Used Strung Vertical for sale (7,567)

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 109238, Technical characteristics: Work Area - Chuck diameter: 260 mm - Maximum workpiece weight: 150 kg - Swing diameter: 280 mm - Maximum workpiece diameter/height: 200/200 mm - X-axis stroke (working stroke): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN - Z-axis stroke: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN - Loading time: 5 to 6 seconds - Standard closed automation (number of loading stations by workpiece diameter): 14 (80–200 mm), 18 (30–160 mm), 30 (30–85 mm) Main Spindle - Spindle interface according to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Motor output at 100% / 40% duty cycle: 25 / 18 kW - Torque at 100% / 40% duty cycle: 280 / 200 Nm Tool Holder with Driven Tools - Toolholders with cylindrical shank according to DIN 69880: 12 positions – BMT65 - Number of positions: 12 - Maximum tool length including holder: 200 mm - Maximum speed: 6,000 rpm - Maximum torque (10% duty cycle): 27 Nm, (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 100 A - Connected load: 36 kVA Dimensions - Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm - Weight: 9,000 kg Main Features and Capabilities: - Vertical design for optimal chip removal and easy workpiece loading/unloading - CNC control: GE Fanuc FS 32i B - High positioning accuracy on X and Z axes: ±0.001 mm (Heidenhain linear scales) - Main spindle: High power output and wide speed range - In-process measurement: Marposs T25 measuring probe - Automated loading/unloading: EMAG O-Type. Parts are loaded and unloaded via integrated automation - Driven tool capability extends machining operations to drilling and milling - Chip conveyor, coolant unit, switchable double cartridge filter, high-pressure pump (15 bar) Credpexxkgpofx Adrsh - Tool life monitoring with sister tool management - Completely enclosed work area with workstation lighting - Documentation: Electronic version available; printed version incomplete Machine status: NOT WORKING - Requires replacement of hydraulic actuator and electrical motor - Live tool motor needs attention

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 179057653, Technical characteristics: Work Area - Chuck diameter: 600 mm - Max. workpiece diameter/height: 450 / 400 mm - Distance from spindle nose to tailstock reference point: 639 mm - X1/X2 axes travel (working stroke): 335/289 mm / Rapid traverse in X: 30 m/min - Z1/Z2 axes travel: 560/494 mm / Rapid traverse in Z: 30 m/min - Fully enclosed with automatic door opening, supporting manual or automatic loading Main Spindle - Spindle according to DIN 55026: Size A6 - Max. speed: 4,500 rpm - Power at 100% / 40% duty cycle: 23 / 18 kW - Torque at 100% / 40% duty cycle: 146 / 115 Nm Tailstock - Interface: MK4 - Clamping force: 850 daN - Clamping stroke: 200 mm Turret Configuration X1/Z1: Toolholder with Powered Tools - Cylindrical shank holders per DIN 69880: 8 - VDI40 - Max. tool length: 130 mm - Number of positions: 1 x 8 - Max. speed: 4,500 rpm - Max. torque at 10% / 100% duty cycle: 27 Nm / 14 Nm Turret Configuration X2/Z2: Toolholder with Powered Tools - X-HOT unit for polygonal turning, max. eccentricity (stroke): 8 mm - X-HOT tool clamping system: HSK 32S Electrical Equipment - Operating voltage: 400 V, 100 A - Connected load: 37 kVA Dimensions - Overall dimensions: Length = 3,000 mm (6,477 mm with chip conveyor), Width = 3,000 mm, Height = 3,650 mm - Weight: 11,000 kg Main Features and Capabilities: - Vertical design for optimum chip removal, suitable for manual or automated loading/unloading - Siemens 840D control, NC1 and NC2 axes - High precision: Positioning accuracy in X, Z axes ±0.002 mm (Heidenhain linear scales) - Powerful main spindle with a wide speed range - Live tooling extends machining capabilities to drilling and milling - Tool life monitoring - Chip conveyor: Knoll - Coolant system filtration up to 40 bar: Knoll FKA/1400 - Workpiece presence detection with low pressure sensor - ROBOT AUTOMATION INFRASTRUCTURE INSTALLED - Fully enclosed work area; integrated lighting Crjdpfsxxinfsx Adroh - Documentation: available both electronically and as hard copy Machine status: Not operational - Missing: valve for emulsion circuit and inductive sensors

