Used Röder Profil Drilling Machine for sale (68,152)

Condition: good (used), Csepel RF50/1250 Radial Drilling Machine A robust and proven radial drilling machine from the quality manufacturer Csepel (Model RF50/1250). The machine is characterized by its solid construction and is ideally suited for metalworking shops, general workshops, or demanding DIY enthusiasts. Technical specifications (according to nameplate): Manufacturer: Csepel (Budapest) Type: RF50 / 1250 Power supply: 3~ (three-phase / 380 V) Frequency: 50 Hz Control voltage: 220 V Operating current: 10 A Lodpfxjzninwj Amtsrp Required fuse protection: 16 A (slow-blow) You can find more items—both new and used—in our shop! International shipping costs available upon request!

Year of construction: 2003, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 300-M270100, Schüco PBS profile machining center – 5-axis CNC, year of manufacture 2003, ready for immediate use TECHNICAL DETAILS X-axis travel: 6,650 mm Y-axis travel: 800 mm Z-axis travel: 500 mm X-axis feed rate: 0–40 m/min X-axis rapid traverse: 40 m/min Y- and Z-axis feed rate: 0–30 m/min Y- and Z-axis rapid traverse: 30 m/min B-axis rotation: 0–90° continuous Lredpexr N Rmjfx Amtsp C-axis rotation: 0–360° continuous B- and C-axis rotation speed: 10,000°/min Positioning accuracy within a macro: max. 300 mm ±0.1 mm Positioning accuracy over a 6,000 mm length: < ±0.15 mm MILLING Maximum tool dimensions for milling and drilling: Ø 50 mm, length = 60 mm Maximum tool dimensions for disc milling cutters: Ø 300 mm Maximum spindle motor power: 7 kW Disc milling cutter spindle motor power: 7 kW Spindle speed: 0–30,000 rpm Tool change time: < 15 s (clamp to clamp) Tool holder: HSK-E-40 steep taper Tool magazine: 9 plus 1 positions Total machine weight: 6.5 tons WORK AREA Number of clamping blocks: 8 units Clamping block positioning: automatic Maximum profile length for 3-sided machining: 6,650 mm Maximum profile length for 5-sided machining: 6,100 mm Maximum profile cross-section with maximum tool length: 300 mm x 230 mm

Condition: used, Dimensions (LxBxH): 280 x 150 x 310 cm Year built: 1988 Overall dimensions LxWxH: 2800x1500x3100 mm Online auction of metalworking and sheet metal processing machines (including a wide selection of SIEGMUND welding and clamping tables and related tools, SAFAN press brakes and SAFAN guillotine shears, MOSMAN YLS-3000 3kW laser welding machine, various FRONIUS, REHM, etc. welding machines, BOMAR, URSUS, ELHA, etc.), remaining stock of sheet metal, materials and inventory, rolling stock, technical equipment, and modern office furniture, released following the recent bankruptcy of Solex Thermal Science (Netherlands) B.V., formerly Mosman Stainless Steel in Haaksbergen, the Netherlands. The online auction opens Thursday 16 July and closes Thursday 3 September. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 1 September Pickup days are on: - Thursday 10 September Lrodpfx Amezm H Iljtep - Friday 11 September Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online auctions continue to grow in the European industrial market, Dome Auctions offers a professional and efficient solution for companies seeking high-quality machinery at competitive prices.

Year of construction: 2023, condition: used, Dimensions (LxBxH): 110 x 55 x 150 cm Serial number: SMK2023072160K-1 Power: 30W Working area: 110x110mm Overall dimensions LxWxH: 1100x550x1500mm Online auction of metalworking and sheet metal processing machines (including a wide selection of SIEGMUND welding and clamping tables and related tools, SAFAN press brakes and SAFAN guillotine shears, MOSMAN YLS-3000 3kW laser welding machine, various FRONIUS, REHM, etc. welding machines, BOMAR, URSUS, ELHA, etc.), remaining stock of sheet metal, materials and inventory, rolling stock, technical equipment, and modern office furniture, released following the recent bankruptcy of Solex Thermal Science (Netherlands) B.V., formerly Mosman Stainless Steel in Haaksbergen, the Netherlands. The online auction opens Thursday 16 July and closes Thursday 3 September. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 1 September Pickup days are on: - Thursday 10 September - Friday 11 September Lrsdpfx Amjzm H Acetop Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online auctions continue to grow in the European industrial market, Dome Auctions offers a professional and efficient solution for companies seeking high-quality machinery at competitive prices.

