Used Schaal Automatic Punching Press for sale (33,187)

Condition: used, Eccentric stamping press HAULICK + ROOS, Type RVD 125 Kedpfx Aohlnzkji Redr Double-column eccentric press Machine No. 212560, Year of manufacture 1981 Pressing force 125 tons Table size 880 x 800 mm Table opening 470 x 140 mm Column distance 900 mm Column distance, side 415 mm Ram stroke 45 mm Ram adjustment range 0-80 mm Installed height as shown in the picture 340 mm Stroke rate 50 to 300 strokes/min Motor power, main drive 22 kW Power connection 380 volts, 50 Hz - Double connecting rod drive with 4-bearing eccentric shaft for off-center ram pressure load - Adjacent electrical cabinet - NC roller feed EBU, width 250 mm, year of manufacture 2003 - Adjacent control panel for the roller feed - Strip feed direction from left to right Space requirement (press) L x W x H 3000 x 2000 x 3020 mm Transport height 2950 mm Weight of the press approx. 11 tons

Condition: excellent (used), Complete production line for sale for manufacturing round metal rainwater drainage systems. Production starts from a sheet metal coil, then forms, stamps, and packages the products. All machines are in very good condition. The equipment is fully assembled and intended for mass production of: - Gutters - Gutter ends - Connectors - Corners - Brackets Kdjdpfx Aijy I Tq So Ror - Downpipe outlets - Elbows - Downpipes - Branch connectors (Tees) - Packaging If you are interested in the offered equipment, have any questions, or would like to receive more detailed information, please do not hesitate to contact us. We will gladly provide the full equipment list, technical specifications, additional photos, or arrange an inspection of the production line. All equipment is connected and can be inspected in operation to see the full production process.

Condition: used, Year of construction: 2003, Manufacturer: Haulick + Roos GmbH Type: RVD 3000-2500 Machine Type: High-performance stamping press Year of manufacture: 2003 Condition: used Rated pressing force: 3,000 kN Pressing force: 300 t Stroke frequency: 20–180 strokes/min Drive power: 80 kW Ram stroke: 20–160 mm Ram adjustment: 150 mm Tool installation height: max. 450 mm Maximum tool length: 2,500 mm Maximum tool width: 1,000 mm Table area: 2,450 × 1,000 mm Ram area: 2,500 × 950 mm Clamp plate opening: 2,250 × 350 mm Kjdjzrz Dxopfx Ai Redr Machine weight: approx. 46,000 kg Strip feed direction: right to left Power supply: 400 V Frequency: 50 Hz Maximum connected load: 80 kVA Maximum fuse rating: 250 A Draw cushion: not available Components of the system: Haulick + Roos high-performance stamping press RVD 3000-2500 DIMECO coil unwinder, type 23S1/D/VV Year of manufacture: 2003 Weight: 1,450 kg Maximum load capacity: 4,000 kg DIMECO roller feed, type 1681/17/BVV Year of manufacture: 2003 Weight: 540 kg ARKU straightening machine Technical data for roller feed: Strip width: 5–420 mm Strip thickness: 0.1–5 mm Maximum strip cross-section: 1,000 mm² Strip speed: up to 125 m/min Feed length: 0.1–999.9 mm Feed accuracy: ±0.1 mm Roller diameter: 100 mm Strip height adjustment: 100 mm, manual mechanical Note: The ram guide should be replaced. The system is currently still in operation and functional. A quote from the manufacturer for complete disassembly and installation of new guides is available for approximately €200,000. We will gladly provide videos of the system in operation upon request.

Condition: used, functionality: fully functional, Year of construction: 1989, machine/vehicle number: 4867, Pressta Eisele Stamping Machine HE 40 S Kdjdpfx Asy Tizksi Rsr Price: 2,000 Euros

Condition: refurbished (used), Year of construction: 1985, functionality: fully functional, Completely overhauled BRUDERER high-speed stamping press BSTA125 incl. new press control system Kdodpfx Aijy D H H Ee Rsr Technical data: Tonnage: 1250 kN Tooling opening: 1170 mm Strokes per minute: 100–850 SPM (depending on selected stroke) Adjustable stroke: 16, 19, 26, 35, 43, 51, 58, 64, 70, 75 mm Ram adjustment range: 89 mm Tool installation height: 268–386.5 mm (depending on selected stroke) Bolster plate: 1150 x 1070 mm Ram area: 1040 x 600 mm Strip pass width: 440 mm Base plate opening: 1120 x 350 mm Strip entry height: 80–180 mm Strip feed direction: left to right Feeder: servo feed