Condition: repair required (used), Year of construction: 2014, functionality: not functional, machine/vehicle number: 67137, Technical characteristics: Work Area - Maximum clamping plate diameter: 250 mm - Maximum turning diameter: 250 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 200 mm - X-axis travel: 886 mm / Rapid traverse X: 60 m/min - Z-axis travel: 250 mm / Rapid traverse Z: 30 m/min - Y-axis travel: -85/+100 mm / Rapid traverse Y: 30 m/min - Standard closed automation (number of loading stations by workpiece diameter): 14/(80...200), 18/(30...160), 30/(30...85) Main Spindle - Spindle (Weiss) per DIN 55026: Size A6 - Maximum speed: 5,500 rpm - Power at 100% duty cycle: 38 kW - Torque at 100% duty cycle: 300 Nm Secondary Spindle HSK63 - Spindle head size/type: HSK-A63 - Nominal speed: 2,700 rpm / Nominal power: 12 kW / Nominal torque: 42.4 Nm - Maximum speed: 15,000 rpm Credpfjxxi Ursx Adroh - Power at 100% duty cycle: 38 kW - Torque at 100% duty cycle: 300 Nm Tool Holder with Motorized Tools - Turret VDI40, Siemens-drive 0.5.440.220 (manufacturer: Sauter) - Number of stations: 12 - Live tool nominal speed: 3,000 rpm / Nominal torque: 33.1 Nm - Live tool maximum speed: 10,000 rpm / Nominal torque: 56.2 Nm - Live tool nominal power at 100% duty cycle: 10.4 kW Electrical Equipment - Operating voltage: 400 V, fused 100A GL - Connected load: 45 kW Dimensions - Overall dimensions: Length = 4,021 mm, Width = 4,709 mm, Height = 3,527 mm - Weight: 8,000 kg Main Features and Capabilities: - Vertical design for optimal chip evacuation and easy loading/unloading - Control system: Siemens 840D SL - High precision with Heidenhain linear scales for X, Y, Z axes - High-power main spindle (Weiss) with a wide speed range - High-power secondary spindle (Weiss), easily accessible for drilling/milling operations - Automated loading/unloading via integrated automation - In-process control probe: Marposs T25 - Live tooling for extended machining capabilities (drilling, milling, etc.) - Chip conveyor: Knoll - Coolant 'paper' filter unit & chiller: Knoll KF150/500 - Electrostatic mist filter: IFS type IFM1000 Machine status: NOT WORKING - Sauter turret replaced with new unit; assembly not complete – turret motor spindle installation still required - Operator panel safety switch needs replacement

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 101851, Technical characteristics: Work Area - Maximum diameter of the clamping plate: 260 mm - Maximum turning diameter: 260 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 110 mm - X-axis travel: 570 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 200 mm / Rapid traverse in Z: 30 m/min Codpoxvy Azjfx Adrjrh - Y-axis travel: 40 mm / Rapid traverse in Y: 30 m/min - Standard closed automation (number of loading nests by workpiece diameter): 14/(80...200), 18/(30...160), 30/(30...85) Main Spindle - Spindle mount as per DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Power (at 100 / 40% duty cycle): 18 / 27 kW - Torque (at 100 / 40% duty cycle): 202 / 303 Nm Tool Holder with Driven Tools - Cylindrical shank holders as per DIN 69880: 12 – VDI40 - Number of tool stations: 12 - Maximum tool length (including holder): 190 mm - Maximum speed: 6,000 rpm - Maximum torque at 10% duty cycle: 37 Nm, 25% duty cycle: 26 Nm, 100% duty cycle: 14 Nm Electrical Equipment - Operating voltage: 400 – 480 V - Connected load: 42 kW Dimensions - Overall machine dimensions: Length = 2,680 mm (3,820 mm with chip conveyor), Width = 2,040 mm, Height = 2,400 mm - Weight: 6,500 kg Main Features and Capabilities: - Vertical design: Optimal chip evacuation and easy loading/unloading. - Control: GE Fanuc Series 18i-TB. - High precision: Positioning accuracy on X, Z, and Y axes ±0.001 mm, Heidenhain linear scales. - Main Spindle: High power and wide speed range. - Automated Loading/Unloading: Parts are loaded and unloaded via integrated automation. - Driven Tools: Use of live tooling extends processing capabilities to include drilling and milling operations. - Chip conveyor Machine Status: NOT OPERATIONAL - Lifetool Motor - X-axis optical scale defective + connection cable - Z-axis belt - Lubrication pressure switch - Hydraulic main pressure valve - Door safety switch (Euchner)

