Used Scm S 63 for sale (70,977)

Condition: ready for operation (used), Year of construction: 2020, working width: 520 mm, spindle speed (max.): 5,000 rpm, spindle motor power: 9,000 W, working length: 2,310 mm, This SCM Abricht/ Dickenhobelmaschine was manufactured in 2020. It features a working width of 520 mm and an adjustable thicknessing height from 3 mm to 250 mm. The machine includes a "TERSA" cutter block system with 4 disposable knives and offers four feed speeds. Consider the opportunity to buy this SCM Abricht/ Dickenhobelmaschine wood planer. Contact us for further details. • Working width: 520 mm • Thicknessing height: 3–250 mm (adjustable) • Surface table length: 2,310 mm • Feed speeds: 5 / 8 / 12 / 18 m/min Fodpfx Aszt A Eyokhegf • Cutter block: TERSA system, 4 disposable knives, 120 mm diameter • Control unit: READY electronic control • Programmability: up to 99 programs • Axis control: motorized vertical adjustment of thicknessing table with digital position display • Power-assisted changeover: pneumatic/hydraulic automatic lifting of surfacing tables • Supply voltage: 400 V, 3-phase, 50 Hz • Main motor: 9 kW (12 HP) with automatic star-delta start • Braking: automatic electronic motor brake • Suction: 120 mm extraction outlets for surfacing and thicknessing

Condition: ready for operation (used), Year of construction: 2005, travel distance X-axis: 2,980 mm, travel distance Y-axis: 1,280 mm, travel distance Z-axis: 200 mm, number of axes: 3, total height: 2,680 mm, total width: 3,000 mm, overall weight: 3,295 kg, spindle motor power: 6,600 W, product length (max.): 6,970 mm, spindle speed (max.): 18,000 rpm, This 3-axis SCM TECH Z25 PLUS H-R4 was manufactured in 2005. It features a working area of 2500 x 1000 mm and a travel range of 2980 mm on the X-axis, 1280 mm on the Y-axis, and 200 mm on the Z-axis. The machine is equipped with 16 spindles operating at 4000 rpm and an electric spindle with a maximum speed of 18,000 rpm. If you are looking to get high-quality CNC processing capabilities, consider the SCM TECH Z25 PLUS H-R4 machine we have for sale. Contact us for further details. • Working area: 2500 x 1000 mm Fodpfx Aezt Ax Tskhogf • Programmable speeds: X 25 m/min / Y 30 m/min / Z 22.5 m/min • Vector speed: 40 m/min • Drilling unit: 16 spindles, 4000 rpm, 2.2 kW (10 vertical + 6 horizontal) • Main spindle: HSK-63 • Tool magazine: Side magazine, 7 positions

Condition: good (used), Year of construction: 2008, Used SCM Record 110 NT TVN Prisma Year of manufacture: 2008 (in operation since June 2009) 5-axis CNC machine Working area: 6110 x 1250 mm F18 drilling unit Rapid 24 tool changer Laser cross positioning aid UniClamps Reinforced vacuum pump, 250 m3 Chip conveyor Machine is available immediately, disassembled and stored. Fedpfx Aeztxzqekhjgf

Year of construction: 2008, condition: ready for operation (used), Table Fgedpfx Aszt A Dcskhof Table Length 2500 mm Main Drive Spindle Speed 8300 RPM This SCM Superset NTE was manufactured in 2008. A robust used profile milling machine featuring a touchscreen operation, 6 spindles including a UNIWELLE, and a spindle speed of 8300 rpm. It offers a working width up to 240 mm and includes a quick-change spindle system with Powerlock HSK 85. Ideal for detailed woodworking with its comprehensive tooling and motor-driven feed rollers. Contact us for more information about this machine. Application Types Milling (Wood)