Condition: reconditioned (used), functionality: fully functional, ram adjustment: 40 mm, installation height: 2,500 mm, pressing force: 30 t, stroke length: 40 mm, High Speed Automatic Punching Press. Kdodpfx Aievkfmrj Rsr Machine with CE certificate and EUR1 certificate of European origin. Equipped with twin synchronized double rolls feeds for strips widths from 5 mm – 150 mm. PLC touch screen logical interface control. Numerically controlled stamping process (NC). With stroke and speed counter, programmable length, auto stop. Three working modes: Manual, One stroke and Automatic. Pneumatic clutch and brake. Operator’s instruction manual in English. Stroke power: 300 [KN] (30 [tons]). Adjustable stroke: 8-40 [mm]. Table: 540 x 300 [mm]. Adjustable speed 100 – 600 strokes per minute up to 10 in one second. Maximum strip thickness 2.5 [mm]. Central lubrication. Power consumption 5.5 [kW] Technical Air 5-10 [bar]. Warranty: 1 year. Two feeders are used when you need to stamp very thin, soft strip or very heavy strip, to secure precise feeding. All specifications non-binding , subject to change without notice.

Year of construction: 2016, condition: ready for operation (used), Pressing force: 800kN, max. tool installation height: 380mm, max. upper tool weight: 300kg, stroke adjustment: 8mm-140mm, ram height adjustment: 100mm, stroke rate: 100/min, throat depth: 350mm, table dimensions X/Y: 850mm/670mm, ram area: 550mm/400mm. Machine dimensions X/Y/Z: approx. 2250mm/1550mm/2750mm, weight: approx. 9000kg. The machine was completely overhauled by the manufacturer in 2016 (retrofit). In 2024, the clutch, rotary union, press safety valve, and hydraulic oil cooler were replaced. In 2021, the drive motor and belt for the flywheel were converted to frequency-controlled speed. Documentation available. An on-site inspection is possible. Ksdpfx Aiexq Exwo Rjdr

Year of construction: 2007, condition: ready for operation (used), Offered is a Kocher + Beck rotary die cutter/rotary die cutting system, sheet die cutting machine approx. year 2007. Sheet format X/Y approx. 500mm/720mm, material thickness up to max. 0.5mm, die cutting width max. 540mm, unwind max. 732mm, axial adjustment of the magnetic cylinder: +/-7.5mm, machine dimensions X/Y/Z: approx. 2100mm/1150mm/1500mm, weight: approx. 450kg. Inspection possible by arrangement. Kdodpfx Aioxy R E Us Ror

Condition: excellent (used), Year of construction: 2007, AMADA LKI MP 300 LOAD UNLOAD AUTOMATION Year 2007 LKI MP 300M automatic sheet loader / manipulator with 3000mm x 1500mm sheet capacity. Kodpfxjyylqbo Ai Rsdr

Condition: good (used), Year of construction: 1998, Neat used punching machine from Euromac Kdodpszulx Eefx Ai Ror Type CX 1000 30 Capacity 30 ton Unloading 1000mm Overwrap up to 10000mm Including drawer cabinet with lots of tooling and multitool

