Used Hammer Drill for sale (5,305)

Condition: excellent (used), Year of construction: 2012, Vernet Behringer HD-X 918 / HBP 410/923 CNC Sawing / Drilling Line – Year 2012. Split system. 3 Spindle. Automatic tool changer. 24 metres infeed. 18 metres outfeed. Gripper Feed measuring system. Lredpex Ruudsfx Akyjn Infeed and outfeed Cross Transfers.

Year of construction: 2007, condition: like new (used), FICEP 601 DZB CNC DRILLING LINE with 4 way SCRIBING FACILITY I-Beams (without camber): Web height minimum 60mm maximum 610mm. Flange width minimum 30mm maximum 310mm. UNP Channels (web downwards): • Web height minimum 60mm maximum 610mm. Flange width minimum 30mm maximum 300mm. Angles • Flange height (unequal flanges as well) minimum 50 x 50 x 5mm maximum 250 x 250 x 40mm. Lredpfx Aoh N Taajkyon Flats • Width minimum 100nn maximum 610mm. Square tubes • Size minimum 60 x 60mm maximum 300 x 300mm. Rectangular tubes • Size minimum 60 x 30mm maximum 600 x 300mm. All beams • Maximum thickness that can be drilled 50mm. Maximum length (infeed) 12000mm.

Condition: excellent (used), Year of construction: 2012, Voortman V613 / VB1050 Split System CNC Drilling / Sawing Line – Year 2012. Rotating Spindle. Automatic Tool changer. 24 metres In-Feed to VB1050. 24 metres Out-Feed to V613 CNC Drilling line. 24 metres Out-Feed. Roller Feed. VACAM CNC Control. Short piece removal. Lredpfjv U Ea Hsx Akyen

Condition: excellent (used), Year of construction: 2011, Ficep 1003 DZB CNC Drilling / Sawing Line – Year 2011. 3 Spindles. Automatic Tool Changer. Scribing. Short Piece Removal. Lrsdjxmvnuepfx Akyon Hard Stamping. Gripper feed. Infeed and Outfeed Cross Transfers. 1000mm Section Capacity.

Condition: good (used), Year of construction: 2007, DRILLING MACHINE Operating range V630/1000M Min. / max. height 10 – 450 mm Min. / max. width 60 – 1.050 mm Max. positioning weight 9.000 kg Number of drilling units 3x Automatic tool changer 3x (3x 5 positions) Height measuring Included Lredpfxjvpafye Akyjn Width measuring Included Machine weight 12.000 kg Roller feed measuring system Max. speed 42 m/min Min. infeed length 1.500 mm Drilling unit VD40 Feed and positioning servo-motors with servo-invertors Spindle rpm Stepless 100 – 2.500 rpm (servo-motors) Lubrication Internal by mist of air / oil Holder SK 40 Drill diameter oil-tube-drills 8 – 40 mm Drill diameter carbide drills 13 – 32 mm Thread tapping M8 – M24 Centre point marking possibility Yes, 3 sides SAWING MACHINE Sawing machine VB1050 Capacity (h x w) 0° 500 x 1.130 mm Capacity (h x w) +/- 15° 500 x 1.060 mm Capacity (h x w) +/- 30° 500 x 925 mm Capacity (h x w) +/- 45° 500 x 725 mm Capacity (h x w) +/- 60° 500 x 470 mm Saw band speed stepless 40 – 120 m / min Saw drive motor 7,5 kW Saw band dimensions 9.550 x 54 x 1,6 mm Hydraulic band tension 48.000 N Machine weight +/- 8.500 kg

Condition: excellent (used), Year of construction: 2012, · V200 Plate drilling machine (executed with a VD40 drilling unit and an X-Y coordinate table). · VTC 8/40 tool changer (8 places). · Hydraulic numbering unit VN 1/16 · Deburring unit VDB 2 (each hole is automatically deburred). Max. length 1.400 mm* Lrjdpfx Akswphgdoysn Max. width : 1.000 mm Min/max. thickness : 3 - 60 mm Capacity : : 600 kg * Longer lengths (max. 2 400mm) possible by automatic repositioning.

