Vibrating Chute GFA 2000-1200

Condition: ready for operation (used), Year of construction: 2021, operating hours: 20 h, functionality: fully functional, machine/vehicle number: SK02UXKP0365, measuring range X-axis: 550 mm, measuring range Y-axis: 600 mm, Auction of a Zeiss T-Scan Hawk with only 20 operating hours! TECHNICAL DETAILS Maximum measuring range: 550 mm x 600 mm Itodpfx Aex Sqfnohusb Measuring accuracy: 0.02 mm + 0.035 mm/m MACHINE DETAILS Laser class: Class 2M (eye-safe) according to IEC 60825-1:2014 Operating hours: 20 EQUIPMENT Notebook GOM Inspect software

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2023, load capacity: 2,500 kg, throat depth: 2,500 mm, empty load weight: 713 kg, construction height: 3,350 mm, pivoting range: 360 °, Column Slewing Crane M25-2.5 Iedpfx Ahjx Nvtljustb TECHNICAL DETAILS Load capacity: 2,500 kg Jib outreach: 2,500 mm Height: 3,350 mm Slewing range: 360° Outreach: 2,500 mm Underside of jib: 2,980 mm Overall height: 3,350 mm Bolt circle diameter: 530 mm Flange outside diameter: 610 mm Beam flange width: 150 mm Minimum approach dimension (Aa): 420 mm Internal approach dimension (Ai): 820 mm Support column length: 1,530 mm MACHINE DETAILS Weight: 713 kg Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 48 V EQUIPMENT Electric travel trolley Electric chain hoist Lifting capacity: 2,500 kg Lifting height: 4 m Lifting speed: 4 / 0.7 m/min Crane trolley Motorized travel trolley Flange width range: 138–195 mm Flange width: 150 mm Travel speed (max.): 10 m/min Travel speed (min.): 3 m/min MACHINE DETAILS Travel motor (trolley) Power: 0.3 kW Rated current: 1.2 A Starting current: 4.2 A Hoist Hoist motor power: 3.6 kW Hoist motor rated current: 8.2 / 4.3 A Hoist motor starting current: 39 / 6.7 A Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 48 V

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2023, machine/vehicle number: 10000987990, total height: 5,300 mm, total length: 30,000 mm, total width: 8,900 mm, load capacity: 3,200 kg, lifting height: 4,450 mm, Up for auction is a Konecranes overhead crane with 2 bridges, each offering a lifting capacity of 3.2 t. TECHNICAL DETAILS Lifting capacity: 3,200 kg Span: 8,900 mm Lifting height: 4.45 m Hoisting speed: 3.9 m/min (ASR 1.2 m/min) Trolley travel speed: 20 m/min, infinitely variable Ijdpfx Ajx Nvrzjhuetb Crane travel speed: 40 m/min, infinitely variable MACHINE DETAILS Number of bridges: 2 Number of trolleys: 2 Dimensions & Weight Dimensions (L x W x H): 30,000 x 8,900 x 5,300 mm Trolley weight: 230 kg Crane total weight without trolley: 1,300 kg Electrical Data Operating/Control voltage: 400 V / 48 V, 50 Hz Rated power: 3.0 kW EQUIPMENT Runways Radio remote control Conductor rails Overload protection Load spectrum memory Signal horn Pre- and limit switches for trolley and crane travel (slow/stop) Guide rollers to reduce skewing forces Buffer extension to compensate for guide rollers

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2017, machine/vehicle number: 11690446, load capacity: 4,000 kg, lifting height: 6,530 mm, TECHNICAL DETAILS Span: 9.9 m Crane lifting capacity: 4,000 kg Lifting height: 6.53 m Lifting speed at full load: 3.2 m/min Lifting speed at partial load: min. 3.0 m/min up to max. 7.5 m/min Trolley travel speed: 20 m/min Crane travel speed: 40 m/min Itedpfsx Nvpgex Ahujb MACHINE DETAILS Weights Trolley weight: 390 kg Crane weight without trolley: 1,750 kg Classification Crane class: 3U4/Q2, EN 13001-1 Hoist mechanism group: 4.3 + 4.4 m / ISO M6 Crane girder mechanism group: 16 m / M5 Electrical data Power supply: 400 / 48 V / 50 Hz Rated output: 3.3 kW EQUIPMENT Radio control Overload protection Load spectrum memory Pre- and end-limit switches for crane and trolley travel Remote control type “Mini Joystick” Spare transmitter Storage cabinet Spare battery Charging station Signal horn Hook collision protection Hook center-of-gravity alignment Manual crane hook tracking Safety conductor line incl. main disconnect switch and power supply Clampable holding brackets Riser cable (fixed installation) to be provided by customer

