Used Gildemeister Ctx Cnc Turning Centre for sale (16,705)

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 8038938456C, turning length: 450 mm, turning diameter over cross slide: 505 mm, turning diameter: 202 mm, spindle motor power: 10,000 W, spindle speed (max.): 6,000 rpm, spindle bore: 51 mm, Gildemeister CTX 310 Nedpfxjwk E Uzj Adrjld Heidenhain Turn+ The machine its full functional, but have some miner isue.

Condition: good (used), Year of construction: 2007, Machine is in good working condition. Machine come without automatic line. Njdpfxjxf Iamj Adrsld Marked equipement with red not come.. Some accesories and machine equipement are also available. More specs of the machine, check last two pictures.

Condition: ready for operation (used), Year of construction: 2003, operating hours: 5,137 h, spindle speed (max.): 6,000 rpm, travel distance X-axis: 202 mm, travel distance Z-axis: 450 mm, spindle motor power: 12,000 W, total height: 1,730 mm, total width: 1,563 mm, overall weight: 3,500 kg, controller manufacturer: SIEMENS, controller model: Sinumerik 840D powerline, product length (max.): 4,000 mm, number of axes: 3, This 3-axis Gildemeister CTX 310 was manufactured in 2003. It features a maximum turning diameter of 246 mm and a turning length of 445 mm. The machine is equipped with a spindle power of 12 kW and a maximum spindle speed of 6000 rpm. If you are looking to get high-quality turning capabilities, consider the Gildemeister CTX 310 horizontal turning machine we have for sale. Contact us for further details. • Availability: 2 units available • Spindle • Nose: FL 140 h5 • Max torque: 115 Nm (153 Nm at 40% S6) • Bore: 69 mm • Chuck diameter: 170 mm (optional 210 mm) Nlodpfoympcajx Adrjd • Bar capacity: Ø 50 mm • Working range • Swing over bed: 500 mm • Max turning diameter: 246 mm • Max turning length: 445 mm • Distance between centers: 600 mm • Turret and tools • Turret type: VDI 30 • Tool stations: 12 • Driven tools speed: 4200–5000 rpm (depends on control: Fanuc/Siemens/Heidenhain) • Driven tools power: 3.3–4.4 kW • Feeds and axis data • Rapid traverse (X/Z): 24/30 m/min • C-axis rapid: 100 rpm • Feed force (X/Z): 450 daN • Resolution (X/Z): 0.001 mm • Bed • Inclination: 45° • Material: Cast iron • Electrical and auxiliary • Supply voltage: 400 V (±10%), 50 Hz • Total installed power: 24 kVA • Hydraulic system pressure: 50 bar • Coolant tank capacity: 175 liters • Control systems (options): GE-FANUC 21i-TB, Siemens 840D, Heidenhain 4290 E Additional equipment • Chip conveyor (both units) • Extraction unit (one unit)

Condition: good (used), Year of construction: 2003, Main spindle: Speed range - main spindle max. 6,000 min/-1 Drive power - main spindle 16 kW Max. torque 155 Nm C-axis 360 ° Tool turret: Number of tool positions 12 pos. Number of driven tool stations 12 pos. Speed range - driven tools max. 5,000 min -1 Drive power - driven Tools 10 kW Tool holder (VDI 30) Tool shaft 20 x 20 mm Travel paths: x-axis 160 mm z-axis 450 mm Feed rates: Rapid traverse X: 60 m/min Rapid traverse Z: 45 m/min Feed force X: 2.5 kN Feed force Z: 4 kN Rapid traverse C: 200 1/min Max. torque C: 155 Nm Total power requirement Machine weight approx. 3.7 t Space requirement approx. 4.5 x 2.5 x 2.5 m Heidenhain control Nedjv Drigspfx Adrjld Hollow clamping cylinder C-axis and tool drive a Chip conveyor Oil and emulsion mist separator with electrostatic filter