Condition: used, Twin vertical band saw with log lengthener. Suitable for widths from 70mm to 200mm. Log length from 50cm up to 3.7 meters. Cedsyh Hc Rjpfx Adrjrh

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: M+ Mazatrol, table load: 1,000 kg, TECHNICAL DETAILS Travel in the X-axis: 1,660 mm Travel in the Y-axis: 510 mm Travel in the Z-axis: 510 mm Table dimensions: 2,000 × 510 mm Table load capacity: max. 1,000 kg Spindle speed: 7,000 rpm Tool holder: SK 40 Tool magazine: 48 tools MACHINE DETAILS Cjdpfxsz Ahw Hj Adrjrh Control system: M+ Mazatrol Machine weight approx.: 7,500 kg Space requirement approx.: 5 m² EQUIPMENT Chip conveyor: MAYFRAN 4th axis: Tilting rotary table: Rotamatik RM 100

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 410 mm, controller manufacturer: Siemens, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Cedpfxoz Ahxqs Adrjrh Travel range X: 560 mm Travel range Y: 410 mm Travel range Z: 410 mm Clamping area: 650 × 410 mm Table load: 250 kg Spindle speed: 12,000 rpm Tool holder: SK 40 MACHINE DETAILS Control system: Siemens

Condition: good (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: M500.06133, overall weight: 15,000 kg, Emag VSC500 Vertical Turning Machine. Condition Good. Weight 15,000 kg. Delayed removal unit will be ready for removal by the end of September. Csdpfx Adoz Hc Nvjrjrh Buyer responsible for removal, contractor must be licensed and insured.

Year of construction: 2024, condition: used, Audoli & Bertola / Gruppo Aturia VHL 382/2 Industrial Vertical Pump with ABB 110 kW Motor Heavy-duty industrial vertical pump manufactured by Audoli & Bertola, a division of Gruppo Aturia S.p.A., complete with a large ABB electric motor. The pump's nameplate indicates a manufacturing date of 11/2024. Pump specifications: Manufacturer: Audoli & Bertola Division: Gruppo Aturia S.p.A. Type: VHL 382/2 Capacity: 317 m³/h Head: 28 m Speed: 1450 rpm Power: 110 kW Year: 11/2024 CE marked Configuration: Vertical industrial pump Crjdpfoz Di Nwex Adreh Large flanged connections ABB electric motor: Manufacturer: ABB Type: M3BP 315SMA 4 V1 Power: 110 kW Year: 2003 Frequency: 50 Hz Speed: approx. 1486–1488 rpm Protection class: IP55 Insulation class: F Duty: S1 Product code: 3GBP312210-BDG Vertical mounting configuration The pump is offered as a complete assembly with the ABB 110 kW electric motor, as shown in the pictures. Condition: Used industrial surplus Location: Rotterdam, The Netherlands The equipment is available from stock and can be inspected before purchase. This equipment is industrial surplus and is sold as-is, without warranty or claims. Please contact us for further information or to submit an offer.

Condition: used, Year of construction: 2008, machine/vehicle number: LV082, overall weight: 44,000 kg, Pittler PV1250 Vertical Turning Machine/Drill. Weight 44,000 kg. Condition Machine needs work. Delayed removal unit will be ready for removal by the end of September. Csdpfez Hb U Rox Adrjrh Buyer responsible for removal, contractor must be licensed and insured.