Year of construction: 2025, condition: new, Hydraulic C-frame press (punch press) Year of manufacture: 2025 Capacity: 100 tons at 230 bar Control / key switch: 1. Manual setup mode without light sensor 2. Automatic (at full speed) with light sensor Main cylinder: Ø 230 mm Auxiliary cylinders: 2 x Ø 50 x 30 mm Auxiliary guide: 2 x Ø 50 mm Motor: 11 kW – 15 hp Pump: 16 cc – 23 liters / ASC – Helical gear pump Speed: Forward 110 mm/sec – Return 200 mm/sec Pressure phase: 9 mm/sec Installation height: 500 mm Stroke length: 400 mm. Push plate: 750 x 600 mm. – with T-slots Table top: 750 x 600 mm. – with T-slots Table height: 850 mm. (Floor to table top edge) ----- Hydraulic accessories: Hydraulic control block & accessories: REXROTH Pressure adjustment via PLC. (20 – 100 tons) Speed adjustable via PLC. Air cooler Feed valve NG.63 Control accessories: Kdedpfjwag Risx Ai Rsr Siemens S7-1200 Blsbjftg Sgsmmvyhwof Main control box Foldable control panel With side safety door (doors can be moved backwards) SICK 750 + 150 mm light sensors. Ruler for adjusting the stroke length 7" PLC screen – Siemens Movable two-hand control Alarm indicator for faults (light & sound) ----- • The press complies with the EN693 Machinery Directive • Hydraulic two-way valves • Dual-channel fused control system • Safety PLC – SICK • Operating instructions & parts list (German) • Warranty: 24 months ----- Oil capacity: 190 liters (Tank volume: 205 liters) Total weight: approx. 5,500 kg. Overall dimensions: 1300 x 2000 x 2750 mm. Delivery time: 2 - 3 weeks from stock. Paint finish: Light gray & dark gray The machine is available immediately in 2 - 3 weeks. Freight: approx. €2,000 from Konya to Germany

Condition: ready for operation (used), Year of construction: 1995, pressure 35.0 t plate thickness max. 8.0 mm throat 830 mm diameter of seal max. 105 mm table: 1500 x 1200 mm work height max. 920 mm die stroke ca. 90.0 mm strokes per minute ca. 200 Pressure power 220 bar oil volume 80.0 l Kodpfx Aiezf Nrks Rjdr total power requirement 4.0 kW weight of the machine ca. 3200 kg range L-W-H 1600 x 1800 x 1800 mm The IS 35 hydraulic punching machine has been specially optimized for processing sheet metal and extruded parts. It stands out for its flexibility and manufacturing precision. The machines in the IS series are equipped with 35 metric tons of punching force. Features: - Electro-hydraulic punch press with long reach - Robust C-frame construction * Solid cast or welded frame (C-shape) * Extremely high punching precision * Compact design = small footprint * Hydraulic overload protection - Separate control unit - Single and continuous stroke selectable - Infinitely adjustable controller for: * â??top dead centerâ? - Continuously adjustable control for: * â??bottom dead centerâ? - Digital position display - 1x freely movable foot switch - Operating instructions (PDF)

Condition: refurbished (used), Year of construction: 1994, functionality: fully functional, Refurbished BRUDERER Stamping Press BSTA 50L incl. new Press Control PCS-100 Technical Specification Press Force: 500 kN Tool Mounting Area (L-R x F-B): 950 x 650 mm Adjustable Stroke Lengths: 16, 19, 25, 32, 38, 44, 51 mm Strokes per Minute (SPM): - 16 mm stroke: 1,120 SPM - 19 mm stroke: 1,030 SPM - 25 mm stroke: 900 SPM - 32 mm stroke: 795 SPM - 38 mm stroke: 730 SPM - 44 mm stroke: 680 SPM - 51 mm stroke: 620 SPM Power Connection: 76 kVA Servo Motor Output: 47 kW Shut Height (Die): 206 - 294 mm (depending on stroke) Slide Adjustment: 64 mm Strip Feed Width: 250 mm Strip Feed Height: 60 – 140 mm Additional Features - Completely refurbished high-speed eccentric press - Highly dynamic, adjustable stroke mechanism - Equipped with the latest modular high-performance PCS-100 press control - Energy-efficient drive system for reduced CO2 emissions Kdjdpfx Aoydu Tfei Rsr - Industry 4.0 ready via OPC-UA interface - Press force monitoring - Integrated tool monitoring system - Integrated servo feeder system PV100

Condition: good (used), functionality: fully functional, Year of construction: 1991, 1 hydraulic punching machine, manufacturer MUBEA, type HP 1000 / 760. Year of manufacture 1991, punching force 100 tons. Includes punching saddle for K 60-K260 and various tools, manually operated linear punching unit (grid rail 4 m), swiveling and with digital display, carriage clamp, and foot switch. Kdodpfx Aszkg Slji Ror Dimensions L x W x H: 1930 x 780 x 1980 mm. Outreach: 760 mm. Working height: 1135 mm. Punch: 40 in 22 mm. Stroke: 0 - 70 strokes. Stroke rate at full stroke: 11 strokes. Drive power: 8.5 kW. Weight: 3800 kg / 3600 kg. Used, in working order.

