Used Diamond Grinding Pins for sale (9,054)

Condition: used, Year of construction: 2001, functionality: fully functional, OKAMOTO ACC 64 DX Surface Grinding Machine Year: 2001 Servo Automatic Downfeed Lrsdjzv Ef Uspfx Aa Rsr Electromagnetic chuck Coolant filtraion system

Condition: excellent (used), PERFECT PFG-70150AHRD Surface Grinding Machine Lsdpfx Aaozuxt Aj Rjrr Year 2014 Table size 700 x 1500 mm Maximum longitudinal travel 1650 mm Maximum cross travel 760 mm Maximum distance table surface to spindle centre 600 mm Table speed 5 – 25 m/min Magnetic chuck size 700 x 1500 mm Spindle speed 1450 rpm Spindle motor 7.5 kW (10 HP) Grinding wheel size 355 x 40 x 127 mm Floor space required 4810 x 2550 mm Weight 7800 kg Supplied with: Automatic Downfeed System, 1500 x 700 mm Electromagnetic Chuck, Demagnetising Unit, 2 Axis Digital Readout, Remote Handwheel, Spindle Motor Speed Inverter Control, Automatic Paper Strip Filter & Magnetic Separator, Machine Pads & Levelling Bolts, Low Voltage Work Light. For sale with Jet Machinery Ltd Jet Machinery Stock No: #27039 Machine Serial Number: 1485022 Cost: £49,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 2003, CNC External Cylindrical Grinding Machine: total connected load 67 kW, voltage 3x400V 50Hz, nominal current 121A, weight approx. 9500 kg Lrjdezwf Uxepfx Aa Rjr Data Kelvin Chiller (Model KRA45): serial number 0304666, year 2003, cooling capacity 4500W Data Ritz Coolant Pump (Type F2506): serial number 3196140, manufactured in 1994, 2.9kW

Condition: used, Year of construction: 2003, Machine no.: 675157 Max. weight: approx. 3,500 kg (approx. 4,300 kg incl. packaging) Supply/working voltage: 3x400 V, 50 Hz Control voltage: 24 V Nominal current: 20.5 A Main fuse: 25 A (T) CNC control: GE Fanuc Series 21i-T Grinding wheel speed indicator: make EWL, type 4444 Max. peripheral grinding wheel speed: 30 m/s (ø300 mm/12"), 40 m/s (ø400 mm/16"), 45 m/s (ø450 mm/18") Grinding head drive power: 5.0 kW Grinding wheel head R (left-mounted wheel): approx. ø450 x 80 mm Grinding wheel head RS (right-mounted wheel): approx. ø450 x 80 mm Grinding wheel head UR: left standard approx. ø400 x 63 mm, left max. (option) approx. ø400 x 80 mm, right additional max. (option) approx. ø300 x 40 mm; internal grinding attachment bore approx. ø80 mm Sub-table (Z-axis): distance between centers approx. 1000 mm, max. travel approx. 1150 mm, max. speed 12 m/min, resolution approx. 0.1 µm Top table swivel range (at 1000 mm centers): 0 to +6° (0 to +9° with workpiece length under approx. 800 mm) Grinding carriage (X-axis): max. travel approx. 320 mm, max. speed 6 m/min, resolution approx. 0.1 µm Pneumatics: min. connection pressure 6 bar, air consumption approx. 2.5 m³/h Drive motors: X-axis slide 2000 rpm/0.3 kW; grinding spindle (R/UR, ø400 mm wheel) 800-1900 rpm [40-95 Hz]/5.0 kW; sub-table (Z-axis) 2000 rpm/0.3 kW; workpiece headstock 2000 rpm/1.0 kW; automatic indexing (UR machine) 3000 rpm/0.5 kW; lubrication/hydraulic pump 1500 rpm [50 Hz]/0.12 kW or 1800 rpm [60 Hz]/0.15 kW Noise emission: equivalent continuous sound pressure level approx. 70 dB(A) Ambient conditions: max. room temperature +40°C, max. humidity 75% Data Coolant Filtration Unit Lodpfszwf R Tsx Aa Rjrr Max. connection pressure: 3 bar / 1 bar (two circuits) Max. flow rate: 80 l/min / 160 l/min (corresponding to the two circuits)

