Used Tool Grinding Machine Adjustment Device for sale (79,577)

Condition: used, Year of construction: 2005, machine/vehicle number: 25748, Equipped with: Central Lubrication Machine Flushing Coolant Filtering Equipment 480V, 60 Hz Electrics Headstock W/Center Tailstock W/Center Auto Loading Hydraulic System Pneumatic System Central Lubrication Coolant Filtering Equipment Specifications: Working Range of the Machine: -Centering Width: 600 - 1250 mm -Maximum Workpiece Diameter: 320 mm -Oscillation Stroke: +/-1 mm in relation to the oscillation frequency -Oscillation Frequency: 0-200 double strokes/min infinitely adjustable -Spindle Rotation Speed: 0-150 min -1 infinitely adjustable -Loading Height Above Floor: 1,050 mm Horizontal Axis Machine Column Travel: 1650 mm Headstock - Rotation: -Workpiece Rotational Speed: n2= 0-200 min-1 limited to n2=0-150 min -1 Headstock - Oscillation: -Oscillation Frequency: n2 = 800 double strokes/min -Oscillation Amplitude: =/- 1 mm Tailstock - Hydraulic Axis: -Stroke: 250 mm -Analog Transducer: Measuring length 300 mm Machine Weight: Approximate 8 Tons Approximate Space Requirements (Width x depth x height): Fgedpfszn Az Djx Akhsf -Machine: 3,6 x 3,3 x 3,3 meters -Switch Cabinet: 2,4 x 0,6 x 2,1 meters -Hydraulic Aggregate: 0,9 x 1,3 x 1,9 meters -Coolant Filtering Equipment: 1,3 x 1,0 x 2,0 meters Approximate Total Space Requirements: 35,5 meters

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In. Fsdpfx Aertr D Iskhjgf

Condition: good (used), Year of construction: 2011, LANDIS LT-2 TWIN WHEEL CNC ORBITAL CRANK GRINDER Equipped with: Landis 6400 CNC Control Siemens TOUCH HMI Arobetech Steady Rest Fgedpjrtrxxjfx Akhsf Marposs P7 Gage System Lateral Locator Twin CBN Grinding Wheels Rotary Dresser Headstock Tailstock Rittal AC Units Specifications: Maximum Center Distance: 680 mm

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 Fsdpfxsxh Rqto Akhogf max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: FPS-20-RS, Schiatti Angelo FPS 20 RS 2015 Excellent condition 10 spindle glass edging machine including cerium wheel Fgedpfx Aezrx Inekhjf Can dismantle and load for buyer

Condition: new, DAWN DN Series (Single Spindle) Dawn Machinery Machine overview Suitable for grinding inside and outside diameters as well as the end surface of heavy or non circular work pieces. Heavier work pieces can be more easily loaded to the machine by overhead hoist Fully enclosed covers and oil mist reclaiming device prevent leakage of grinding oil and mist. Machine options Model DN-500 Specification Model DN-500 Grinding Diameter (Max) 610mm ø Swing (Max) 610mm ø Fgodpfxeubbp Se Akhof Max work height 400mm Motor Power 18/23kW CNC Control System SIEMENS 828D

