Used Baudin Glass Grinding Machine for sale (67,743)

Condition: new, functionality: fully functional, NEW Rotary table surface grinder available in the UK. With up to a 400mm grinding diameter on this rotary table, vertical spindle surface grinder from Italian manufacturer DELTA, a leading surface grinder manufacturer with over 20,000 units sold worldwide. The rotating table is controlled by asynchronous three-phase bipolar motors with 8/16 poles; thanks to these motors, the table can rotate at a speed of 40 rpm and at a rate of 30 rpm. Delta Rotary surface grinder Maximum grindable surface 400mm Ø Distance between column and wheel axis 315mm Max. distance between magnetic table and wheel 205mm Rapid feed per turn of handwheel 2mm Micrometric feed by small handle 0,01mm Size of cup wheel 200 x 80 x 78mm Ø Size of abrasive segments 50 x 20 x 90mm Motor power of the wheel (4 HP)-3 kW Godpjnziakjfx Ahtobr RPM of the wheel (50 Hz) 2840rpm/min Electropump motor power (0,08 HP)-0,06 kW Mass of the machine 680kg Rotary table surface grinder Standard Equipment Low tension electric system (24V). Cooling system with electropump Wheel-holder flange and grinding wheel. Grinding wheel guard Table guard.- Stakes key Instruction book/testing certificate Two colour painting RAL 5018-7032, bicomponent multicoat of paint CE conformity certificate with respect to the Units Directive CEE 89/392 and subsequent modifications Stock machine complete with Automatic Downfeed control

Condition: new, functionality: fully functional, Topking X-25 CNC Cylindrical Grinding Machine Topking “The X-25 CNC cylindrical grinding machine is the perfect answer for UK manufacturers facing space constraints,” explains Simon Rood. “Unlike traditional T-type base designs, the X-Series utilises a revolutionary cross-slide structure. This design allows the X-25 to reduce floor space requirements by over 30% while significantly enhancing stability. It is a superior choice when space is limited, making it ideal for busy production environments where every square metre counts.” Machine overview INTRODUCTION Compact CNC cylindrical grinding machine with an impressive capacity. The X series CNC cylindrical grinding machine integrates advanced design and innovative features, offering efficient, precise, and flexible machining solutions. This grinder can meet various processing needs and ensure high-quality results for small or large components. Gedpsubbqijfx Ahtebr The X-axis and Z-axis of the X-series CNC cylindrical grinding machine adopt a cross-slide design, effectively reducing the footprint and axial travel, thereby saving production space. The high-rigidity machine body and the heavy-duty spindle and tailstock significantly increase the component load capacity. The high rigidity machine body ensures stability during grinding, providing high-quality machining results. The operating system is equipped with a high-performance CNC control system and a built-in graphical user interface (GUI), making setup easy and enabling users to operate with ease. The grinding applications are extensive, offering customers the most suitable machining solutions. Specification Swing (Max) 270mm Distance between centres 200mm Grinding Diameter (Max) 250mm Weight between centres (Max) 5kg CNC Control System FANUC or Mitsubishi CNC Controls

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Maximum grinding diameter: 200mm Maximum grinding length: 340mm Gbodpfxszrt Ipo Ahtjr Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Coolant system Wheel guard Machine lighting

Condition: used, Year of construction: 1995, grinding length 600 mm Gedpfxszkv Ayj Ahtjbr grinding width max. 320 mm workpiece height max. 500 mm magnetic clamping plate 300 x 605 mm horiz. table movement: longitudinal man. max. 750 mm horizontal table movement: cross max 340 mm sanding disc diameter 355 mm table load max. 420 kg grinding wheel width 50 mm bore 127 mm spindle turning speed range 1500 U/min rapid traverse vertical 400 mm/min weight of the machine ca. 2500 kg dimensions of the machine ca. ca. 2800x2000x1800 mm

Condition: good (used), * Machine length: ~ 19600 mm * Machine width: ~ 6200 mm * Machine height: ~ 2500 mm * Max weight of roll: 50 T Godpfjud R Szox Ahtebr * Roll length: max 13000 mm * Roll diameter: max 2000 mm * Grinding spindle speed: 450 – 1800 rpm * Cutting speed: 10 – 45 m/s * Adjustment distance: ~ 13900 mm Machine delivered new in 1986, upgraded in 2014 including new Siemens controls.