Condition: used, Year of construction: 2003, Surface and Profile Grinding Machine table clamping surface approx. 600 x 250 mm grindable workpiece area (including 25 mm wheel width) approx. 600 x 300 mm max. permissible table load including magnetic plate approx. 130 kg height above floor approx. 1085 mm main spindle drive speed range 800-4200 rpm drive power 10 kW cutting speed 35 m/s grinding wheel diameter 300 mm, width 25/30 mm, bore 76.2 mm X-axis pendulum grinding travel speed (hydraulic, infinitely variable) 1000-24000 mm/min X-axis creep-feed grinding travel speed (AC servo motor) 5-1000 mm/min usable pendulum stroke 630 mm machine weight approx. 3400 kg, total weight approx. 3800 kg electrical supply 400V, 3-phase, 50Hz, rated current 30A, connected load 16kVA, supply fuses 35A Lodpfx Ajzwfzloa Rjrr

Condition: used, Year of construction: 2004, CNC Surface Grinding Machine CNC control Siemens Sinumerik with handwheel, GRIPS 32 control software spindle drive motor type MS501/5 machine weight approx. 2300 kg, total weight approx. 3500 kg electrical supply 400V, 3-phase, 50Hz, rated current 29A, connected load 20kVA, supply fuses 50A Table clamping surface (standard): approx. 500 x 250 mm, other sizes available upon request Grindable workpiece area incl. 25 mm wheel width: approx. 600 x 300 mm Grindable workpiece area with VJCE cover incl. 25 mm wheel width: approx. 600 x 290 mm Lrsdpfxezwfmhj Aa Ror Distance from table top to upper limit switch (Y) at 250 mm wheel diameter: approx. 366 mm Max. permissible table load incl. magnetic plate: approx. 130 kg Height above floor: approx. 1085 mm Main spindle drive speed range: 800-4200 rpm, other options available upon request Main drive power: 10 kW at max. rpm, option 5 kW at max. rpm Cutting speed: 35 m/s, other options available upon request Grinding wheel diameter: 300 mm, option 250 mm Grinding wheel width: 25/30 mm, option 50 mm Grinding wheel bore: 76.2 mm, option 50.8/51 mm available upon request Radial wheel wear allowance: approx. 45 mm X-axis pendulum grinding speed (hydraulic, infinitely variable): 1000-24000 mm/min X-axis creep-feed grinding speed (AC servo motor): 5-1000 mm/min X-axis travel between limit switches: approx. 660 mm X-axis usable pendulum stroke: approx. 630 mm Y-axis travel speed: 0.1-2000 mm/min Y-axis travel between limit switches: approx. 360 mm Y-axis measuring system resolution: 0.0002 mm Z-axis travel speed: 0.1-2000 mm/min Z-axis travel between limit switches: approx. 280/275 mm Z-axis travel between limit switches with JC/JCE cover: approx. 270/265 mm Z-axis measuring system resolution: 0.0002 mm Installation length: approx. 3400 mm Installation width: approx. 2700 mm Installation depth (without control pendant): approx. 2440 mm Machine weight without full enclosure and control cabinet: approx. 3000 kg Machine weight with full enclosure and control cabinet: approx. 3700 kg Supply voltage: 400V AC -5% to +10%, 50 Hz, option 60 Hz Control voltage: 230V AC / 24V DC Connected load at 5 kW / 10 kW grinding power: 13.5 / 20 kVA Fuse protection: 35 A Data Cooling Unit (Erba/Schüler): equipment no. 85056334 Data Cooling Unit (Hyfra Pedia TRK 20-EF): equipment no. 85056333, year 2004 Data Filter Unit (Airtech MFE 20-SP): serial no. 393196, year 06/2004, rated voltage 230/400V, rated current 3.0A

