Folding carton gluing machine

Jagenberg Jagenberg Diana 104-1 + Japack 40-2

Condition: good (used), Year of construction: 2007, overall weight: 1,400 kg, volume flow: 522 m³/h, pressure (max.): 12.8 bar, Equipment: refrigerant dryer, PROD. ATLASCOPCO TYPE GA45VSDFF YEAR 2007 CAPACITY (kW) 45 45kw OUTPUT (m3/min) 8.7 CIS (bar) 12.8 INVERTER yes Ppedpfx Aovrg R Ujnpju BUILT-IN DRYER yes EXCHANGER no COOLED (AIR/WATER) air ON TANK no DOCUMENTS no CONNECTION 1 1/2 NEW/USED USED

Year of construction: 2017, condition: excellent (used), HIGHLY AUTOMATED, MODULAR SYSTEM FOR DIGITAL BOOK PRODUCTION ("BOOK ON DEMAND") AND SHORT RUNS – TECNAU LIBRA 800 Intended Use: Suitable for the conversion and processing of short runs and single copies ("books of one") with variable sizes, page counts, and covers. Performance: from print run 1; up to 800 copies per hour Book Format: min. 100 x 125 mm / max. A4 Thickness: min. 2 mm / max. 60 mm Ppsdpfxoylyhdj Anpou Equipment / Further Details: Line Configuration: 1.Roll-to-Stack Feed: Unwinder, merger, Dupla cutter, and book assembly station for the production of book blocks with 2-up printing. 2.Sheet Feeder: A variable number of loose sheets can be added as inserts to the book block. The sheets must have the same size and print run as the book block being processed. 3.Infeed to Binder: Manual feeding station for pre-fabricated book blocks, conveyor with scanning station, book turnover module, and robotic loader at the binder. 4.Variable Binder: For the production of softcover books. The binder is equipped with PUR for the spine and hot-melt glue for the side gluing. 5.Softcover Cover Feeder: Configured with a sheet cover feeder; pre-printed covers are fed, trimmed at the front, side-trimmed, and creased to the exact thickness of the corresponding book block. 6. Cooling tower/cooling screw (product-specific) not included - can be ordered according to customer requirements (product type). The cooling belt can be configured according to the available space and requirements at the machine's installation site. The price of the belt depends on the configuration. We would be happy to advise you on selecting the right belt. 7.Variable Three-Knife Trimmer: Suitable for trimming books with variable dimensions in three axes and different cover types. 8.System Control Software Finishing Line The entire process is controlled via 2D Data Matrix codes. Through the code, the system receives authorization for the following automatic settings and workflow control: • Information on book dimensions and inserts (quantity and sequence) • Binder setup (spine position, thickness, and length) • Cover preparation: Softcover → creasing, cutting, edge trimming • Correct book-to-cover matching • Three-knife trimmer (blade positioning is automatically adjusted to the book dimensions) Very good condition // Dismantling, packaging of the machine and securing (insurance of the machine during transport) will be done by the manufacturer / Tecnau.

Condition: used, Year of construction: 2007, operating hours: 22,824 h, functionality: fully functional, machine/vehicle number: M1142, product width (max.): 635 mm, working width: 330 mm, roll width: 335 mm, type of input current: AC, cutting length (max.): 635 mm, input voltage: 380 V, input frequency: 50 Hz, NILPETER MO3300 Servo, 2007 10 units, 330 mm wide, combined label printing press (offset/flexo/screen/cold foil/lamination) Web unwind unit, web alignment unit, splicing table, web cleaner, corona treater, web feed unit 4 M and 6 MO platforms (1 M, 3 MO, 2 M, 3 MO, 1 M) Offset units (5 21" cassettes / 6 24" cassettes / 6 25" cassettes) 2 rotary screen cassettes 2 flexo cassettes 1 cold foil/lamination cassette GEW UV VCP-XC-38-10 system installed Psdpsyfg Tmefx Anpspu Dampening system Baldwin Stationary lamination unwinder, Gap Master rotary die cutter, Flash removal and winding unit, Product winding.
