KM 110-520 C1

KraussMaffei

Condition: excellent (used), Year of construction: 2008, KRAUSSMAFFEI injection molding machine KM 1000-4300 MX SIDE INJECTION UNIT KM 380 BOLT-ON LRX ROBOT General Information Parameter Data Manufacturer KraussMaffei Model KM 1000-4300 MX Year of manufacture 2008 Serial number 61012454 Clamping force 11,000 kN (1100 t) Machine weight 54,000 kg Design Two-platen, hydraulic Number of injection units 2 Additional unit KM 380 BO L (Bolt-On) Robot KraussMaffei LRX Note: The KM 1000 designation indicates a 1000 t class, while the stated clamping force of 11,000 kN corresponds to 1100 t. 2. Clamping Unit Parameter Value Clamping force 11,000 kN Dimensions of mounting plates (H x V) 2210 × 1910 mm Column spacing (H x V) 1550 × 1250 mm Minimum mold height 600 mm Maximum mold height 1200 mm Opening stroke 2000 mm Ejector stroke 300 mm FP / MP centering rings 250 / 250 mm Maximum mold weight – fixed platen 25,000 kg Maximum mold weight – movable platen 25,000 kg Maximum total mold weight 50,000 kg Main injection unit – unit no. 1 Parameter Value Screw diameter 80 mm L/D ratio 23 Injection volume 1810 cm³ Volumetric injection rate 503 cm³/s Maximum hydraulic pressure 190 bar Maximum specific injection pressure 2328 bar Screw stroke 354 mm Specified maximum screw speed 955.8 – to be confirmed by the unit Additional side injection unit – unit no. 2 KRAUSSMAFFEI KM 380 BOLT-ON Parameter Value Manufacturer KraussMaffei Type KM 380 BO L Year of manufacture 2008 Serial number 61011975 Unit weight 2500 kg Type Additional side injection unit Screw diameter 40 mm L/D ratio 20 Injection volume 204 cm³ Volumetric injection rate 161 cm³/s Maximum specific injection pressure 1860 bar Screw stroke 160 mm Specified maximum screw speed 391 – to be confirmed by the unit The additional side injection unit enables the implementation of multi-component processes, including 2K technology, provided that a suitable mold and control configuration are used. Robot and automation The machine is equipped with a KraussMaffei LRX linear robot, designed to automate the process of removing parts from the injection mold. The robot model, its year of manufacture, serial number, payload, and ranges of motion for the X, Y, and Z axes need to be confirmed based on the nameplate or documentation. Hydraulic equipment and control Equipment Quantity / parameters Hydraulic mold cores – fixed platen (FP) 2 Hydraulic mold cores – movable platen (MP) 2 Total number of hydraulic core circuits 4 Sequential injection control 16 zones Hot runner control 48 zones Main injection unit Ø 80 mm Side injection unit Ø 40 mm Robot KraussMaffei LRX Technological configuration Laedpe Adpc Dsfx Ahaeh The machine has two independent injection units, which allows it to be used in multi-component production. The configuration includes: • Main injection unit with an 80 mm screw. • Additional Bolt-On side unit with a 40 mm screw. • Four hydraulic core control circuits. • Sequential control of 16 zones. • Control of the mold hot runners – 48 zones. • KraussMaffei LRX linear robot • Transport data Element Weight KM 1000-4300 MX injection molding machine 54,000 kg KM 380 BO L side unit 2500 kg Total weight 56,500 kg

Condition: good (used), Year of construction: 2008, Ref. no.: 18643 Manufacturer: ARBURG Ljdpfxoxvy Rle Ahaeah Type: 470 C 1500-400 Golden Editions Year of construction: 2008 Clamping unit Clamping force: 150 ton Opening stroke: 500 mm Distance between tie bars: 470 x 470 mm Mould height min.: 250 mm Opening width: 750 mm Injection unit Screw diameter: 35 mm Injection volume: 154 cm³ Shot weight: 141 g Injection pressure: 2500 bar Measurements and weight Dimensions: 4,6 x 1,6 x 2,1 m Machine weight: 4850 kg Additional information & extras Core pull: 1 pcs Further information: Communication card for ProSeS interface is available (OPC-UA). Robot interface is available (EUROMAP 67). he Golden Edition is a special version of the well-established ALLROUNDER C series, known for its optimized hydraulic performance, stable production process, and high reliability. The machine has a clamping force of 150 tons and is ideally suited for the production of technical plastic parts as well as applications requiring high quality standards. Key advantages of this series include: * Robust and durable construction * High process stability and repeatability * Reliable ARBURG control system * Good availability of spare parts * Suitable for continuous industrial operation The Golden Edition version also stands out with its enhanced performance and excellent price-performance ratio in the used machinery market. Thanks to its versatility, this machine is widely used in industries such as automotive supply, technical plastic parts, and serial production.