Condition: good (used), functionality: fully functional, Mitutoyo length measuring system, model KA 12 (for longitudinal and transverse movement) Retrofitting with a CNC control system for the draw-in device, including air conditioning unit, Center distance: 630 mm, the machine has no tailstock and was specifically used for chucking operations, Ljdpfezv Uhrex Aa Rsrr Max. grinding diameter: 280 mm, Max. grinding wheel size: 400 x 40 x 127 mm (not included in the scope of supply), Grinding spindle speed: 2040 rpm, 6 speed stages of the tool spindle: 22.4 to 280 rpm, Drive motor: 4 kW, Accuracy / smallest division value: 0.001 mm, Taper in tailstock and tool spindle: Morse 4 Largest table longitudinal travel: 760 mm, Weight between centers: 120 kg, Total power consumption: approx. 9.3 kW, Machine weight: approx. 2600 kg, Machine dimensions: L 3075 x W 1650 x H 1500 mm Year of manufacture: corresponds to the serial number: 1989 - 1991 Swiveling headstock (± 90°) and grinding head (± 45°), Hydraulic table movement and automatic feed, Cooling system, Machine lighting, Operating manual in German and electrical diagrams.

Condition: used, Technical details: grinding length: 600 mm centre height: 180 mm swing dia.: 360 mm workpiece weight: 80 kg max. dia. of grinding wheel: 500 mm grinding wheel width: 80 mm Lrsdsrkr U Eopfx Aa Rjr grinding wheel hole diameter: 203,2 mm peripheral speed: 45 m/sec There is also a 3200 liter coolant tank including cooling unit + fire extinguishing system. *

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: FPS-20-RS, Schiatti Angelo FPS 20 RS 2015 Excellent condition 10 spindle glass edging machine including cerium wheel Can dismantle and load for buyer Ledpfjzrx Insx Aa Rerr

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Verticale glass grinding line for max. glass sizes : 1500 x 3300 mm 2 vertical glass grinding machines Bottero 111 F + Kuka robot + vertical glass wasching machine Bottero Ljdpfxszvw Iue Aa Rorr min. glass size : 200 x 300 mm

Condition: used, Surface Grinding Machine BLANCHARD type 20D Shelf diameter: Ø 915 mm Shelf speed: from 5 to 27 RPM Grindstone diameter: Ø 500 mm Maxi height under wheel: 450 mm Spindle motor: 30 CV - 715 RPM Electromagnetic chuck Rapid Up/Down Voltage 220 V Tri Dimensions (L x W x H): 3700 x 2000 x 2600 mm Weight: 6 T Ledpfx Aezwgumja Rorr

Condition: used, Surface Grinding Machine HARIG Super 612 - No 1 Travel X: 300 mm Travel Y: 170 mm Travel Z: 250 mm Grinding wheel: Ø 200 mm Spindle motor: 3600 RPM Manual movement X - Y - Z Manual magnetic tray 345 mm x 145 mm Lredpfezwgr Eox Aa Rer Auto lubrication axes X and Y Delivered with 2 new grinding wheels 1 vacuum cleaner Voltage: 380 V Width: 1400 mm Depth: 1500 mm Total height: 1900 mm Weight: approx 1 T

Condition: used, Year of construction: 1986, Surface Grinding Machine MONOPRECIS 1DR - #2 Travel X: 400 mm Lodpfxozwgrrj Aa Rjrr Travel Y: 150 mm Maxi grinding height (Z): 220 mm Year of construction: 1986 Axes X - Y - Z manual Magnetic chuck: manual / tilted Magnetic chuck dimensions: 255 x 130 mm Grinding wheel dimensions: Ø max 170 mm Voltage: 380 V Dimensions (L x W x H): 1300 x 1100 x 1600 mm Weight: approx 500 kg

Condition: used, Surface Grinding Machine BURDETT type No 70 - 18" x 6" Travel X: 350 mm Travel Y: 150 mm Maxi grinding height: 180 mm Manual magnetic chuck Magnetic chuck dimensions: 350 x 150 mm Lsdpfx Aaszwgrlj Rjrr Grinding wheel dimensions: Ø 210 mm x thickness 25 mm X and Y Axes: auto pass taking Z Axe: manual Lubricant tank Voltage : 380 V Dimensions (L x W x H): 1300 x 1200 x 1700 mm Weight: approx 1 T

Condition: used, Year of construction: 1983, Surface Grinding Machine MONOPRECIS 1DR Travel X: 400 mm Travel Y: 150 mm Maxi grinding height (Z): 220 mm Year of construction: 1983 Manuel Magnetic chuck dimensions: 2500 x 130 mm Max Grinding wheel dimensions: Ø 170 mm Diamond system Manual movement Voltage: 380 V Lrsdpfxjzwgq Io Aa Rsr Dimensions (L x W x H): 1300 x 1200 x 1800 mm Weight: approx 800 kg