Condition: new, functionality: fully functional, Jainnher Machine Co., Ltd. was established in 1982 and is dedicated to developing grinding machine technology, diversity and automation equipment. Jainnher is constantly offering new and improved machinery. The new JAINNHER JHP-4015 CNC Plunge Type machine with FANUC CNC Control. Hydrostatic and Hydrodynamic bearings. Capacity Max ø work swing Ø400 mm Max grinding length 1500mm Max grinding dia. Ø380 mm Max workpiece weight 150 kgs Distance between centres 1500mm Centre height 200mm Grinding wheel Grinding wheel size Ø410 x 50-100 x 203.2mm Max peripheral 33 m/sec Wheel speed 1250rpm Wheel head Feed angle 90 Swivel angle ±0 Rapid traverse speed 6m/min Max. travel 280mm Min. setting unit 0.0001mm Grinding feed rate 0.001~6000m/min Oil Pressure Hydrostatic = 20kg Hydrodynamic = 3kg Tailstock Retraction of quill 30mm Quill diameter 70mm Centre taper MT.4 ( MT.5 option) Hydraulic cylinder pressure 20kg Work head Spindle speed (variable) 10~500rpm/min Centre taper MT.4 ( MT.5 option) Spindle type Telescopic (option Swivel angle 120 (90ºCCW;30ºCW) Work- table Min. setting unit 0.0001mm Swivel angle CCW/CW +7º/-4º Rapid traverse speed 10m/min Max. travel 1500mm Motor Grinding feed rate 0.001~6000mm/min Grinding wheel motor 7.5HP 4P(opt. 10.0HP) 4P Workhead motor 1.5KW Work table (Z axis) 1.8KW Work table (X axis) 1.8KW Hydraulic pump 1/4 HP 4P Wheel head pump Hydrostatic = 2.0HP Fedonzib Ejpfx Akhsgf Hydrodynamic = 1.0HP Coolant pump 1/8 HP 2P Magnetic coolant separator 1/25HP 2P Oil cooler ----- Oil tank Hyd. oil tank(slideways, screw ends & measurement) 60L Wheel head lubrication 50L Coolant tank 160L Machine N.W (Fully enclosed) 8080 kg G.W (Fully enclosed) 8480 kg Dimension (Fully enclosed) 4900 x 2100 x 2000mm Packing (Fully enclosed) 5090 x 2200 x 2200mm

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 1761-1700, 457 x 152mm capacity. Equipped with magnetic chuck, power rise and fall to wheel head, table guard, coolant system, and dust extraction. SPECIFICATION Jones & Shipman Model 540P Working Surface of table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor to table height 1035mm Table traverse speed range per min 1.5 – 18m Cross feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Fedenxi Uuspfx Akhogf Wheel spindle center to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 2880rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution MACHINE EQUIPPED WITH Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction

Condition: new, Year of construction: 2025, functionality: fully functional, With a grinding diameter of 200mm x 300mm long, the JHP-2003CNC is the most compact plunge type grinding machine in the range and utilises the FANUC Oi-TF CNC control. Designed for heavier grinding applications, the JHP-2003CNC can accomadate workholding and components to 80kgs. This fully enclosed machine is supplied with Renishaw probing, full machine enclosure and mist collector. Jainnher CNC Plunge Cylindrical Grinding Machine Description: JHP-2003 CNC Capacity Max ø work swing 200mm dia Max grinding length 300mm Max grinding dia. 200mm dia Max workpiece weight 80 kgs Distance between centres 300mm Centre height 100mm Grinding wheel Grinding wheel size Ø405 x 50 x 127 Max peripheral 33 m/sec Wheel speed 1780rpm Wheel head Feed angle 90 Swivel angle ±0 Rapid traverse speed 6m/min Max. travel 220mm Min. setting unit 0.0001mm Grinding feed rate 0.001~6000m/min Hydrodynamic pressure ----- Tailstock Retraction of sleeve 30mm Sleeve diameter D:48mm Centre taper MT.3 Hydraulic cylinder pressure 20kg Work head Spindle speed (variable) 10~500rpm/min Centre taper MT3 Fgsdpfjnxk N Ssx Akhof Spindle type Cartridge type Swivel angle 120 (90ºCCW;30ºCW) Work- table Min. setting unit 0.0001mm Swivel angle CCW/CW +10º/-3º Rapid traverse speed 8mm/min Max. travel 640mm Motor Grinding feed rate 0.001~6000mm/min Grinding wheel motor 5HP 4P(opt. 7.5HP) 4P Workhead motor 1.0KW Work table (Z axis) 1.2KW Work table (X axis) 1.2KW Hydraulic pump 1/4 HP 4P Wheel head pump ----- Coolant pump 1/8 HP 2P Magnetic coolant separator 1/25HP 2P Oil cooler ----- Oil tank Hyd. oil tank(slideways, screw ends & measurement) 30L Wheel head lubrication ----- Coolant tank 80L Machine N.W (Fully enclosed) 3800 kg G.W (Fully enclosed) 4100 kg Dimension (Fully enclosed) 3300 x 2100 x 2200mm Packing (Fully enclosed) 3500 x 2200 x 2200mm Jainnher CNC Plunge Cylindrical Grinding Machine Standard Accessories: JAINNHER JHP-2003CNC X-axis linear scale Work lamp Foot pedal Angle adjustment gauge Hydraulic tailstock with manual movement Grinding wheel and flange Tungsten carbide tipped centres (MT3) Automatic lubrication system Diamond dresser at lower worktable Magnetic separator MC-40/coolant tank/pump Levelling bolts and blocks Tool kits and toolbox Fully enclosed splash guard & oil mist device Touch probe gauge (Renishaw) Transformer

