VERTICAL CLAMP FOR WINDOWS

ITALPRESSE

Year of construction: 2007, condition: ready for operation (used), A heated plate press Italpresse is available. Press force: 180t, max. hydraulic pressure: 600bar, cylinder stroke: 325mm, opening: 325mm, max. temperature: 300°C. An on-site inspection is possible. Laodpfx Asy Antwsm Nja

Year of construction: 1999, condition: ready for operation (used), A molded part press Italpresse for the woodworking and furniture industry is available. Motor power: 160hp, Press force: approx. 160t, Cylinders: 2, Weight: approx. 17600kg. An on-site inspection is possible. Laedpfx Aoy Ant Dsm Nsa

Condition: used, total length: 1,100 mm, total width: 3,880 mm, total height: 3,170 mm, - Documentation available: No Laedpfjwivp Hox Am Nja - CE marking present: Yes - CE certificate present: No - Transport dimensions: 1100mm x 3880mm x 3170mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Peter Stroomberg

Condition: used, Year of construction: 1991, High frequency press Brand: Italpresse Type: GB/13 Laedpfx Ajwng Tmom Nea Max pressure: 120T Pressing area 2500x1300mm Pressing height 200mm 6 cylinders diameter 90mm Speed 12m/min. Complete line with loading system, gluing machine, destacker and High frequency cabinet (separate for sale) Machine needs some maintenance. Probably the PLC lost his parameters, and some small parts needs to be changed.  - Details: - └ Description: Exclusive High-frequency cabinet - Year: 1991 - Documentation available: No - CE certificate present: No Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), functionality: fully functional, shelf length 3500 mm shelf width 1300 mm 8 hydraulic cylinders Lasdpfxeyxwzcs Am Noa cylinder diameter 85 mm integrated oil heating power supply 380V

Condition: used, Year of construction: 2014, functionality: fully functional, input voltage: 400 V, input frequency: 50 Hz, pressing force: 962 t, stroke length: 200 mm, table width: 1,400 mm, table length: 2,750 mm, working width: 1,400 mm, operating temperature: 135 °C, operating pressure: 290 bar, workpiece height (max.): 200 mm, workpiece weight (max.): 250 kg, cylinder diameter: 270 mm, opening width: 200 mm, plate width: 1,400 mm, pressure: 25 bar, temperature: 150 °C, We are offering this used ITALPRESSE MARK C/ 14-27.5/2 veneer press, year of manufacture 2014. Machine type: MARK/C 14-27.5/2 Serial number: 184450514 Rated voltage: 400 V Frequency: 50 Hz Year of manufacture: 2014 Single-level through-feed press system with top ram Machine is in perfect working condition Meets CE safety standards The machine can also be purchased together with other machines as part of a complete production line. Heating plate dimensions: 1400 x 2750 mm Number of heating plates: 2 units Number of levels: 1 unit Cylinder stroke: 200 mm Daylight opening: 200 mm Feed side: 1400 mm Specific pressure at 100%: 25 Kg/cm² Total pressing force: 9620 kN Cycle time: 2-30 min Operating temperature: 135°C Max. surface operating temperature: 150°C Intended heating medium: thermal oil Number of press cylinders: 6 units Diameter of press cylinders: 270 mm Return cylinders: 4 units Operating pressure: 290 bar Closing speed: 50 mm/sec Laedpfxoyxp Tws Am Nja Opening speed: 50 mm/sec Operating voltage: 400 V Mould data: External mould dimensions: 1340 x 2540 mm Max. mould weight: 250 kg Mould cover dimensions: 1200 x 2400 mm Moulds are not included in this offer but can be supplied at additional cost Powered infeed roller conveyors: Dimensions: 1400 x 3500 mm Feed speed: 8-40 m/min Light barrier control Electropneumatic shaking device for the upper Mylar film Electronic flatness control Automatic switching to pressing speed Compressed air equipment in the lower press table Cylinder support plates are insulated and drilled from solid material for water cooling Feed speed with frequency control Powered outfeed roller conveyors, dimensions: 1400 x 3500 mm Electrical control cabinet / Siemens S7 PLC control panel Dismantling and collection at buyer’s own expense Pick-up location: A-8265 Kroisbach an der Feistritz If you have any questions or require further information, please send us a message or give us a call.

Condition: ready for operation (used), A heated platen forming press Italpresse in bottom piston design is available. Press force: 660t, platen dimensions X/Y: 1900mm/1600mm, heating power: 31kW, connected load: 108kW, rapid stroke cylinder diameter: 70mm, weight: approx. 28000kg. Documentation available. An on-site inspection is possible. Laodpfjyxgrdsx Am Noa

Condition: excellent (used), functionality: fully functional, pneumatic clamps automatic strip feed Ledpfx Aoyxczbjm Noaa aggregate angle adjustment pneumatic spindle movement strip supports oscillating drill movement adjustment feed stroke adjustment 380V power supply

Condition: used, Technical specifications: Max. dimension of glued component: 1600 x 3000 mm 3 vertical presses 2 horizontal presses Hydraulic presses Power supply: 400 V Motor power: 1.5 kW Motor speed: 1450 rpm Lodpfxjyv Atre Am Neaa Overall dimensions: Length: 1200 mm Width: 3500 mm Height: 2500 mm

Condition: good (used), Code: 0328 Lasdpfxsyuyl Is Am Nsa Brand: ITALPRESSE Model: GL / 14,5 - 50 - 420 T - CE Standard Hydraulic press for composite materials and solid surfaces, moulds and decorative panels, suitable for use in the aerospace, aviation, woodworking, furniture, interior design, automotive, shipbuilding, construction, energy, defence, sports and public transport sectors, and various – CE Standard – Year 2005 Technical data: N°5 solid steel plates 1450 x 500 mm N° 3 pistons Diathermic oil heating Total thrust 420 tonnes Working diagram - see enclosed diagram Max power 9,3 Kw Full-load current 19 A The oil tank is located on top of the press and is fitted with a sight glass for checking the oil level Fluid (oil) temperature controller Two-hand control for closing the press Photocell safety barriers Fixed safety guards