Condition: used, JONES SHIPMAN 1307 EIT CYLINDRICAL GRINDING MACHINE MAKE JONES AND SHIPMAN, MADE IN ENGLAND MODEL 1307 EIT CENTRE HEIGHT 185.0 mm MAX DIAMETER 370.0 mm MAX GRINDING LENGTH 1016.0 mm Lrsdpfoy Hi Epex Aa Ror MAX GRINDING WHEEL 350.0 mm x 40.0 mm GRINDING SPEED 40 – 320 RPM TABLE ROTATION 16 DEGREE TO – 12 DEGREE MAX INTENAL SPINDLE SPEED 24,000 RPM PLUS VARIABLE SPEED WORK HEAD INTERNAL SPINDLE. DOUBLE SWIVEL WHEEL HEAD. METRIC DIALS RANGE OF MAGNETIC CHUCKS PENDANT CONTROL HYDRAULIC PACK PAPER FILTRATION SYSTEM REBUILT BY ANDMAR EXTENSIVE RAGE OF TOOLING AND ACCESSORIES HYDRAULIC PACK

Condition: repair required (used), Year of construction: 1981, grinding length: 6,600 mm, grinding width: 520 mm, grinding height: 260 mm, table width: 550 mm, grinding spindle motor power: 52,000 W, We are offering this Göckel G 80 eL surface grinding machine, manufactured in 1981, which requires repair. Manufacturer: Gustav Göckel Maschinenfabrik GmbH D-6100 Darmstadt Machine type: G 80 eL Serial number: 6062 Lredpfxezvqh Uj Aa Rjr If you have any questions or would like more information, please feel free to send us a message or call us. - Grinding length: 6600 mm - Width: 550 mm - Magnet width: 300 mm - Grinding width: 520 mm - Grinding height: 260 mm - Grinding height at right angles: 150 mm - Grinding motor: 52 KW Please note: the machine is delivered without a water tank. Pumps, hoses, and accessories are included.

Condition: good (used), Year of construction: 1999, 8-spindle grinding system Electrical connection power: 17 kW/380 V/50 Hz Lsdow Sdhnjpfx Aa Rerr

Year of construction: 2018, condition: used, overall weight: 10,000 kg, total length: 2,300 mm, total width: 6,500 mm, total height: 2,400 mm, BUDERUS CNC 235 – CNC Grinding and Machining Center Machining / Spindle 2 machining areas / channels Max. machining length: 150 mm Max. swing diameter: Ø 310 mm Workpiece spindle speed: 0–3,000 rpm Spindle bore: Ø 45 mm Workpiece spindle positioning via C-axis Table speed X/Z: 0–30 m/min Motor Spindle WMZ / DVS Type: GS 205-045/17 Year of manufacture: 2014 Automation Automatic workpiece feed / conveyor system Coolant / Filtration System LIQUI-Filter GmbH Lredpfx Aaezwa Rhj Rjr System: UR1060 / MW260 / Gamma 13 Tank capacity: 2,400 l Year of manufacture: 2015 Cooling System HYFRA gamma 13-F-S Cooling capacity: 13 kW at 32 °C Year of manufacture: 2015 Measuring Technology JENOPTIK post-process measuring technology Year of manufacture: 2018 Supply Data 3 × 400 V / 50 Hz Installed power: approx. 45 kW Compressed air requirement: 15 Nm³/h at 5 bar Control: Siemens SINUMERIK 840D Travel Z-axis: 300 - mm Workpiece diameter over bed max.: 150 mm Weight approx.: 10,000 kg Dimensions (LxWxH) approx.: 2300 x 6500 x 2400 mm Travel X-axis: 1240 - mm Year of construction: 2,018 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: Free loading on truck under power: No

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Type PSG 63 – UAN Year of manufacture: 1988 Grinding length: 600 mm Grinding width: 320 mm Max. workpiece height: 500 mm Ljdezvv Rbepfx Aa Rjrr Table travel (longitudinal): 750 mm Table travel (cross): 340 mm Grinding wheel diameter: 350 mm Grinding wheel width: 40 mm Spindle speed: 1500 rpm Rapid vertical feed: 400 mm/min Power: 3.7 kW Automatic feed Magnetic chuck Coolant system Weight: 2500 kg Price: EUR 2,000—plus VAT, ex location