Condition: ready for operation (used), functionality: fully functional, spindle mount: MK 4, drilling depth: 240 mm, total width: 480 mm, total length: 550 mm, drilling capacity: 45 mm, spindle speed (max.): 1,270 rpm, spindle speed (min.): 68 rpm, spindle stroke: 240 mm, SPECIFICATIONS Brand: Erlo Model: TCA-45 Capacity: 45 mm ø Table length: 550 mm Table width: 480 mm Spindle taper: MK4 Speed: 68 - 1,270 RPM Lsdpfx Amjx Dcfhotjrp Arm reach: 360 mm Stroke: 240 mm Table height adjustable manually Automatic feed Gear-driven Machine dimensions: 1,000 x 700 x 2,400 mm

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, New machine, purchased in 2020. Ideal for: Furniture manufacturing Kitchen manufacturing Carpenters/joiners Series drilling for Blum fittings and hinges Technical specifications: 3 x 400 V 1.1 kW Professional industrial version The machine comes from a workshop liquidation. Lrsdoznkufspfx Amtjp Scope of delivery: Machine Stops/accessories, base frame as shown in the pictures Operating manual Inspection/test run possible by arrangement.

Condition: ready for operation (used), Alzmetall AB 35 HST / Bench drill press & Walter Gras Arbo3 quick-change head -Drilling capacity / steel approx. 40mm -Drilling capacity / cast iron approx. 45mm -Threading capacity max. M25 -Spindle taper MK 4 -Spindle stroke 180mm -Speed range (VARIABLE) 65 - 1750 rpm -Switchable speed range 130-480 / 480-1750 rpm -Automatic feed rates 0.1-0.2-0.3mm/rev -Drilling depth adjustable via depth scale Lrsdjzn Unvopfx Amtop -Speed indicator -Right / left rotation -Swiveling drill head with tool -Height-adjustable work table via hand crank -Coolant system -Emergency stop -Work light Dimensions: L x W x H 1 x 0.8 x 2.1 meters / Weight approx. 1200KG Errors and omissions excepted.

Condition: excellent (used), Year of construction: 2010, Maximum drilling diameter: 20 - 252 mm Drilling diameter in concrete: 20 - 202 mm Number of speeds: 3 Electrical connection: 220 V, 2300 W Weight: 7.4 kg Lrsdpfx Aoznvrpemtsp

Condition: used, High-performance drilling machine ALZMETALL, type Abomat 20 Production drilling machine Serial No. 452, Year of manufacture 1996 Drilling capacity in steel ST 60: 25 mm Drilling capacity in cast iron GG 20: 30 mm Spindle mount: SK 40 - M16 Overhang: 280 mm Drill slide stroke: 500 mm Distance from spindle nose to table: 185 - 685 mm Table size: 490 x 400 mm Spindle speed: 50 - 500 rpm, infinitely variable Drill slide feed: 20 - 224 mm/min, infinitely variable Drill slide rapid traverse: 4.5 m/min Feed motor power: 0.18 kW Rapid traverse motor power: 0.75 kW Drill spindle motor power: 1.1 kW (speed 1000 rpm) Mains connection: 400 volts, 50 Hz Lrjdpfx Amoikrtqetep - Spindle speed infinitely variable via frequency inverter - Drill slide feed infinitely variable via frequency inverter - 2 operating modes: setup and automatic operation - Central lubrication - Control cabinet on the back of the machine - Swiveling control panel - Mounted on a steel plate (700 x 650 x 40 mm) with precise height adjustment Space requirement L x W x H: 1200 x 700 x 2530 mm Weight: approx. 1000 kg Good condition

