Used Nardini Lathe for sale (5,513)

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Description WE OFFER AN NICE WORKING CONDITION INDEX ABC 42 - TWO MACHINES WE HAVE AWAILIBLE TWIN SPINDLE TWIN TURRET INCLUDIN COMPLETE TOOLINGS AND SPARE PARTS MACHINE IS CONECTED ON POWER AND CAN BE INSPECTED UNDER POWER FOR CUSTOMER WE CAN ORGANIZE TRANSPORT AS WELL Machine Category CNC Turning- and Milling Center Make INDEX Type ABC 42 (*934) Year 2004 Control C200-4 / 840C Siemens Country of origin Germany Other information CNC - Turning- and MillingCenter INDEX - ABC 42 - two turrets - live tool stations - subspindle on upper turret - 1x back drilling device - with percussion unit - many accessories Technical Details Backside processing: C-Axis 0,001 ° change-time tool to tool 0,2 sec clamping diameter max. 42 mm clamping length max. 38 mm control C200-4 / 840C Siemens dimensions of the machine ca. 7,0 x 3,0 x 2,5 m Driven Tool Positions: 8 Feed force X: 8,3 / Z: 5,5 kN Fixed tools max. 5 pos Main spindle: max. Torque 7,5 Nm number of toolpositions 6 pos. power capacity - driven tools 3,3 kW power capacity - main spindel 13 / 21 kW Lrodpfxovk E Nmo Akuol rapid traverse X: 16 / Z: 24 m/min shaft cross cut 25 x 48 DIN 69880 spindle bore 15,5 mm spindle diameter in front bearing 85 mm spindle hollow 36 mm spindle passage 36 (42) mm Spindle speed - driven tools 6.000 min -1 Spindle speed range subspindle max. 4.500 min/-1 Subspindel: total power requirement ca. 30 kW travel -x axis 81 mm travel -z axis 80 mm turning length max. 280 mm turning speed range - main spindle max. 6.300 min/-1 Turret 1: Turret 2: weight of the machine ca. 3,0 t Accessories bar feeder Index LM 3200 Chip conveyor Coolantsystem Documents driven tool stations hydraulic system parts catcher Subspindle Turret 2x

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, WE OFFER AN VERY NICE CONDITION 5 AXIS CNC LATHE HWACHEON MACHINE IS WORKING IN DAILY PRODUCTION ORDERS, SOLD WILL BE BECAUSE SOON IS COMING A BIGGER NEW. MODEL: CUTEX -180BL YSMC YEAR: 2019 Ledsv Acpnjpfx Akuerl HEAD STOCK HEIGHT: 1130mm MAX SPINDLE SPEED: 4500 RPM MAX CHUCK DIA: 8 INCH MAX CHUCK SPEED: 5000 RPM MAX WORKING DIA: DIAMETER 300 X 425 L WEIGHT: 4700 KG RATED VOLTAGE: 3 PE / 220 V (ac) FREQUENCY 50HZ ELECTRICAL POWER SUPLY 35 kWA RATED CURRENT 100A SHORT CIRCUT CURRENT RATING 5 kA LARGEST MOTOR 95 A CIRCUIT BREAKER CAPACITY 100A AMPERE INTERRUPTER CAPACITY 50 kA AIR SUPPLY: 0.5 MPa