Condition: used, Year of construction: 2019, operating hours: 6,742 h, total height: 2,200 mm, total length: 6,950 mm, total width: 1,100 mm, Colour: White Weight: 3.700 kg - Year: 2019 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AH00001378 Fsdpozr Hyxjfx Akhogf - Operating hours: 6742 - Number of units [pcs]: 9 - └ 1st unit type: Pre-milling unit - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit - - Tools available: Yes - └ 5th unit type: Fine milling unit - - Tools available: Yes - └ 6th unit type: Corner rounding unit - - Tools available: Yes - └ 7th unit type: Radius scraping unit - - Tools available: Yes - └ 8th unit type: Flat scraping unit - - Tools available: Yes - └ 9th unit type: Brushing unit - - Tools available: Yes - Min. edge band thickness [mm]: 10 - Max. edge band thickness [mm]: 60 - Min. feed speed [m/min]: 10 - Max. feed speed [m/min]: 25 - Feed speed control: Variable - Glue system: Glue pot - Type of glue: PUR/EVA - Voltage [V]: 400 - Current consumption [A]: 47 - Fuse [A]: 63 - Power [kW]: 10.0 - Transport dimensions: 6950mm x 1100mm x 2200mm (l x w x h) - Transport weight [kg]: 3700kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), Catalog number: 7713 TECHNICAL DATA - max width of workpiece: 240mm - max height of workpiece: 130mm - 6 spindles: 1) horizontal lower 240mm, 7.5kW 2) vertical right 130mm, 5.5kW 3) vertical left 130mm, 5.5kW 4) horizontal upper 240mm, 7.5kW 5) horizontal upper 240mm, 5.5kW Spindles 4 and 5 are adjustable up/down electrically 6) horizontal lower 240mm, 5.5kW - all spindles are adjustable up/down, left/right Fgodpsztzhgjfx Akhjf - spindle diameter 40mm *from above: - 8 feeding rollers, toothed metal rollers, including 3 double rollers - 4 discharge rollers, smooth, rubber rollers, including 2 double rollers *from below: - 3 smooth feeding rollers - 3 side pressure rollers - stepless feed speed adjustment via a frequency inverter - rollers are pneumatically pressed - feed motor 7.5kW - feed on Cardan shafts - electric adjustment of cutting depth - body lifting motor 0.75kW - length of the infeed table: 2480mm - pneumatic opening/closing of the cabinet - pneumatic blowing of the table - central lubrication of the table - diameters of the dust extraction nozzle: 3x120mm, 3x150mm - dimensions (L/W/H): 5300x1700x1800mm - weight: 5000kg ADVANTAGES – Made in Italy – With 6 heads – For both wet and dry wood – Pneumatic opening of the cabinet – Pneumatic blowing of the table – Spindles 4 and 5 are adjustable electrically – Used planer, very good condition Net price: 99900 PLN Net price: 23785 EUR, depending on the exchange rate of 4.2 EUR (Prices are subject to change due to higher fluctuations)

Condition: excellent (used), Catalog number: 6368 TECHNICAL DATA - max. width of the workpiece: 230mm - max. height of the workpiece: 130mm 7 spindles: 1) horizontal, lower: 230mm, 5.5kW 2) vertical, right: 130mm, 5.5kW 3) vertical, left: 130mm, 5.5kW 4) horizontal, upper: 230mm, 7.5kW 5) horizontal, upper: 230mm, 11kW 6) horizontal, lower: 230mm, 18.5kW 7) universal: 230mm, adjustable at an angle of 360 degrees, 5.5kW - all spindles adjustable up/down, left/right - all spindles equipped with an electric brake - spindle diameter: 40mm - spindles 4 and 5 adjustable electrically up/down - top: 8 feed rollers, metal, twisting, including 2 double rollers - top: 4 feed rollers, rubber - top: 2 pressure rollers - bottom: pawls - bottom, side: 3 pressure rollers - bottom: 2 metal feed rollers, smooth - bottom: 2 double feed rollers, rubber - rollers are pneumatically pressed - feed on Cardan shafts - stepless feed speed adjustment: 5-36 m/min - feed motor: 4kW - electric adjustment of planing thickness: 0.75kW - length of the infeed table: 1980mm - enclosed in a cabinet - central lubrication of the table - dust extraction port diameters: 5x120mm, 2x150mm - dimensions (L/W/H): 5500x1840x1900mm - weight: approx. 5000kg ADVANTAGES - Made in Italy - With 7 heads - For wet and dry wood - Last spindle is universal - Unpainted - Used planer, very good condition Fodpeztzgiofx Akhjgf Net price: 116,900 PLN Net price: 27,830 EUR, depending on the exchange rate of 4.2 EUR (Prices may vary depending on exchange rate fluctuations)

