Universal Moving Column Milling Machine

KEKEISEN UBF-R 2000/13

Condition: used, Year of construction: 2006, travel distance X-axis: 980 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, table width: 1,250 mm, table length: 750 mm, rotary table diameter: 700 mm, DMG DECKEL MAHO DMU80 monoBLOCK HEIDENHAIN iTNC530 Rotary T: dia700mm T:1,250x750mm 18,000rpm HSK-A63 ATC32 Touch probe TS640 Blum Laser Chip Conveyor Dcedpsvxngdsfx Af Hor

Condition: like new (used), Year of construction: 2010, Machine Type: CNC Cylindrical Grinding Machine Manufacturer: Fritz Studer AG Model: S22 Year of Manufacture: 2010 Control System: FANUC 31i-A CNC Machine Base: Granitan® S103 mineral casting Configuration: Fixed straight wheelhead for external (OD) grinding Dodpfxjwl Uvko Af Hocr Automation: Automatic loading system with FANUC robot integration Distance Between Centers: 650 mm (25.6”) Center Height: 175 mm (6.9”) Max. Workpiece Weight: 150 kg (330 lbs) Max. Workpiece Length: 700 mm Max. Workpiece Diameter: 449 mm Grinding Wheel Diameter: 610 mm Grinding Wheel Width: 160 mm Grinding Wheel Speed: Up to 3,200 rpm Spindle Power: 15 kW (20.5 hp) Wheelhead Type: Fixed straight X-Axis Travel: 310 mm Z-Axis Travel: 850 mm X-Axis Max. Speed: 15,000 mm/min Z-Axis Max. Speed: 30,000 mm/min C-Axis: Full rotation capability for workhead Programming Interface: StuderWIN with FANUC 31i-A Additional Software: StuderGRIND Automation Interfaces: Standard interfaces for loaders and peripherals Other Equipment: Rotary dresser, Heidenhain scales, various clamping fixtures

Condition: used, Year of construction: 2002, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m Photos of identical machine with centre height 225mm Base: Kellenberger Kel-Varia UR175-1000 Kelco 120 Grinding head UR with T1-T2-T3 Basic equipment: -T1 500mm grinding disc diameter -T2 400mm grinding wheel diameter -Infinitely variable, high-resolution axis -Marposs measuring device for tool measurement Dcjdpfx Aeuxfucef Hor -Active longitudinal positioning -GAP on T1 and T2 from ELASO contactless integrated in the control interface Semi-automatic balancing from ELASO integrated into the control interface -Tailstock with manual retraction -MK5 workpiece headstock with short taper DIN 55026 Belt-driven internal grinding device Options at an extra charge: - New high-precision workhead with torque drive - Internal grinding device for high-frequency spindles diameter 120mm -HF internal grinding spindle Fischer MFM-1224/42/31 D-21 -HF spindle with HSK holder 24,000 rpm with integrated GAP sensor. (delivery time) -CNC-controlled C-axis non-circular grinding -hydrostatic threaded spindle in x -new hydrostatic unit with only 1 pump and pressure accumulator thus better energy efficiency. -monitoring of the water content in the hydrostatic system -Suction system Further options available on request Mechanical overhaul: -Complete machine overhauled according to Kellenberger measurement protocol -New service-friendly cab -repainting Electrical overhaul: -New modern CNC CIRCULAR GRINDING MACHINE control with BEMA rough grinding surface -New control cabinet -New drive technology -Replacement of all electrical cables Berus pressure switches etc. -New absolute glass scales in x and z -New absolute rotary encoder (for B-axis) Control system: The grinding software consists of a basic licence and various options that are possible depending depending on the equipment of the machine. Basic software - External and internal pendulum grinding - External and internal plunge-cut grinding - External and internal pendulum grinding - External and internal plunge-cut grinding - External and internal taper pendulum grinding - External and internal radius grinding, radius dressed on disc - Semi-automatic pendulum grinding - Workpiece zeroing - Grinding wheel zeroing - Measuring the dressing diamonds - 2 moulding diamonds - 1 shaped diamond or dressing roll (dressing roll required) - Moulding roller (dressing roller required) - 3 Flat dresser - Corrections - Z-position measurement (probe required) - GAP probing (grinding device required) OPTIONS at an extra charge: Software profile plunge-cut grinding: - External and internal profile plunge-cut grinding with profile disc Profile grinding software: - External and internal profile grinding with straight disc Software thread grinding: - Single and multi-start external and internal thread grinding with thread on the disc disc Dressing. Dressing of single and multi-groove discs. Flank angle freely selectable. Trapezoidal thread grinding software: - Additional dressing of trapezoidal threads possible External and internal non-circular plunge-cut grinding: - External and internal non-circular plunge-cut grinding Non-circular grinding software: A prerequisite for non-circular grinding is that the workpiece axis is equipped with a high-resolution rotary encoder so th...