Condition: excellent (used), Year of construction: 1985, functionality: limited functionality, Description Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Lrodpfx Aevk E Ayekusl Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, Description WE OFFER AN NICE CONDITION TWO MACHINES EMCO HYPERTURN 665 WITH BARR FEDERS AND TOOLS ACCESSORIESS YEAR: 2005 FULLY FUNCTIONAL , READY TO WORK CONNECTED ON POWER. FOR THE CUSTOMER WE ORGANIZE DISMANTLING LOADING AND TRANSPORT Description For sale: Well-maintained EMCO Hyperturn 665 MC Plus IEMCA Master 880MP-E bar loader, chip conveyor, and high-pressure coolant pumps! Machine was exclusively used for machining brass parts! CNC Turning and Milling Center | EMCO Hyperturn 665 MC Plus with main and sub-spindle, C and Y axes, dual turrets each with 12 driven tool stations! Technical Data: Swing diameter over bed: 600 mm Swing diameter over cross slide: 500 mm Control: Siemens Sinumerik 840D Max. turning diameter: 430 mm Max. turning length: 744 mm Max. bar capacity: 65 mm Travel - X: 270 mm Travel - Z: 750 mm Travel - X2: 205 mm Travel - Z2: 750 mm Travel - Y: 100 (+/- 50) mm Main spindle speed: 0 - 5,000 rpm Sub-spindle speed: 0 - 7,000 rpm Tool turret: 2x 12 positions, all driven! Tool holder: VDI 30 Upper turret: X, Z, Y axes Lower turret: X, Z axes Sub-spindle traverse (left/right): Z3 axis C11 spindle: 65 mm diameter (hollow chuck cylinder) C12 spindle: 45 mm diameter (solid chuck cylinder) with part ejector Tool turret type: Sauter 2x 14 bar high-pressure pumps Accessories: Complete tooling cabinet with driven and static toolholders as well as carbide inserts and tool holders Collet chucks for main and sub-spindle Full documentation etc. Machine available immediately! Ready for operation! Loading will be handled by us! Transport can be organized upon request! TECHNICAL DATA: Specifications: Max. swing diameter 430 mm dia. Max. rotary. About Bed 600 mm Dia. Turning length 744 mm Distance between spindle lugs 975 mm Lredpsvk E Atofx Akujl Main engine power 21/29 kw Main spindle speed range 0-5000 rpm Bore through drawing tube 65 mm dia. C axis - main spindle movement 0.001 degree Y axis 100 +/- 50 mm B Axis Movement Stepless 45 Degree Tool turret 1 with 12 VDI 30 stations Powered stations turret 1 12 pc. - 4000 rpm Y+B pieces. Engine power driven tools 6.7 Kw Tool turret 2 with 12 pc. VDI 30 stations Counter spindle C axis - counter pindel movement 0.001 degree Counter spindle speeds 0-5000 D46485 Pr/min Motor power counter spindle 17/22 Kw Control Siemens 840 D Controlled in 8 axis - x1-x2-z1-z2-c1-c2-y-b axes Accessories: BAR FEDER AND HUGE LIST OF TOLLINGS ON PHOTOS Length: 3400 mm + convoyer , Height: 2300 mm, Width: 2550 mm, Weight: 7600 kg

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Specifications Manufacturer HARDINGE Ledpfx Aovk E Ddokuorl Model HARDINGE TWIN SPINDLE LATHE QUEST 8/51 Year 2002 Description 2002 HARDINGE QUEST 8/51 CNC SUB SPINDLE, DRIVEN TOOLING LATHE WITH GE FANUC SERIES 16I-T CONTROL 150mm Dia 3 Jaw Power Chuck. Collet Chuck Sub Spindle, 12 Station Turret. Quantity Of Static & Driven Holders. S/No. QC-28 (2002).

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, turning diameter over cross slide: 570 mm, turning diameter: 800 mm, center height: 400 mm, center width: 4,000 mm, turning length: 3,800 mm, No reserve price - guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning diameter: 800 mm Center height: 400 mm Turning length: 3,800 mm Distance between centers: 4,000 mm Max. swing diameter over cross slide: 570 mm Max. swing diameter in gap: 1,130 mm Work spindle Spindle head according to DIN: 55027, size 11, internal taper 20 Spindle diameter at front bearing: 165 mm Spindle bore: 120 mm Face plate diameter: 564 mm Max. chuck diameter: 380 mm Max. spindle speed: 750 rpm Tailstock Quill taper: Morse 6 Quill diameter: 110 mm Max. manual quill stroke: 310 mm Feed rate Longitudinal carriage: 0.092 - 1.590 mm/min Cross slide: 0.046 - 0.795 mm/min Lrsdpfow Rqrwjx Akujl MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 6600 x 1850 x 2250 mm Weight: 10,900 kg EQUIPMENT Comprehensive accessory package included.