Condition: used, Year of construction: 1996, Working width: 520 mm Planer shaft: Tersa Number of knives: 4 Jointing table length: 2300 mm Jointing fence angle adjustable: yes Jointing tables folding: pneumatic Fodpfxsy A Hh Te Akhjgf Maximum thicknesser pass height: 250 mm Thickness table height adjustment: electric Thickness indication: digital Feed speed: 5 / 8 / 12 / 19 m/min Infeed roller: steel Outfeed roller: rubber Pressure beam: segmented Table rollers: no Motor power: 5.5 kW Motor brake: yes, automatic Extraction connection: 120 mm Machine length: 2300 mm Machine width: 1100 mm Weight: 980 kg

Condition: used, Year of construction: 2002, Saw unit: swiveling 45° Carriage length: 3200 mm Max. saw blade diameter: 400 mm Saw blade bore: 30 mm Motor power: 7.5 kW Speeds: 3000/4000/5000 rpm Max. cutting width: 1300 mm, input via keyboard Control panel: at eye level, with Easy control system Height adjustment: input via keyboard Swivel adjustment: input via keyboard Swivel angle display: digital Cutting width display: digital Guide: double roller carriage, steel Fedjzktp Rspfx Akhsgf Stop: scale adjustment Scoring saw: manual PSV protective guard: Yes End position locking: Yes Automatic motor brake: Yes Description: On/off switch on the saw carriage Weight approx.: 1115 kg Dimensions: 3200 x 1800 x 1900 mm Dust extraction diameter: 1 x 80, 1 x 120 mm Location: Nattheim

Condition: used, • Four-sided planer with a classic spindle • Working width up to 240 mm • Working height up to 120 mm • Min. Working height 6 mm • Spindle speed: 6000 rpm • Infinitely variable feed 5-25 m/min (optionally up to 36 m/min) • Long axial adjustment path on the vertical spindle, up to 80 mm Fgodpfx Akoxxkt Ajhef • All tool spindles with independent motors

Condition: used, machine/vehicle number: 008288, Position 1: Panel Feeding and Loading SCM-MAHROS - STEFANI - CELASCHI Position 2: Double Sided Squaring/Edgebanding Machines SCM-MAHROS - STEFANI - CELASCHI Position 3: Panel Turning Device SCM-MAHROS - STEFANI - CELASCHI Position 4: Double Sided Squaring/Edgebanding Machines SCM-MAHROS - STEFANI - CELASCHI Fedsx Nv S Ujpfx Akhsgf Position 5: Panel Turning Device SCM-MAHROS - STEFANI - CELASCHI Position 6: Splitters SCM-MAHROS - STEFANI - CELASCHI Position 7: Panel Stacking and Offloading SCM-MAHROS - STEFANI - CELASCHI

Condition: not inspected (used), Year of construction: 2004, functionality: fully functional, operating hours: 3,450 h, input voltage: 400 V, tilt adjustment saw blade: 45 °, height adjustment type: electric, actuation type: electric, total length: 3,500 mm, total width: 2,100 mm, total height: 1,800 mm, overall weight: 1,200 kg, Equipment: CE marking, documentation/manual, saw blade guard, scorer, Welcome to Maschinenhandel Knipfer We would be happy to arrange a viewing of the machines on our premises by appointment. Since someone is not always on-site, please call or send a message in advance. ━━━━━ SCM SI 450 Vanguard A very nice panel saw with top-notch features! The machine is located in 92353 Postbauer-Heng. - Approximately 3,500 operating hours - Parallelogram support table - All axes CNC controlled - Scoring unit - Parallel fence adjustable with ball screw drive (high-end solution; it is usually adjusted with a steel bar) - On/off switch on the sliding table - Year of manufacture: 2004 - Including operating manual ━━━━━ IMPORTANT NOTE All information is subject to change without notice. Technical changes are reserved by the manufacturers. Price changes, sales subject to prior sale, and printing errors are reserved. Prices apply for collection. Shipping is possible for an extra charge and by arrangement. Fgodpfx Akjztduvohef A forklift is available for loading.

