Storage tanks [6 pcs.]

KASPAR SCHULZ

Condition: used, tank capacity: 5,982 l, GENERAL INFORMATION Features: Disc valve, spray head Design: vertical Itjdpfx Ahsxqdg Hsueb Max. overpressure: 0.9 bar Stand type: Height-adjustable feet Location: external storage Nameplate: Volume: 5,982 litres Product contact material: V2A 1.4301 (AISI304) Condition: used Previous application: beer VESSEL Max. permissible operating temperature: 20 °C EQUIPMENT Manhole / dome: in the cylinder Outlet: present

Condition: excellent (used), Stainless steel tank 6000 l double jacket Volume 6000 l Double jacket Very good condition, directly from production!!! Itjdpok D T Rtsfx Ahusb

Year of construction: 2020, condition: used, tank capacity: 2,700 l, GENERAL INFORMATION Equipment: Disc valve, spray head Design: upright Year of construction: 2020 Notes: Stated total height according to drawing; CE marking and declaration of conformity available only for 2 vessels External diameter: 1,650 mm Internal diameter: 1,450 mm Total height: 2,550 mm Heating/cooling: available Insulation: available Max. allowable operating overpressure: 3.0 bar Max. overpressure: 3.0 bar Base type: height-adjustable feet Location: outdoor storage Technical documentation: drawing, CE marking and declaration of conformity Cylinder temperature control: double jacket Nameplate: Volume: 2,700 litres Double jacket volume: 10.0 litres Product-contact material: V2A 1.4301 (AISI304) Condition: used Cylindrical height: 1,250 mm Previous application: brewery VESSEL Number of feet: 4 pcs HEATING/COOLING JACKET Itodpfjx Dlpcex Ahujb Bottom temperature control: double jacket INSULATION Insulation jacket: hermetically welded Insulation material: stainless steel EQUIPMENT Manhole / dome: in cylinder Outlet: DN32 DIN 11851 MATERIAL SPECIFICATION Temperature control system material: V2A 1.4301 (AISI304) Foot material: stainless steel

Condition: used, Year of construction: 1993, Storage tank with 2 torospherical heads. Fitted with bottom and side-wall cooling jackets. 2 tanks, each 83 hl total volume, with 2 x cooling jackets Additional title: 2 vertical tanks Total volume: 83 hl Ijdpfx Ahexbqh Ejustb Operating pressure: 0,9 bar Operating temperature: 20 °C Width: approx. 1800 mm Height: approx. 4030 mm Material: Stainless steel 1.4301 Position: vertical Base construction: 4 x pipe feet Features: bottom cooling jacket; side-wall cooling jacket; sampling valve; 2 x sight glass; side manway; CIP piping; outlet valve (butterfly valve); Contact thermometer; solenoid valve for glycol piping

Condition: used, Item: AV-11841-Vertical40m3tank Used vertical tanks, capacity 40.000L Exterior dimensions: Dia Ø 3200/3400 mm Total H 9600 mm incl. gear. Cylinder height: 7200 mm. Vertical stainless steel tanks - 3 pcs. Insulated with 100 mm rockwool completed with flat plate. Conical bottom 35 degrees with 4" outlet. Itjdpoi E Abijfx Ahusb Klöffer top with manhole. Powerful top mounted agitator. 37 kw agitator. AISI 316.

Condition: used, Year of construction: 2002, CIP tanks for water, caustic, acid and disinfectant. Additional title: 4 vertical vessels Ijdpfxjxbpibe Ahujtb Volume: 1270 l Caustic tank, acid tank, disinfectant tank Material: Stainless steel Features: Water tank, 870 l; Caustic tank, 1270 l; Acid tank, 1270 l; Disinfectant, 1270 l

Condition: used, Fermentation cellar with tanks, equipped with 2 dished heads. - 2 tanks with 83 hl gross content each, with 2 x cooling zones - 4 tanks with 52 hl gross content each - 2 tanks with 79 hl gross capacity each. Itodpfx Ajxbn Rkohueb Additional title: Years of manufacture 1991 - 1993 Features: 2 Tanks, each 79 hl; 4Tanks, each 52 hl; 2 Tanks, each 83 hl

Condition: used, functionality: fully functional, usable tank capacity: 15,000 l, Item: AV-12052-AV12053-Vertical-Tank-15000L Exterior dimensions: Dia Ø 2300 mm Total H 5500 mm. Itodpfx Ahjq A R S Douob Vertical stainless steel tanks - one piece to offer Conical bottom 35 degrees with 4" outlet. Conical top 15 degrees with manhole. AISI 304.

Year of construction: 2001, condition: used, Stainless steel pressure tank for approx. 10 hl net capacity; cooled by means of double jacket on the frame and firmly welded insulated. Individual sale conceivable. Additional title: year of construction 2000/2001 Gross content: 1122 l Perm. working overpressure: 3 bar Perm. working temperature: 20 °C Content cooling zone: 5 l Length: 1000 mm Width: 1000 mm Height: 1700 mm Material: stainless steel Features: Manhole in the frame, spraying head with spraying head line and shut-off flap DN 25, safety valve and manometer, outlet flap, thermometer Height-adjustable tube feet Ijdpsw Td Epjfx Ahustb

Condition: used, Cold area with an annual capacity of 1,000 to 3,000 hl, consisting of 1 fermentation vat: Kaspar Schulz, 13.43 hl, year of construction: 2000 2 fermentation tanks: 1 x Kaspar Schulz, 24.22 hl, year of construction: 2000 1 x Kaspar Schulz, 42.19 hl, year of construction: 2000 4 storage tanks: 4 x Kaspar Schulz, 21.5 hl, year of construction: 2000 6 bright beer tanks: 6 x Kaspar Schulz, 11.22 hl, 3 bar, year of construction: 2000/2001 2 centrifugal pumps: 1 x Hilge, mobile, 15 m3/h, 2.7 bar, year of construction: 2000 1 x Hilge, mobile, 15 m3/h, 2.5 bar, year of construction: 2013 1 desi tank, 1 x cylindrical stainless steel tank on feet with side outlet, year of construction: 2000 with pipework and switch cabinet for automatic cooling system. Ijdpow Td Dlsfx Ahuetb Additional title: with centrifugal pumps and disinfection tub Features: Fermentation vat, 2 x fermentation tank, 4 x storage tank, 6 x pressure tank, 2 x centrifugal pump, 1 x desi tank, pipework and control cabinet for refrigeration control

Condition: excellent (used), functionality: fully functional, Item: AV-12421-Vertical-12000L Itsdpornuhpefx Ahuob Jacketed Insulated Vertical Tanks Dimensions: Dia Ø 2600 mm Total H 4400 mm. Stainless steel tank - 4 pcs. identical Manhole at top, conical top with ventilation and conical bottom 15 degrees with 2" outlet. Scrape agitator with gear AISI 304

Year of construction: 1990, condition: ready for operation (used), System includes (1) Pan, year of construction: 1990 (2) Lauter tun, year of construction 1970 (3) Whirlpool, year of construction: 80s, controls: WAGO, with hop dosing system, plate cooler and various pumps. Isdohv H E Aepfx Ahuetb