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. Lredpfx Akexdmgvjuel The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Lredpfx Aoxpqm Rskuel Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: excellent (used), Model: 4M/65E Condition: Very good Dimensions: 80.00 (H) x 60.00 (W) x 120.00 (L) inches Additional Description: - Automatic copy lathe - To make spades, shovels, curling's, gun holders, axes, legs, cricket bats and so on. - Makes 4 pieces at the same time. - Router (no sanding attachment) Lrsdpfx Akjxz Tfaeuel - Speed regulation on slide. - Works great

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 270, center width: 900 mm, center height: 210 mm, spindle speed (max.): 3,000 rpm, Equipment: CE marking, TECHNICAL DETAILS Swing diameter over bed: 420 mm Centre height: 210 mm Centre distance: 900 mm Spindle bore: 55 mm Spindle speed: 4 - 3,000 rpm MACHINE DETAILS Lrjdpfxjy Rx A Se Akuol Control type: Teach-in Control system: CNC EQUIPMENT Digital readout (Weiler) Documentation available CE marking

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 3098034, travel distance X-axis: 203 mm, travel distance Z-axis: 762 mm, spindle speed (max.): 1,800 rpm, bed width: 445 mm, center width: 900 mm, TECHNICAL DETAILS Swing diameter over bed: 900 mm Lsdpfx Akoy Rxxmsuorl Centre height: 450 mm Centre distance: 900 mm Bed width: 445 mm X-axis travel: 203 mm Z-axis travel: 762 mm Spindle bore: 60 mm Max. spindle speed: 1,800 rpm MACHINE DETAILS Control: CNC Dimensions & Weight Dimensions (L x W x H): 2,400 x 1,600 x 1,950 mm Weight: 2,000 kg Transport packages: 2 pcs EQUIPMENT Documentation CE marking

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, spindle speed (max.): 450 rpm, workpiece weight (max.): 5,000 kg, working width: 2,000 mm, spindle diameter: 105 mm, TECHNICAL DETAILS Swing diameter over bed: 1,050 mm Working width: 2,000 mm Working depth: 1,050 mm Max. workpiece weight: 5,000 kg Spindle diameter: 105 mm Spindle bore: 105 mm Spindle speed: 2.24–450 rpm Thickness: 105 mm Distance between centers: 2,000 mm Max. workpiece weight: 5,000 kg MACHINE DETAILS Motor power: 22 kW Dimensions & Weight Dimensions (L x W x H): 4,900 mm x 1,900 mm x 1,700 mm Weight: 8,000 kg Control: Conventional Lsdpsy Rxrtofx Akusrl EQUIPMENT Four-jaw chuck Steady rest

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning length: 380 mm, turning diameter: 450 mm, spindle bore: 59 mm, rotational speed (max.): 5,000 rpm, controller model: Seicos 40L Multi, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Ledpfxsy R Dmio Akuerl Turning diameter: 450 mm Turning length: 380 mm Maximum machining diameter: 340 mm Travel X-axis: 215 mm Travel Z-axis: 400 mm Bar capacity: 51 mm Spindle speed range: 30 to 5,000 rpm Spindle drive power: 11 / 7.5 kW Spindle nose: A2-6 Spindle bore: 59 mm Bearing diameter: 100 mm Turret: 16 stations Feed rate: 0.001 to 500 mm/min Rapid traverse X/Z: 30 m/min Tool shank diameter: 25 x 25 mm Drill shank diameter: 40 mm Tailstock taper: MT 5 Tailstock quill stroke: 300 mm MACHINE DETAILS Control unit: Seicos 40L Multi Total power requirement: 23 kVA Dimensions & Weight Space requirement: approx. 5.5 x 2.8 x 2.2 m Machine weight: approx. 4.6 t EQUIPMENT Documentation Chip conveyor Tailstock Signal light Parts discharge chute Tool setting arm Work area illumination Tool holder