Condition: excellent (used), Horizontal/vertical rotary table Chuck: Ø 350 mm Shelf diameter: Ø 400 mm Height without mandrel: 140 mm Total height: 250 mm Base dimensions: Length 430 mm x Depth 370 mm Weight: approx 150 kg Crodpfsz I A I Ujx Adrsh Possibility to work horizontally or vertically The increment is done by the front handle

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 11 Cjdpfxjwuclxj Adrorh

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, controller manufacturer: MITSUBISHI, spindle speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 300 mm Travel range, Y-axis: 250 mm Travel range, Z-axis: 250 mm Spindle speed range: 60–15,000 rpm Spindle speed control: stepless Tool changer: vertical Magazine capacity: 12 Tool interface: SK 30 Workpiece clamping area: 400 × 250 mm MACHINE DETAILS Control system: MITSUBISHI Jaw width: 100 mm EQUIPMENT Fixed angular table Dual-pallet changer 4 × Allmatic vices Various tool holders SK 30 Electronic handwheel Full-protection enclosure with sliding doors and interior lighting Coolant system with paper band filter Coolant system Two-color signal light Chip conveyor Codpfxjz Hxb Us Adrerh 6 × Machine feet Operating manuals

Condition: used, machine/vehicle number: 008700, X axis working area: 3050 mm Y axis working area: 1300 mm Main Electrospindle power: 7.5 KW Crodozq Ur Hepfx Adrjh Number of controlled axes: 3 axes Total number of drilling spindles: 52 Total number of tool changer positions: 6

Condition: not inspected (used), Year of construction: 2003, Vertical CNC milling machine MORI SEIKI NV500A/50 (2003) at auction. MSG-501 control, X-axis travel 800 mm, table 1,100 x 600 mm, 30-tool magazine, spindle up to 8,000 rpm, machine weight approx. 6,700 kg. Used CNC mill Crjdpfoz I Ebqox Adrsh

Condition: ready for operation (used), Year of construction: 2013, operating hours: 10,649 h, functionality: fully functional, machine/vehicle number: 101161, travel distance X-axis: 1,020 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 920 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 14,000 rpm, A new spindle was installed one year ago! TECHNICAL DETAILS Travel in X-axis: 1,020 mm Travel in Y-axis: 620 mm Travel in Z-axis: 920 mm Swivel range of B-axis: +30° to -120° Spindle speed range: 1–14,000 rpm Tool holder: SK 40 Tool magazine capacity: 40 Clamping surface of rotary table: 1,200 × 610 mm Diameter of rotary table: 500 mm Crsdpjz Hwutofx Adroh MACHINE DETAILS CNC control: Heidenhain iTNC 530 Operating voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Power: 75 kVA Rated current: 100 A Main fuse: 120 A Machine weight: 8,740 kg Operating hours (according to counter) Spindle running time: 10,649 h Program running time: 11,159 h Machine operating hours: 24,317 h Control operating hours: 26,901 h EQUIPMENT Fixed rotary table NC rotary table WALTER B-axis swivel head with torque drive Vertical tool changer 3D measuring probe Heidenhain Electronic handwheel Fixed full protective enclosure with interior lighting Internal cooling system Coolant system Oil mist extraction Chip conveyor Operating manual

Condition: ready for operation (used), Year of construction: 2006, operating hours: 3,010 h, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, controller model: Fanuc Oi-MC, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,000 mm Travel range, Y-axis: 530 mm Travel range, Z-axis: 510 mm Table length: 1,200 mm Table width: 510 mm Orientation: Horizontal Tool interface: ISO 40 Max. spindle speed: 10,000 rpm Cedpfsz Ebb Usx Adrjrh Tool positions: 24 MACHINE DETAILS Control: CNC Control system: Fanuc Oi-MC Number of axes: 3 Power: 11 kW Dimensions & Weight Dimensions (L x W x H): 2,850 x 2,150 x 2,300 mm Net weight: 6,000 kg Shipping packages: 3 Operating hours: 3,010 h EQUIPMENT Spindle cooling Documentation CE marking External cooling Tool magazine Chip conveyor Tools included

