Used Zangheri&Boschetti Multispindle Drill for sale (4,931)

Condition: good (used), Year of construction: 2003, NAGEL MODEL TBT M320-6 6 SPINDLE CNC HORIZONTAL GUN DRILL, 2003 Equipped with: Panel Mate Power Pro Control Counter Rotation Cross Drilling High Pressure Coolant System Auto Loader Magnetic Chip Separator Hydraulic System Iodpfortrztjx Ab Njib Chiller Specifications: Maximum Drill Depth (Approx): 16" Maximum Drill Length: 36" Number of Drill Spindles: 6 Spindle Motors (3): 7.5HP HP Per Spindle: 3.75 Drill Head Slide Stroke: 16.9" Maximum Diameter Mild Steel: 0.750"

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Iisdortrx Repfx Ab Njb Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw Isdpfx Abew Nytne Neib - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 - Number of tool positions: 5

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle adaptor MK 3 - right - left rotation Ijdpfx Abjdkx Ane Nsib - Drilling spindle stroke 150 mm - drilling spindle speed infinitely variable 80 - 1170 rpm - 2 feeds 0,1 / 0,2 mm/rev - throat 290 mm - max distance table - drilling spindle 780 mm - table with 2 T-slots 480 x 400 mm - Height adjustable via toothed rack with hand crank - Drive 400 V / 0,9 / 1,3 kW - Space requirement approx. W 600 x H 2100 x D 900 mm - Weight approx. 420 kg - with: - coolant device - quick-action drill chuck 1-13 - illumination

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm Ijdpfev S Iqcox Ab Njib total power requirement 4 kW

Condition: used, functionality: unexamined, W.J. Meddings Ltd. Meddings Bench Pillar Drill – Industrial Precision Drilling Machine Heavy-duty industrial bench-mounted pillar drill manufactured by W.J. Meddings Ltd., Slough, England. Renowned for precision engineering and durability, Meddings drills are widely regarded as some of the best British-built workshop drilling machines. This compact industrial drill is ideal for precision drilling, fabrication, toolroom work and engineering applications. Machine Details: Manufacturer: W.J. Meddings Ltd. Country of Manufacture: England Machine Type: Bench Pillar Drill Multi-speed belt-driven spindle Industrial cast iron construction Adjustable work table Single-phase electric motor fitted Features: Heavy-duty industrial build quality Adjustable spindle speed via pulley system Precision drilling head Adjustable table height and positioning Compact workshop footprint Guarded spindle/chuck area Smooth manual feed operation Reliable Meddings engineering design Applications Suitable for: Engineering workshops Fabrication shops Toolrooms Metalworking Maintenance departments Precision drilling operations Small production work General industrial use Condition: Good used industrial condition with cosmetic signs of workshop use and surface wear consistent with age. complete and operationally intact. Included: Meddings bench drill Adjustable work table Installed motor Chuck assembly Guards and fittings shown in photographs Shipping & Collection Inspection welcome by appointment. Isdpfoy Shx Eex Ab Njib Forklift loading available. Pallet delivery can be arranged at buyer’s cost.

Condition: used, functionality: fully functional, power: 3.68 kW (5.00 HP), input voltage: 380 V, type of input current: three-phase, Microcut Vertical Turret Milling Machine – 5HP Iiodpfx Abey R Ebne Nob Microcut vertical turret milling machine manufactured by Buffalo Machinery Co. Ltd, Taiwan. Heavy duty industrial machine fitted with power feeds, coolant system and machine vice. Model: 5VK type with 5HP motor and 380V 3 phase supply. Suitable for precision engineering, fabrication, maintenance workshops, toolrooms and general machining work. Features include: Vertical turret milling head Large T-slot table Power feed controls 5HP motor 380V 3 phase Machine vice included Coolant tray and lubrication system Variable speed head Heavy cast iron industrial construction Machine is in good used workshop condition with normal cosmetic wear from industrial use. It is complete and operational. Ideal for engineering shops, maintenance departments and production work. Loading available on site. Transport can be arranged. Viewing welcome. Open to sensible offers.