Condition: used, Year of construction: 2006, Web height min 80mm. max 1220mm. Flanges height min 42mm.max. 600mm. U channels min. 80mm 1200mm Flanges height min.45mm max 300mm. Angles min. 80x80x8mm max.300x300x50mm Flats min.100mm max.1220mm Square tubes min.80x80mm max.600x600mm Rectangular tubes min. 80x40mm max.1200x600mm Positioning weight max. 15000Kg Linear weight of the section to be handled max. 750Kg/m Carriage speed max. 30m/min. No. of drill heads 3 - two horizontal Drill Heads with single spindle - one vertical Drill Head with single spindle Max. drilling diameter 50 mm. - with tapered adaptor No.4 Max. thickness that can be drilled 75 mm. Spindle rotation motor per head (a.c.) 15 kW Spindle R.P.M. (with continuous adjustment by program) RPM 180 - 3000 Positioning stroke to suit the gauge line :- vertical drilling unit 20 to 1200 mm.- horizontal drilling units 10 to 600 mm. TOOL CHANGE - number of tools change devices n. 3 - number of tools to be changed n. 6 - adaptor size ISO 45 Model 1260 BH for sections cold sawing : - sawing capacity at 90° min. 80 x 10 mm - sawing capacity at 90° 1250 x 600 mm - sawing capacity at 45° 800 x 600 mm - sawing capacity at 60° 500 x 500 mm - sawing band motor 11 kW - sawing speed 20÷100 m/min. - band size 67 x 1.6 Lrjdox N Icljpfx Akyon

Year of construction: 2007, condition: good (used), Danobat CNC Drilling / Sawing Line – Year 2007 Single Rotating Spindle. 18 metres In- Feed Rollers. 12 metres Out- Feed Rollers. Pincher Unit Feed. Infeed Cross Transfers. Outfeed Cross Transfers. 750mm Capacity. Ljdpfx Ajig T Amskysrn Sawing Capacity: Round cutting capacity(without vertical jaws, angle 0 degrees) 520 mm. Rectangular cutting capacity (without vertical jaw, angle 0 degrees) 700mm X 500 mm. Maximum capacity with vertical jaws 700 X 500 mm. Round cut capacity with 45 degree turn, 450 mm. Rectangular cutting capacity with 45 degree turn, 450 X 500 mm.

Condition: excellent (used), Year of construction: 2009, Year 2009 VOORTMAN V600 CNC SINGLE SPINDLE DRILLING MACHINE with 5 station automatic tool changer. 18 metres length, drilling capability 16.3 metres. Profile Capacity 35mm -1050mm. Ljdew D Uqfjpfx Akyorn Drill capacity 8mm-40mm.

Condition: excellent (used), Year of construction: 2013, Vernet HD-X 618 / HBP 410/723 G CNC Drilling / Sawing Line – Year 2013. 3 Spindle Drill. 16.5 metres In-Feed. 14 metres Out-Feed. Lodpfxex Rut Ts Akyjrn Pusher Unit Feed. Milling / Slotting. Solid Carbide Tooling. Small parts conveyor. 4 way Scribing. In-Feed Cross Transfers. Out-Feed Cross Transfers.