Condition: used, Radial drilling machine, Kolb, heavy-duty design. Lredpfxeznl Dbe Amtjp

Condition: used, Year of construction: 1988, Radial drilling machine Manufacturer: Tai Pin Type: TPR 1230 Year of manufacture: 1988 Drilling capacity in steel: Ø 42 mm Drilling capacity in cast iron: Ø 55 mm Thread cutting (steel/cast iron): M25 / M38 Overhang (column to spindle center): 330 – 1,230 mm Spindle stock travel: 880 mm Column diameter: 300 mm Lodpfx Ameznvibotjrp Tool holder: MK 4 (Morse taper 4) Quill stroke (spindle stroke): 270 mm Spindle speeds: 12 steps, 37 – 1,253 rpm (at 50 Hz) Automatic feeds: 3 steps (0.05 / 0.09 / 0.15 mm/rev) Distance spindle – base plate: 467 – 1,360 mm Outrigger height adjustment: 620 mm 23726

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: Bottom & end face - Swivel range: 0–90 degrees via handwheel - Pneumatic workpiece clamps: 3 pcs. Lrsdpfszn Ah Rex Amtep - Opening: Max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see pictures) Availability: at short notice Storage location: 63934 Röllbach

Condition: used, Universal Milling Machine DECKEL Type FP 1 Universal milling machine Machine No. 2101 – Year of manufacture: 1979 Manual travel X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.5 and 1.9 kW, pole-changeable Electrical connection: 380 Volt, 50 Hz - Stepless feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at the vertical milling head: 60 mm - Vertical milling head can be swiveled and extended horizontally by 100 mm - Fixed angle table 600 x 210 mm - Coolant system integrated in the machine base - Standalone control cabinet - Original chip tray for mounting on the machine base - Electrical schematic available Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg Good condition Lrodpfx Amer U St Ujtep

Condition: used, 4-axis CNC drilling and milling machine IXION Type 30 CNC W VMC, BAZ, machining center Year of construction approx. 1997, machine overhauled in 2020 Travel X: 600 mm Y: 350 mm Z: 600 mm Table size 800 x 400 mm T-slot spacing 75 mm Table load 300 kg Spindle holder SK 40 (tightening bolt DIN 69872 A) Spindle speed 20-5000 rpm Torque at the spindle max. 150 Nm Distance between spindle nose and table max. 660 mm Feed speed X, Y and Z 0 - 5000 mm/min. infinitely variable Rapid traverse speed X, Y and Z 15000 mm/min. Tool change time approx. 5 sec. Tool change time from chip to chip approx. 7.5 sec. Milling capacity in St 60 150 ccm/min. Drilling capacity in St 60 35 mm Thread cutting capacity in St 60 M24 Spindle motor drive power 5 kW (10 kW at 25% duty cycle) Mains connection 400 Volt, 50 Hz - CNC control Heidenhain TNC 415 with 12" TFT display - Electronic handwheel - RS 232 interface - 12-position tool changer - hydro-mechanical tool clamping - Rotary axis as dividing head on the table = 4th axis, MECATECNICA type DCN 250-8, jaws lathe chuck Ø 200 mm Speed approx. 25 rpm, transmission ratio 1:180 - Cabin lighting via 2x halogen spotlights - Chip conveyor with coolant pump - Switch cabinet fixed to the machine Space required for transportation Length 320 cm x width 230 cm x height 300 cm Footprint of the machine with chip conveyor L x W x H 3200 x 3100 x 3000 mm Weight of the machine 3100 kg Weight of the chip conveyor approx. 200 kg Ledpfx Ameu Tln Nstsrp good condition