Condition: used, functionality: fully functional, ELLIOTT PROGRESS NO.3A PILLAR DRILL - HEAVY DUTY INDUSTRIAL Robust British-made industrial pillar drill suitable for workshop, fabrication, or engineering use. Make: Elliott Model: Progress no. 3A Type: Geared head Pillar Drill Iisdpfey N Tikjx Ab Njb Power: 440v, 3-phase Features: Heavy duty cast construction geared speed selection (approx. 110-1780 rpm) large adjustable table industrial capacity machine Condition: Used complete and in original condition

Condition: excellent (used), Year of construction: 2019, HD-SFVO 412-S HBE 320/523 G- YEAR 2019. Marking-drilling-milling-shearing & sawing line Iiodpfxoy R Tk Ro Ab Njb HD-SFVO 412-S DRILLING CAPACITY. Flat bars: 50x10 to 400x30 Angles: 50x50x5 to 250x250x20 IPN-IPE: 80 to 400 HEA-HEB: 100 to 400 UPN-UPE: 80 to 400 Square and rectangular tubes: 50x50 to 300x300x20 HBE 320/523 G SAWING MACHINE. Effective cross-section (mm): 90°: 400x300 Bevel cut, left pivot (W x H, mm): 75°: 400x300 60°: 400x300 45°: 330x300 30°: 200x300 Bevel cut, right pivot (W x H, mm): 75°: 400x300 60°: 400x300 45°: 310x300 Power supply: • Three-phase 400V ± 15 V + ground, 50Hz • Installed power: 40 kVA Compressed air: • Minimum pressure: 6 bar • Maximum flow rate: 3 Nm³/h Operating temperatures: • From 10°C to 40°C Milling unit specially designed for machining small square or rectangular tubes (slotted holes, shaped cuts, etc.). With the engraving equipment: ability to engrave letters or numbers for part identification. Allows, among other things, marking of tubes with sufficient depth to ensure legibility after painting or galvanizing Secure holding of the bar during milling: the bar is clamped in the movable vice system to ensure proper machining while minimizing vibrations. Improved positional tolerance of one hole relative to another within a group of holes (within a maximum length of 150 mm) Additional features Cycle for centre punching, countersinking, tapping, deburring, and chip breaking Automatic measurement of tool length (HSS) Side and centre tool cooling 230-ton shear Feature Mobile hydraulic shear Straight cut Average cutting time: approximately 2 to 2.5 seconds Capacities: HEB 140 IPE 300 IPN 280 Angle bars 150x150x18 L 200x100x14 UPE 300 UPN/UPAF 300 Flat bars 300x20

Year of construction: 2010, condition: good (used), Double mitre saw DGS400 for 45° (frame) cuts with digital left stop. Drilling or dovetail milling machine T20NC for frame assembly. 4 motors at 1.1 kW. Speed: 26,500 rpm. Direction of rotation: right and left. Milling cutter / drill bit. Iisdpfx Aexxytxsb Njb

Condition: ready for operation (used), Year of construction: 1994, overall weight: 7,000 kg, Arm length 1800 mm, drilling capacity 80 mm, weight 7000 kg Iisdpfx Absyzq Dpj Nsb

Condition: used, Year of construction: 1991, bore capacity in steel (diameter) / mm throat / mm bore stroke / mm Iiedpfx Ajy S Dvmjb Nob total power requirement 1,5 kW

Condition: used, Year of construction: 2000, number of spindles / bore capacity in steel (diameter) / mm bore stroke / mm Iedpfx Aoy S Dm Sjb Neib BD13M – 5-Spindle Gang Drill / Bench Drill

Condition: used, Year of construction: 1981, machine/vehicle number: 800 02 81 46, type of input current: three-phase, Specialized EDM drill (eroding machine / hole starter EDM machine) Iiodpfxey Su Iys Ab Njb This machine is primarily used in metalworking as a hole starting EDM machine or for spark eroding the removal of broken tools (such as taps, drills, or reamers) from valuable workpieces. This is done with extreme precision without damaging the surrounding thread or material.

