Worm Grinding Machine

Klingelnberg HNC 35

Year of construction: 1990, condition: ready for operation (used), Max. workpiece diameter: 10-350mm, max. grinding length/ width: 690/ 60mm, clamping length: 950-1330mm, swing angle: -60 to 60°, length: 6200mm, width: 4000mm, height: 2500mm, weight: 9t, with oil filtration system, oil mist extraction and additional accessories. Hodsiph T Hopfx Aa Ujnk

Condition: used, Year of construction: 2005, Reishauer RZ150 gear grinding machine Hjdpfx Aasxz E Sro Usnk

Condition: good (used), Year of construction: 2014, spindle turning speed range 170 - 18000 U/min weight of the machine ca. 7,5 t dimensions of the machine ca. 5,00 x 4,00 x 2,20 m --> Control conversion (2014) to Siemens Sinumerik 840D Solutionline --> Overhaul of the new control system in 2016 --> Technical data Grinding diameter: 20 - 300 mm --> Oscillation diameter: 350 (500) mm --> Workpiece length: 300 (1300) mm --> Recommended grinding depth up to: 300 mm --> Grinding table stroke Z-axis (total): 650 (950) mm --> Resolution: 0.001 mm --> Rapid traverse: 12 m/min-1 --> Grinding stroke speed: 0 - 9.99 m/min-1 Hnedpfxsw Intae Aa Ujk --> Feed rate: 0 - 99.99 m/min-1 --> Step feed value during reversal: 0 - 0.999 mm --> Grinding table stroke X-axis (total): 150 mm --> Resolution: 0.001 mm / Ø --> Rapid traverse: 5 m/min-1/R --> Grinding stroke speed: 0 - 5 m/min-1/R --> Feed rate: 0 - 99.99 m/min-1/R --> Step feed value during reversal: 0 - 0.999 mm / Ø --> Swivel capability of the workpiece headstock: --> B-axis: -32° (-23°) / +2° --> Resolution: 0.0001° (0.36") --> U-axis stroke (total): 300 mm --> Resolution: 0.001 mm / Ø --> Travel speed: 5 m/min-1 --> Centre height above workpiece table: 200 (300) mm --> Centre height above grinding table: 330 (430) mm --> Workpiece spindle passage: 50 (70) mm --> new in 1988

Condition: as good as new (ex-display), Year of construction: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment – air cushion: 280 mm Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Hnedpetqf Rzofx Aa Usk Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Turret head B-axis with 1° division Belt filter system included Hnjdpfevt A Rtex Aa Uok

Condition: used, TECHNICAL DETAILS - max. grinding length: 500 [mm] - max. grinding diameter: 3000 [mm] EQUIPMENT - 1 grinding spindle 12000 [t/mm] Hnjdou Hac Rjpfx Aa Uok - retractable wheel dressing device - coolant tank with pump and paper filtration

Condition: good (used), Year of construction: 2007, Height of points 150 mm Distance between points 1000 mm Grinding wheel dimensions (h x id x w) Ø400xØ127x50mm Internal head 4 pcs Center height 150mm Max. workpiece weight 80Kg Hsdpferakimex Aa Uonk X-axis travel (transverse) 350mm X axis speed 10 meters per minute Z axis travel (longitudinal) 1000mm Z-axis speed 12 meters per minute Z-axis resolution 0.00004" B-axis turning range 210° B-axis resolution 0.00004 B-axis resolution 0.0001° B-axis resolution 0.0001 Drive capacity 10 HP Grinding wheel diameter 400mm Max. width Grinding wheel width 63mm Spindle Speed Range 0-1000 RPM Spindle turning range 0° - 90° Tailstock stroke 30mm Tailstock stroke 30mm Equipped with Fanuc 21i-TB CNC Control Dimensions 3350x 2130x 2130 Weight 4535Kg Accessories: Steady rests, magnetic chuck, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.