Condition: used, Univ. universal milling machine DECKEL, Type FP 1 Machine No. 28317, Year of manufacture approx. 1960 Travel distances: X: 245 mm, Y: 150 mm, Z: 340 mm Table size: 600 x 210 mm Spindle mount, horizontal: MK 4 - S20 x 2 Spindle speed, vertical: 95-1900 rpm, 12 steps Spindle speed, horizontal: 60-1200 rpm, 12 steps Motor power: 0.8 and 1.1 kW, pole-changing Power connection: 380 Volt, 50 Hz - Spindle speed controlled via 2 motor speeds and 6 gear stages - Feed in the X and Z axes - Coolant system with mechanical pump in the machine base - Quill travel on the vertical milling head: 60 mm - Vertical milling head swivels +/- 90° - Metal substructure made of angle iron with machine feet Space requirement L x W x H: 1100 x 900 x 1650 mm Lrsdeiy Ekvopfx Amtop Weight: 650 kg Good condition

Condition: used, CNC Universal Coordinate Drilling and Milling Machine FEHLMANN Type PICOMAX 100-CNC 3 CNC Control HEIDENHAIN TNC 155 Manufacturer's No. 16186651 Year of Manufacture 1986 Spindle Taper FEHLMANN SF32 Drilling Capacity Ø 30 mm in steel Thread Cutting up to M20 in steel Travel X: 850 mm, Y: 435 mm Lodohik Ezspfx Amtjrp Quill Stroke Z: 210 mm Vertical Movement of Milling Head 580 mm Feed X and Y 1 to 8000 mm/min. Feed Z 1 to 4000 mm/min. Rapid Traverse X and Y 8 m/min. Rapid Traverse Z 4 m/min. Table Clamping Surface 1570 x 500 mm Distance Spindle Nose - Table 130 - 720 mm Overhang Spindle - Column 450 mm Spindle Speed 50 - 7100 RPM, stepless Spindle Drive 10 kW Total Connected Load 20 kW Mains Connection 400 Volt, 50 Hz - CNC Control HEIDENHAIN TNC 155 with TFT monitor - 3 axes controlled, X, Y and Z quill adjustment - hydro-mechanical tool clamping FEHLMANN SF32 - threading device - cable remote control for machine operation and axis movements - motorized vertical movement of the milling head with shutdown via adjustable cams - 3D probe RENISHAW, Type MP 11F with FEHLMANN SF32 mount - 20 tool holders FEHLMANN SF32 - swiveling tool holder with 21 tool positions - coolant system in the machine frame - control cabinet fixed to the machine - documentation: operating manual, control manual and electrical diagrams Space Required L x W x H 2350 x 2000 x 2300 mm Weight 3.2 tons very good condition

Condition: used, Univ. universal tool milling machine DECKEL, Type FP 1 Lredpfxsghtvao Amtjp Machine No. 51265, Year of manufacture approx. 1967 Travel distances X: 300 mm, Y: 150 mm, Z: 340 mm Table size 600 x 200 mm Spindle mounting SK 40 - S20 x 2 Spindle speed 40-2000 rpm, 16 speeds Motor power 1.0 and 1.6 kW, pole-changing Mains connection 380 volts, 50 Hz - Feed in the X and Z axes - Spindle speed via 2 motor speeds and 8 gear stages - Quill movement on the vertical milling head 60 mm - Swivel, rotary, and tilting angle table - Coolant pump in the machine base - Adjacent control cabinet Space required L x W x H 1100 x 1100 x 1600 mm Weight 690 kg Good condition

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Universal Milling Machine Machine No. 2101 - Year of manufacture: 1979 Travel (manual) X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.4 / 1.8 kW, pole-changeable Power supply: 380 Volt, 50 Hz - Stepless feed in X and Z axes Ledpfx Amor D T U Dstjrp - Spindle speed via 2 motor speeds and 8 gearbox stages - Quill stroke at the vertical milling head: 60 mm - Vertical milling head tiltable and horizontally extendable by 100 mm - Fixed angle table 600 x 210 mm - Coolant system in the machine base - Separate control cabinet - Original chip tray mountable on machine base - Wiring diagram available Space required (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg In very good condition

