Horizontal machining center

KONDIA A-6

Condition: repair required (used), Year of construction: 2008, functionality: not functional, machine/vehicle number: B-7969, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / T-slot width: 18 mm # Axis description: 3 LINEAR AXES (X, Y, Z) / 4th Axis # Rapid traverse: X, Y, Z - 30 m/min # Travels: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock capabilities: # Max. distance from spindle to table: 650 mm # Spindle nose: ISO7388 (with internal coolant supply), Tool holder size: 40 # Spindle speed range (standard): 100–14,000 rpm, Max. torque / at 330 rpm: 63.7/89.4 Nm Automatic tool changer: # Number of tools: 20, Selection system: sequential/random, Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, Max. tool length: 300 mm, Max. tool weight: 6.5 kg # Tool change time: 3 s Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Floor space required: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Electrical cooling cabinet # Spindle cooling system # Documentation: Electronic available / printed manual not available Lrsdpexxvtuofx Agmow Machine status: NOT WORKING # 4th axis broken – repairable – dismantled from machine # Tool changer broken – repairable – dismantled from machine # Hydraulic pump broken – requires complete replacement

Condition: used, Year of construction: 2007, x-travel 600 mm y-travel 400 mm z-travel 510 mm table-size 800 x 400 mm Control HEIDENHAIN iTNC 530 spindle turning speed - stepless 12.000 U/min feed speeds - directly programable 30.000 mm/min tool taper ISO40 tool magazin: 20 total power requirement 25 kW weight of the machine ca. 4,2 t dimensions of the machine ca. LTH 3,5 x 2,1 x 2,95 m Control unit operating time: 32,790 hours. Spindle operating time: 10,310 hours. Includes Heidenhain electric handwheel. Ljdpfx Ajxu Nxcjgmorw Includes electric touch probe. Includes internal coolant supply. Includes chip conveyor. Includes Gressel Gripos machine vise. Includes USB port.

Condition: used, Year of construction: 2009, functionality: limited functionality, machine/vehicle number: B-8023, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th Axis # Rapid traverse speed: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock features: # Spindle distance: 200 mm # Maximum distance from spindle to table: 650 mm # Spindle nose: ISO7388 (with internal cooling), Tool Holder (Size 40) # Speed range (standard): 100/8,000 rpm, Max torque: 85 Nm at 330 rpm, 7.5 kW Automatic tool changer: # Number of tools: 20, Selection system: Sequential/random, Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. Tool change time (fastest): 3 s. Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Ljdexxi Skopfx Agmorw Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # 4th axis: Nikken CNC180 FA (2012) # Broken tool detection system: Blum Novotechnik # Chip extractor # Lubrication system # Electrical panel cooling system # Spindle cooling system: HARBOR Model HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine condition: OPERATIONAL — with 1 spindle / 2nd spindle defective — can be repaired.

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: B-8024, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rates: X, Y, Z – 30 m/min # Travel paths: Longitudinal (X-axis) 600 mm, Transverse (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock: # Spindle distance: 200 mm # Max. distance from spindle center to table: 650 mm # Spindle interface: ISO 7388 (with internal coolant), Tool holder size: 40 # Speed range (standard): 100 – 8000 rpm, Maximum torque at 330 rpm: 85 Nm, 7.5 kW Automatic tool changer: Lrodpfx Agjxxi Ewomew # Number of tools: 20, Selection system: sequential/random, Max. tool diameter (adjacent): 85 mm, Max. tool diameter (non-adjacent): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 3 seconds Electrical connection: # Voltage: 3x400V / 50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4200 kg Equipment included: # CNC control – GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Cooling system # Electrical cabinet # Spindle chiller: HARBOR Model: HBO-750PTSB2 # Documentation: Digital and hard copy available Machine condition: NOT OPERATIONAL # Y axis motor defective – requires replacement (not repairable) # 2 tool changer units defective – require replacement (not repairable) # Spindles defective – require replacement (not repairable) # Hydraulic unit defective – needs replacement or repair

Condition: repair required (used), Year of construction: 2010, functionality: not functional, machine/vehicle number: B-8029, Technical Characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Table surface to floor height: 850 mm (maximum load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / T-slot width: 18 mm # Axis description: 3 linear axes (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rate: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock Capabilities: # Spindle distance: 200 mm # Max. distance from spindle to table: 650 mm # Spindle nose: ISO7388 (with through-spindle coolant), Tool holder: Size 40 # Speed range (standard): 100–8000 rpm, Maximum torque / at 330 rpm: 85 Nm, 7.5 kW Automatic Tool Changer: Lsdpfxexxiy Ij Agmjrw # Number of tools: 20, Selection system: Sequential / random, # Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, # Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. # Tool change time: 3 s. Electrical connection: # Supply voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # Chip extractor # Lubrication system # Cooling system # Electrical panel # Spindle cooling system: HARBOR Model: HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine Condition: NOT WORKING # Tool changer: 1 unit broken – needs replacement (not repairable) # Spindles: broken – need replacement (not repairable) # Hydraulic unit: broken – needs replacement or repair