Condition: ready for operation (used), Year of construction: 2003, machine/vehicle number: 212062, functionality: fully functional, cutting height (max.): 1,550 mm, cutting width (max.): 3,300 mm, saw blade diameter: 250 mm, overall weight: 1,250 kg, plate height: 55 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum vertical cutting height: 1,550 mm Maximum horizontal cutting height: 1,510 mm Maximum cutting width: 3,300 mm Maximum cutting depth: 55 mm Maximum saw blade diameter: 250 mm Crjdpfx Adjz Eav Rersh MACHINE DETAILS Voltage: 400 V Current consumption: 6 A Fuse rating: 16 A Power: 2.2 kW Shipping packages: 1 unit Dimensions & Weight Dimensions (L x W x H): 4,510 x 1,450 x 2,300 mm Unladen weight: 1,250 kg FEATURES CE marking Horizontal cutting Vertical cutting

Condition: ready for operation (used), Year of construction: 2001, machine/vehicle number: 31 504, functionality: fully functional, cutting height (max.): 2,200 mm, cutting width (max.): 5,300 mm, saw blade diameter: 300 mm, overall weight: 700 kg, plate height: 80 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Crodsz Ea Imepfx Adrsh Maximum vertical cutting height: 2,200 mm Maximum horizontal cutting height: 2,100 mm Maximum cutting width: 5,300 mm Maximum cutting depth: 80 mm Saw blade diameter: 300 mm Saw blade bore: 30 mm MACHINE DETAILS Voltage: 400 V Current draw: 10 A Fuse rating: 16 A Power: 4.4 kW Shipping packages: 1 unit Dimensions & Weight Dimensions (L x W x H): 6,660 x 2,070 x 3,010 mm Weight: 700 kg FEATURES CE marking Horizontal cutting Vertical cutting

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: Fanuc Series 18-M, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 500 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 500 mm Rapid traverse rate, X-axis: 30,000 mm/min Rapid traverse rate, Y-axis: 30,000 mm/min Rapid traverse rate, Z-axis: 30,000 mm/min Table length: 650 mm Table width: 500 mm Spindle speed: 10,000 rpm Speed ranges: 2 Spindle interface: ISO 40 Tool positions: 30 Tool selection: Random MACHINE DETAILS Control system: Fanuc Series 18-M Coolant pressure: 20 bar Dimensions & Weight Dimensions (L x W x H): 3,140 x 2,090 x 2,900 mm Codoz Ir Iwepfx Adrsrh Weight: 7,000 kg

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 610 mm, controller model: WinMax, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 762 mm Travel range, Y-axis: 508 mm Travel range, Z-axis: 610 mm Spindle speed: 12,000 rpm Table area: 1,020 × 510 mm Cedpfxez Ahx Ds Adrerh Table load capacity: 1,500 kg MACHINE DETAILS Control system: WinMax EQUIPMENT Internal cooling system (ICS) Fourth axis

Condition: ready for operation (used), Year of construction: 2004, operating hours: 19,357 h, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, controller model: Siemens Sinumerik 810D, spindle speed (max.): 9,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Number of axes: 4 Travel in X-axis: 1,600 mm Travel in Y-axis: 400 mm Travel in Z-axis: 400 mm A-axis: 360° × 0.001° A-axis speed: 20 rpm Spindle speed: 0–9,000 rpm Speed control: stepless Tool interface: DIN 69871 SK40 Working feed rate: 5–28,000 mm/min Rapid traverse rate X/Y/Z-axis: 28,000 mm/min Table design: Bridge table with 4 sides Table length: 1,800 mm Table width: 113 mm Table load capacity: approx. 150 kg Magazine design: Chain magazine Magazine capacity: 44 Max. tool diameter: approx. 70 mm Max. tool diameter with free adjacent positions: approx. 200 mm Max. tool length: approx. 240 mm Max. tool weight: 5 kg Max. total weight of tool magazine: approx. 200 kg Tool change time: approx. 8 s MACHINE DETAILS Control system: Siemens Sinumerik 810D Total power consumption: 14 kW Dimensions & Weight Dimensions (L x W): approx. 6,500 x 3,500 mm Machine weight: approx. 9,000 kg Operating hours: 19,357 h EQUIPMENT Second milling spindle Crodpjz Izdhjfx Adreh Exchangeable milling spindle Coolant system (coolant tank: approx. 480 l) Internal cooling External cooling Clefil RBF-E100 unit (coolant pressure: 20 bar) Clamping system Hydraulic clamping options in the machining area Pneumatic clamping options in the machining area Römheld hydraulic unit (max. hydraulic pressure: 500 bar) Additional equipment Chip conveyor Coolant nozzle in the machining area Enclosed work area enclosure according to UVV Automatic measuring probe RWP20.00 Various SK40 tool interfaces Technical documentation Layout plan