Condition: good (used), Year of construction: 2008, screw conveyor diameter: 75 mm, Type: KME 75-36 R AC Year of manufacture: 2008 Capacity: Screw ø 75-36D; approx. 660 kg/h Condition: Functionality tested Drive: A.C. motor 182.0 kW Ledpfxe Abnido Ahaoah Note: Co-extruder, year of manufacture 2015

Condition: good (used), Year of construction: 2008, screw conveyor diameter: 75 mm, Capacity: Screw conveyor, ø 75-36D; approx. 600 kg/h Drive: A.C. motor, 182.0 kW Lsdpfxj Abc Hkj Ahaeah

Condition: like new (used), Year of construction: 2010, operating hours: 65,850 h, functionality: fully functional, machine/vehicle number: 61013689, clamping force: 2,500 kN, screw diameter: 50 mm, clearance between the columns: 630 mm, displacement volume: 432 cm³, injection pressure: 2,304 bar, injection weight: 393 g, Equipment: documentation/manual, As a dealer in injection moulding machines, we are offering the following well-maintained used injection moulding machine We also, of course, purchase well-maintained injection moulding machines manufactured from 2010 onwards We have been wholesalers of used injection moulding machines for over 25 years In light of recent developments – tax information and benefits for used machinery From 1 July 2025, used machinery will also be eligible for a special annual depreciation allowance of 30% for tax purposes. In addition to the lower price compared to a new machine, you can claim the same depreciation amounts as for a new machine Lsdpoxqhuuofx Ahajah Keyword: Growth booster (Section 7(2) EStG-E) Currently in stock and tested at our Hanover warehouse Manufacturer: Krauss Maffei Model: KM 250 1000 CX Control unit: MC5 Year of manufacture: 2010 Operating hours: 65,850 h Machine number: 61013689 Processed material: PE and PP – thermoplastics Extras - 2 x core pull (movable WAP, fixed WAP) - Pneumatic valve 1 on FWAP - Pressure accumulator for increased injection capacity - Fast SK removal CX Midrange - Ejection of cooled nozzle plug - Start handling during mould movement - Start-up sequence - Cycle time analysis - External USB keyboard - Graphical analysis – maintenance instructions - Electronic coding of injection unit - Pneumatic valve on BWAP blow-out - 12 temperature control points - Potential-free contact BDE - Process monitoring - Cycle storage - Trend graph - Target/Actual graph - PV control - Active back pressure control - From first owner - Origin: Germany Regular maintenance carried out by the manufacturer and previous owner Clamping unit Clamping force: 2500 kN / 250 tonnes. Column spacing: 630 x 630 mm Platen dimensions: 995 x 1050 mm Opening width: 820 mm Mould height: 330 mm min. Opening width max. 1150 mm Ejector stroke: 200 mm Ejector force: 57 kN max/26.3 kg Injection unit Screw diameter: 50 mm Injection volume: 432 cc Shot weight: 393 g/PS Injection pressure: 2304 bar Electrical Pump: 45 kW Heating: 5 zones, 18.7 kW Weight: 13,900 kg. Dimensions: 5.7 x 2.3 x 2.3 m. Complete documentation, manual and software Available immediately from our warehouse in Hanover, Germany, or free delivery subject to reimbursement of freight costs The machine is offered with a functional test certificate The machine is our sole property The machine in question is available immediately from our warehouse in Hanover, is offered in a functionally tested condition and can be viewed whilst powered up. Information about the machines we offer and our company - We only sell machines purchased from current production from our warehouse in Hanover - All machines on offer are inspected and tested prior to dismantling - We do NOT sell goods from insolvency estates - We are NOT a broker dealing in third-party property. - All machines on offer come from successful companies for whom maintenance and upkeep are a matter of course - All machines on offer can be viewed at our warehouse

Condition: as good as new (ex-display), Year of construction: 2025, KraussMaffei KM 651-6100 GX hydraulic injection molding machine LRX 250 robot Year of manufacture: 2025 TECHNICAL DATA Manufacturer: KraussMaffei Year of manufacture: 2025 Clamping force: 6500 kN (650 tons) Machine type: hydraulic injection molding machine Robot: KraussMaffei LRX 250 CLAMPING UNIT Clamping force: 6500 kN (650 t) Mold opening force: 455 kN Ljdpfxs Aaxp Se Ahajah Platen dimensions: 1660 × 1530 mm Tie bar spacing: 1200 × 1020 mm Mold opening stroke: 1450 mm Minimum mold height: 450 mm Maximum mold height: 1000 mm Maximum platen clearance: 1900 mm Ejector stroke: 300 mm Ejector force front/rear: 140/70 kN INJECTION UNIT Screw diameter: 95 mm L/D ratio: 23.0 Injection pressure: 1795 bar Injection volume: 3367 cm³ Injection shot weight: 2391 g (HDPE) Injection speed: 110 mm/s Injection rate: 780 cm³/s Screw speed: 147 rpm Plasticization rate: 102 g/s Nozzle closing force: 166 kN ELECTRICAL AND HYDRAULIC SYSTEM Pump motor power: 97 kW Installed heater power: 54 kW Number of cylinder heating zones: 7 Dry cycle time according to Euromap 6: 3.3 s / 840 mm Dry cycle time according to KraussMaffei: 2.9 s / 600 mm Oil tank capacity: 1435 l DIMENSIONS AND WEIGHT Machine length: 10,190 mm Machine width: 3030 mm Machine height: 2510 mm Net weight: 38,500 kg KRAUSSMAFFEI LRX 250 ROBOT Manufacturer: KraussMaffei Model: LRX 250 Type: linear robot, 3-axis Payload: below 25 kg (including gripper and part) X-axis – stroke from mold: 900 mm Y-axis – vertical stroke: 1000/1000 mm, telescopic Z-axis – transverse stroke: 2500 mm Axis drives: servo motors Vertical axis: equipped with a motor brake Part removal side: opposite to the operating side