Condition: used, Heavy-duty hydraulic hole-press, perforated panel press or gluing press for gluing or securing workpieces such as frames, panels, windows or doors. Technical data: - Cylinders: 6 - Hold-down units: 3 Kdodpfx Aijzryy Sj Rsr - Pressing area: 260 x 145 cm

Condition: good (used), functionality: fully functional, actuation type: hydraulic, punching force: 70 t, punching diameter: 28 mm, throat depth: 500 mm, overall weight: 1,600 kg, Used hydraulic punching machine Brand: GEKA Model: HYD 70-SD Serial number: 3659 Throat: 500mm Cutting capacity: - L 90º: 130x130x13mm - Plate: 450x13mm - Round: 45mm - Square: 45mm - Notched: 250x250x6mm Maximum punching size: 28x20mm Tonnage: 70T Includes punches and dies as shown in the photographs. Kdjdpfxsznh She Ai Rsr *Machine has been completely inspected and is in perfect working order.

Condition: used, Punching force: 200 kN Kjdpfxjrmudgo Ai Rjdr Thread, for example a 13 mm hole in 12 mm steel Viewfinder via handwheel Assortment of tools is included in the price

Condition: used, functionality: fully functional, For sale is a MABI 8Z dished end punch which we used as a multi-hole punch. Ksdpjx Dbunjfx Ai Redr

Condition: good (used), functionality: fully functional, Peddinghaus profile and punching machine with automatic stop Kedpfxjyg D Nne Ai Rsdr Very well maintained Punching force 45 t Incl. various punching dies

Condition: new, functionality: unexamined, Year of construction: 2024, machine/vehicle number: 16.41-PS0382, control type: CNC control, degree of automation: automatic, actuation type: electric, sheet thickness (max.): 8 mm, input voltage: 400 V, input current: 20 A, type of input current: three-phase, 2024 Pima Power PS 1225 Brand new Complete machine. Machine was tipped on its side during transit and was damaged. Machine is stored in Our warehouse in California USA. Contact to set up in person inspection. Kdsdpew Nbh Hofx Ai Rsr

Year of construction: 2001, condition: ready for operation (used), functionality: fully functional, punching force: 1,000 t, operating speed: 93 mm/s, stroke length: 55 mm, table length: 1,100 mm, table width: 800 mm, machine/vehicle number: 100597, TECHNICAL DETAILS Press force: 10,000 kN Table surface (W x D): 1,100 x 800 mm Stroke range: 15 - 55 mm Clearance at max. stroke: 28 - 98 mm Puzzle thickness: up to 3 mm Format width (max.): 1,100 mm Punching speeds Upwards: 47.8 mm/s Downwards: 93.7 mm/s Punching: 0.28 mm/s Hydraulic unit Type: 250 Dimensions (L x W): 1,310 x 910 mm Oil capacity: 670 l Unit weight: 1,000 kg Oil weight: approx. 550 kg Weight with oil fill: approx. 1,550 kg Automatic punching table Type: 355 Table top size (W x D x thickness): 1,000 x 700 x 10 mm Hardness: 62 HRC Surface finish: 7 MACHINE DETAILS Electrics Operating voltage: 400 V Frequency: 50 Hz Rated machine current: 50 A Incoming line protection: 63 A Control voltage: 230/24 V Rated power: approx. 30 kW Protection class: IP 54 Power requirement: approx. 8 kW Pneumatics Operating pressure: 6 bar Dimensions & Weight Ksdpfoy Ampdex Ai Rjdr Puzzle disassembler dimensions (L x W x H): 3,150 x 1,620 x 2,900 mm Working height: approx. 1,700 mm Total weight: 33,000 kg Weight of puzzle disassembler: approx. 1.8 t Noise level: < 70 dB(A)

