Used Clarkson Milling Recording for sale (11,297)

Condition: not inspected (used), Mazak CYBERTECH TURN 4500M live tools Fpedpfsz I Egmjx Afuon

Condition: used, Storage location: Nattheim Fpedpfsz H Tw Rsx Afusn

Condition: used, Height-adjustable with a rabbeting cutter; the fence can be adjusted via the handle and is mounted on a sturdy table with rollers. Location: Nattheim Fpsdpez H Txbjfx Afujn

Condition: used, Special milling pantograph for children's bed legs. Fpodpfx Afsy S Aclsuon Pedal head movement, pneumatic workpiece movement.

Condition: used, Year of construction: 2003, operating hours: 40,009 h, functionality: fully functional, machine/vehicle number: 211, Technical Specifications (CME FS-2) Working Table: Table clamping surface: 2000 x 850 mm Maximum permissible table load: 3500 kg T-slots: 1 x H-7 / 5 x H-10 (slot spacing: 100 mm) Travels and Feeds: X-axis travel: 1800 mm Y-axis travel: 1000 mm Z-axis travel: 1000 mm Working feed rate: 5 - 5000 mm/min Rapid traverse: 20,000 mm/min Spindle and Drive: Spindle motor power: 22 kW Spindle taper: ISO-50 / DIN 69871 Fpjdpfxeztrt He Afuen Spindle speed range: 50 - 4000 rpm Accuracy and Construction: Positioning accuracy (3 axes): +/- 0.005 mm Repeatability (3 axes): +/- 0.005 mm Ball screws (X, Y, Z): diameter 50 x pitch 10 mm Total machine weight: 13,000 kg (13 tons) Auxiliary Drive Motors: Hydraulic motor power: 1.1 kW Lubrication motor power: 0.4 kW Coolant pump motor power: 0.3 kW

Condition: ready for operation (used), Year of construction: 1998, machine/vehicle number: 79-12/075-98, functionality: fully functional, input voltage: 380 V, input current: 86 A, input frequency: 50 Hz, type of input current: three-phase, spindle diameter: 30 mm, pivoting range: 45 °, rip fence adjustment: manual, actuation type: electric, table length: 2,000 mm, total length: 2,220 mm, total width: 710 mm, total height: 1,220 mm, overall weight: 450 kg, Equipment: documentation/manual, Everything on the machine is in perfect working order. The sliding table has a length of 1920 mm. It was manufactured without brakes. It is in the condition shown in the pictures and is available for testing on a pallet. Fedpfx Asz N S Izofujpn

Condition: used, Technical details: max. turning diameter: 320 mm turning length: 1040 mm control: OSP E 100 L Dialog Fanuc greates pass round over bed: 530 mm standard turning dia.: 350 Max. distance between centres: 1200 mm max. workpiecediameter: 525 mm Traverse X-Axis 1: 500 Traverse X-Axis 2: 350 mm Traverse Y-Axis 1: 160 (+80/-80) mm Traverse Z-Axis 1: 1200 mm Traverse Z-Axis 2: 1200 mm Spindle 1 Power: 22 kW Spindle 1 RPM: 3800 1/min spindle nose: JIS A2-8 spindle bore: 80 mm bar material dia.: 65 mm C-Axis: 0,001° Number of Turrets: 2 Turret No.1 stations / rotary tools: 12/12 Fpjdpfxjz Ig Swo Afujn Turret 1 tool RPM: 4500 1/min Turret No.2 stations / rotary tools: 12/12 rapid traverse X-axis: 20 m/min rapid traverse Z-axis: 25 m/min total power requirement: 33 kVA weight of the machine ca.: 10 t dimensions of the machine ca.: 6,0 x 2,5x 2,3 m High pressure coolant system: INterlit 8/20 bar Accerories Chip conveyor part counter total counter tool setting Signal lamp 3 colors spindle load monitor B Spindle 1 Chuck SMW 300 mm CNC Turning-and Milling Center The Okuma LT 300 MY has 2 turrets, the upper turret has Y-axis with milling function, the lower turret has milling function. It has main- and subspindle. This allows synchronized machining using 2 turrets. There is an Interlit paperfilter/high pressuire system with the machine with coolant cooler. There are 7 identical machines available, all in very good and well maintained condition. *