Condition: used, Year of construction: 2005, operating hours: 70,000 h, clamping force: 1,600 kN, displacement volume: 4,546 cm³, injection pressure: 1,778 bar, overall weight: 89,000 kg, screw conveyor diameter: 105 mm, terms of delivery: EXW (ex Works) delivery time: on request Ledpfx As Aarg Rshaoah terms of payment: 100% prior to delivery

Condition: good (used), Year of construction: 1993, Netstal 1750 / 870 HP Closing force: 175 tons Year of manufacture: 1993 Ledpfx Asg U Arxehasah

Condition: used, Year of construction: 2016, operating hours: 26,000 h, clamping force: 850 kN, displacement volume: 679 cm³, injection pressure: 2,000 bar, overall weight: 55,000 kg, screw conveyor diameter: 95 mm, terms of delivery: EXW (ex Works) delivery time: on request terms of payment: 100% prior to delivery Ljdpfxsz S N Rfe Ahasah

Condition: excellent (used), Year of construction: 2020, KRAUSSMAFFEI KM 201-380 PX electric injection molding machine Year of manufacture: 2020 Operating hours: 21,849 h Clamping force: 2,000 kN (200 tons) Control system: MC6 Drive system: servo-electric with servo-hydraulic components Machine characteristics • Five-point, double toggle mechanism for the clamping unit, three-platen design. • Servo-electric drive for the clamping unit. • Servo-electric drive for injection and plasticizing. • Servo-hydraulic drive for the injection unit movement. • MC6 control system based on an industrial computer with real-time Ethernet communication. • Plasticizing unit for thermoplastics with a 40 mm diameter screw. Clamping unit Parameter Value Clamping force 2,000 kN (200 t) Mold opening force 300 kN Mounting plate dimensions (H × V) 870 × 820 mm Distance between columns (H × V) 635 × 585 mm Mold opening stroke 500 mm Minimum mold height 250 mm Maximum mold height 550 mm Maximum plate clearance 1,050 mm Ejector stroke 200 mm Ejector force forward / backward 39 / 19 kN Ejector speed 350 mm/s Injection unit Parameter Value Screw diameter 40 mm L/D ratio 20:1 Maximum injection pressure 1,860 bar Injection volume 201 cm³ Injection shot weight 183 g Injection speed 125 mm/s Injection rate 157 cm³/s Maximum screw speed 334 rpm Plasticizing rate 24.7 g/s Screw torque 337 Nm Nozzle clamping force 34 kN Nozzle radius 10 mm Nozzle orifice diameter 4 mm Electrical and hydraulic parameters Parameter Value Connected load 13.8 kW Electrical protection 63 A Installed heater power 11.5 kW Number of cylinder heating zones 5 Dry cycle time according to EUROMAP 6 2.0 s / 445 mm Oil tank capacity 200 l Weight and dimensions Parameter Value Net weight with control cabinet 14,300 kg Machine length 6,120 mm Machine width 2,170 mm Lajdpfsz Szncex Ahash Machine height 2,210 mm

Condition: used, Year of construction: 1999, Injection molding machine Krauss-Maffei 800 /5700MC, year of manufacture 1999. Technical specifications available on request. Laedoyg Hbtepfx Ahajh

Condition: used, Year of construction: 1998, Injection moulding machine Krauss Maffei KM 300 1400 C1, year 1998 Control: Mc 3 Clamping force: 3000 kN Ljdpfx Asxuq Rmehaoah Shot weight: 900 g Core pull: 2 Screw diameter: 60 and 70 mm Operating hours: approx. 18,000 h

Condition: used, Year of construction: 2009, Used Krauss Maffei injection moulding machine, type CX 650-3000, year 2009, screw diameter 80 mm, 6 core pulls, 6 pneumatic needle controls, 12 internal tool heaters, 6+6 cooling water circuits, approx. 51,200 operating hours, approx. 61,500 pump hours. Sale includes LRX 250 handling with 4 vacuum circuits and 4 gripper circuits. Known defects: leaks on the upper operator-side tie bar and at the injection unit. Additionally, the low-pressure pump no longer regulates precisely. Ledpfx Aoyg Hcqshaoah
