Injection molding machine

KraussMaffei KM 80 C1

Condition: used, Year of construction: 1989, operating hours: 74,900 h, clamping force: 850 kN, screw diameter: 40 mm, overall weight: 3,700 kg, Machine no. 145464 Year of construction 1989 Machine weight 3700 kg (without oil filling) Clamping force 850kN Heating 8,31KW Motor 18,5KW Total power 27,2KW Bodpfxjr Hrqrj Afcocw Machine cycles 7,112,306 Operating hours 74,900h Interfaces: Master computer, handling, blow-out, selector switch, core pull 1 hydraulic, mold temperature control 3 pcs. The following accessories etc. are included with the machine: Complete 50 injection unit thermoplastic , Selecting diverter , Hydraulic infeed conveyor (height adjustable 3 levels) (integrated in control) , Diskette drive external (Arburg original) , Documentation and work reports from the machine by Arburg Service , Machine setting course CMD documents (folder) , E-plan , Documents also in digital form , Oil filling (must be pumped into a container before transport (pump is available)) , Electronic water battery

Condition: like new (used), Year of construction: 2006, operating hours: 33,107 h, functionality: fully functional, Top machine from cleanroom production (pharmaceutical sector) - Equipped with 820 mm rotary table - Including GEKU Robot SR 500 ST (x=600, y=1400, z=2500 mm) - Only 33,107 operating hours - Safety enclosure / protective cage - Horizontal conveyor belt - Hardly any paint damage / almost as new in appearance - Fully operational The machine can be inspected under power by prior arrangement. Technical Specifications Manufacturer: Engel Model: V 330H/80V/130 Combi 2-Color with rotary table Serial number: 162036 Year of manufacture: 2006 Operating hours: 33,107 h Dimensions L/W/H: see drawing Weight: 10,600 kg Functionality: fully operational Condition: excellent Special features Control system: CC 200 Screw diameter: 25 / 22 mm Shot weight: 72 / 35 g Injection pressure: 2391 / 2066 bar Injection volume: 79 / 38 cm³ Clamping force: 1300 kN / 130 tons Tie bar spacing: tie-bar-less Ejector stroke / force: 61 kN / 100 mm Bedpeub Umqsfx Afcjcw Clamping unit: hydraulic Motor power: to be provided Heating capacity: to be provided Total power: to be provided The machine is immediately available from our warehouse in Hannover, Germany, and has been tested. Extras 2-component / 2-color machine Rotary table (820 mm diameter) Geku Robot SR 500 ST Safety enclosure / protective cage CC 200 control, German and English languages GEKU Robot Details SR 500 ST Control: Simotion X axis: 600 mm Y axis: 1400 mm (vertical) Z axis: 2500 mm (horizontal) A flip axis: SWM 45 C axis: Servo Gripper: SWS16 B axis: not available Warranty Warranty up to initial commissioning Loading/Shipping Free loading onto buyer's truck or free delivery against freight reimbursement from our warehouse in Hannover, Germany Financing – on request – leasing option Price on request

Condition: excellent (used), Year of construction: 2016, operating hours: 28,600 h, functionality: fully functional, clamping force: 2,000 kN, screw diameter: 55 mm, displacement volume: 570 cm³, Clamping force 2000 kN Mould opening force, max. 101 kN Travel force movable platen opening 50 kN Travel force movable platen closing 42 kN Size of mould platens (h x v) 915 x 915 mm Distance between tie bars (h x v) 560 x 560 mm Mould opening stroke 700 mm Mould height min 550 mm Max. daylight 1250 mm Hydraulic ejector - stroke 200 mm Bedpsxz Tq Nsfx Afcscw Ejector force 58/28 kN Injection unit: Screw diameter 55 mm Ls/D ratio 23 Injection pressure 2387 bar Stroke volume 570 ccm Shot weight (PS) 519 gr. Injection rate 261 ccm/s Screw speed 260 1/min Plasticising rate max. 49 g/s Nozzle pressure 87 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 45 kW Installed heating capacity 23 kW Adjustable barrel heating zones 6 Reservoir capacity 525 ltr. Dimensions and weights: Dimensions of the machine ca. 6,00 x 2,10 x 2,10 m Total machine weight 11500 kg Max. mould weight 2535 kg Accessories: - Anti vibration pads Additional Options: - Electrical plasticizing motor - Accumulator - 2 x Air valves - 2 x core pulls on movable plate - 1 x core pull on fix plate - 8 x hotrunner controller - Robot interface according to Euromap 67