Condition: ready for operation (used), Year of construction: 1998, Available immediately, ex works: Console milling machine REFORM Type UF 32 Year of manufacture 1998 Table 1400 x 300 mm Lrjdpfezvv N Rjx Aa Rjr Travel distances X/Y/Z 1100/300/520 mm SK 50 Spindle speeds 31.5 – 1400 rpm Drive power 7.5 kW Digital display Hydraulic vice Weight 2.7 tons Many tools, milling cutters Price: Euro 3,000.00 plus VAT, ex works

Condition: excellent (used), functionality: fully functional, HOFMANN, Type GS-2, Max. disc diameter 600 mm Max. load capacity approx. 150 kg Balancing mandrel length 290 mm Dimensions W x D x H approx. 750 x 350 x 450 mm Weight approx. 30 kg . Lrodpszwdygofx Aa Ror Special price: EUR 500 net, packaged .

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Machining diameter: 3,000 mm Machining height: 500 mm Z-axis travel, left support: 551 mm Z-axis travel, right support: 350 mm Lrjdpezvxhvjfx Aa Rsr W-axis travel: 1,100 mm Rotation speed, left/right: 2,000 min-1 Max. table load: 6,000 kg 2x grinding supports – swiveling 2x diamond dressing tools Magnetic clamping plate by SAV Control system update in 2004 Control system: R&D MTC 2x-G

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Machining diameter: 4,200 mm Machining height: 550 mm Diameter of magnetic chuck: 4,000 mm Max. speed of rotary table: 13 min-1 Control system: SIEMENS SINUMERIK 840D PL RIGHT GRINDING HEAD Swiveling range, external: 50° Swiveling range, internal: 47° Max. grinding wheel diameter: 610 mm Max. grinding wheel height: 255 mm Max. workpiece height: 550 mm Travel – X: 2,820 mm Travel – Z: 820 mm Rapid traverse X + Z axes: 10,000 mm/min LEFT GRINDING HEAD Max. grinding wheel diameter: 610 mm Max. grinding wheel height: 255 mm Max. workpiece height: 540 mm Travel – U: 2,870 mm Travel – W: 790 mm Rapid traverse U + W axes: 10,000 mm/min Ljdpfxezvxg Sj Aa Rerr GRINDING WHEEL MAGAZINE Right magazine: Number: 5 Left magazine, number: 4 DIMENSIONS AND WEIGHTS Machine weight: approx. 143,000 kg Machine dimensions (L x W x H): approx. 13,400 x 8,945 x 4,250 mm ACCESSORIES - Automatic grinding wheel changer, left (4) & right (5) - Automatic dressing unit for both grinding heads, MARPOSS P7 - Various grinding wheels and arbors - Oil mist emulsion extraction system - Automatic balancing device - Hydrostatic guidance in all machining axes DESCRIPTION The machine is in exceptionally good condition and has only been used for the highly precise finishing of large bearings for offshore wind turbines. The machining process included grinding the inner and outer diameters, as well as the highly precise raceways of the rolling bearings. The machining results achieved demonstrate the machine's outstanding performance. Inner and outer diameters with a workpiece diameter of up to 4,000 mm were ground within a tolerance of ±20 µm. A profile accuracy of 2–3 µm was achieved for the raceways.

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, Processing diameter: 4,200 mm Table speed: 12.3 min-1 Max. workpiece weight: 9,000 kg X-axis: 1,110 mm Lrjdozvxglepfx Aa Rer Processing height: 850 mm Workpiece height: min. 50 / max. 850 mm Control system: SIMATIC S7-300 Tool holder: Grinding segments Integrated dressing unit on the grinding head In 2010, the machine underwent a comprehensive mechanical and electrical overhaul. As part of this modernization, the entire automation and drive technology was converted to Siemens technology. The machine is equipped with a MARPOSS P7 in-process measuring system. The measuring system is fully integrated into the Siemens SIMATIC S7-300 PLC control system via PROFIBUS.