Year of construction: 1995, condition: ready for operation (used), 4 Lenz CNC PCB drilling and routing machines are offered. 1) One CNC vertical PCB drilling and routing machine, Lenz LGX 460-2AL, year of manufacture: 1995, travel X/Y: approx. 550mm/460mm, rapid traverse X/Y: approx. 40m/min, max. drilling rate Z-axis: approx. 500strokes/min, spindles: Precise SC53H, spindle speed: approx. 20000rpm, tool holder: 3mm, tool capacity: 308, control: SIEB & MEYER CNC 44.00. Equipped with a cooling unit and a loader. Overall dimensions of the base machine X/Y/Z: approx. 1650mm/1700mm/2250mm, additional length of the loader unit: approx. 820mm. 2) One CNC vertical PCB drilling and routing machine, Lenz GX 460-2, year of manufacture: 1989, travel X/Y: approx. 550mm/460mm, number of spindles: 2, rapid traverse X/Y: approx. 15m/min, max. stack height Z-axis: approx. 10mm, tool holder: 3mm, tool capacity: 88, control: SIEB & MEYER CNC 45.00, equipped with a cooling unit, overall dimensions X/Y/Z: approx. 2100mm/1450mm/1800mm. 3) One CNC vertical PCB drilling and routing machine, Lenz GX 600-1, year of manufacture: 1991, travel X/Y: approx. 650mm/600mm, number of spindles: 1, rapid traverse X/Y: approx. 15m/min, spindle: Precise SC63, spindle speed: approx. 20000rpm, tool holder: 3mm, tool capacity: 88, control: SIEB & MEYER CNC 44.00. Equipped with a cooling unit, overall dimensions X/Y/Z: approx. 2000mm/1500mm/1800mm. 4) One compact CNC vertical PCB drilling and routing machine, Lenz TB 500-1, travel X/Y: approx. 475mm/390mm, number of spindles: 1, rapid traverse X/Y: approx. 10m/min, spindle speed: approx. 15000rpm, tool holder: 3mm, control: SIEB & MEYER CNC 35.00. Equipped with a cooling unit and a spare control unit, overall dimensions X/Y/Z: approx. 1500mm/1100mm/1520mm. The machines can be purchased individually or as a package. Inspection possible by appointment. Lrsdpfsznmy Dsx Amtop

Condition: used, Year of construction: 1993, Used machine Year of manufacture: 1993 Lrjdpfxew I Uy Te Amtjp Features and technical data: 2-jaw drill chuck up to 20 mm shank diameter Pneumatic positioning adjustment on 2 levels 0-100 mm Max. drilling depth: 150 mm Precision indexing rail 12 mm Center locking and cross adjustment 2 pneumatic safety clamping cylinders Motor 1.5 kW Speed: 2800 rpm Long hole drilling device, lowerable, with 2 program cams Machine weight approx. 310 kg Machine dimensions (W x D x H): 1100 x 1100 x 1500 mm (without stop) Availability: short-term Location: Röllbach

Condition: ready for operation (used), Bench drill – ALZMETALL AB 35 S - Drilling capacity in steel approx. 45 mm - Drilling capacity in cast iron approx. 48 mm - Spindle mount MK 4 - Arm reach approx. 350 mm - Drilling stroke approx. 180 mm - Spindle speeds / 2 stages / 65 - 1450 rpm (VARIABLE) - Automatic feed rates 0.1-0.2-0.3-0.4 mm/rev - Drilling depth stop - Table clamping surface approx. 600x460 mm - Table adjustment approx. 600 mm - Table height adjustable via crank - Column diameter approx. 200 mm - Motor power approx. 3.5 kW - Coolant system - Work light - Speed indicator Dimensions: L x W x H 1.1 x 0.7 x 2.1 meters / Weight approx. 1200 kg Errors and omissions excepted. Lsdeznlf Eopfx Amtjrp

Condition: used, Flying profile cutting machine for Dreistern P3.125 with accessories Production direction: left to right Travel distance: 2000 mm Aluminum carriage with shaft recirculating ball guide Height adjustment via hydraulic cylinder and wedges Disc spring clamping of height adjustment, hydraulically releasable Low-backlash Graessner gearbox with Rexroth servomotor Folding table: Roller guide Hydraulically folding Rollers recessed in the table Dimensions: 380 x 6200 mm Accessories: 7.5 kW hydraulic power unit with cooler and accumulator Infeed roller guide Hole index detection Hydraulic valves on the carriage Punching unit Separation device Original documentation In perfect working condition until disassembly at the customer's plant. Control unit not included. For integration into an existing roll forming line, we can support you with: Ljdpsy Sldfjfx Amtjrp Planning Mechanical overhaul Control system construction Painting Safety concept CE documentation