Condition: like new (used), Year of construction: 2010, operating hours: 65,850 h, functionality: fully functional, machine/vehicle number: 61013689, clamping force: 2,500 kN, screw diameter: 50 mm, clearance between the columns: 630 mm, displacement volume: 432 cm³, injection pressure: 2,304 bar, injection weight: 393 g, Equipment: documentation/manual, Here, as a specialist dealer in injection moulding machines, we offer the following well-maintained used injection moulding machine for sale. Of course, we also purchase well-maintained injection moulding machines currently in use. Year of manufacture: 2010. We have been wholesalers of used injection moulding machines for over 25 years. Current tax notice – Advantage for buying used machines: From 01/07/2025, used machines will also qualify for special tax depreciation of 30% per annum. In addition to the lower price compared to new machines, you can claim the same depreciation amounts as for a new machine. Keyword: growth booster (§ 7 paragraph 2 EStG-E). Currently in stock at our Hannover warehouse and tested. Manufacturer: Krauss Maffei Model: KM 250 1000 CX Control unit: MC5 Year: 2010 Operating hours: 65,850 h Machine number: 61013689 Processed material: PE and PP thermoplastics Extras: 2 additional robots: Linear robots LRX 100 and LRX 50 can also be purchased separately - 2 x core pull (movable and fixed WAP) - Pneumatic valve 1 on fixed WAP - Accumulator for increased injection performance - Rapid SK removal CX Midrange - Ejection of cooled nozzle plug - Start handling during mould movement - Mould approach control - Cycle time analysis - External USB keyboard - Graphic analysis – maintenance instructions - Electronic coding of injection unit - Pneumatic valve on moving WAP for blowing out - 12 temperature control zones - Potential-free BDE contact - Process monitoring - Cycle storage Bjdpfxjxqhuus Afcjcw - Trend graphic – target/actual diagram - PV control - Active back pressure control - Single-owner machine – sourced in Germany Regular maintenance by manufacturer and previous owner Clamping Unit Clamping force: 2500 kN / 250 t Tie bar distance: 630 x 630 mm Platen size: 995 x 1050 mm Max. opening stroke: 820 mm Min. mould height: 330 mm Max. opening: 1150 mm Ejector stroke: 200 mm Ejector force: max. 57 kN / return 26.3 kN Injection Unit Screw diameter: 50 mm Injection volume: 432 ccm Shot weight: 393 g / PS Injection pressure: 2304 bar Robot LRX S50 - 3 gripper circuits – 4 vacuum circuits Robot LRX 100 - 1 gripper circuit – 4 vacuum circuits Electrical Equipment Pump: 45 kW Heating: 5 zones, 18.7 kW Weight: 13,900 kg Dimensions: 5.7 x 2.3 x 2.3 m Complete documentation and software manual Available immediately ex our Hannover warehouse or delivered to your location (delivery at cost). The machine is functionally tested and in our sole ownership. The requested machine is immediately available from our Hannover warehouse, functionally tested, and can be inspected under power. About our machines and company: – We only sell machines owned by us, purchased from ongoing production, from our Hannover warehouse – All machines are inspected and tested before disassembly – We do NOT sell insolvency stock – we are NOT brokers dealing with third-party property – All machines come from successful companies where maintenance and care are taken as a matter of course – All listed machines are available for viewing in our warehouse

Condition: good (used), Year of construction: 1993, Netstal 1750 /870 HP Bcedpsg U Arxofx Afcow Closing 175 TO Year 1993

Condition: good (used), Year of construction: 1997, Krauss-Maffei KM 110-520 C1 Year: 1997 Screw diameter: 45 mm Clamping force: 110 tons Tie bar distance: 47x47 cm Shot weight: 234 g Bcedpfsyh Rymox Afcew

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: 61003771, clamping force: 1,100 kN, screw diameter: 45 mm, clearance between the columns: 470 mm, displacement volume: 275 cm³, injection pressure: 1,878 bar, injection weight: 250 g, mold height (min.): 300 mm, ejector force: 22 N, ejector stroke: 150 mm, opening stroke: 900 mm, plate length: 745 mm, plate width: 770 mm, installation height: 600 mm, total length: 4,480 mm, total width: 1,510 mm, total height: 2,190 mm, overall weight: 6,000 kg, heating capacity: 13 kW (17.68 HP), pump power: 18,500 W, Krauss Maffei injection moulding machine Bcjdpfxjyllk Do Afcjw 100t clamping force – used In continuous production until the end of 2024 – currently disconnected from power Available at short notice – production hall is being cleared
