Wide-belt sander

Kündig Titan 1100

Condition: excellent (used), Calibration and fine sanding machine with 1 sanding unit 1 motor, processing from above Working width 1000 mm Sanding belt dimensions 2200 x 1030 mm Workpiece dimensions 3 - 170 mm Table height adjustment motor 0.18 kW, 400 V, 50 Hz Main motor 7.5 kW, 400 V, 50 Hz 2 feed speeds 5.5 & 11 m/min 1st unit: Combination unit, sanding drum, rubberized, 90 Sh / pneumatic sanding pad Sanding pad NEW 2nd unit: Cleaning brush Compressed air requirement approx. 6 bar Suction diameter 200 mm Dimensions approx. L x W x H = 1385 x 1980 x 1900 mm Weight approx. 1800 kg Automatic workpiece thickness adjustment with digital display Oscillation of the sanding belt Sanding belt emergency stop with disk brakes Table extension with 3 rollers in the outfeed Emergency stop button Main switch TRANSPORT CARPET LIKE NEW - was replaced by us approx. 3 years ago MORE THAN 30 WIDE BELT SANDERS Note used machines: Bsdpoudxchefx Af Holr - Subject to errors in technical specifications and prior sale. - Prices quoted are ex location - free loading! - The machines have been cleaned and functionally tested. - All machines are purchased as seen without any warranty. The buyer is free to inspect the machines on site. - Special agreements are only possible in written form. (Inquiries will only be answered with your address and telephone number).

Condition: reconditioned (used), Year of construction: 1993, functionality: fully functional, Weight approx. 1140 kg Connected load 380V 7.5kW Scoring unit 0.75 kW manually adjustable via pneumatic connection, can be raised and lowered Trimming length 2800 mm speeds 600/5000/4000/3000 rpm via V-belt Electric tilt with digital display Electric height adjustment with digital display Blodpfx Ajq Au Huef Her Cutting width 1000 mm rear support table 950 x 400 mm wide angle fence 2500 mm with extension 2840 mm with 2 stops suction connection 120 mm + 80 mm for PSV Parallelogram protection device with narrow and wide hood Trimming fence Air requirement for scorer 6bar connection

Year of construction: 1988, condition: used, rolls: 4 speed: 2 - 30 m/min number of speeds: 2 Getriebe, 2 Motor, 2 Zahnrad-wechsel (8) Bodsw Dd Rhspfx Af Helr

Condition: used, Year of construction: 1983, Used machine Year of manufacture: 1983 Condition: fully checked and serviced, incl. new feed belt Features and technical data: - Incl. combination unit with contact roller and sanding shoe - Height-adjustable contact roller for calibration - Air cushion pressure shoe controlled by the workpiece - 4-way adjustable grit compensation - With pneumatic belt tensioning device - Rotating cleaning brush on the machine's outfeed side - Sanding width: 1350 mm - Sanding belt length: 1900 mm - Passage height: 150 mm - Main motor: 15 kW - Steplessly adjustable feed speed 2.5 - 12.5 m/min - Roller table at infeed - Digital display for the motor-driven workpiece thickness adjustment Bljdowka T Sjpfx Af Hsr - Extraction ports: 2 x 200 mm Dimensions: approx. 2300 x 2000 x 2300 mm Weight: approx. 2300 kg Pictures show the machine in unrestored condition! Availability: approx. 4-6 weeks after order placement Location: Röllbach

Condition: used, Wide belt sander Bütfering, year of manufacture 1985, not so good condition, including pneumatic sanding shoe, electric table lift, 1350 mm table width, connected load 40A, approx. 2,200 kg Blsdpfjvrvlhex Af Hor Prices subject to change, errors, printing and typesetting errors reserved