Condition: used, Year of construction: 2008, Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Nlodpfsya Iirsx Adred Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: ready for operation (used), operating hours: 31,819 h, turning diameter over cross slide: 290 mm, turning length: 600 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 645 mm, rotational speed (max.): 5,000 rpm, - CNC lathe with EPL 2 control, equipped with round magnet. It was last used for fine contour turning of hardened components. (without chuck, tailstock and chip conveyor) Technical data Swing diameter over bed: 300 mm Swing diameter over face: 290 mm Travel path X: 210 mm Travel path Z: 645 mm Speed range: 25 - 5000 rpm Tool carrier: universal disk turret Tool positions: 12 Tool holder: 30 mm (DIN 69 880) Nledpfxjqcu Uvs Adrsd

Condition: ready for operation (used), Swing diameter over bed/face slide: 570mm/420mm, turning diameter: 420mm, turning length: 635mm, traverse path X/Z: 220mm/635mm, speed: 5000rpm, spindle bore: 79mm, max. bar diameter: 65mm. Tool positions: 12, driven tools: 6, tool holder: VDI 30, rapid traverse X/Z: 24m/30m/min. Machine dimensions X/Y/Z: approx. 3500mm/2500mm/2000mm, weight: approx. 4500kg. On-site inspection is possible. Nledpfxsv Uqcgs Adrsd

Year of construction: 2009, condition: ready for operation (used), Turning diameter: 200mm, passage diameter: 330mm, passage diameter over cross slide: 260mm, travel X/Z: 160mm/460mm, feed X/Z: 24m/min, speed: 5000rpm, spindle clearance: 51mm, spindle power: 16.5kW/11kW, torque: 1665.5Nm/112Nm, tailstock: 400mm, tool positions: 12. Machine dimensions X/Y/Z: approx. 4200mm/1700mm/2300mm, weight: approx. 3500kg, control: Siemens Sinumerik 810D. Including chip conveyor. Documentation available. On-site inspection is possible. Nsdov Dkb Iepfx Adrsld

Year of construction: 1998, condition: ready for operation (used), Base machine CTX 200E with driven tools, C-axis and 1x back working. Includes DATAPILOT software package TurnPlus, cooling unit for control cabinet, hinge belt chip conveyor, discharge height: 1100mm including coolant tank, tool holder set for universal disc turret with tool holders for external machining, boring bar holders, tools with cylindrical shank holders, sealing plugs, reducing sleeves. Bar gripper, axial complete, workpiece pick-up device, tool spindles 3x axial for drilling/milling/tapping, 1x radial for drilling/milling/tapping, 1x for saw blades, collet chuck complete for main spindle, collet chuck complete for counter spindle, 17x DIN collets 173E round Ø 3-40mm, 2x DIN collets 173E, hex SW 7 and 12mm, 2x DIN collets 173E, square SW 8mm. Bar loading magazine IEMCA BOSS 542/32, guide channel set LW 13, additionally for IEMCA BOSS 542, 13x guide jaws for bar loading magazine IEMCA BOSS 542/32, Ø 8-41mm. With complete documentation. The machine has been idle for one year as the turret head is missing, no further defects known, operating hours unknown, without maintenance records. With bar loader and numerous tools. Nodpfxow Tl Ifs Adrold

Condition: ready for operation (used), Year of construction: 2003, operating hours: 11,600 h, functionality: fully functional, spindle bore: 107 mm, spindle speed (max.): 4,000 rpm, overall weight: 10,000 kg, controller model: Siemens 810D, Equipment: chip conveyor, TECHNICAL DETAILS Maximum swing diameter: 680 mm Swing diameter over X-guide: 565 mm Longitudinal travel: 1,300 mm Cross travel: 315 mm Spindle head: h5 Spindle diameter at front bearing: 150 mm Spindle bore: 107 mm Maximum torque: 600 Nm Spindle speed: 4,000 rpm Chuck diameter: 315 mm Rapid traverse X-axis: 60 m/min Rapid traverse Z-axis: 45 m/min Nedpfx Asymn Ibodrsld Tool turret for: 12 tools Driven tools: 12 Tool holder: VDI 40 Quill stroke: 120 mm Quill taper: MK 5 MACHINE DETAILS Control system: Siemens 810D Dimensions & Weight Machine dimensions with chip conveyor (L x W x H): 5,700 x 2,600 x 2,210 mm Machine weight: approx. 10,000 kg Operating Hours Power-on hours: 47,781 h Spindle hours: 11,600 h EQUIPMENT Hydraulic steady rest, clamping range 30-245 mm Chip conveyor KNCS-N 315-91 power chuck