Condition: used, Technical data: - Conveyor belt width: 150 mm - Motor: 3 kW - Weight: 490 kg Fgodpfszryw Rjx Akhsf

Condition: refurbished (used), Year of construction: 1998, functionality: fully functional, grinding width: 1,100 mm, power: 11 kW (14.96 HP), height adjustment type: electric, Refurbished automatic wide belt sander suitable for calibration of solid wood and sanding of veneered components. The SANDYA 10 model belongs to the higher range of SCM automatic wide belt sanders, characterized by an exceptionally rigid frame, top-quality sanding performance, and versatile applications. Fgsdpfx Akjwx I Tpshjf 2 units: roller + roller with platen and shared 11 kW motor 1. Calibration roller - steel 2. Sanding roller - soft rubber + pneumatic sanding platen Sanding width: 1100 mm 2 feed belt speeds Automatic thickness measurement Motorized thickness adjustment with display + fine-tuning Table extensions at infeed and outfeed Pneumatic oscillation Very good technical condition, completely refurbished Czech manual available CE safety standard Suitable for calibration and sanding of solid wood and veneer EXCELLENT TECHNICAL CONDITION The machine is refurbished, set up, and tested.

Condition: used, Year of construction: 1994, Motor 6 / 7.5 kW with 4-roller feed, fixed speeds. Speed extensions. Height of worktable: 920 mm. Spindle tilting: -10° + 45°. Max. spindle projection above table: 175 mm. Spindle speeds: 3250/6500-5000/10000 rpm. Max. tool diameter: 250 mm. Weight: approx. 950 kg. Location: Nattheim. Fgodpfxjw Enw Ij Akhsf

Condition: used, Year of construction: 2012, GENERAL FEATURES: CNC machining center with a fixed machine table and a moving tool carrier in a portal design for drilling and milling operations on panels made of various materials (chipboard, MDF, solid wood, plastic, etc.). MACHINE STRUCTURE: The base structure is a monolithic design made of thick-walled material, reinforced by welded-in parts across the entire machine bed, making it extremely stable. The table design, with a large base, ensures long-lasting precision and stability. The machine layout allows the user an optimal workflow despite a minimum of space. The mobile portal carrier is made from a solid monoblock. It is positioned in the X-direction on prismatic, ground guides using ball screw slides. On this mobile tool carrier, the working unit is in turn attached to prismatic, ground guides and the ball screw slide. Axis movement is achieved using "brushless" motors in the X/Y/Z axes. The drive system operates in the X-axis via a pre-tensioned precision rack and pinion drive, and in the Y/Z axes via ground ball screws of the highest precision class. AXIS MOVEMENT: The movement of all axes takes place on prism linear guides with a large cross-section and ball screw shoes with a large contact surface, which ensure optimal sliding even at the highest speeds and accelerations. The precise and rapid positioning of the moving portal (X-axis) is achieved by a pinion and rack with helical teeth. Ball screws with a large cross-section ensure the accurate positioning of the working unit along the moving portal (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. STANDARD MACHINE DESIGN: Milling spindle with 5-axis positioning, 11kW (15HP), HSK63, 1200-20000 RPM. The machining unit consists of a powerful 11 kW (15 HP) motor, which is liquid-cooled and capable of 5-axis positioning. This feature enables machining operations to be performed with a tool that can be oriented in any direction; therefore, fewer angular movements are required. The base structure of the milling unit is based on a design with two non-orthogonal axes that intersect next to the tool. This feature guarantees a robust carrier for heavy-duty milling applications. Thanks to the non-orthogonal axes, it is possible to perform numerous repositionings without using too much space. This allows the machining of complex geometries without the risk of collision with the workpiece and achieves an angle of -10° in relation to the machine table. All machining operations are facilitated by the small dimensions of the group in relation to the rotation axis of the spindle: when the group is in a horizontal position, the dimension is only 35mm. WORK TABLE TV: The work table is designed to guarantee the operator maximum "freedom of movement." The vacuum quick-change clamping system provides maximum flexibility with precise positioning and optimal work piece holding. The table consists of moving consoles that are adjusted in the X-axis on ground guides with ball screw shoes and a special profile to ensure Fodpfxszrvvve Akhsgf