Condition: used, functionality: fully functional, mount diameter: 10 mm, spindle speed (min.): 6,000 rpm, spindle speed (max.): 12,000 rpm, table length: 1,130 mm, table width: 250 mm, – Italian production TECHNICAL SPECIFICATIONS: - Number of spindles: 8 - Number of units: 4 - Unit motor power: 4 x 1 kW - Adjustable angle of end units: 0° - 20° - Mechanical oscillation - Oscillation motor power: 0.37 kW - Max. oscillation length: 100 mm - Oscillation speed adjustment - Independent unit oscillation - Basket diameter: 10 mm - Distance between outermost spindles: 1170 mm Lredpex Npimefx Amtep - Min. distance between units: 84 mm - Spindle speed: 6000 / 12000 RPM - Unit height adjustment - Unit width adjustment - Table dimensions: 1130 mm x 250 mm - Table height and depth adjustment - Three pneumatic clamps - Inverter power: 4 kW - Connector diameter: 2 x 100 mm - Machine dimensions (L/W/H): 235 / 165 / 200 cm - Weight: ~ 1750 kg

Condition: ready for operation (used), The U2PRW cutting and drilling machine is designed for processing slats and furniture fronts made of solid wood or MDF. The machine works in a semi-automatic cycle. During one cycle the machine performs: cutting at a given angle (in the range of 45 - 90 degrees) and drilling in the jammed plane, or the edge of the element. - Made in Poland TECHNICAL PARAMETERS: max. height of cut material 60 mm max. width of cut material at an angle of 45° 70 mm max. width of the material at an angle of 90° 150 mm max. length of cut material 2200 mm min. length of cut material at 45° 455 mm diameter of main saw 250 or 300 mm undercutter diameter 100 mm max. diameter of bottom milling cutter 35 mm max. depth of bottom milling 15 mm diameter of face drill embedment and bottom milling cutter 10 mm Drill head (face drilling): spindles 4 axial spacing of spindles 32 ; 32 ; 40 mm linear arrangement of spindles max. depth of face drilling 60 mm installed power 7 kW working pressure 0.6 Mpa overall dimensions (length / width / height) 4300 / 1600 / 1570 mm Machining units The machine is equipped with two machining units. The left unit, which is fixed, and the right unit - a sliding unit. Each machining unit consists of the following sub-assemblies - units: a main saw, an undercutting unit, a drilling unit that drills into the jammed plane, and a drilling unit that drills into the bottom of the workpiece. Bottom hole drilling unit The described aggregate is installed as an option. It is used in the processing of corner ties for doorframes with adjustable width. It makes a blind bore , for the can connector. The picture shows the mounted red cover which is at the same time the base for the machined angle strips and the cover with chip extractor. Workpiece pressure The machine tool is also equipped with a clamping system operating in two planes. The clamping area includes horizontal and vertical clamps. The horizontal clamps are responsible for pressing against the vertical bases and straightening the workpiece. Vertical ones, on the other hand, are responsible for immobilizing the workpiece during machining. The horizontal pressure always precedes the vertical pressure. Ledpfx Asq Ii Dlemterp Control The machine's control is clear, easy to use and functional. It allows switching on or off all aggregates separately, additionally with division into left and right sides. All aggregates have independent drive. The right-hand processing unit is set by pressing the control buttons on the control panel. The executive mechanism is a gearbox with an electric motor driving a trapezoidal screw. An electronic control system US with an operator panel and digital display is used to read and set the length of the workpiece. This system is also responsible for automatic corrections to the counter readings when the cutting angles change by 45° and 90°. In addition, it is responsible for automatic basing.

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Lrsdpfxjxwaz Ho Amtop