Condition: ready for operation (used), Year of construction: 2011, operating hours: 18,533 h, functionality: fully functional, machine/vehicle number: PA158, turning length: 450 mm, turning diameter: 300 mm, workpiece weight (max.): 9 kg, workpiece length (max.): 150 mm, workpiece diameter (max.): 225 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning length: 450 mm Turning diameter: 300 mm Workpiece diameter max.: 225 mm Workpiece length max.: 150 mm Workpiece weight max.: 9 kg MACHINE DETAILS Lredpfsy R Uy Hox Akujl Operating hours: 18,533 h Rated voltage: 380 V Number of phases: 3 Frequency: 50/60 Hz Maximum power consumption: 22.9 kVA Total current consumption: 34.8 A Motor current consumption max.: 72 A Short-circuit power data / current interruption at: 15 kA Dimensions & Weight Space requirement (L x W x H): approx. 2,550 x 2,150 x 2,100 mm Machine weight: approx. 4,900 kg Note: Since other machines need to be moved to allow for loading, the stated disassembly and loading costs apply.

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 1938, turning length: 250 mm, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, workpiece length (max.): 850 mm, workpiece diameter (max.): 300 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning length: 250 mm Turning diameter: 340 mm Max. spindle speed: 4,500 rpm Lrodpoy R Uxiofx Akuol Max. workpiece diameter: 300 mm Max. workpiece length: 850 mm Workpiece clamping: Three-jaw chuck, Kitagawa B-210 MACHINE DETAILS Control: Okuma OSP 7000L Max. power: 22 kW Rated voltage: 400 V Number of phases: 3 Frequency: 50 Hz Max. power consumption: 30.1 kVA Total current draw: 43.4 A Max. motor current: 106 A Circuit breaker at: 10 kA Note: As other machines need to be moved for loading, the stated dismantling and loading costs apply.

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 178979, turning length: 309 mm, turning diameter: 280 mm, travel distance X-axis: 190 mm, travel distance Z-axis: 330 mm, controller model: Mazatrol 640T Nexus, No reserve price – guaranteed sale to the highest bidder! The technical data is sourced from the manufacturer's information. The seller assumes no liability for its accuracy! TECHNICAL DETAILS Max. turning diameter: 280 mm Max. machining length: 309 mm Swing diameter: 550 mm X-axis travel: 190 mm Z-axis travel: 330 mm Spindle bore: 61 mm Rapid traverses X/Z: 30/33 m/min Lrodpfx Aoy Sln Rjkuol MACHINE DETAILS Control: Mazatrol 640T Nexus Main power circuit: 3AC Main circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current: 31 A Main motor voltage: 400 V Rated power: 24 kVA Weight: 3,500 kg Note: The bar feeder is not included in the offer.

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 265771, turning diameter: 350 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 195 mm, travel distance Y-axis: 560 mm, workpiece weight (max.): 20 kg, The technical data is based on manufacturer specifications. The seller cannot guarantee its accuracy! TECHNICAL DETAILS Travel X-axis: 195 mm Travel Z-axis: 560 mm Maximum spindle speed: 5,000 rpm Rapid traverse X-axis: 30 mm/s Rapid traverse Z-axis: 33 mm/s Maximum turning diameter: 350 mm MACHINE DETAILS Ljdpfx Akoy Saiieuorl Control: Mazatrol Smart Main power circuit: 3-phase AC Main power circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current consumption: max. 53 A Main motor voltage: 400 V Rated power: 29.1 kVA Dimensions & Weight Machine dimensions (L x W x H): 2,650 x 1,700 x 1,700 mm Machine weight: 4,500 kg