Condition: used, Year of construction: 1996, functionality: fully functional, machine/vehicle number: 51BG93, grinding width: 50 mm, total height: 2,600 mm, total length: 4,600 mm, total width: 2,100 mm, feed length X-axis: 800 mm, feed length Y-axis: 400 mm, workpiece weight (max.): 500 kg, grinding wheel diameter: 400 mm, table load: 500 kg, type of input current: DC, overall weight: 4,000 kg, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 510 mm, input voltage: 400 V, Equipment: documentation/manual, The machine is well-maintained and in good working order. It is currently still in full operation. It can be inspected in weeks 34 and 35. Several flanges will be included. Paper band filters, etc., are also included. The machine is sold without warranty. Gbodpfx Ajztzhmjhtor

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm Gjdpfswgnz Aox Ahtsbr table-size 800 x 400 mm table speeds 1 - 25 m/min cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges. Control doesn't work continuesly !!

Condition: used, Year of construction: 1988, grinding length 0600 mm grinding width 200 mm workpiece height 250 mm magnetic plate size 600 x 200 mm Gjdpfx Ahsu Rt E Tetjbr total power requirement 4,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 2000 x 1200 x 1650 mm With magnetic plate 600 x 200 mm and automatic dressing arrangement.

Condition: used, Year of construction: 1990, working area D= 30 mm speed 20 m/min Bar length 3000- 6000 mm weight of the machine ca. 3 t Gbsdpfx Ahszl E Rcjtjr dimensions of the machine ca. 9 x 2 x 2,4 m Belt grinding line with 2 grinding units for pipes and bars. Surface of round material is grinded by through feeding.

Condition: used, Year of construction: 1982, grinding length 0600 mm grinding width 200 mm workpiece height 250 mm magnetic plate size 600 x 200 mm total power requirement 4,5 kW Gbedpfxeu Rt Dij Ahter weight of the machine ca. 2,5 t dimensions of the machine ca. 2000 x 1200 x 1650 mm With magnetic plate 600 x 200 mm and automatic dressing arrangement.

Condition: used, Year of construction: 2013, functionality: fully functional, Control system: SIEMENS Sinumerik 840D sl Workpiece spindle unit (U-/B1-/L-axis adjustment) Godpsztrg Hjfx Ahtebr Travel (U-axis): 470 mm Swivel angle (B1-axis with longitudinal adjustment): -1° / +12° Swivel angle (B1-axis, workpiece spindle unit): -20° / +30° Manual longitudinal adjustment of the workpiece spindle (L-axis adjustment): 470 mm Drive power of the workpiece spindle: 3.8 kW Speed (continuously variable): 1 – 895 rpm Spindle head size: A5 according to DIN 55026 Through bore: 55.5 mm Max. workpiece diameter: 400 mm Max. load on the spindle head: 200 kg Center height above swivel bridge: 200 mm Internal grinding unit (Z1/X1/B2) Travel, Z1-axis: 470 mm Travel, X1-axis: 200 mm Drive power S1/S2: 3.5 kW Mounting bore, grinding slide S1/S2: Ø100 mm Mounting length, grinding slide S1/S2: 80-60-80 mm Max. grinding diameter and depth: 300 mm Max. grinding wheel dimensions: Ø250 x 50 mm External and surface grinding unit (Z2/X2) Travel, Z2-axis: 470 mm Travel, X2-axis: 325 mm Drive power, external grinding spindle: 16.5 kW Mounting bore, grinding slide: Ø120 mm Mounting length, grinding slide: 222 mm Max. grinding diameter and length: 400 mm Max. grinding wheel dimensions: Ø500 x 50 x 127 mm