Condition: repair required (used), Year of construction: 2011, operating hours: 8,545 h, functionality: not functional, turning length: 310 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 190 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 370 mm, mount diameter: 30 mm, Condition: Non-functional. The machine has an unknown malfunction in the turret, making referencing and axis movement impossible. The machine requires repair! TECHNICAL DETAILS Turning length: 310 mm Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Distance between centers: 500 mm X-axis travel: 190 mm Z-axis travel: Z1: 335 / Z3: 370 mm Y-axis travel: 80 mm Control: Heidenhain CNC Pilot 4290 Nsdpfx Adjw T Srdsrold Spindle speed: 6,000 rpm Spindle bore: 73 mm Bar capacity: 50 mm Main spindle torque: 95 Nm at 100% and 127 Nm at 40% Tool turret - number of stations: 12 Tool holder: VDI 30 mm Rapid traverse X + Z axes: 30 m/min MACHINE DETAILS Total power requirement: 20 kVA Chip conveyor dimensions (LxWxH): 3.2 x 0.45 x 1.5 m Operating hours (on-time): 36,443 h Spindle hours: 8,545 h Interface: yes EQUIPMENT - 160 mm 3-jaw chuck with matching flange - 2 sets of spare jaws - 12-station turret with driven tooling - Sauter disc turret (C-axis = 300 rpm) - Chip conveyor 450 K-1/250; year of manufacture 2000 - Manual chuck fitted – no hydraulic chuck - Electrical cabinet with Rittal cooling

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Working Table: Flat table Main Electrospindle power: 12 KW Nledsx A E Tfspfx Adrjd Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 15

Condition: used, machine/vehicle number: 005796, X axis working area: 3700 mm Y axis working area: 1550 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Nsdpohwi U Tjfx Adrold Total number of drilling spindles: 10 Total number of tool changer positions: 8

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Nlsdpfxswuz Eks Adrsd Total number of tool changer positions: 16

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Nsdpfx Ajwuclxsdreld Total number of drilling spindles: 11

Condition: used, machine/vehicle number: 007564, X axis working area: 3700 mm Y axis working area: 1550 mm Working Table: Flat table Nsdpfjum H Ekox Adrold Main Electrospindle power: 10 KW Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 13

Condition: used, machine/vehicle number: 008647, X axis working area: 3650 mm Y axis working area: 1500 mm Njdezdquwjpfx Adrold Working Table: Flat table Main Electrospindle power: 8.5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 26 Total number of tool changer positions: 12

Condition: excellent (used), Year of construction: 2019, operating hours: 2,100 h, functionality: fully functional, turning length: 3,028 mm, turning diameter over cross slide: 690 mm, turning diameter: 650 mm, spindle bore: 166 mm, DOOSAN PUMA 5100 XLMB CNC LATHE FANUC CONTROL 32i B YEAR 11/2019 , INSTALLED 2020 SWING OVER BED 900 MM SWING OVER SADDLE 690 MM MAX TURNING LENGTH 3028 MAX TURNING DIA 650 MM HYD CHUCK 550 MM DIA X 362 Z 3150 C 360 INDEXING 0.001 12 STATION TURRET Nlsdpfx Adeznu Dqjrjd BORING BAR 60 MM MAX RPM 1500 BAR CAPPACITY 166.37 MM TAILSTOCK - QUILL 120 DIA - NO 6 MT LIVE TOOLING SWARF CONVEYOR TOOL PRESETTER COOLANT SYSTEM HYD STEADY IS THERE BUT NOT FITTED TO MACHINE FULL LOAD 82 AMPS NETT WEIGHT 13.2 TON

Condition: used, Year of construction: 2015, Mazak Vertical Centre Smart 530C CNC Vertical Machining Centre with Mazatrol Matrix 2 Control. S/No. 259026 (2015), Table Size 1300mm x 550mm, Spindle Speed Max 12,000rpm, 30 Tool Drum Type ATC Fitted with Various Tool Holders and Renishaw Probe, CAT40 Spindle Taper, LNS Turbo MH500 Swarf Conveyor, Machine Weight 6800kg, User Manual on CD. Country of Origin: United Kingdom Nedpfx Ajznllxedrsld Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2015, Mazak Vertical Centre Smart 530C CNC Vertical Machining Centre with Mazatrol Matrix 2 Control. S/No. 264426 (2015), Table Size 1300mm x 550mm, Spindle Speed Max 12,000rpm, 30 Tool Drum Type ATC Fitted with Various Tool Holders and Renishaw Probe, CAT40 Spindle Taper, LNS Turbo MH500 Swarf Conveyor, Machine Weight 6800kg, User Manual on CD. Country of Origin: United Kingdom Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described. Nedpeznlllofx Adreld

