KUKA Central Hand ZH 150/180

KUKA 5 x ZH 150/180 generalüberholt

Condition: excellent (used), Angular sawing plant Dcjdpeukhd Aefx Angjp Numerical Control OSI Plus - Software Optiplanning N. 2 Pre-loading roller tables (mm) approx. 4500 x 2200 each Lifting table (mm) 4500 x 2200 1° Rear-pusher, with No. 5 clamps/grippers Turning device (rotating unit) at 90° 1° Panel saw (longitudinal) max. cutting width (mm) 4500 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 ( Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min Cutter for shredding trimmings 2° Rear-pusher, with No. 10 clamps/grippers 2° Panel Saw - Max cutting width mm 2200 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 (Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min No. 2 Front supporting tables with Air blowing system mm 2200 x 1500 Automatic unloader (bridge) for cut panels "RBO (BIESSE)" Mod. Lifter with 6 stacking stations

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Rubber-coated vertical rollers as fence and feeders during workpieces process Dcjdeihfiijpfx Angep In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Separate electric and command cabinet Total installed power (Kw) 35 WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Condition: excellent (used), Flexible N.C. line for drilling, routing and "hardware" insertion. Numerical Control "TPA" Albatros. Composed by: 1) Hedgehog loader, with 12 positions (for 12 panels), vertical panel introduction. Dcodpfx Anshvagkogsp 2) CNC Drilling and routering machine Mod. Over 25.13 with inserter (for bushes, shelf support and base). - N. 1 operating head (estimated KW 5,5) with tool storing revolver (10 positions) - N. 1 boring head with 24 independent spindles (X axis) - N. 1 boring head with 2 independent spindles (Y axis) - N. 1 boring head with 5 independent spindles (Z axis) - N. 1 insertion unit (bushing screwing) - N. 1 insertion unit (shelf support pressure) - N. 1 storage and feeding tank 3) Unloader (90° side-deplacement), with motorized conveyor for vertical outfeed of the panel. 4) Unloader - tilting (0°-90) moves the panel from vertical to horizontal, with motorized conveyor

Condition: excellent (used), Flexible N.C. automatic line for drilling, routing and inserting (hardware). Numerical control with Albatros software. Consisting of: KZ2046) Infeeder with hedgehog (buffer) store (18 positions) KZ2047) Transfer with motorised conveyoring belt Dcodsidmkrepfx Angep KZ2048) CNC Mod. Vector GLR-X 30-13 KZ2049) Transfer with motorised conveyoring belt KZ2050) CNC Mod. Vektor XK 40-13 KZ2051) Transfer with motorised conveyoring belt KZ2052) CNC Mod. Idrak 3 KZ2053) Transfer with motorised carpet with 90° inclination on a rollers table KZ2054) Rollers conveyor with also motorised belts (to move panels at 180° to the assembly lines)

Condition: used, machine/vehicle number: 005642, Position 1: Panel Feeding and Loading IMA + MEINERT-COMBIMA/II/650/A/R3 Position 2: Double Sided Squaring/Edgebanding Machines IMA + MEINERT-COMBIMA/II/650/A/R3 Position 3: Panel Turning Device IMA + MEINERT-COMBIMA/II/650/A/R3 Position 4: Double Sided Squaring/Edgebanding Machines IMA + MEINERT-COMBIMA/II/650/A/R3 Position 5: Panel Turning Device IMA + MEINERT-COMBIMA/II/650/A/R3 Dcsdowuciwspfx Angsp Position 6: Panel Stacking and Offloading IMA + MEINERT-COMBIMA/II/650/A/R3

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) Dodpezvgn Dofx Angjcp - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Optional: - Machine with workpiece return Quickly found Offer machines Register for newsletter Unsubscribe from newsletter Contact us Overview

Condition: excellent (used), BATCH-SIZE ONE - FULL CNC Flexible LINE for Drilling, Routering and hardware Inserting process, for the Front doors (of furniture). With Numerical Control NST panle PC W2k (FERRO CAN BUS) Dcsdpfx Anjyzyy Togjp Composed by: A) WORKPIECES LOADING SYSTEM (Infeeding Hedgehog Buffer) B) FLEXIBLE DRILLING-INSERTING MACHINE Mod. BAT-RTW-CNC With 4 working stations: - Station No. 1: Workpieces (panels) in-feed and positioning - Station No. 2: Drilling and routering - Station No. 3: Inserting (hinges, adapters and shock absorbers) - Station No. 4: Workpieces (panels) release and out-feed C) WORKPIECES UNLOADING SYSTEM (Outfeeding Hedgehog Buffer) To process panels with following dimensions: - LENGTH: MIN mm (194) 270 - MAX mm 1450 (1500) - WIDTH: MIN mm 130 (120) - MAX mm 700 - THICKNESS: MIN mm 13 - MAX mm 40