Condition: used, Year of construction: 2017, functionality: fully functional, Grinding area with standard supports: 1 to 30 mm, with special support: 30 to 60 mm; dimensions of the grinding wheel: 355 x 205 x 180 mm; grinding wheel speed: 1680 rpm; speed of the regulating wheel: continuously adjustable from 0 to 300 rpm; drive power of the grinding wheel: 7.5 kW; drive power of the regulating wheel: 1.5 kW; optional accessories: continuously variable speed control, digital 2-axis display (Mitutoyo), paper band filter (40 l/min), automatic feed magazine for through-feed grinding (partial range 2 to 10 mm, length 20 to 100 mm), discharge conveyor with collection container, dressing unit for accommodating a diamond dressing wheel (80 mm), fire extinguishing system, oil mist extraction, oil collection pan; including CE certificate. Gbodpfjztq N Hox Ahter

Condition: used, Year of construction: 2005, Junker cylindrical grinding machine, type EJ 10 Year of manufacture: 2005 Control system: Siemens Center distance: 150 mm Gbodpsznx Hcofx Ahtor Height of centers: 100 mm Maximum workpiece weight: 5 kg Maximum grinding wheel diameter: 400 mm Maximum grinding wheel width: 63 mm Grinding wheel bore: JUNKER spindle bore 27 mm This offer is exclusively intended for commercial enterprises as defined in §14 of the German Civil Code (BGB).

Condition: ready for operation (used), Year of construction: 2002, overall weight: 7,000 kg, center height: 160 mm, distance between centers: 2,000 mm, controller model: Siematic Rack PC 840, positioning accuracy: 0.001 mm, Automatic reamer tool grinding machine / reaming cutter grinding machine! For grinding the chip chamber and chip face on round reaming tools. TECHNICAL DETAILS Tooth length: 1,700 mm Center distance: 2,000 mm Center height: 160 mm Resolution X-axis: 0.001 mm Resolution Y-axis: 0.001 mm Resolution Z-axis: 0.001 mm Resolution W-axis: 0.001 mm MACHINE DETAILS Axis control: 4 axes Control system: Siemens Rack PC 840 Processor: Pentium 3 Program memory: 20 GB Operating system: Windows 2000 Weight: 7,000 kg Gbsdpfxszt Si Ue Ahtor EQUIPMENT Simultaneous machining via 2 handwheels

Condition: not inspected (used), machine/vehicle number: 23095, type of input current: three-phase, overall weight: 4,500 kg, input frequency: 50 Hz, input voltage: 380 V, input current: 17 A, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Power supply: 3~ Frequency: 50 Hz Operating voltage: 380 V Control voltage: 220 V Gbedpfx Aezt Sfpehtor Rated current: 17 A Fusing Rated current of main fuse, fast-blow: 35 A Rated current of main fuse, slow-blow: 25 A Machine weight: approx. 4,500 kg

Year of construction: 1987, condition: good (used), Reform SPW 30 CNC – High-performance grinding machine (roll grinding machine) Machine number: 3728-87 Year of manufacture: 1987 Gbjdpfx Ahobq A Huotor Grinding length: 2,000 mm

Condition: good (used), Grinding wheel – diameter: 175 mm Spindle overhang: 180 mm Operating voltage: 400 V Machine weight, approx.: 300 kg Space required, approx.: 0.90 x 0.60 x 1.80 m Gedpfx Ahjc Skfbstsbr

Condition: good (used), functionality: fully functional, SINUS – Magnet by JUNG model HF 50 RD Width x Depth: 450 x 175 mm Gbsdpfszt Sx Nox Ahter Pitch: 9 mm

Condition: excellent (used), functionality: fully functional, grinding length: 1,200 mm, Hidroprecis Tangential Grinding Machine model RSPB 1200, machine with electromagnetic chuck of 1200x 500mm, table stroke 1350mm, grindable surface 1200 x 600mm, maximum grindable height 575mm cross stroke 550mm, useful table support plane 1200 x 400mm, magnetic chuck height 110mm, grinding wheel motor power 10hp 1500rpm, grinding wheel diameter 400 x 127 x 50mm -400x127x100mm, machine with diamond dresser, machine in good condition, estimated weight 5500kg Gbsdpfov Rnivjx Ahtsr

Condition: used, Heesemann MFA 6 Impression Q2 - LF multi-purpose automatic surface sander for precise surface, veneer, varnish and intermediate sanding in woodworking. The machine is suitable for solid wood, coated workpieces and delicate surfaces in furniture and interior fit-out. The infinitely variable feed rate and vacuum clamping ensure a clean and even sanding finish. Technical data: - Working width: 1,350 mm Gbedoztvz Uepfx Ahtor - Grinding units: 2 - Clearance height: max. 150 mm - Motor power: 17 & 15 kW