Condition: used, Kitamura JigCentre 7 CNC Machining Centre. Serial No. 50274 with Fanuc System 11m CNC Control (Tape), Table Working Area 1500mm x 800mm, Load Capacity 2000kg, Travels X Axis 1100mm, Y Axis 850mm, Z Axis 460mm, Spindle Speeds 60 - 6000rpm, 30 Tool ATC, BT40 Spindle Taper, Rapid Feeds X & Y 12,000mm/min, Z 9,000mm/min, Cutting Feeds 0 - 5000mm/min, Tsudakoma Powered Rotary Table (300 Ø), Machine Weight 8300kg Location: This lot is located in Birmingham, UK. A charge of £450 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchase Njdpfsznkmuex Adreld

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning diameter: 545 mm, spindle speed (max.): 12,000 rpm, travel distance X-axis: 410 mm, travel distance Y-axis: 140 mm, travel distance Z-axis: 570 mm, Equipment: chip conveyor, The MAZAK Integrex 100-IV is a compact and highly precise CNC turning and milling center designed for complete machining of complex workpieces in a single setup. Thanks to the combination of turning and milling functions, as well as the integrated B and Y axes, the machine is particularly suitable for demanding precision parts in the medical technology, mechanical engineering, and precision engineering industries. The machine was manufactured in 2007 and is equipped with the powerful MAZATROL Matrix control. This enables both dialog-oriented and ISO programming and offers modern functions for efficient and productive manufacturing. Key technical data: The travels are 410 mm in the X-axis, 140 mm in the Y-axis (±70 mm), and 570 mm in the Z-axis. The B-axis has a swivel range of 225°, enabling complex 5-axis machining. The C-axis of the main spindle operates with a high positioning accuracy of 0.001°. The maximum turning and swing diameter is 545 mm each. The main spindle reaches speeds of up to 6,000 rpm with a power of approximately 11 kW, which enables dynamic and precise turning operations. The integrated milling spindle operates with speeds of up to 12,000 rpm with a power of approximately 5.5 kW and is ideally suited for milling, drilling, and threading operations. The machine features a tool changer (available) with a maximum tool length of 210 mm and a KM tool holder, which ensures high rigidity and fast tool changes. Equipment: The equipment includes: • Chip conveyor • Tool measurement system "Tool Eye" With a machine weight of approximately 5,040 kg, the Integrex 100-IV impresses with its compact design, high precision, and flexibility – ideal for economical complete machining in modern production environments. You are in the best hands with us – professional, reliable, and with a passion for machines! Necoyir I Rs Eanhd Held Nsdozpyvhopfx Adrold PS CNC Service Germany GmbH & Co. KG All information is subject to change without notice.

Condition: used, Year of construction: 2011, control FANUC Series 31i-MODEL A weight approx. 9.000 kg rated capacity 75,21 kVA In our assessment, the machine is in good used condition and can be inspected under power by appointment. Nljdpfezpzfwjx Adred Accessories, tools, and work-holding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 2010, control FANUC Series 31i-MODEL A weight approx. 9.000 kg rated capacity 75,21 kVA In our assessment, the machine is in good used condition and can be inspected under power by appointment. Nlodpfx Aozpzfqsdrsd Accessories, tools, and work-holding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 2004, functionality: fully functional, turning length: 2,000 mm, Mazak CNC Mill – Turn Centre Model: E-650H Control: Mazatrol 640M Pro Year: 2004 Distance Between Centres: 2000mm Swing Over Bed: 905mm Machine With: Nlodpszlhp Iefx Adred C Axis Y Axis Live Tooling/Milling B Axis 800mm Power Chuck Manual Steady 375mm Open Steady 600mm Air Filer Mist