Condition: excellent (used), Year of construction: 2006, operating hours: 53,000 h, functionality: fully functional, Full-option CNC gear grinding machine in outstanding condition, previously used in special-purpose machinery manufacturing. The machine produces up to 200 different gear types/products for special orders in batch sizes from 1 to 10,000. Manufacturer: Reishauer Model: RZ 150 Type: CNC Gear Grinding Machine Year of manufacture: 2006 Serial number: 7XXXX Machine specifications: - 2 identical workpiece spindles - Workpiece spindles with tailstocks - Turret design - Enclosed machining area - External loading and unloading station - Especially designed for run-in gearings Equipment: - Grinding worm profiling device Reishauer RP 120 - Hoffmann belt suction filter system HSF 150 - OLAER cooling unit CD35.02-NE - OLAER designation PC31.02NE-S - ELBARON extraction/filter unit RON/A2000V-2V-RH - 5-axis robotic automation (optional) Operating data: - Total operating hours: approx. 70,569.5 h - Run-time / part counter workpiece spindle / workstation 1: counter reading 01794635 - Run-time / part counter workpiece spindle / workstation 2: counter reading 002929 Hoffmann belt suction filter system HSF 150 - Connection: 400 V / 50 Hz - Phases: 3 / PE - Operating voltage: 400 V - Connected load: 31.4 kW - Nominal current: 56.9 A - Control voltage: 24 V DC - PLC voltage: 24 V DC - Valve voltage: 24 V DC - Lamp voltage: 24 V DC OLAER cooling unit CD35.02-NE / PC31.02NE-S - Year of manufacture: 2005 - Refrigerant: R134a - Fill quantity: 2.1 kg - Max. permissible operating overpressure HD: 21.7 bar - Max. permissible operating overpressure ND: 10.6 bar - Voltage: 400 V / 3 Ph / 50–60 Hz alternative: 480 V / 3 Ph / 60 Hz - Max. current: 5 A - Power: 2.5 kW ELBARON RON/A2000V-2V-RH - Year of manufacture: 07/2005 - Weight: 74 kg - Connection: 3 x 400 V AC / 50 Hz alternative: 1 x 230 V / 60 Hz - Power: 3.56 kW - Current: 7.0 A - Protection class: IP54 - High voltage max.: 9.9 kV DC - Current max.: 24.8 mA Condition: - Machine under power - Operated in single-shift to two-shift operation - Preventatively maintained - Very well-kept condition - Comprehensive documentation available Hodpfx Aasyxrygo Ujnk Scope of delivery: - Without tools - Without production fixtures - Without grinding wheels - 5-axis robotic automation optional - Comprehensive documentation available Availability: - Inspection by appointment - Available from 06/2026 Sales information: - Sale as seen and inspected - Warranty excluded

Condition: used, Year of construction: 2008, max. wheel diameter 700 mm max. module 10 (18) min. module 1 table diameter 530 mm Table speed max. 350 1/min Distance of shafts 50 - 680 0 workpiece weight 4.000 kg Hodpfx Aajyv Ipfs Uonk Axial travel 1.000 mm tangential adjustment 300 mm pivoting angle + / - 45 Grad power capacity 32 kW spindle turning speed range 3.500 - 12.000 U/min tool diameter 320 mm total power requirement 80 kW weight of the machine ca. 25,00 t

Condition: used, Year of construction: 2012, max. wheel diameter 300 mm gear width 320 mm max. module 10 min. module 0,5 ical angle 45 ° frequency 50 Hz voltage 400 V main fuse 125 A x-axis 270 mm y-axis 250 mm z-axis 320 mm A - axis +/- 45 ° B - axis 360 ° C-axis 360 ° total power requirement 89 kW weight of the machine ca. 23,5 t dimensions of the machine ca. 11,2 x 5,5 x 2,9 m automated Oil slinger station EWAB workpiece storage Hoffmann coolant filter system HSF 100 SE/K Minimax fire extinguishing system W+W air filter system Hodpfsx R U Hasx Aa Uenk Promot Automation "Cellmaster" (3 cells) year 2019