Year of construction: 2026, condition: new, Bosporas Machinery is a manufacturer of coil processing, press feeding and metal forming systems, delivering high-performance and customized industrial solutions worldwide. Our press solutions are designed for punching, perforating, embossing and sheet metal forming applications. Depending on production requirements, we offer advanced servo punch press systems for flexible programmable production and high-speed mechanical presses for continuous mass production. These machines can be supplied as standalone units or integrated into complete coil-fed automatic production lines. ⚙️ AVAILABLE PRESS SOLUTIONS 🔹 SERVO PUNCH PRESS The Servo Punch Press is designed for precision, flexibility and intelligent production control. Key Features: 40 Ton punching capacity 6 tool stations for multi-tool operation Dual-servo controlled X-Y punching system Punching at programmable coordinates 22 kW hydraulic punching drive Up to 90 strokes per minute Automatic scrap conveyor system Advantages: High precision punching performance Programmable motion profiles Lower noise and reduced maintenance Energy efficient operation Fast setup for different part designs 🔹 PERFORATION HIGH SPEED MECHANICAL PRESS The High-Speed Mechanical Press is ideal for continuous perforation, embossing and repetitive punching operations in mass production environments. Suitable For: Sheet metal punching Perforating Embossing Tool & die applications High-volume production lines Advantages: High production speed Stable continuous operation Reliable mechanical drive system Ideal for repetitive operations Cost-effective mass production solution 🔧 ENGINEERING FEATURES Robust industrial machine construction PLC & HMI control systems Easy integration with feeders and automation lines Tooling flexibility based on product design Long service life and low maintenance structure ⚡ OPERATIONAL ADVANTAGES Two technologies for different production needs Flexible solutions from custom parts to mass production Standalone or turnkey line integration Improved efficiency and reduced downtime Short lead time compared to European manufacturers 🏭 APPLICATION AREAS Sheet metal manufacturing Perforated panel production Electrical cabinets HVAC products Construction components Automotive parts White goods industry 🧩 OPTIONAL CONFIGURATIONS Coil feeding integration Decoiler & feeder systems Custom dies and tooling Kdjdoy Anr Topfx Ai Rjr Conveyor systems Automation upgrades Turnkey production solutions 📸 REFERENCE PROJECTS Images and videos can be shared showing different press systems successfully operating in various industrial applications. Additional references and technical details are available upon request.

Condition: used, Year of construction: 1994, punching force max. 50 t throat 510 mm stroke 32 mm Kedpfxjyrhyus Ai Rsdr stroke - stepless adjustable 10 - 32 mm no. of strokes 35 bei 10 mm Hub/min Working height 1070 mm daylight 350 mm table width 255 mm dimensions ca. 1080 x 650 x 1680 mm material layer 630 X 535 weight ca. 1400 kg Scraper, height-adjustable and removable, with interchangeable plate Hydraulic low-pressure finder for foot switch operation Two-stage foot switch and electrical controls Integrated hydraulic unit With punching saddle for dies no. 3, up to Ø 32.5 mm Quick-change device for punches 2 and 5 up to Ø 31.5 mm Peddinghaus blue series with material support table no. 513, dimensions 630 x 535 mm

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, pressing force: 16 t, total width: 700 mm, center height: 1,050 mm, working height: 1,050 mm, Automatic straightening system, mechanically overhauled, fitted with new SIMATIC S7-1500 control and Drive Controller CPU 1504D TF. Max. centre distance 500 mm, straightening force 16 t, straightening stroke 20 mm, idle stroke 95 mm, working height 1050 mm, power rating 10 kVA, average consumption 1.3 kW. Option: The machine can be equipped with a lifting beam conveyor (through the machine), as well as infeed/outfeed belts according to customer requirements, and also with a safety fence. Kedoxldiqspfx Ai Rjdr Currently, the machine is equipped with 1 straightening station; expansion is possible.

Condition: good (used), functionality: fully functional, Weight: 3.5 tons Kdjdpfxjztknpj Ai Rsr Punching force: 1000 kN Reach: 760 mm Can punch, for example, a 40 mm hole in 22 mm steel Drive power: 8.5 kW Height (approx.): 2.15 m Width x Depth (approx.): 0.8 x 2 m Stroke release via foot switch.