Condition: new, functionality: fully functional, he EUROPA JAINNHER JHV-1008CNC vertical grinding machine is designed for grinding of large components used in the transport, aerospace, power generation, oil & gas, hydraulic and precision components. With a grinding internal diameter range from Ø50 to 800 mm, a maximum outside diameter of Ø1000 mm. The maximum height of the workpiece is 800mm, with a maximum worktable load of 1200 kg. EUROPA Jainnher JHV-1008 CNC Vertical Grinder Capacity Range of I.D. grinding 50 – 800mm Maximum O.D grinding 1000mm Z axis maximum grinding height (OD) 800mm Z axis maximum grinding height (ID) 50 – 250 : 325mm / 250 – 800 : 800mm Maximum swing diameter 1000mm Fgedpjnzkvhjfx Akhjf Maximum installed component height 800mm Maximum work table load 1200kg Email for latest factory build availability

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: BO 94392, A familair machine in any toolroom, this Jones and Shipman 540P is equipped with a 6″ x 18″ magnetic chuck, power rise and fall, coolant system and dust extraction. A toolroom institution: USED Jones & Shipman Model 540P Horizontal Spindle Surface Grinding Machine Specification Working Surface of the table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor-to-table height 1035mm Table traverse speed range per min 1.5 – 18m Cross-feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle centre to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 3000rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution Machine equipped with Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Lighting Fedponxi R Usfx Akhegf

Condition: new, Perfectly built to optimise grinding and accuracy efficiency. Auto cross with hydraulic longitudinal. Manual vertical axis. Table longitudinal travel by sensor and solenoid valve - continuous lubrication. Specification Perfect D4080AH Saddle type surface grinder Table size 400 x 800mm Max. Grinding surface 400 x 800mm Max. distance centre of spindle to table 500mm (Option: 650mm) Table speed 5 ~ 25m/min Table guideway V & Flat way Auto. Cross feed increment approx. 0.5mm ~ 20mm Rapid power cross feed approx. 1100mm/min (60Hz) 900mm/min (50Hz) Cross feed on hand wheel 1 rev 5mm 1 gra 0.02mm Rapid power head elevation 550mm/min (60Hz) 450mm/min (50Hz) Vertical feed with MPG 1 rev 2mm 1 gra 0.01mm Auto down feed (Option) 0.001mm ~ 0.999mm/time Wheel speed 60Hz/50Hz 1750rpm (60Hz) 1450rpm (50Hz) Wheel dimensions 406 x 50 x 127mm Spindle motor 5HP Hydraulic pump motor 2HP Auto. Cross feed motor 1/5HP Standard Equipment Grinding wheel and wheel flange Flange extractor Wheel balancing arbor and base Wheel dresser with diamond Levelling screws and plates Tool box and tools Working light Manual AD5 Automatic downfeed control Magnetic chuck and demagnetiser Fedpfsnzh Uiex Akhjgf Coolant system with paper filter