Condition: new, functionality: fully functional, Key features of the DOOSAN T4005 Drill Tap Center may include: Iijdpjy Sv Tqefx Ab Nob High Precision: The DOOSAN T4005 Drill Tap Center is engineered for precise drilling and tapping results, delivering consistent quality in manufactured components. High-Speed Spindle: Featuring a powerful, high-speed spindle, the machine efficiently processes various materials—such as metals, plastics, and composites—while maintaining productivity. Multi-Axis Capability: Many DOOSAN T4005 models are equipped with multiple axes, enabling complex machining operations and greater flexibility in component production. Automatic Tool Changer: The machine often includes an automatic tool changer, allowing for smooth transitions between different tools and minimizing setup times to enhance efficiency. User-Friendly Interface: The CNC system typically offers an intuitive user interface, simplifying programming, process monitoring, and operation for users at all experience levels. Robust Construction: Designed for industrial use, the machine is built with high-quality materials and components to ensure durability and continuous operation. Customization Options: Depending on the manufacturer, the CNC machine may offer various customization options to adapt to specific machining or production requirements.

Condition: good (used), Year of construction: 1982, Drilling diameter: 50 mm, gray cast iron: 60 mm Maximum spindle-guide distance: 1600 mm Vertical arm travel: 875 mm Carriage travel on the arm: 1280 mm Arm rotation: 180° Morse 5 spindle taper Spindle stroke: 310 mm Number of spindle speeds: 16 Ijdpfx Abswlh E So Nsib Maximum spindle torque: 31,000 Nm Mounting surface: 1820 x 986 mm Dimensions: 3100 x 1120 x 3396 mm Weight: 4300 kg

Condition: good (used), Rotary hammer, chisel hammer, combination hammer, Bosch hammer, cordless rotary hammer -Manufacturer: Bauhaus Toolson, Cordless drill/driver type PRO-AS 18 Li-1 -Includes: charger and 1x battery -Number: 4x drill drivers available Price: per piece -Transport dimensions: 240/180/H240 mm Total weight: 1.9 kg/pc. Iijdpfx Abouwgg De Njb

Condition: used, Line boring machine WEBO with 4 stations type B 20 make no. 376/13; 376/14; 376/27; 376/36 year of construction approx. 1970 drilling capacity 20 mm spindle adaptor MK 2 - long spindle sleeve drilling head distance 335 mm Iedpfoihmwtsx Ab Nsib throat 260 mm pinol stroke 190 mm table size 350 x 1500 mm distance drilling spindle/table min.30 mm / max. 700 mm Spindle speed drill head 376/13 355, 500, 710, 1000, 1400, 2000, 2800, 4000 rpm. Spindle speed drill head 376/14 355, 500, 710, 1000, 1400, 2000, 2800, 4000 rpm. Spindle speed drill head 376/27 250, 355, 500, 710, 1000, 1400, 2000, 2800 rpm. Spindle speed drill head 376/36 180, 250, 355, 500, 710, 1000, 1400, 2000 rpm. Motor power 1,1 / 1,3 kW Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 4 V-belt steps - drill head height adjustment via toothed rack and hand crank approx. 300 mm - height adjustable drilling table approx. 350 mm space requirement L x W x H 1750 x 1100 x 1900 mm weight 1900 kg good condition

Condition: used, Vertical milling head, milling head with motor drive THIEL Tool holder: MK 5 (Morse taper size 5) Quill stroke, spindle travel: 80 mm Spindle speed at motor speed 1410 rpm = 490 / 780 / 1200 rpm. Spindle speed at motor speed 2950 rpm = 970 / 1530 / 2380 rpm. Spindle bore: 37 mm Motor power: 1.4 / 1.8 kW Motor speed: 1410 / 2850 rpm Power connection: 400 Volt, 50 Hz Iisdpfexddwrjx Ab Njb - Spindle speed via 2 motor speeds and 3 belt stages - Mounting flange milling head Ø 215 mm with 2 bores Ø 15 mm, hole spacing 180 mm - suitable for tools with drawbar thread (ejector tang interferes with clamping) Required space L x W x H: 450 x 400 x 350 mm Net weight: 61 kg Good condition