Condition: not inspected (used), Year of construction: 1988, functionality: unexamined, machine/vehicle number: 0278, turning diameter over cross slide: 240 mm, turning diameter over bed slide: 400 mm, center height: 120 mm, spindle speed (max.): 2,000 rpm, bar passage: 53 mm, No reserve price – guaranteed sale to the highest bidder! Bidding commits you to timely collection between 23.06.2026 and 26.06.2026! TECHNICAL DETAILS Swing diameter over bed: 400 mm Swing diameter over cross-slide: 240 mm Spindle speed: 45 - 2,000 rpm Spindle bore: 53 mm Centre distance: 1,000 mm Centre height over bed: 200 mm Centre height over cross-slide: 120 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 2,400 x 900 x 1,600 mm Machine weight: 1,500 kg Lredpfxey D Sdio Akuel EQUIPMENT Tailstock Multifix quick-change toolpost Three-jaw chuck (diameter: 200 mm) + additional three-jaw chuck Toolholder Turning tools Indexable inserts External reference: 11

Condition: ready for operation (used), Year of construction: 2008, operating hours: 18,349 h, functionality: fully functional, turning length: 1,000 mm, turning diameter: 340 mm, spindle speed (max.): 4,800 rpm, controller model: OSP P200L, Equipment: chip conveyor, TECHNICAL DETAILS Turning length: 1,000 mm Turning diameter: 340 mm Ledpfx Akjy Txycouorl Spindle speed (max.): 4,800 rpm Axes: 4 Tool turret A: VDI40 V12 with driven tools Tool turret B: VDI40 V8 MACHINE DETAILS Control system: OSP P200L Operating hours: 18,349 h EQUIPMENT Touch probe Chip conveyor Coolant station Standard spindle bore Tailstock: manual

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, turning length: 280 mm, spindle speed (max.): 4,200 rpm, travel distance X-axis: 155 mm, travel distance Z-axis: 320 mm, controller model: OSP 700L, TECHNICAL DETAILS Maximum turning length: 280 mm X-axis travel: 155 mm Z-axis travel: 320 mm Spindle speed: 4,200 rpm MACHINE DETAILS Ledpfx Akjy S S Hgousrl Control system: OSP 700L Turret: V12, direct mounting EQUIPMENT Chip conveyor Touch probe Coolant pump Parts collector Collet chuck

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, spindle speed (max.): 3,200 rpm, overall weight: 6,500 kg, controller model: U-10L, TECHNICAL DETAILS Maximum turning diameter: 210 mm Maximum turning length: 500 mm X-axis travel: 155 mm Z-axis travel: 520 mm Spindle speed: 3,200 rpm MACHINE DETAILS Ledpjy S Sytefx Akujrl Control system: U-10L Dimensions & Weight Dimensions (L x W x H): 2,700 x 1,900 x 1,700 mm Total weight: 6,500 kg EQUIPMENT Documentation/Manual Adjustable spindle speed Parts catcher Touch probe V12 turret VDI 30 (all powered) Manual tailstock Chip conveyor Coolant pump Bar loader Samsys MUS-3000, year 2007 SMW chuck KNCS-N210-52