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Spindle power : 15 [kW] - Spindle speeds : 5500 [rpm] - Max. bar diameter : 42 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE Djdpfx Aeuhampsf Hjcr - Spindle power : 15 [kW] - Spindle speeds : 5500 [rpm] - Max. bar diameter : 42 [mm] - C axis indexing precision : 0.001 [°] - Travel : 330 [mm] TURNING-MILLING SPINDLE - X/Z stroke : 410/400 [mm] - Y stroke : 200 [mm] - B Axis stroke : -25/+115 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK40 - Spindle speeds : 30000 [rpm] - Spindle power : 8 [kW] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 60 - Tool exchange time : 1.2 [sec] - Number of positions : 60 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 3300 x 2900 [mm] - Machine height : 2100 [mm] - Machine weight : 5000 [kg] MACHINE HOURS - Number of working hours : 11659 [h] EQUIPMENT - CNC : Fanuc 31i model A5 - Linear scales - Coolant tank * with high-pressure pump : 70 [bars] * Coolant through spindle - Oil mist extractor : ELBARON RON/A 100 DV - Spindle cooling unit - Workpiece probe : Renishaw OMP40-2 - Parts catcher - 1 NAKANISHI HTS1501S spindle : 150.000 [rpm] - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Bar puller

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Kellenberger Kel-Varia Baureihe mit Kelco 90 Steuerung. Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung -Neu aufgebauter Schaltschrank -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse) Standardausstattung: Dcjdpfx Aouwv H Tjf Hjr -WSS mit Konus MK5, optional mit Adapter MK5/Kurzkegel -RST mit MK4 Konus. Optional mit Feinverstellung -Schleifspindelstock T1/T2/T3 -T1 Schleifscheibendurchmesser 400mm -T2 Schleifscheibendurchmesser 300mm -T3 Innenschleifeinrichtung riemengetrieben. -Schleifspindelmotor 4,4kW -B-Achse hochauflösend -Marposs Messsystem zur Schleifscheibenvermessung. -Längspositionierung Marposs -GAP Control (Sensor am Schleifspindelstock) Optionen gegen Aufpreis: -HF Innenschleifspindel -Hochgenauer, höchst kippsteifer Werkstückspindelstock -Messteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, Year of construction: 2005, grinding diameter 500 mm grinding length 1500 mm centre height 250 mm Control GRINDplusIT Maschine wird teilüberholt mit Messprotokoll und Gewährleistung innerhalb Deutschlands und Anrainerstaaten geliefert. 1 UR-RS 175 / 1500 standard version (T1, T2, T5, T7) 1 grinding wheel set T1 400x63x127mm 1 grinding wheel set T2 400x63x127mm 1 grinding wheel set T5 400x63x127mm 1 internal grinding device T7 0120 mm for HF spindles 1 centre height 250 mm 2 grinding head motor: drive power 10.0 kW 1 CNC control Heidenhain GRINDplusIT Djdpswulrhsfx Af Hscr 1 Kel-ASSIST 100 PLUS (includes Kel-Assist 100 and thread calculation) 1 KEL-POLY, out-of-round grinding 1 KEL-NET for CNC control GRINDplusIT 1 B-AXIS GRINDplusIT: ‘CNC-controlled B-axis’ (standard) 1 GRINDplusIT: v constant 35m/s or 45m/s_adjustment of grinding spindle via control 1 T1, T2, T5, T7: T1 and T2: v=constant, T5: v=variable (Danfoss), T7: HF spindle 1 operating unit for 1x MFM or MFV spindles, VACON 22kW 1 x HF internal grinding spindle Fischer MFM 1224/42/31 re. HJND 21 1 x HF internal grinding spindle MFV 1260/4 re 1 x HF internal grinding spindle IBAG HF 33 S 60 P 1 tailstock with manual retraction 1 MICRO-ADJUSTMENT: tailstock lower section with micro-adjustment 1 spring-loaded quill insert 1 pneumatic relief for the tailstock 1 upper table flooding (standard) 1 reinforced workpiece spindle MK 5 DIN 55026 size 5’ 1 C-AXIS: CNC-controlled C-axis to workpiece spindle box reinforced 1 lower part FIXED for the workpiece spindle box reinforced 1 KELPOS: Active longitudinal positioning MOVOMATIC, mounted on the grinding head 1 diameter measuring head Movomatic; DU200 1 measuring control unit Movomatic ES124 / digital 1 KELSET: KELSET tool measurement system, MARPOSS 1 Basic module for KEL-TOUCH cut-off sensor and KEL-BALANCE balancing device 1 KEL-TOUCH, cut-off sensor for diagonal/tandem 1 Full emulsion enclosure 1 Coolant cleaning gun connected to the table 1 Emulsion grinding mist extraction system 1 lubricant for initial filling HF dressing device type IBAG on OT Data from state of delivery without guarantee