Condition: used, Column Drilling Machine INFRATIREA - ORADEA Type PH - 031 Serial No. Year of manufacture 1975 Drilling capacity 40 mm Spindle taper MK 4 - short quill Throat depth 320 mm Ijdpfx Abstrpifj Neib Quill stroke 250 mm Table size 400 x 400 mm Column diameter 160 mm Spindle speed 85 - 1500 rpm, 6-speed gearbox Motor power 2.2 kW Power supply 400 Volt, 50 Hz - Spindle speed adjustable over 6 gear steps - Right and left-hand rotation - Automatic feed 0.10 - 0.16 - 0.25 - 0.4 mm/rev - Swivel drill table - Table height adjustment via hand crank - Clamping surface on machine base - Coolant pump integrated in base Required space L x W x H 1000 x 600 x 2450 mm Weight 700 kg

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, ALZMETALL AX 4 / SV pillar drilling machine 3KW Manufacturer: Alzmetall Type: AX 4 / SV Condition: NEW Iijdey S Axgjpfx Ab Njb Year of manufacture: 2025 Drilling capacity steel E335 (St 60) 55 mm Thread cutting Steel E335 (St 60) M 42 Cast EN-GJL-200 M 56 Short spindle MK 4 Spindle stroke 140 mm Usable projection 300 mm Column diameter 145 mm Machine table, usable support 615 x 430 mm Distance spindle-table min./max. 150/735 mm T-slots, number x width x distance 2 x 14 x 224 mm Feed 0.1 + 0.3 mm/rev Machine height approx. 1850 mm Net weight approx. 380 kg Drive stepless Motor 1500 rpm Power 3.0 kW Spindle speed rpm 70-2400 Standard equipment: Main switch with motor protection switch, lockable Mushroom push button (latching) for EMERGENCY STOP Speed adjustment stepless Speed display digital Feed overload protection Protection class IP 54 Spindle protection with electrical protection Paint: DD structural paint signal white RAL 9003, PANTONE 7545c, black Machine oil: initial filling; Container supplied loose Available options: - LED machine light - Thread cutting device with soft start (from 2025) - Coolant device in the base - Digital drilling depth display - Drilling depth fine adjustment 0.1 mm

Condition: new, ALZMETALL column drilling machine Alzstar 23 S Manufacturer: Alzmetall Type: Alzstar 23 S Condition: NEW Drilling capacity steel E335 (St 60) 23 mm Thread cutting Steel E335 (St 60) M 14 Cast EN-GJL-200 (GG20) M 16 Short spindle MK 2 Spindle stroke 100 mm Thrust 250 mm Ijdpfsy S Avlox Ab Neib Column diameter 90 mm Machine table, usable support 370 x 300 mm T-slots, number x width x distance 2 x 14 x 160 mm Distance spindle-table min./max. 140/670 mm Hand feed Machine height without options approx. 1770 mm Net weight approx. 175 kg Drive stepless Motor 750 / 1500 rpm Power 0.6 / 0.95 kW Spindle speed rpm 225-4300 Standard equipment: Mushroom push button (latching) for EMERGENCY STOP Reversing switch for clockwise and counterclockwise rotation Motor protection switch Stepless speed adjustment Digital speed display Protection class IP 54 Connection plug (fully assembled, cable length 2m) Spindle protection with electrical fuse Paint: DD structural paint light gray RAL 7035, anthracite RAL 7016