Condition: refurbished (used), Huron NU5 Universal Milling Machine Ex University Superb Condition Fjdpfxjz D Dlye Afuopn Table size: 1,635 × 460 mm Longitudinal travel – X: 1,300 mm Cross travel – Y: 700 mm Vertical travel – Z: 500 mm Spindle taper ISO 40 Spindle-speed range 30–2,066 rpm Table-feed range: 1.6–820 mm/min Rapid traverse – X/Y/Z: 2,800 mm/min Maximum head-to-table distance: 649 mm Main motor: 8.7 kW / 11.7 hp Machine dimensions : 2,361 × 2,500 × 1,648 mm For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #79260 Machine Serial Number: 5568 Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 1982, feed length X-axis: 1,300 mm, feed length Y-axis: 700 mm, feed length Z-axis: 550 mm, spindle speed (max.): 2,066 rpm, overall weight: 4,000 kg, 3-axis visual accuracy Table size: 1635 x 460 mm Fpedpfx Afozh Ht Deuen Travel: 1300 x 700 x 550 mm Maximum spindle speed: 2066 rpm Weight: 4000 kg

Condition: used, Year of construction: 1997, operating hours: 32,000 h, total height: 2,700 mm, total length: 5,500 mm, total width: 2,500 mm, Colour: White Empty weight: 13.000 kg - Year: 1997 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 120245 - Operating hours: 32000 - Drive system: CNC - Horizontal/vertical: Horizontal and vertical - Control system brand: Heidenhain - Number of axes [pcs]: 5 - X-axis travel [mm]: 1200 - Y-axis travel [mm]: 880 - Z-axis travel [mm]: 800 - C-axis rotation [°]: 360 - Table length [mm]: 1250 Fedpfx Afsy Uv U Heuspn - Table width [mm]: 1000 - Tool holder: SK40 - Max. spindle speed [rpm]: 18000 - Options: Tool magazine, Digital readout - └ Type of digital readout: Heidenhain - └ Tool magazine [pcs.]: 30 - Transport dimensions: 5500mm x 2500mm x 2700mm (l x w x h) - Transport weight [kg]: 13000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 4,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 3,000 rpm, CNC Heidenhain TNC 426 30-tool changer SA 50 spindle with automatic tool changer Maximum spindle speed: 3000 RPM Table size: 6000 x 1100 mm Travel: 4500 x 1200 x 1000 mm Fpsdpfx Afezh U Hfjuon Chip conveyor 4th axis Tooling

Condition: used, Year of construction: 2017, x-travel 550 mm y-travel 2.000 mm z-travel 550 mm Control Siemens number of spindles 4 Stück Pneumatics 5,5 bar weight of the machine ca. 28 t Fpodpfx Afezwg Uteujn The machine has undergone an extensive overhaul. Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Year of construction: 2007, turning diameter max. 356 mm turning length 705 mm control MSX 850 III MAPPS Mitsubishi greates pass round over bed 923,8 mm Swing dia. over traverse guideway 755 mm standard turning dia. 275 mm max. spindle speed 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bearing diameter 140 mm spindle bore 91 mm max. bar capacity 80 mm Fjdjzb N Uxspfx Afujpn chucking diameter 305 mm C-Axis 0,001 ° Spindle speed range subspindle max. 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle nose JIS A2-5 spindle bearing diameter 85 mm spindle bore 43 mm chucking diameter 210 mm C-Axis 0,001 ° number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Shank diameter 26 mm Drill shank diameter 50 mm Spindle speed - driven tool stations max. 6.000 min -1 turret change time 0,25 sec. x-axis 260 mm z-axis 795 mm b-axis 734 mm feed speeds max. 30.000 mm/min rapid traverse X/Z/B: 30 m/min rapid traverse C: 400 min/-1 total power requirement 39 kVA weight of the machine ca. 6,0 t dimensions of the machine ca. 5,0 x 2,5 x 2,3 m CNC - Turning- and MillingCenter MORI SEIKI - NL 2500 SMC / 700 - Tool-Drive - C-Axis - Subspindle - WITHOUT extraction system