Condition: good (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 2882-0275, travel distance X-axis: 1,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 700 mm, controller manufacturer: Deckel Maho, controller model: Dialog 112, workpiece length (max.): 1,250 mm, workpiece width (max.): 800 mm, workpiece weight (max.): 1,250 kg, total height: 2,900 mm, total length: 3,900 mm, total width: 4,100 mm, table width: 800 mm, table length: 1,250 mm, table load: 1,250 kg, rotational speed (max.): 8,000 rpm, overall weight: 9,100 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 10,000 W, spindle nose: SK 40, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, type of input current: AC, For sale is a vertical CNC machining center, Deckel Maho DMC 100 V, manufactured in 1998. The machine is in good condition and fully functional. Technical specifications: Manufacturer: Deckel Maho GmbH Type: DMC 100 V Year of manufacture: 1998 Serial number: 2882-0275 Travel in X-axis: 1,000 mm Travel in Y-axis: 800 mm Travel in Z-axis: 700 mm Table size: approx. 1,250 x 800 mm Table load: approx. 1,250 kg Spindle speed: up to 8,000 rpm Tool holder: SK 40 Tool magazine: 30 positions Operating voltage: 400 V / 3-phase Rated current: 70 A Weight: approx. 9,100 kg Cedpfjz I R Euox Adrorh If you are interested or have any further questions, please do not hesitate to contact us. Location: 30827 Garbsen.

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 640 mm, controller model: SIEMENS 840 D, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,100 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 640 mm Number of pallets: 2 Table size: 2 × 1,000 × 450 mm Table load capacity: 600 kg Spindle speed range: 50–10,000 rpm Drive power: 18.5 kW Tool interface: DIN 69871 / ISO 40 Feed rate range X/Y/Z: up to 10,000 mm/min Rapid traverse rate in all axes: 30 m/min MACHINE DETAILS CNC path control: SIEMENS 840 D Number of tool positions: 30 Machine dimensions & weight Machine dimensions L × W × H: approx. 3,605 × 3,041 × 3,220 mm Machine weight: approx. 6,700 kg EQUIPMENT 2-position pallet changer 30-position tool changer Internal coolant supply (ICS) Full enclosure with electrically interlocked safety doors Linear guides with double roller recirculating bearing for even absorption of high torques in all directions Csdoz Ibb Tjpfx Adrsrh Ball screws in all 3 axes Machine bed made of Meehanite cast iron for high precision, rigidity, and vibration damping Swivel chip conveyor with integrated coolant system Preparation for 4th axis CE compliant

Condition: used, Year of construction: 2006, functionality: fully functional, turning diameter: 1,000 mm, controller model: Siemens 840 D, tool length: 500 mm, number of slots in tool magazine: 44, TECHNICAL DETAILS Working area Swing diameter: 1,000 mm Crodpfoz Hmc Tox Adrjh Swinging diameter: 1,000 mm Z-axis travel: 900 mm MACHINE DETAILS Control system: Siemens 840 D Tool holders: SK 50, VDI 60 Tool magazine: 44 positions Tool weight: max. 35 kg Tool length: max. 500 mm
