Vertical cnc lathe

INDEX V100

Condition: excellent (used), Year of construction: 2002, Control: Siemens SINUMERIK 840D, C200-4D Ltodpfx Aoxxmy Ssc Hsa Spindle speed: 6000 rpm Travel X/Y/Z: 280/280/145 mm Number of turrets: 1 with 6 positions Number of tool stations: 2x4 Chip conveyor Pallet conveyor belt Pallets

Condition: new, Year of construction: 2023, General Control : Siemens 840 DSL Main spindle Material passage : 65 mm max. speed : 5.000 rpm Spindle passage : 85 mm Spindle head : AD140 Drive power : 27 kW Torque : 145 Nm tool turret Tool holders : ISO-10889 Number of stations : 2 x 12 Number of driven tools : 2 x 12 Max. Speed : 6.000 rpm Ledpfx Acjrxc Eij Hjta Travel Y : ±60 mm B-axis : 360 degrees Workpiece infeed and outfeed Type : Schnaithmann Designed for : 12 pallets Pallet size : 160mm x 200mm Total load of the system max. : 500 kg Equipment Chip management : Chip conveyor Coolant management : Eco-Fluid coolant system : switchable 8/80 bar Coolant tank : 750 l with paper belt filter

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation - Coolant tank with pump - Chip conveyor Ltodpfxeuhbfms Ac Hsa

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Installed power : 2,5 [kW] Ljdpfx Aouhbftsc Hjta EQUIPMENT - CN Siemens 840D - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation - Coolant tank with pump - Chip conveyor

Condition: used, Year of construction: 2014, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm travel -z axis 375 mm c-axis 360 ° control FANUC Ltsdpeqvd Iuefx Ac Hja Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] Ltedpeuhbgdofx Ac Hea - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] Ltedpfx Aeuhbf Tsc Hja EQUIPMENT - CN Siemens 840D - Axis C

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, input voltage: 400 V, year of last overhaul: 2023, ATTENTION: THIS MACHINE AT A ONE-TIME SPECIAL PRICE. General description: Year of construction: 2001/2023 Manufacturer: Emag Machine type: VL3 Technical Data: Control: Fanuc 21i-T Rotation diameter: approx. 210 mm Maximum speed 6,500 1/min Turret: VDI 40 mm, 12 stations The machine does not have a life tool. Hinged belt chip conveyor Spindle holder: GR. 5 Circulating parts conveyor. Machine weight: approx. 5.5 t Lodpstpu Szofx Ac Heta The following work was carried out during this overhaul in 2023: -Machine was completely dismantled, cleaned and repainted, The main spindle was re-supported -The guides and guide shoes were replaced in the X-axis and Z-axis -The ball screw in the X-axis and Z-axis was replaced -New unit for central lubrication and new hoses -Hydraulic unit was checked and serviced. Drive coupling between motor and pump was replaced -Cooling unit was checked and serviced: Temperature difference controller was replaced - Clamping cylinder was re-mounted and sealed. Gearbox of the A-axis was re-mounted and coupling between motor and gearbox was replaced -Electrical cabinet was cleaned -Control panel was replaced -New screen -New interior lighting -Turret was dismantled, wearing parts checked, cleaned and resealed -Cleaned turret encoder and encoder wheel -Length measuring systems in X-axis and Z-axis disassembled and cleaned -Pick-up station springs replaced -X-axis and Z-axis motors were checked for bearing damage -The windows on the work door were replaced. -The chip conveyor was completely dismantled, re-stored, cleaned and painted -Of course, various small parts of the machine were also replaced The product has been described by us with the utmost care. The description is non-binding and should be checked during an inspection.

Condition: refurbished (used), Year of construction: 2012, Offered is a vertical turning and grinding center EMAG VSC 250 DS. The machine will be mechanically overhauled and rebuilt by EMAG. Ltedpfxeh Tkdqs Ac Hsa Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens 840Dsl TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 console with grinding spindle 18 kW, 45000 1/min Delivery time and additional equipment of the machine on request.

Condition: good (used), Year of construction: 2008, feed length X-axis: 575 mm, feed length Y-axis: 90 mm, feed length Z-axis: 300 mm, Order No. 3.2-115 1 used CNC Lathe GILDEMEISTER type CTV 160, built 2008 1 used CNC Lathe GILDEMEISTER type CTV 160, built 2008 Siemens 840D control 3-jaw chuck Chip conveyor Coolant device Siemens 840D control 3-jaw chuck Coolant device Chip conveyor Technische Daten / technical details: Drehdurchmesser / turning diameter 160 mm Lsdpfxeubvv Ts Ac Hota X / x 575 mm Z / z Y/y 300 +-90 mm mm Drehzahlbereich / spindle speed range 6000 UpM / rpm Weight of the machine ca. / weight ca. 6000 kg Technical data, accessories and description of the machine are not binding. Technical data, accessories and description of the machine are not binding.