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Fpsdpfxeu Nc Rie Afusn Reference tool SK40 Milling head SEMPUCO *

Condition: used, Year of construction: 1996, Technical details: x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm control: Heidenhain TNC 425 spindle taper ISO: SK 40 DIN 69871 Fpedpfju Nc T Rox Afuen quill stroke vertical: 75 mm distance between column - table edge: 190 (fest) vertikal mm spindle head swivable left - right: 90° Vertikal-Spindel ° distance between table/spindle: min./max.: 165/565 Vertikal-Spindel mm distance between table/spindle: min./max.: 165/565 Horizontal-Spindel mm turning speed range: 20 ... 4500 U/min tool changer with: 32 tools (Typ HTC 32) feed:: 1 ... 5000 mm/min Table dimensions: 850x440 mm table swivelabel +/-: nein = starr ° table load: 500 kg total power requirement: 15 kW weight approx.: 3500 kg dimension machine xH: 2,5 x 3,0 x 2,1 m dimensions electric cabinet LxWxH: 1,6 x 0,6 x 1,7 m Universal Milling and Drilling Machine Equipment: - cooling tank capacity 100 litres, flow rate 16 l/min - control panel with jib length arm - hand wheel control unit - 8 pieces machine base The machine can be demonstrated under power. i.D. *

Condition: used, Year of construction: 1998, Technical details: x-travel: 760 mm y-travel: 550 mm z-travel: 300 mm control: Röders RMS 6 Vers. 2.70 spindle taper ISO: HSK E40 turning speed range: 42.000 stufenlos U/min spindle head swivable left - right: -52 ° / +5° (B-Achse) ° feed:: 0 - 30.000 mm/min Tool changer: 18-fach Werkzeuge + 2 places for Werkzeugvermessung Table dimensions: 860 x 550 mm table load capacity: 800 kp Number of working hours: siehe Foto h compressed air: 6,5 bar total power requirement: 20 kW weight approx.: 7000 kg dimension machine xH: 3,1 x 2,4 x 2,6 m dimension coolant device: ca. 0,6 x 0,8 x 0,7 m other features: Highspeed direct spindle digital axis drives AC servo motors ball screw spray cooling (microjet cooling jet and lubrication unit) working spindle Fischer MFW - 1230/42 up to 42.000 rpm tool measuring laser and probe system PS 25.00 Manual control unit Climatic cabinet Cooling water recooler Hyfra The machine can be demonstrated under power. Fpsdpfeu Ndbpox Afuen *

Condition: used, Year of construction: 1985, Technical details: x-travel: 485 mm y-travel: 385 mm z-travel: 380 mm control: Contour 1 Bahnsteuerung spindle taper ISO: SK 40 spindle head swivable left - right: 90° ° quill travel: 80 mm milling head vertical adjustable: 150 ( y-Achse) mm range of revolution per miute: Spindel vertical: 50 - 2.500 / 18 step U/min feed:: X/Y/Z: 2 - 1000 steples mm/min rapid traverse : X/Y/Z: 2000 mm/min revolution per minute: horizontal: bis 1.000 U/min Table dimensions: 460 x 800 mm Fsdpeu Ndcmsfx Afujpn table load: 0,4 t total power requirement: 9,5 kVA machine weight approx.: 1900 kg dimension machine xH: 2,35 x 2,2 x 2,0 m -Equipment: - Operation via control panel Grundig elektronic with boom - Cooling with pump - machine lighting - Linear interpolation, circular polarization in XY and XZ planes - quick chuck - manual control unit *