Condition: new, functionality: fully functional, The Robbi OMICRON 32 CNC Series was developed in response to need for medium-high production volumes. The machine can be equipped with automatic measurement devices to process complex components and is equipped with the latest-generation of SIEMENS 840D sl control system. Machine Specifications CNC 3206 Maximum distance between centres 630mm Maximum grinding length 630mm Height of centres over table 160mm Swing over table 315mm CNC 3210 Maximum distance between centres 1030mm Maximum grinding length 1030mm Height of centres over table 160mm Swing over table 315mm Machine is equipped with: CNC SIEMENS SINUMERIK 840D sl, PCU 50.3 Wheel head and table automatic electronic feeds controlled by brushless motors Incremental optic rule for micro positioning of wheelhead Table manual swivelling system for taper grinding with dial gauge Re-circulating ball screw with preloaded nut for wheelhead and table movement Anti-friction material on wheelhead guides Electric installation, in cooled cabinet Fedpenzia Dofx Akhogf Hydraulic unit for tailstock control Pneumatic unit Centralised lubrication Factory build machine

Condition: new, functionality: fully functional, Machine Specifications 600R T7 Maximum distance between centres 630mm Maximum grinding length 630mm Height of centres over table 160mm Swing over table 315mm 1000R T7 Maximum distance between centres 1030mm Maximum grinding length 1030mm Height of centres over table 160mm Swing over table 315mm High positioning accuracy with the possibility to apply on request linear encoders on one or both axis. The Robbi Omicron T7 PLC is built around the SIEMENS operating system, and provides a CNC machine experience, controlled via the T7 PLC control. This provides the same performance available on the CNC plus the great versatility of the T versions, thanks to the: Fgjdpenzicijfx Akhsf New software developed on the last SIEMENS CNC 840 D SL TP 700 comfort panel. The smart interface fully developed by ROBBI gives the possibility to program even multiple and complex components without the needs of CNC programming skills. The auto teach of the first diameter and all the table positions permits a quick pre-set of the component reducing the programming time. The auto compensation of the dressing wear permits to maintain sharp and stable the grinding wheel along the process. Factory build machine

Condition: new, functionality: fully functional, NEW Perfect DT Series of machines with the touch screen display and easy to use interface. Automatic NC controlled downfeed operation with spark out. Plunge grinding, criss-cross grinding and surface grinding. 300 x 600mm grinding capacity 500mm spindle centre to table 355 x 38 x 127mm grinding wheel Fine pole mag chuck + demagnetiser Coolant system with paper filter and magnetic seperator NC Auto downfeed control system LCD touch screen control panel with easy to use graphical interface Fgjdpfxsnzh T Nj Akhsf Criss-cross grinding function Auto criss stroke adjustment via the touch screen control Ballscrew and microfeed for the cross feed Stepless variable hydraulic system Quantitive lubrication system Back water splash shield

Condition: new, functionality: fully functional, NEW Rotary table surface grinder available in the UK. With up to a 400mm grinding diameter on this rotary table, vertical spindle surface grinder from Italian manufacturer DELTA, a leading surface grinder manufacturer with over 20,000 units sold worldwide. The rotating table is controlled by asynchronous three-phase bipolar motors with 8/16 poles; thanks to these motors, the table can rotate at a speed of 40 rpm and at a rate of 30 rpm. Delta Rotary surface grinder Maximum grindable surface 400mm Ø Distance between column and wheel axis 315mm Max. distance between magnetic table and wheel 205mm Rapid feed per turn of handwheel 2mm Micrometric feed by small handle 0,01mm Size of cup wheel 200 x 80 x 78mm Ø Size of abrasive segments 50 x 20 x 90mm Motor power of the wheel (4 HP)-3 kW RPM of the wheel (50 Hz) 2840rpm/min Electropump motor power (0,08 HP)-0,06 kW Mass of the machine 680kg Rotary table surface grinder Standard Equipment Low tension electric system (24V). Cooling system with electropump Wheel-holder flange and grinding wheel. Grinding wheel guard Table guard.- Stakes key Instruction book/testing certificate Two colour painting RAL 5018-7032, bicomponent multicoat of paint CE conformity certificate with respect to the Units Directive CEE 89/392 and subsequent modifications Fsdpenziakefx Akhogf Stock machine complete with Automatic Downfeed control