Condition: excellent (used), Year of construction: 2019, HD-SFVO 412-S HBE 320/523 G- YEAR 2019. Marking-drilling-milling-shearing & sawing line HD-SFVO 412-S DRILLING CAPACITY. Flat bars: 50x10 to 400x30 Angles: 50x50x5 to 250x250x20 IPN-IPE: 80 to 400 HEA-HEB: 100 to 400 UPN-UPE: 80 to 400 Square and rectangular tubes: 50x50 to 300x300x20 HBE 320/523 G SAWING MACHINE. Effective cross-section (mm): 90°: 400x300 Bevel cut, left pivot (W x H, mm): 75°: 400x300 60°: 400x300 Lrsdjy R Tk Repfx Akyon 45°: 330x300 30°: 200x300 Bevel cut, right pivot (W x H, mm): 75°: 400x300 60°: 400x300 45°: 310x300 Power supply: • Three-phase 400V ± 15 V + ground, 50Hz • Installed power: 40 kVA Compressed air: • Minimum pressure: 6 bar • Maximum flow rate: 3 Nm³/h Operating temperatures: • From 10°C to 40°C Milling unit specially designed for machining small square or rectangular tubes (slotted holes, shaped cuts, etc.). With the engraving equipment: ability to engrave letters or numbers for part identification. Allows, among other things, marking of tubes with sufficient depth to ensure legibility after painting or galvanizing Secure holding of the bar during milling: the bar is clamped in the movable vice system to ensure proper machining while minimizing vibrations. Improved positional tolerance of one hole relative to another within a group of holes (within a maximum length of 150 mm) Additional features Cycle for centre punching, countersinking, tapping, deburring, and chip breaking Automatic measurement of tool length (HSS) Side and centre tool cooling 230-ton shear Feature Mobile hydraulic shear Straight cut Average cutting time: approximately 2 to 2.5 seconds Capacities: HEB 140 IPE 300 IPN 280 Angle bars 150x150x18 L 200x100x14 UPE 300 UPN/UPAF 300 Flat bars 300x20

Year of construction: 2010, condition: good (used), Main Technical Specifications Profiles to be processed • Max. section volume mm 1100 x 1100 • Bar length max. metres 12 Drilling Capacity • Drill heads no. 1 • Spindles per vertical drill head no. 1 • Drilling diameter max. mm 31.75 • Drilling diameter (with reduced feed) max. mm 40 • Power per head (a.c.) kW 5,5 • Program controlled spindle rotation speed with continuous variation RPM 180 - 1000 Other Specifications • X axis positioning speed (portal) mt/min. 20 • Y axis positioning speed (drill head) mt/min. 4 Lrjdpfeig T Axox Akysn

Year of construction: 2007, condition: good (used), ■ V600 Drilling machine (moveable drilling cabinet, executed with 1 horizontal drilling unit and automatic tool changer) ■ Drilling table with power rail length 15 metres, effective length 12 metres Lrodpfx Akjq Hgg Uoysn ■ Hardware and software (includes VACON 110 machine control) ■ Safety devices (safety bumpers) ■ Year of construction 2007

Condition: excellent (used), Year of construction: 2022, Specification: Vertical Drill Block with 13 Spindles Horizontal drill block with 4 spindles in the X Ledezdki Uopfx Akyjrn Horizontal drill block with 2 spindles in the Y Grooving Saw D=100mm Plausibility check 10kw tool change spindle 4 position tool changer Workpiece length max 200-3050mm Workpiece width 70-850mm Workpiece thickness 8-56mm Powertouch screen Woodwop for machine Energy Saving Mode

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 14008455, Fehlmann Picomax 54 model with Heidenhain TNC 320 control, in very good condition. Technical specifications: - Year of manufacture: 2008 - Travel in X, Y, and Z axes: 500/260/480 mm - Travel of the drilling spindle: 160 mm - Table dimensions (L x W): 880 x 320 mm - Maximum table load: 250 kg - Distance from table to spindle nose: 0 - 605 mm - Feed rate in X/Y: 1 - 2000 mm/min - Feed rate in Z: 1 - 1200 mm/min Lodpfx Akszgwiyjyern - Rapid tool change system: SF 32 - Spindle speed range, infinitely variable: 7100 rpm - Machine dimensions (W x D x H): 1850 x 2550 x 2400 mm - Weight: 2150 kg Accessories: - Heidenhain TNC 320 control - 4th axis with tailstock and Rohm 140mm 3-jaw chuck - Various holders - Microscope - Heidenhain probe - Machine lamp - Cooling system