Condition: new, ALZMETALL Alzstar 18-T/S, Manufacturer. Alzmetall Type: Alzstar 18-T/S Condition: New Drilling capacity in St 60: 18 mm, Thread cutting in St 60: M 12, Thread cutting in GG 20: M 14, Short spindle: MK 2, Spindle speed: 225-4,300 rpm, Spindle stroke: 80 mm, Throw: 190 mm, Column diameter: 65 mm, Machine table - usable support: 300x240 mm, T-slots number - width - distance: 2 x 12 x 80 mm, Distance spindle-machine table min./max.: 75/357 mm, Machine base plate usable support: 300x240 mm, T-slots number - width - distance: 2 x 12 x 80 mm, Distance Spindle base plate min./max.: 437/437 mm, Feed by hand, Machine table height adjustment: hand crank, Total power requirement: 0.37/0.55 kW, Machine height: 840 mm, Weight: 110 kg Standard equipment: Main switch with motor protection switch, lockable Reversing switch for clockwise and counterclockwise rotation Infinitely variable speed adjustment Protection class IP 54 Mushroom push button (latching) for EMERGENCY STOP Spindle protection with electrical protection Optional: - LED machine light - Under table Isdpfoy S Au Ujx Ab Nsib - Drill chuck 1-13 or 3-16 Available now. For self-collection. Forklift available. Shipping also possible Subject to errors, changes and prior sale. Other Alzmetall table drilling machines and pillar drilling machines always in stock!

Condition: new, ALZMETALL AX3/SV pillar drilling machine NEW Manufacturer: Alzmetall Type: AX3 SV Condition: New Drilling capacity steel 40 mm Thread cutting steel M24 Cast M30 Short spindle MK 3 Spindle stroke 120 mm Isdjy S Auzspfx Ab Njib Usable projection 293 mm Column diameter 115 mm Machine table 515 x 360 mm Distance spindle-table 117/701 mm T-slots 2 x 14 x 224 mm Feed 0.1 + 0.2 mm/rev Machine height approx. 1840 mm Net weight approx. 270 kg Drive continuously variable Motor 750/ 1500 rpm Power 1.0 / 1.6 kW Spindle speed rpm 80-1125 Additional equipment: - Reversing switch - Machine light LED - Thread cutting device - Coolant device B Available immediately from stock

Condition: new, As a machine dealer in Offenburg, we have new and used ALZMETALL table drilling machines and column drilling machines in our range. You can find an overview of the drilling machines on our homepage. If you have any questions, just call us. Here we offer the new series of ALZMETALL pillar drilling machines with TOUCH display: ALZMETALL AX3 iTRONIC-V pillar drilling machine Condition: NEW Standard equipment 7“ TFT - LCD display with touch function: - Manual input of spindle speed setpoint - Speed display actual value - Integrated drilling depth display with touch zero point transfer - Virtual drilling depth scale in the display - Machine status displays and warnings in the display - Service information - Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Continuous speed setting using adjustment lever - Spindle protection with electrical protection - Three separate buttons for clockwise rotation - anti-clockwise rotation - stop - Mushroom push button (latching) for EMERGENCY STOP - Lockable main switch - Clockwise and anti-clockwise rotation via contactor control - Control voltage 24 volts - Protection class IP 54 - Paint finish: DD structural paint signal white RAL 9003, PANTONE 7545c, black Technical data: Manufacturer: ALZMETALL Type: AX 3 iTronic-V Drilling capacity steel E 335 (St 60) (mm): 40 Thread cutting steel E 335 (St 60): M 24 Thread cutting cast iron EN-GJL-200 (GG 20): M 30 Short spindle: MK 3 Spindle stroke (mm): 120 Iodpfoy S Auuex Ab Njib Usable projection (mm): 293 Column diameter (mm): 115 Machine table (mm): 515 x 360 T-slots (mm): 2 x 14 x 224 Distance spindle-table (mm): 117 / 701 Feed: 0.1 + 0.2 mm/rev Machine height (mm): approx. 1840 Drive: stepless Speed range (r/min): 160 - 2250 Motor (kW): 1.45 / 1.9 Weight (kg): approx. 270 Special equipment included: - Foot switch in addition to the thread cutting device Other options can be retrofitted: - LED machine light - Coolant system B - Technology calculator in the display - Maximum drilling depth display Optional accessories: - Machine vice size 3/125mm BB type BON3 - Machine vice size 4/160mm BB type BON4 - Keyless drill chuck Supra 1-13mm or 3-16mm MK3 Available at short notice. For self-collection. Forklift available. Shipping also possible Subject to errors, changes and prior sale. Not the right machine? Then please contact us.