Condition: new, functionality: fully functional, Topking X-25 CNC Cylindrical Grinding Machine Topking “The X-25 CNC cylindrical grinding machine is the perfect answer for UK manufacturers facing space constraints,” explains Simon Rood. “Unlike traditional T-type base designs, the X-Series utilises a revolutionary cross-slide structure. This design allows the X-25 to reduce floor space requirements by over 30% while significantly enhancing stability. It is a superior choice when space is limited, making it ideal for busy production environments where every square metre counts.” Fgsdpfx Aoubbqiokhef Machine overview INTRODUCTION Compact CNC cylindrical grinding machine with an impressive capacity. The X series CNC cylindrical grinding machine integrates advanced design and innovative features, offering efficient, precise, and flexible machining solutions. This grinder can meet various processing needs and ensure high-quality results for small or large components. The X-axis and Z-axis of the X-series CNC cylindrical grinding machine adopt a cross-slide design, effectively reducing the footprint and axial travel, thereby saving production space. The high-rigidity machine body and the heavy-duty spindle and tailstock significantly increase the component load capacity. The high rigidity machine body ensures stability during grinding, providing high-quality machining results. The operating system is equipped with a high-performance CNC control system and a built-in graphical user interface (GUI), making setup easy and enabling users to operate with ease. The grinding applications are extensive, offering customers the most suitable machining solutions. Specification Swing (Max) 270mm Distance between centres 200mm Grinding Diameter (Max) 250mm Weight between centres (Max) 5kg CNC Control System FANUC or Mitsubishi CNC Controls

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Maximum grinding diameter: 200mm Maximum grinding length: 340mm Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Fgsdpfjzrt Ipex Akhsf Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Coolant system Wheel guard Machine lighting

Condition: not inspected (used), Mitutoyo Quick Vision Apex QV-X404P1L-C CNC Image Measurement System Manufacturer: Mitutoyo Corporation Model: Quick Vision Apex Type: QV-X404P1L-C Code No.: 363-131EU Year of Manufacture: 2007 Machine Type: CNC Image Processing Measurement System Measuring Range: approx. 400 × 400 × 250 mm For sale is a used Mitutoyo Quick Vision Apex CNC Image Processing Measurement System for non-contact dimensional measurement and inspection tasks. The system is offered including the existing PC workstation, two monitors, Mitutoyo control unit, installed QVPAK measurement software, documentation, and other accessories as shown in the pictures. The existing PC system and QVPAK software start. However, the complete machine and measurement function could not be fully tested. Technical Data: Manufacturer: Mitutoyo Corporation Model: Quick Vision Apex Type: QV-X404P1L-C Code No.: 363-131EU Year of Manufacture: 2007 Country of Manufacture: Japan Measuring Range X / Y / Z: approx. 400 × 400 × 250 mm Measurement Principle: non-contact optical image measurement Control: CNC Fgsdpfx Aoztyabokhsf Measurement Software: Mitutoyo QVPAK Software: QVPAK (R): Version 7.502.0010 QVGEO: Version 7.502.0010 Statistics: Version 7.502.0010 Dimensions: Machine and transport dimensions have not been verified and are therefore not provided as binding information. Equipment: Mitutoyo Quick Vision Apex measurement system PC workstation Fujitsu Siemens CELSIUS PC system 2 Fujitsu monitors Keyboard and mouse Mitutoyo control unit / joystick with emergency stop Installed QVPAK measurement software Mitutoyo MCOSMOS / MiCAT data carriers GEOPAK documentation QVPAK documentation Other Mitutoyo operating manuals and documents Clamping plate / workpiece holder Connecting cables and accessories as shown in the pictures Transport Data: Transport by forwarding agent is possible. Exact transport dimensions and transport weight must be agreed upon before collection or shipment. Condition: Used condition with age- and usage-related signs of wear. Visible damage is present on the machine housing, see pictures. The PC system and the existing QVPAK software start. However, the complete machine and measurement function could not be fully tested from a software perspective. Due to the age of the existing PC system, suitable drivers could no longer be provided or installed for individual hardware components. Therefore, complete communication between the measurement system, PC hardware, and measurement software could not be verified. The machine is explicitly offered as untested or for re-commissioning by qualified personnel. Scope of Supply: Mitutoyo Quick Vision Apex QV-X404P1L-C including PC workstation, two monitors, control unit, existing software, documentation, and accessories as shown in the pictures. The machine is available for short-term delivery. Inspection possible by arrangement. The scope of supply is as shown in the pictures. Subject to changes, errors, and prior sale.