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2024, machine/vehicle number: 10000987991, overall weight: 5,110 kg, load capacity: 6,300 kg, main lifting speed: 4,000 mm/min, lifting height: 5,200 mm, 6.3t S-DG Double-Girder Overhead Crane TECHNICAL DETAILS Crane rail type: 60 × 40 Load capacity: 6,300 kg Span: 17.100 m Maximum deflection of crane bridge at rated load: 22.8 mm Wire Rope Hoist Max. lifting capacity of hoist 1: 6,300 kg Hoist classification: 1.2 + 1.2 m (D_min) Lifting height: min. 4.9 m / max. 5.20 m Type of trolley: double rail trolley Wire rope control: with hook drift Hook type/size: RSN2.5V Speeds Hoisting speed at rated load: min. 0.08 m/min to max. 4.0 m/min CSR speed at partial load: max. 6.00 m/min Trolley travel speed: max. 20 m/min Crane travel speed: max. 40 m/min MACHINE DETAILS Weight of crane including hoist: 5,110 kg Electrical Data Supply voltage: 3 Ph / 400 V / 50 Hz Control voltage: 48 V Area of application: indoors Ambient temperature: min. 5 °C to max. 40 °C Motor Power Main hoist motor: 4.5 kW Duty cycle main hoist motor: 60% ED Trolley travel motor: 1 × 0.45 kW Duty cycle trolley travel motor: 40% ED Crane travel motors: 2 × 0.65 kW Duty cycle crane travel motors: 40% ED EQUIPMENT DynADrive inverter control Control Pro Performance 4-stage hoist limit switch Hoist brake Wire rope drum Gearbox Overload protection Load spectrum recorder Slow/stop limit switches for trolley and crane travel Crane equipped with REMOX516MI radio remote control Includes signal horn (sound level 98 dB) Includes spare transmitter for radio remote control Includes storage cabinet for remote control Rope angle features Safety festoon line approx. 30 m long, along central support row Includes mains disconnect switch and power feed at any point Rising main (fixed installed cable) to be provided by customer Itsdpjx Nvlbsfx Ahueb Note: Further technical details can be found in the attached quotation.

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 8531, Auction of a Famot MEXPOL TUM 35! Isdox Ngnmepfx Ahuetb

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 40167, Auction of a MAHO universal milling machine! Itodsx Ngkzspfx Ahuob

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2016, operating hours: 50 h, machine/vehicle number: 2390, bending force (max.): 100 t, stroke length: 140 mm, throat depth: 300 mm, distance between stands: 2,600 mm, overall weight: 6,650 kg, TECHNICAL DETAILS Bending force: 100 t Cylinder stroke: 140 mm Open width without tooling: 345 mm Distance between uprights: 2,600 mm Throat depth: 300 mm Approach speed: 160 mm/s Bending speed: 10 mm/s Return speed: 130 mm/s Rotational speed: 1,500 rpm MACHINE DETAILS Control system: DA 66 T Oil capacity: 125 L Itodpjx Eyv Nofx Ahuob Total weight: 6,650 kg Power: 7.5 kW Voltage/Power supply: 400 V AC Control voltage: 24 V AC/DC Operating hours: under 50 h

Condition: ready for operation (used), Year of construction: 2006, operating hours: 17,716 h, functionality: fully functional, machine/vehicle number: 0144, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 675 mm, controller model: Heidenhain iTNC 530, TECHNICAL DETAILS Itsdpfx Ajx Trpqohujb X-axis travel: 1,200 mm Y-axis travel: 600 mm Z-axis travel: 675 mm Work spindle speed: 30 - 8,000 rpm Tool holder: ISO B 40 Table size: 1,220 x 620 mm T-slots: 18 T-slots: 5 x 18 mm T-slot spacing: 100 mm Table load capacity: 1,700 kg Control system: Heidenhain iTNC 530 Feed rate X / Y / Z: 3,000 mm/min Rapid traverse X,Y / Z: 24 / 20 m/min MACHINE DETAILS Voltage: 3 x 400 V AC + PE, 50/60 Hz Control voltage: 24 V DC Connected load: 16 kW Weight: 8,000 kg Operating hours Control on: 44,842 h Machine on: 36,513 h Program run: 15,882 h Drives on: 31,655 h Spindle on: 17,716 h

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 220.242, cutting length (max.): 4,300 mm, saw blade diameter: 350 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Cutting Data Nominal cutting length: 4,300 mm Maximum saw blade diameter (S): 350 mm Scoring blade diameter (V): 300 mm Maximum saw blade projection above table (U): 95 mm Stack Height and Panel Thickness Maximum stack height (P): 80 mm Minimum panel thickness (P): 3 mm Strip Aligner Minimum aligning force: 300 N Maximum aligning force: 990 N Additional Specifications Maximum clamp opening (K): 90 mm Working height: 970 mm Overall height: 2,020 mm Machine Accuracy Itedpfjx Sqpmox Ahueb Positioning accuracy: ± 0.1 mm (measured at feed-in) Cutting straightness: ± 0.1 mm over 3 m cutting length Electrical Power and Speeds Main saw motor power: 15 kW Saw carriage forward speed: 5 – 120 m/min Saw carriage return speed: 120 m/min Feed-in forward speed: up to 80 m/min (Europe 25 m/min EN 1870-13) Feed-in return speed: up to 80 m/min EQUIPMENT Strip aligner Label printer Optimization software HPO/F N5