Condition: excellent (used), Year of construction: 2020, operating hours: 4,000 h, functionality: fully functional, CNC turning center Doosan Puma 700 XLY II Turning length: 5,050 mm Turning diameter: 700 mm with driven tools and Y-axis Basic equipment: - CNC control Fanuc 0i with Manual Guide i - 45" inclined bed in tubular construction - Main spindle with 4 bearings. Spindle bearing accuracy class P 4 - Lifetime lubrication - Internal clamping device hydraulically actuated with internal clamping cylinder complete with safety device, coolant collection tray, stroke control and draw rod - Automatic central lubrication - Tailstock programmable - Flat bed guides hardened and counter surface coated with Rulon 142 - Coolant system with 7 bar delivery pressure - Guide rail cover Z-axis - Full enclosure - Watertight work area lighting - Integrated alignment screws and mounting plates Including Doosan options: - Tailstock programmable (towed by the turret) - Oil skimmer - Coolant system with 14 bar delivery pressure - Electronic tool breakage monitoring - Automatic tool measuring arm - 3-color warning light - Clamping force monitoring - Additional handwheel - NC option Arbitrary Speed Threading - 2x Drilling & Milling head BMT 85 CC PRECI-FLEX; straight ER50 - 2x Drilling & Milling head BMT 85 CC PRECI-FLEX; angled ER50 - Preparation for programmable hydraulic steady rest (includes complete basic body, connected to open/close the steady rest via M-function and the basic body can be automatically positioned in the Z-direction, towed by the cross slide without the steady rest) Schunk ROTA NC 630-180 2520-Sv90" Chuck diameter 630 mm Manufacturer Schunk with involute gearing 90" incl. flange and draw rod adapter Steady rest RX6-ZSW-100520 50-SCUW-95 self-centering, hydraulic steady rest, sealed housing (proofline), measuring system for clamping range monitoring (SCU-V), integrated flushing channels / chip protection, flushing nozzles, extra compact design, integrated cylinder with pressure converter. Clamping range from 100mm to 520mm Brinkmann pressure boosting pump 30 bar incl. 50p Mahle filter approx. 30 bar, can be switched on via M-function incl. cartridge filter Fedpfx Afjzlcyueuspn Coolant gun with its own pump Coolant gun for cleaning the work area when the door is open In automatic operation without function Hinged belt chip conveyor, discharge on the right, inclination angle 50 degrees, discharge height 1150 mm Chip cart Type SKM750; 0.75m3 volume; 1000kg load capacity; with rollers and forklift pockets

Condition: used, Year of construction: 2002, turning diameter 390 mm turning length 507 mm control MSG 805 MAPPS max. turning diameter 390 mm greates pass round over bed 680 mm Swing dia. over traverse guideway 510 mm centre distance 618 mm turning speed range - main spindle 45 - 4.500 min/-1 Fedpfx Afevzhiqsuepn power capacity - main spindel 11 / 7,5 kW spindle bearing diameter 110 mm spindle bore 73 mm max. bar capacity 51 mm spindle nose JIS A2-6 chucking diameter 210 mm C-Axis 0,001 ° x-axis 235 (195+40) mm z-axis 520 mm number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tool stations max. 3.000 min -1 power capacity driven tool-stations 5,9 / 4,5 kW Shank height for square tool 25 mm Drill shank diameter max. 50 mm turret change time 0,2 sec. tailstock adjustment 490 mm dia. of quill 85 mm taper of center MT 4 quill stroke 120 mm rapid traverse X: 18 / Z: 24 m/min Tipp feed 0 - 1.260 mm/min total power requirement 30,1 kW weight of the machine ca. 4,5 t dimensions of the machine ca. 5,0 x 2,5 x 2,5 m CNC - Turning- and Millingcenter MORI SEIKI - SL 204 MC