Condition: ready for operation (used), Year of construction: 2007, operating hours: 5,426 h, functionality: fully functional, machine/vehicle number: 101098, travel distance X-axis: 400 mm, travel distance Z-axis: 200 mm, workpiece length (max.): 130 mm, TECHNICAL DETAILS Lrodpfx Aey T Iupjkuol Travel range, X-axis: 400 mm Working stroke, X-axis: 150 mm Travel range, Z-axis: 200 mm Chuck diameter: 160 mm Turning diameter: max. 200 mm Machining diameter: max. 130 mm Part length: max. 110 mm Main spindle Spindle flange according to DIN 55026: Size 5 Spindle bearing, diameter front: 80 mm Speed, hybrid bearing: max. 6,000/7,500 rpm Main drive AC asynchronous motor: 1MB200E Indramat Low-voltage technology: Fanuc Power at 100/40 % duty cycle: 16/24 kW Torque at 100/40 % duty cycle: 102/153 Nm Rated speed: 1,500 rpm Feed drive Rapid traverse speed X: 60 m/min Rapid traverse speed Z: 30 m/min Feed force X and Z: 5 kN Ball screw diameter X and Z: 40 mm Acceleration X/Z: 5/5 m/s² Tool holder Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Tool length incl. holder: max. 190 mm Pitch circle diameter: max. 740 mm Pitch circle diameter Lifetool: max. 620 mm Tool holder with driven tools Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Speed: max. 6,000 rpm Rated speed: 3,000 rpm Torque at 10 % duty cycle: max. 37 Nm Torque at 25 % duty cycle: max. 26 Nm Torque at 100 % duty cycle: max. 14 Nm MACHINE DETAILS Closed standard automation Number of carrier bars with workpiece diameter 27 mm: 85 Number of carrier bars with workpiece diameter 18 mm: 130 Permissible total load: max. 120 kg Pick-up stroke depressed: 1 mm Pick-up stroke over-depressed EMERGENCY STOP: 5 mm Pick-up spring travel: max. 30 mm Chain length: 162 inches Chain pitch: 25.4 mm Chain tension with 27 carrier bars: 400 N Chain sprocket: Z = 30 Gear ratio: i = 100 Motor revolution/band revolution: 540 Loading time: 2–4 s Electrical equipment Operating voltage: 400–480 V Control voltage DC: 24 V Control voltage AC: 230 V Frequency: 50/60 Hz Connected load: 31 kW Supply line fuse: 50 A Design of the electrical system: VDE 0113 Operating hours: 5,426 h

Condition: ready for operation (used), Year of construction: 2006, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040033, rotational speed (max.): 5,000 rpm, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Work area X-axis: 360 mm Work area Y-axis: 120 mm Work area Z-axis: 260 mm Handling area X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Lrodpfsy T Itrox Akusl Feed force X/Y: approx. 8,000/10,000 N Feed force Z: 10,000 N Rapid traverse rate X/Z/Y: approx. 80/40/7.5 m/min Acceleration X/Z/Y: 7 m/s² MACHINE DETAILS Control system: SIEMENS Sinumerik Power at 100% duty cycle ED, main spindle: 20 kW Torque at 100% duty cycle ED: 105 Nm Power at 40% duty cycle ED: 27 kW Torque at 40% duty cycle ED: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm

Condition: ready for operation (used), Year of construction: 2005, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040018, rotational speed (max.): 5,000 rpm, controller model: SIEMENS Sinumerik, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Work area X-axis: 360 mm Work area Y-axis: 120 mm Work area Z-axis: 260 mm Handling area X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Feed force X/Y: approx. 8,000/10,000 N Feed force Z: 10,000 N Lredpfx Akey T Im Eeusl Rapid traverse rate X/Z/Y: approx. 80/40/7.5 m/min Acceleration X/Z/Y: 7 m/s² MACHINE DETAILS Control system: SIEMENS Sinumerik Power at 100% duty cycle ED, main spindle: 20 kW Torque at 100% duty cycle ED: 105 Nm Power at 40% duty cycle ED: 27 kW Torque at 40% duty cycle ED: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm

Condition: ready for operation (used), Year of construction: 2004, operating hours: 63,778 h, functionality: fully functional, machine/vehicle number: 06800002061, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel X-axis: 800 mm Travel Z-axis: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter in the front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Accuracy when positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque at 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Lrjdpfsy T Ikkox Akujl Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump power: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 63,778 h