Condition: used, KED II HDZ drum sander or belt sander for sanding timber and other materials. Technical data: - Sanding belt: 300 x 1,010 mm - Motor: 2.2 kW Gbsdpeztvzusfx Ahtor - Dimensions (L x W x H) approx.: 1,050 x 600 x 1,000 mm

Condition: used, Langbein double-saddle grinding bench with left/right feed for woodworking. Gbsdpfxsztvznj Ahtsr Technical data: - Clamping length per side: approx. 450 mm - Spindle diameter: 45/35 mm

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 110 mm, spindle speed (max.): 160,000 rpm, spindle speed (min.): 8,000 rpm, workpiece weight (max.): 250 kg, overall weight: 6,000 kg, travel distance W-axis: 400 mm, Hauser Coordinate Grinding Machine S35. Fully functional. Gedpexp Hq Esfx Ahtsbr Very good motors and additional accessories available. The machine is under power and can be inspected. Grinding trials can be arranged by appointment. U-axis in excellent condition. Positioning is highly precise. C-axis for contour grinding is available and fully operational. Control: Fanuc O-M The machine is in daily use and continues to be highly accurate. Fanuc components have been replaced over the last two years. Old parts have been exchanged for new ones. Machine is being sold - > bought as seen -> "As is where is" - no manufacturer or seller warranty. Training on the machine and control system is possible at any time, either at our facility or on your premises. (We are also happy to assist with any further questions.)

Condition: used, Year of construction: 2000, grinding diameter 500 mm grinding length 1000 mm centre height 250 mm -major maintenance -New table geometry -partial painting of the interior Gedpfxoxzk Nis Ahtebr grinding wheel equipment LEFT 400x63x127mm (standard) grinding wheel equipment RIGHT 300x40x127mm Internal grinding unit Ø120mm for HF spindles CNC control KELCO 120 C-axis for non-circular grinding. Kel-Poly B-AXIS: CNC-controlled B-axis KELCO 120: v constant 35m/s or 45m/s High-frequency internal grinding spindle Operating unit for MFV and MFZ spindles Hydraulic quill retraction for the tailstock NO micro-adjustment on the tailstock Spring-loaded quill insert Top table cooling Standard workpiece headstock MK 5 DIN 55026 size 5" Micro-adjustment for the standard workhead Dressing device on the lower table Active longitudinal positioning KELPOS, MARPOSS, mounted on the grinding head Tool measuring system KELSET, MARPOSS MARPOSS gate sensor Measuring control MARPOSS Minialsar prepared Paper belt filter

Condition: used, TECHNICAL DETAILS - Spindle speeds : 5 - 300 [rpm] - C axis indexing precision : 0.001 [°] - Vertical travel of the main spindle : 130 [mm] - Vertical travel of the main spindle (manual mode) : 140 [mm] - Rotational speed of the grinding spindle with motor : 4500 - 80.000 [rpm] - Rotational speed of the grinding spindle with turbine : 100.000 - 160.000 [rpm] - Cylindrical grinding without/with intermediate plate max. : 230 / 360 [mm] - Maximum grinding length Z (with block) : 125 [mm] - Maximum acute angle in conical grinding : 16 [°] Gsdpex Av Adsfx Ahtebr - Maximum grinding depth in conical grinding with angle : 44 [mm] LINEAR AXES - Travels on X/Y/Z axes : 700 / 500 / 500 [mm] - Rapid traverses rates (X/Y) : 4000 [mm/min] - Cutting feed rates (X/Y) : 0 - 2000 [mm/min] TABLE - Table dimensions : 770 x 630 [mm] - Maximum weight upon table : 500 [kg] - Distance table / spindle nose (min./max.) : 0 - 600 [mm] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2650 x 2577 [mm] - Machine height : 2677 [mm] - Machine weight : 5600 [kg] MACHINE HOURS - Number of working hours : 44995 [h] EQUIPMENT - CNC : Fanuc - Coolant tank * with high-pressure pump * with paper filtering unit - Oil mist extractor - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.
