Vertical cnc lathe

INDEX V100

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 Ledpfx Aouhbgwsmveag - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, Year of construction: 2002, turning diameter max. 420 mm turning length 1250 mm control INDEX, C 200-4 D swing diameter 630 mm travel x1 320 mm travel z1 1250 mm travel x2 170 mm travel z2 1250 mm travel x3 320 mm travel z3 1250 mm main spindle speed max. 3000 U/min main spindle drive 53 kW spindle passage 102 mm spindle head DIN 55026 Gr. 11 max. torque on the spindle 675 Nm sub spindle - spindle speed range max. 3000 U/min sub spindle drive 53 kW sub spindle - spindle passage 102 sub spindle - spindle head DIN 55026 Gr. 11 sub spindle - spindle torque 675 Nm travel sub spindle 1250 mm feed power X1 14000/Z1 14000 N rapid traverse X1 20/Z1 40 m/min feed power X2 8600/Z2 14000 N rapid traverse X2 20/Z2 40 m/min feed power X3 14000/Z3 14000 N rapid traverse X3 20/Z3 40 m/min Lsdpfx Amet U R Hzsvjag numbers of turret head positions Rev. 1 = 12 numbers of turret head positions Rev. 2 = 10 numbers of turret head positions Rev. 3 = 12 number of driven tool stations 12 / 10 / 12 speed of driven tools max. 6000 U/min max. torque 36 / 21 / 36 Nm tool taper DIN 69880 tool taper ø 40 x 63 mm total power requirement 120 kW weight of the machine ca. 19 t dimensions of machine L x W x H 5,77 x 2,47 x 2,62 m Accessories: segment bushing chuck HAINBUCH on main spindle, collet chuck HAINBUCH, SPANNTOP SP on sub spindle, various tool holders (also for driven tools), chip conveyor, coolant - all 3 turrets are prepared for coolant through spindle, but the highpressure coolant pump and tank are not with the machine -

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] Lajdpfjuhbgdox Amveg - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] Lajdeuhbfmepfx Amvog - Weight : 4000 [kg] - Installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation - Coolant tank with pump - Chip conveyor

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, input voltage: 400 V, year of last overhaul: 2023, Description – General: Year of manufacture: 2001/2023 Manufacturer: Emag Machine type: VL3 Technical data: Control system: Fanuc 21i-T Swinging diameter: approx. 210 mm Maximum speed: 6,500 rpm Turret: VDI 40 mm, 12 stations The machine does not have a live tool. Hinged belt chip conveyor Spindle mount: GR. 5 Rotating parts conveyor. Machine weight: approx. 5.5 t The following work was carried out during this overhaul in 2023: - The machine was completely disassembled, cleaned, and repainted. - The main spindle was fitted with new bearings. - The guides and guide shoes in the X-axis and Z-axis were replaced. - The ball screw in the X-axis and Z-axis was replaced. - New unit for central lubrication and new hoses. - The hydraulic unit was inspected and serviced. The drive coupling between the motor and pump was replaced. - The cooling unit was inspected and serviced; the temperature difference controller was replaced. - The clamping cylinder was fitted with new bearings and seals. - The gearbox of the A-axis was fitted with new bearings, and the coupling between the motor and gearbox was replaced. - The electrical cabinet was cleaned. - The control panel was replaced. - New screen. - New internal lighting. Lodotpu Szopfx Amvjag - The turret was disassembled, wear parts were inspected, cleaned, and re-sealed. - The turret encoder and encoder wheel were cleaned. - The length measuring systems in the X-axis and Z-axis were disassembled and cleaned. - The springs of the pickup station were replaced. - The motors of the X-axis and Z-axis were checked for bearing damage. - The panes on the work door were replaced. - The chip conveyor was completely disassembled, fitted with new bearings, cleaned, and painted. - Various small parts on the machine were also replaced, of course. The product has been described by us with the utmost care. The description is non-binding and should be verified during an inspection.

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] Lodpfx Ajuhbftsmveag - Weight : 4000 [kg] - Installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation - Coolant tank with pump - Chip conveyor

Condition: refurbished (used), Year of construction: 2012, Offered is a vertical turning center EMAG VSC 250. The machine had a mechanically overhaule in 2022 and will be sold like new. The machine is equipped with automation belt. Other peripherals is not included, and can be offerd if requested by customer. CONTROL Siemens 840Dsl Laodjh Tkdqjpfx Amvsg TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Year of construction: 2004, condition: ready for operation (used), Two identical Index CNC lathes including peripheral equipment and accessories are available. Main spindle: D90/Size 8, max. main spindle bore: 90mm, max. workpiece diameter: 340mm, max. workpiece length: 450mm, max. workpiece weight: 100kg, speed: 4200rpm, power: 35.5kW, torque: 550Nm, front bearing diameter: 140mm, clamping stroke: 32mm, clamping pressure: 80bar, travel X/Z: 1500mm/340mm, rapid traverse: 30m/min, feed force: 8kN, tool stations 1/2: 10/10, mounting plate dimensions X/Y: 300mm/490mm. Including coolant system, tool holders, clamping equipment and angle toolholders. Documentation available. An on-site inspection is possible. Expected to be available from autumn 2026. Individual sale possible. Ledpfxezkld Tj Amveag

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: S4ES_V16, CNC lathe with main spindle and 12-position turret Laedpfjyzn Tnox Amvjg Make: EMCO, Model: EMCOTURN E45 Year of manufacture: 2019, Serial number: S4ES_V16 Control: Siemens, type Sinumerik 828 Maximum turning diameter: 220 mm Chip conveyor: Manufacturer Bürener, type SPE62/12 ----- Attractive offer – flexible & worry-free We offer you not only a high-quality product, but also tailored financing options to suit your needs. Whether down payment, installment payment, or custom financing models – together we will find the right solution. On request, we also take care of the entire transport organization. From planning to reliable delivery, we ensure a smooth and on-time process, so you don't have to worry about a thing. 📞 Feel free to contact us for further information or a non-binding quote. We provide personal and competent advice. Subject to prior sale, modifications, and errors!
