2: Beam panel saws with automatic warehouse IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Pgedpfewuuf Djx Aflop Position 3: Single Edgebanders IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 4: Panel Feeding and Loading IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 5: Panel Stacking and Offloading IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 6: CNC Machine Centres For Routing, Drilling And Edgebanding. IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 7: CNC Machine Centres For Routing, Drilling And Edgebanding. IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 8: Cardboard Cutters IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3 Position 9: Strapping machine IMA + MEINERT-COMBIMA SYSTEM/I/R75/1170/F/R3