Condition: excellent (used), CATALOGUE NUMBER 7967 Fsdpfjzruttjx Akhogf TECHNICAL DATA - max. width of workpiece: 1100 mm - max. height of workpiece: 170 mm 2 units: 1) metal grooved roller for calibration 2) grooved rubber roller + shoe + metal roller – from above: - slip rubber roller - unit (two units on one motor) 15 kW - slip rubber roller - take-off rubber roller - tape blowing – from below: - 2 slip metal rollers - conveyor belt - 2 slip rubber rollers - pneumatic tape oscillation - grinding thickness potentiometer - electric table lifting + manual (for precise adjustment) - pneumatic brake - 2 feed speed types - working pressure 6-8 bar - dust extraction nozzle diameter 2x140 mm - overall dimensions L/W/H 1830x1670x1950 mm - weight 1160 kg ADVANTAGES - Made in Italy - 2 grinding units - Unpainted - Used sander, in perfect condition Net price: 72900 PLN Net price: 17357 EUR, depending on the exchange rate of 4.2 EUR (Prices may vary due to higher fluctuations)

Condition: not inspected (used), Year of construction: 2001, SCM SUPERSET XL Moulder 5 spindles (Comp.5) Description Number of spindles 5 Fjdpfxezqc Snj Akhsgf Spindle sequence bottom-right-left-top-bottom Infeed table length 2500mm Working width 25-260mm Working height 6-180mm Feed speed 6-36 mtr / min Spindle speed 6,000 rpm 400Volt 50Hz CE (All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!) (Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten! Keine Garantie auf gedruckte Daten!) Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: excellent (used), Catalog number 8036 TECHNICAL DATA max. width of workpiece 1100mm max. height of workpiece 170mm 2 units: – from above: rubber roller, pressure roller, knurled 1) metal roller, knurled, for calibrating rubber roller, pressure roller 2) rubber roller, knurled + sequential shoe + metal roller rubber roller, pressure roller total power of units 15kW -from below: 2 rubber rollers, slip rollers conveyor belt Fsdpfxezrnwls Akhegf 2 rubber rollers, slip rollers grinding thickness potentiometer belt blowing system pneumatic belt oscillation controlled by photoelectric sensors electric table lifting + manual (for precise adjustment) 2 feed speed types 0.3kW with pneumatic brake working pressure 6-8bar diameter of dust extraction nozzle 2x140mm overall dimensions L/W/H 1840x1650x2000mm weight 1160kg – unpainted – made in Italy – automatic shoe – 2 units – grinding thickness potentiometer – DTR documentation – used grinder, very good condition Net price: 48900 PLN Net price: 11640 EUR, depending on the exchange rate of 4.2 EUR (Prices may vary due to significant fluctuations)

Condition: used, Year of construction: 2004, 3200mm carriage Fgjdpfxezqg Ruj Akhof Electric tilting blade electric cutter Digital display Blade diameter 350mm 380V

Condition: excellent (used), Year of construction: 1993, Manufacturer: SCM Model: T150 Class Year of manufacture: 1993 Motor upgraded: 5.5 kW Fodpfx Akoyx Nadjhogf Tilting range: -10° to +45° Electromagnetic brake Motor with 2 speeds / pole-changeable Speed settings: 3000/4500/6000/7000/10,000 rpm Forward/reverse rotation Table size: 2700 x 700 mm Spindle diameter: 30 mm Table extension: 2 x 650 mm Extendable frame support Aluminum fence jaws Milling fence with fine adjustment - Electric height adjustment - Electric tilt adjustment Feeder: Wegoma VS 44 - 4 rollers Extraction connection: 120 x 120 mm Space requirement: approx. 2700 x 1300 x 1600 mm Weight: approx. 1000 kg Location: 54634 Bitburg, loaded free on truck, unpacked Delivery as-is, as inspected and function tested without refurbishment, without warranty or guarantee

Condition: used, machine/vehicle number: 008722, X axis working area: 3050 mm Y axis working area: 900 mm Main Electrospindle power: 5.5 KW Number of controlled axes: 3 axes Fgsdsztkb Aspfx Akhjf Total number of drilling spindles: 14