Condition: ready for operation (used), Year of construction: 1994, overall weight: 7,000 kg, Arm length 1800 mm, drilling capacity 80 mm, weight 7000 kg Ljdpfxjyzq Dpo Akyjrn

Condition: good (used), functionality: fully functional, total width: 940 mm, total height: 1,850 mm, spindle speed (max.): 1,650 rpm, spindle speed (min.): 45 rpm, This Bimak Mod. 35 MT/C is a well-maintained column drilling machine equipped with a cross table and features a Mitutoyo digital readout on two axes. The machine supports both clockwise and counterclockwise rotation, which can be easily switched using a foot pedal for efficient operation. The Laip quick-change system includes ten tool holders, consisting of two drill chucks and seven collet holders, providing flexibility for various drilling and tapping tasks. An additional collet holder is required for milling operations with this machine. This holder is not included but can still be ordered as new. Manufacturer: Bimak Model: Mod. 35 mt/c Condition: Used Mains voltage: 400V Drive: V-belt Spindle taper: MC4 Spindle stroke: 150 mm Automatic spindle feed: No Speed ranges: 14 (45 - 1650 rpm) Digital readout: Mitutoyo Coolant pump: Yes Reversible (CW/CCW): Yes Cross table dimensions: 600 x 240 mm Machine dimensions: 940 x 1100 x 1850 mm (Width x Depth x Height) Ledpfx Akext Ivkjyjrn Motor: 0.8 / 1.5 kW See website for a video of the machine in operation.

Condition: used, machine/vehicle number: 005836, X axis working area: 3000 mm Y axis working area: 1000 mm Main Electrospindle power: 3.5 KW Number of controlled axes: 3 axes Lrjdpfx Aowuckuokyen Total number of drilling spindles: 82

Condition: used, Year of construction: 2014, functionality: fully functional, power: 3.8 kW (5.17 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, workpiece width (max.): 800 mm, number of axes: 3, overall weight: 1,100 kg, Equipment: CE marking, Horizontal drilling Vertical drilling Lredpsy Sh H Nofx Akysn Grooving Panel width up to 80 cm

Condition: used, with adapter plate Lrsdpjy Rvq Hefx Akysn

Condition: used, with adapter plate Ledey Rvqtepfx Akyorn

Condition: good (used), Year of construction: 1992, Drilling machine, bench drill, pillar drill, column drill -Manufacturer: Alzmetall, Pillar drilling machine type AX2 S -Spindle mount: MK2 -Motor: 0.37 / 0.55 kW -Speed adjustment: stepless -Speeds: 450 - 4300 rpm -Table size: 250 x 250 mm -Travel distance: 560 mm -Spindle stroke: 90 mm -Protrusion: 250 mm Lrodpfsyv Ahvjx Akyon -Column Ø: 90 mm -Dimensions: 720/540/H1650 mm -Weight: 145 kg

Condition: used, Used machine Used Hettisch Blue Max hardware drilling machine Motor power: 0,8 kW Motor speed: 2800 rpm 4 drilling spindles with longitudinal stops one foot switch press-in die missing!!! Lrjdpfow I Um Tex Akyen Availability: by arrangement Location: Solingen

Condition: used, Used machine Condition: age-appropriate for efficient dowel hole drilling of longitudinal and transverse pilaster strips for frame doors, door panels drawer parts crossbars of all kinds 3 spindle motor bung spacing 25/25 mm stroke max 80 mm Motor 1,5 HP Support table 260 x 130 mm Height adjustment from 5-40 mm according to scale Lodpfxjw Nabxo Akyjrn with reversible folding fence Foot valve control NRW

Condition: good (used), Type: SSB 3 A Ljdsxlqxfopfx Akyern Machine No.: 5607 Year of manufacture: 1973 Equipment: - MK3 quill - Machine lamp - Quick-action drill chuck incl. morse taper arbor, clamping range 3-16 mm - Infinitely variable speeds Range 1: 0-900 rpm Range 2: 0-1700 rpm - Thread cutting device Condition: good, workshop-tested, speed variator with new bearings