Condition: used, Year of construction: 1995, grinding length 600 mm grinding width max. 320 mm workpiece height max. 500 mm magnetic clamping plate 300 x 605 mm horiz. table movement: longitudinal man. max. 750 mm horizontal table movement: cross max 340 mm sanding disc diameter 355 mm table load max. 420 kg grinding wheel width 50 mm bore 127 mm Fgsdpfozkv Ayex Akhof spindle turning speed range 1500 U/min rapid traverse vertical 400 mm/min weight of the machine ca. 2500 kg dimensions of the machine ca. ca. 2800x2000x1800 mm

Condition: good (used), * Machine length: ~ 19600 mm * Machine width: ~ 6200 mm * Machine height: ~ 2500 mm * Max weight of roll: 50 T * Roll length: max 13000 mm * Roll diameter: max 2000 mm * Grinding spindle speed: 450 – 1800 rpm * Cutting speed: 10 – 45 m/s * Adjustment distance: ~ 13900 mm Machine delivered new in 1986, upgraded in 2014 including new Siemens controls. Fgjdpfx Aeud R Szjkhef

Condition: used, Emco F3 universal milling machine from a vocational training workshop With axis digital readouts Includes accessories as shown in the picture X: 350 mm Y: 300 mm Z: 200 mm Table: 600 x 200 mm Rapid traverse rate X, Y axis: 1200 mm/min Spindle speeds: 80 – 2200 (8) rpm Quill travel: 45 mm Fgedpfsztwgfox Akhsf #8498 Net price

Condition: good (used), Year of construction: 1982, functionality: fully functional, Tool milling machine with 3D control, manual handwheels, and a universal table adjustable in three axes. Control: Deckel Dialog Control 4: 3D contouring control, including drilling and milling cycles Monitor, electronic handheld control panel Terminal for program input and output Technical specifications: Travel range X/Y/Z 300 x 220 x 400 mm Speed 31.5 - 3,150 rpm with 21 gear stages Feed rate 4-2,000 mm/min Rapid traverse 4 m/min Drive power 1.6-2.0 kW SK 40 tool holder Hydraulic tool clamping Universal milling table with digital display: Clamping area 600 mm x 320 mm Table load 180 kg C-axis rotation range 360° A-axis tilt range 15°/45° Fgodpfx Akjwid Spehjf B-axis swivel range +/- 45° Vertical milling head: Manual quill stroke - horizontally 65 mm, vertically 60 mm Additional equipment: Manual machine handwheels with scale Direct travel measurement of the NC axes Cooling water system Special accessories: Approx. 33 tool holders (without tools) - see photo High-speed milling spindle Machine data: Machine weight approx. 1,380 kg Space requirement including accessories L approx. 2,940 mm, W approx. 1,900 mm, H approx. 1,960 mm Power supply: 380 V, 50 Hz, 12 kVA The machine is in good, fully functional condition. It can be inspected with power and chippings by appointment.

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm Fjdpfx Aswgnz Ajkhogf workpiece height 400 mm table-size 800 x 400 mm table speeds 1 - 25 m/min cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges. Control doesn't work continuesly !!

Condition: used, Year of construction: 1988, grinding length 0600 mm grinding width 200 mm workpiece height 250 mm magnetic plate size 600 x 200 mm total power requirement 4,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 2000 x 1200 x 1650 mm Fgodpfxou Rt E To Akhsf With magnetic plate 600 x 200 mm and automatic dressing arrangement.
