Double-sided high speed press

KAISER KSTU 1600 – 12,5-3PSR (CE)

Condition: good (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 0540/98, Manufacturing number: 0540/98. Year of manufacture: 1998 ,. Capacity: 400 tons. Stroke length: 300 mm. Stroke: 10-40 / min. Slide adjustment 300 mm. Installation height: 700 mm. The table measures 1600 x 1300 mm Isdpfjicbbzjx Ahusht Net weight: 45 tons. Gable opening: 1600 mm. Exterior dimensions 2 x 3 x 6 meters. Control system MEAB. Coil feeder / straightener iRON RNE 50B / 11. Decoiler iRON SA6000 max 700 mm.

Condition: like new (used), Year of construction: 1991, functionality: fully functional, overall weight: 19,000 kg, pressing force: 160 t, type of input current: three-phase, power: 15 kW (20.39 HP), punching force: 160 t, input voltage: 200 V, Equipment: safety light barrier, Manufacturer: AIDA Type: NC2-160 Push force: 160t Year of manufacture: approx. 1991 Stroke length: 130mm Ihsdpfx Asu D Ad Eehuet Distance above table: (adjustable) 235-335mm Table size: 2030x600mm Bear size: 1500x600mm Electric power: 3x200V(!!), 15kW - Japanese standard Net weight: 19000kg Size: 2140x2210x3175mm Automatic greasing system. Automatic cutting oil dosing - RAZIOL EST-02 Optionally with sheet feeder and straightener.

Condition: used, Year of construction: 1997, pressure 130 t distance between columns 1600 mm stroke 8 - 140 mm Ihedsvuugcepfx Ahuot no. of strokes 50 - 200 Hub/min dayligth (stroke and adjustment up) 520 mm column travel -side 610 mm table surface area 1600 x 880 mm hole in the table 1000 x 350 mm table height over floor 950 mm ram surface 1600 x 880 mm power requirement 24,2 kW weight of the machine ca. 28,00 t required space 4,3 x 2,2 x 3,8 m ram adjustment 100 mm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, hydraulic clutch/brake combination, hydraulic overload protection in ram, pneumatic counterbalance in ram, motoric ram adjustment, automatic stroke adjustment, electronic roll feed (Hensel, EVX 500) with hydraulic intermittent lifting 2025 - in progress: new electrical (safety) control - Siemens S7-1500 F, easy operation via touch-panel Video at seller's site before dismantling available

Condition: used, Year of construction: 1997, Press capacity: 315 ton Ram stroke adjustable: 30 - 100 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 370 mm Table surface area : 1600 x 1100 mm Ihjdpfeuqd Tmex Ahuet Slide area: 1600 x 1100 mm Hole in table: 600 x 180 mm Number of strokes: 15 - 180 s.p.m. Table height over floor: 1200 mm Required power: 170 kW Height over floor approx.: 4900 mm Dimensions L x W x H: 4900 x 1900 x 4900 mm Weight of machine approx.: 55 ton Standard configuration The press was converted to CE standard in press was converted to a SIEMENS S7 control conveyor system still has a SIEMENS S5 control system. Extended machine accessories Die lifters in the table Automation Feeding unit KEMMERICH consisting ofDecoiler levelling machine roll feeder Coil loading car

Condition: used, pressure 160 t distance between columns mm stroke 200 mm table surface area 2040 x 840 mm throat 450 mm no. of strokes 30 - 55 Hub/min dayligth 450 mm ram surface 1700 x 800 mm ram adjustment 100 mm total power requirement 11 kW weight of the machine ca. 21,1 t dimensions of the machine ca. 2,2 x 1,94 x H 3,66 m Isdpfx Ahjtqm Dgeueht - safe for hand inlay work - Conversion to West - Photoelectric barrier

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, table length: 2,000 mm, table width: 1,200 mm, pressing force: 200 t, stroke length: 100 mm, Raster punching machine with Desch compact drive 3-piece tie-rod cast construction Fixed stroke 100 mm Hydraulic overload protection Ihjdpfx Aexcbcvohuot Mechanically overhauled in 2021 Siemens S7 control system Optional with straightening machine and strip feeding line

Condition: used, Year of construction: 1997, Pressure total: 315 ton Ram stroke: 160 mm Slide adjustment: 100 mm Shut height (stroke down, adjustment up): 1.050 mm Free frontal opening L-R: 2.740 mm Free lateral opening F-B: 1.500 mm Distance between oil tray: 2.400 mm Table surface area : 2.740 x 1.800 mm Slide area: 2.400 x 1.700 mm Number of strokes: 10 - 60 s.p.m. Required power: 75,5 kW kW Working hours machine: 77.341 h Height over floor approx.: 5.500 mm Dimensions L x W x H: 5.400 x 3.300 x 5.700 mm Weight of machine approx.: 80 ton Control: Siemens S5 Standard configuration Ihodovmfzhjpfx Ahuet hydraulic tool clamping device Extended machine accessories Tool changing cart

Condition: used, Year of construction: 1994, pressure 250 t distance between columns 1650 / 1400 mm stroke fix 150 mm no. of strokes 30 - 75 Hub/min Ihjdpfx Aovuucwohust dayligth (stroke and adjustment up) 665 mm column travel -side 550 mm table surface area 1600 x 900 mm hole in the table 1000 x 300 mm table height over floor 980 mm ram surface 1400 x 900 mm power requirement 42,0 kW weight of the machine ca. 33,00 t required space 2,8 x 2,5 x 4,4 m permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch/brake combination (Ortlinghaus), hydraulic overload protection in ram, pneumatic counterbalance in ram, FIX stroke, motoric ram adjustment, motoric centralized lubrication Werkzeugwechselsystem elektronischem Walzenvorschub (Normatic, AESL 500-2,8) electronic roll feed (Normatic, AESL 500-2,8) with motor (Indramat), motorised adjustable material guide, motorised height adjustment tool changing system distance table - ram without tool changing system approx. 765 mm can be offered without putting into operation or alternatively with new control Siemens S 7-1500 F

Condition: used, Year of construction: 1986, pressure 160 t stroke 20 - 120 mm no. of strokes 20 - 120 /min distance between columns 1300 mm column travel -side 520 mm dayligth 570 mm table surface area 1250 x 900 mm hole in the table 900 x 250 mm table height over floor 1000 mm ram surface 1100 x 700 mm ram adjustment 100 mm material width 20 - 320 mm Ijdpfx Asvut Rtohueht material thickness 0,3 - 4,0 mm feed length 1,0 - 9999,99 mm power requirement 18,5 kW weight of the machine ca. 25,0 t dimensions of the machine ca. 3,0 x 2,3 x 3,7 mxmxm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch/brake combination, electro-hydraulic overload protection, automatic stroke adjustment, motoric ram adjustment, pneumatic counterbalance in ram, motoric centralized circular lubrication electronic roll feed make Kaiser type KWV 320 Z, yom 2000 with hydraulic intermediate lifting of the rolls

Condition: good (used), Year of construction: 1982, Table width 1.8 m Strokes per min. 30 - 150 Weight 47.000 KG Ihsdpfxsvi Iimo Ahujt
