CNC Gear hobbing machine LIEBHERR LC 282

LIEBHERR LC 282 CNC

Condition: good (used), Year of construction: 1997, TBT ML 200-2-850 deep hole drilling machine TECHNICAL DATA Type: M200-2-850 Number of spindles: 2 Drill carriage stroke: 850 mm Drilling method: Single-lip drilling Drilling depth with: Submersible spindle: 120 mm Sealing housing: 400 mm Lodpfx Aovca Rcobzehc Sealing housing with bezel: 350 mm Spindle drive Power: 2 / 3.5 / 1.5 kW Voltage: 140 / 350 / 350 V Speed: 14 / 11 / 6 / A Feed - own drive Feed speed: 20 - 500 mm/min Rapid traverse speed NC operation: 12 m/min Feed force: 1.5 kN Motor power: 2.2 Nm at 3000 rpm Clamping tailstock Motor power: 0.75 kW at 1000 rpm Spindle speed: 500 rpm Stroke max: 200 mm Main dimensions L x W x H: 4600 x 2500 x 2100 mm Transport weight: 3200 kg Control: Sinumerik 805 M No liability is assumed for the correctness, completeness and up-to-dateness of the information provided

Condition: good (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 39035, National Machinery 750 S3 Operational - Working 5 FORGING STATION Supplied with control process and soundproof cabin Machine Size: 750 S3 Number of dies and punches: 5 Lhjdpfxotnhp Re Abzec Total heading load (kN): 2730 Number of strokes/min. (min/max): 90 Cutoff diameter: 22 mm. Cutoff length (min/max): 4,75/80 mm. Kickout stroke - die (min/max): 19/100 mm. Kickout stroke - punch: 52,4 mm. Motor size (kW): 55 Net weight (kg): 41.500

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm Lodpfsrtrvyjx Abzehc -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: excellent (used), Specifications Manufacturer LORENZ Model LS 150 Year 2005 Condition Used Stock Number in fabbrica Max diameter 150 mm Module 3 Lhjdpoxgprgofx Abzsc Stroke 50 mm Description Available on May 2025 SIEMENS SINUMERIK 810 D

Condition: used, Year of construction: 1981, National 2-3 Hot Former Ljdjwl Iw Uepfx Abzehc induction heater, feeder, straightener

Condition: good (used), Year of construction: 2007, max. wheel diameter 1200 mm gear width 260 mm max. module 16 min. module 0,5 stroke 270 mm distance between table/spindle 920 mm taper of shaper cutter SK control Liebherr LH 90 Lhjdpewzmp Iofx Abzec table diameter 900 mm min. workpiece diameter-at internal hobbing 1200 mm strokes - infinitely variable 50-1000 Hub/min spindle diameter 125 mm table hole 320 mm Distance of shafts Min/Max 0-820 power requirement Stosskopf 30 KW total power requirement 72 KVA weight of the machine ca. 24 t dimensions of the machine ca. 6,5x2,9x4 m Liebherr LH 90 control, 9 axis CNC, top condition.

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 130 mm gear width: 170 mm max. module: 3 min. module: 0,5 total power requirement: 48 kVA weight of the machine ca.: 9 t Lhjdpfx Aewdyx Ujbzoc dimensions of the machine ca.: 7,64 x 3,14 x 3,25 m For technical data, see PDF-File enclosed *

Year of construction: 1984, condition: ready for operation (used), A Pfauter vertical CNC gear hobbing machine is available. Modules min./max.: 1/3, max. workpiece diameter: 150mm, max. tooth width: 150mm, milling head tilt: +/-45°, milling cutter axis-table axis distance: 10mm-160mm, table diameter: 160mm, table bore: 63mm. Tool holder: SK40, max. cutter diameter: 130mm, max. cutter length: 220mm, speed: 600rpm, feed: 1500mm/min, tangential path: 170mm, rapid traverse: 3m/min. Machine dimensions X/Y/Z: approx. 4000mm/3000mm/2500mm, weight: approx. 6500kg. On-site inspection is possible. Lodewkih Eepfx Abzshc

Condition: ready for operation (used), Year of construction: 1984, Romanian Hot Former AMP 20 line Press Capacity : 220 tons, Forming section : 3, Forming load: 90 ToF, Bar Diameter: 14 to 25 mm, Part Outer Diameter, Max.: 35 mm, Cut-Off Length: 15 to 40 mm, Ram Stroke: 110 mm, Ejector Stroke: 55 mm, Die Center Distance: 110 mm, Production Per Minute: 12 to 180 , Weight: 11 tons, Technical documentation: yes Movie underpower available Ledpfstaui Uox Abzehc

Condition: good (used), Year of construction: 1998, spindle diameter 90 mm control Siemens SINUMERIK 840 C voltage 400 V stroke position adjustment 100 mm Lhedpfx Asxyadtebzoc table hole 150 mm no. of strokes 100-1200 Hub/min weight of the machine ca. 8,0 t Key data Normal module: 6 mm Max. workpiece pitch circle diameter: 250 mm Max. tooth width (straight teeth): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance workpiece/jigging spindle: –80 mm to +320 mm Stroke position, stroke length Max. stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Stroke drive Stroke rates infinitely variable Standard: 100 to 1200 DH/min Motor for stroke drive: 9 kW Maximum cutting speed: 150 m/min Feeds Rotation axes (tool C1, workpiece C2 axis): Feed stepless relative to 100 mm pitch circle diameter: 1.0 to 9420 mm/min Radial axis (column slide X1 axis): Feed continuously variable: 1.0 to 9420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / weight Total connected load: 26 kVA Total weight (standard version): approx. 9,000 kg