Condition: used, Year of construction: 2013, x-travel 1.135 mm y-travel 1.050 mm z-travel 750 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 14.000 min/-1 power capacity - main spindel 19 kW max. Torque 100 Nm tool taper HSK-A 63 table surface area 1.400 x 1.050 mm max. table load 2.500 kg max. workpiece sizes 1.400 x 1.240 mm max. workpiece height 750 mm number of toolpositions 30 pos. tool taper HSK-A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 365 / 395 mm max. tool weight 8,0 kg change-time chip to chip 6,1 sec Fpsdpoyztyaefx Afuen feed speeds max. 40.000 mm/min rapid traverse 40 m/min Accelaration 6 m/s² Feed force ( X / Y / Z ) 14 / 20 / 14 kN total power requirement 44 kVA weight of the machine ca. 14,4 t dimensions of the machine ca. 6,0 x 5,0 x 3,3 m CNC - MachiningCenter Vertical DMG MORI SEIKI - DMU 105 monoBLOCK - Spindle hours: approx. 9,518 h - Production package: (Chip conveyor, 600 l coolant system, paper belt filter, internal coolant supply 40 bar / 23 l/min through spindle center) - Air Clear: Air curtain for viewing window

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 124 control – in very good condition. CE compliant! Technical data: >> Year of manufacture 2000, machine no. 343017 >> Fixed angular table >> Speed: continuously variable up to 4000 rpm Fpjdpjz E R Ahofx Afusn >> Feed rate: continuously variable in 3 axes from 0 to 2000 mm/min >> Travel distances X/Y/Z: 400/320/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Vertical quill stroke: 60 mm >> Vertical quill and horizontal quill – SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 13 KVA Accessories and equipment: >> Heidenhain TNC 124 control >> Hydraulic chuck, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control, and programming examples >> Handwheels >> Coolant system >> Electronic handwheel Heidenhain >> Heidenhain probe About the machine: Offered is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 124 control. This universal milling machine is in very good, original condition. It comes from a company where it was used primarily for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for both vertical and horizontal operation. The conversion from vertical to horizontal is very simple by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on-site while it is powered up.

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, controller manufacturer: SIEMENS, controller model: Sinumerik, table width: 550 mm, table length: 2,600 mm, spindle speed (max.): 12,000 rpm, number of axes: 4, This CHIRON MILL 2000 Vertical Machining Center was manufactured in the year 2003. It is equipped with a Siemens Sinumerik control unit. The machine has a spindle speed of 12000 rpm. Additional equipment Fjdpfxez E Rame Afujpn • Chip conveyor Machine Benefits Technical Machine Benefits • Rapid feed 40 m/min • Tool magazine with capacity for 24 tools

Year of construction: 1989, condition: excellent (used), functionality: fully functional, Manufacturer: RAPID Model: GK 4535-KU Rotor / grinding chamber dimensions: 450 x 350 mm Number of rotor knives: 3 Number of stator knives: 2 Fpsdpjxz D R Tofx Afuen Drive motor power: 18.5 kW Technical condition: very good!!! Equipment: plastic discharge + silo

Condition: used, Slow-speed pre-shredder for rubber, plastic, cables, composite materials Well-suited for material composite separation, e.g. tires, scrap cables With integrated safety shear coupling for protection against foreign objects Rotor: 600 mm diameter x 1450 mm working width Enclosed rotor with staggered segment knives, mounted on cassettes 24 rotor knives, 2 stator knife rows Fpedpsz Hxirefx Afujn Swiveling screen basket, perforation as required With feed device (pendulum arm) Drive power: 90–200 kW

Condition: used, Cutting mill for high loads (heavy duty) Make NETZSCH CONDUX Type CS 500/600-4 Inlet opening approx. 600x600 mm Fsdpfx Afez Hxmweuspn Semi-open 5-knife rotor, 4 stator knives Drive motor 75 kw