Condition: reconditioned (used), Number of spindles 6 St. Working width 240 mm Working height 200 mm Length of the planing table 2500 mm Feed speed 6-36 m/min. Dimensions (L/W/H) 4900x1700x2000 mm weight of the machine ca. 3500 kg Control SCM Mobile 10 SCM Superset NT PLUS Comp. 31 for window production ----- The machine will be partial reconditionned at our facility prior to delivery. Highlights: - Machine with 6 spindles (2 with HSK mounting) - Spindle speed 8,300 rpm - Working width 240 mm, working height 200 mm - Electronic horizontal and vertical spindle positioning - PRL equipment for glazing bead separation Fodpfx Aozq Hiqekhogf - Air-cushion table - Touchscreen control Technical Data: Working width: max. 240 mm (kit for min. width 15 to 25 mm) Working height: max. 200 mm Feed speed: infinitely variable 6 to 36 m/min via inverter Infeed table: length 2,500 mm Machine weight: approx. 3,550 kg Dimensions: length 4,900 mm / width 1,700 mm / height 1,700 mm 1st Spindle: _____ First bottom spindle, horizontal (jointer/planer) Motor with brake, 11 kW Diameter: 40 mm Speed: 6,000 rpm 2nd Tool Mount (HSK): _____ First right tool mount, vertical Motor with brake, 7.5 kW Speed: 8,300 rpm HSK 85S quick-change system Electronic vertical and horizontal positioning 3rd Tool Mount (HSK): _____ First left tool mount, vertical Motor with brake, 7.5 kW Speed: 8,300 rpm HSK 85S quick-change system with pneumatic unit Electronic vertical and horizontal positioning Electronic tool diameter adjustment (setup) 4th Spindle: _____ First top spindle, horizontal Motor with Brake 11 kW Speed ??8,300 rpm Electronic horizontal positioning Electronic tool diameter adjustment (setup) 5th Spindle: _____ Second horizontal top spindle Motor with brake 7.5 kW Speed ??8,300 rpm Electronic vertical and horizontal positioning Electronic tool diameter adjustment (setup) 6th Spindle: _____ Second horizontal bottom spindle Motor with brake 7.5 kW Speed ??8,300 rpm Electronic vertical and horizontal positioning Additional technical features: _____ - 2 feed units following the top spindles to reduce the axis spacing from 620 mm to 450 mm (for short workpieces) - Driven, motorized feed roller integrated into the machine table - Pneumatic hold-down pressure before the jointing spindle (can be deactivated from the control panel) - Pneumatic feed deactivation for the final unit following the 2nd bottom spindle; operable even when the sound enclosure is closed - Pneumatic "TTL" pressure elements before the first horizontal top spindle - Air-cushion lubrication in the machine table to minimize friction - Manual lubrication pump for the machine table - Central lubrication system for guideways and controlled axes - 5 x electronic horizontal positioning (positions 2 – 3 – 4 – 5 – 6) - 4 x electronic vertical positioning (positions 2 – 3 – 5 – 6) - 3 x electronic tool diameter adjustment (setup) Positions (3 – 4 – 5) - Mobile 10 control system - PRL equipment (Glazing bead package) for cutting out the glazing bead - Soundproofing and safety enclosure with electromagnetic interlock (CE standard) Dust extra...

Condition: used, total height: 2,000 mm, total length: 8,400 mm, total width: 1,080 mm, Colour: Grey Weight: 3.500 kg Price: On request - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AH/335516 - Number of units [pcs]: 12 - └ 1st unit type: Spraying device - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit - - Tools available: Yes - └ 5th unit type: Rough milling unit - - Tools available: Yes - └ 6th unit type: Corner rounding unit - - Tools available: Yes - └ 7th unit type: Radius scraping unit - - Tools available: Yes - └ 9th unit type: Flat scraping unit - - Tools available: Yes - └ 10th unit type: Brushing unit - - Tools available: Yes - Voltage [V]: 400 - Current consumption [A]: 68 - Fuse [A]: 68 - Transport dimensions: 8400mm x 1080mm x 2000mm (l x w x h) - Transport weight [kg]: 3500kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Fgsdpeyudwzsfx Akhjf Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Fsdpfxsvvi I Rs Akhegf