Condition: ready for operation (used), total height: 3,900 mm, total width: 2,900 mm, total length: 8,000 mm, controller manufacturer: Heidenhain, empty load weight: 13,000 kg, Type: TMML6-centrum Maximale afstand van kolom tot midden van spindel: 1210 mm (diepte van de kiel) Gereedschapswisselaar met 30 posities Spaantransportband Kan achteraf worden uitgerust met nieuwe Heidenhain-besturing Originele tafel kan opnieuw worden gebruikt of een T-gleuf vloerplaat om hogere werkstukken te kunnen bewerken Longitudinal travel X-axe: 3023 mm Crosstravel Y -axe: 800 mm Travel Z-axe (Height): 1528 mm Dimensions clamping space - table: 4200 x 1000 mm Max Height of workpiece: 2000 mm Dsdpfx Afev St Efs Hjcr Power on spindle: 20 kW Admission in millingheadspindle (ISO): ISO 50 Max speedrange: 50 > 1980 rpm

Condition: used, CNC cylindrical grinding machine STUDER S31 CNC LeanPro with "Pictogramming" Distance between centers: 1000mm Center heigh 175mm Grinding Wheel head rotation (B) 360° (1°) 2 ext Grinding Wheels 1 int Grinding Wheel Ext Grinding wheel 400 mm x 40 mm x 127 mm overhauled spindle > see photos Dcsdpfswim U Hox Af Hor Workhead CM 4 0-1000 RPM CNC Fanuc Programming: Pictogramming Heidenhain linear encoders This machine can be inspected under power in our warehouse in Gussago BS Italy

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT50 - Spindle power : 40 [kW] - Spindle speeds : 12000 [rpm] - Gearbox - Speed ranges : 2 LINEAR AXES - Travels on X/Y/Z axes : 2400/1650/1750 [mm] - Rapid traverses rates (X/Y/Z) : 42 [m/min] - Cutting feed rates (X/Y/Z) : 20 [m/min] B ROTARY AXIS - Travel : 360 [°] - Indexing precision : 0.001 [°] TOOL CHANGER Dodpfx Asw Ephbsf Hecr - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 116 - Tool exchange time : 3.8 [sec] PALLET CHANGER - Pallet changing device type : Rotopalette - Pallet size : 1600 x 1250 [mm] - Pallets number : 2 - Maximum weight upon pallet : 5000 [kg] - Distance table center / spindle nose (min./max.) : 100 - 1750 [mm] - Maximum workpiece diameter : 2500 [mm] - Maximum workpiece height : 1850 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 86 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 9.485 x 6.155 [mm] - Machine height : 4.370 [mm] - Machine weight : 50000 [kg] MACHINE HOURS - Number of working hours : 15446 [h] EQUIPMENT - CNC : Fanuc 31i-model B5 Interface : Ethernet / RS232 / USB / PCMCIA - SOFT SCALE II - Electronic handwheel - Rigid tapping - 3 colors status lamp - Coolant tank * with high-pressure pump : 70 [bars] * Coolant through spindle * with paper filtering unit * with cooling unit for coolant * With washing gun * With cabin washing - Chips conveyor - Spindle cooling unit - Tool probe - Workpiece probe : Renishaw RMP60 - Tool breakage detection : SOFT AC - Pallets number : 2 - Milling vice - Tool-holders

Condition: excellent (used), Year of construction: 2000, The machine can be inspected and tested in our warehouse after prior appointment. Dcedpfswl Uq Iox Af Hsr
