Used Filter Hose Chip Extraction for sale (16,597)

Condition: excellent (used), Year of construction: 2010, Tekol / Trumpf Laser Welding System Tekol LAP S4 with TRUMPF TruPulse 44 and TBH GL230 Extraction Unit Description: For sale is a professional laser welding system Tekol LAP S4 equipped with an integrated TRUMPF TruPulse 44 pulsed Nd:YAG laser and TBH GL 230 extraction and filter unit. This system is an enclosed precision laser welding station designed for fine, pinpoint, and low-distortion welding of metal components. The pulsed laser enables highly controlled heat input, clean weld spots, and reproducible results. Ideal for precision engineering, toolmaking, repair welding, prototyping, and small series production. Enclosed safety housing with protection system, control panel, rotary indexing table, and extraction/filter system. Technical Data – Tekol LAP S4 Operating voltage: 400 V ~ N / PE Mains type: 3~ 400 V, 50 Hz Nominal current: 32 A (approx. 22.5 kVA) Control voltage: 24 V DC Dimensions: Length: approx. 1330 mm, Depth: approx. 1300 mm, Height: approx. 2030 mm Weight: Machine: approx. 800 kg Travel: X-axis: approx. 160 mm Y-axis: approx. 100 mm Z-axis: approx. 100 mm Rotary indexing table: 2-station Technical Data – Laser TRUMPF TruPulse 44 Laser type: Nd:YAG pulsed laser Wavelength: 1064 nm Max. average power: 42 W Min. pulse power: 201 W Max. pulse power: up to 3 kW Pulse duration: 0.2 – 50 ms Max. pulse energy: 30 J Max. pulse frequency: up to 900 Hz Beam parameter product: 16 mm·mrad Technical Data – Extraction Unit TBH GL 230 Voltage: 230 V / 50–60 Hz Power: 0.36 kW Free-blowing air volume: approx. 390 m³/h Effective air volume: approx. 330 m³/h Lasdpfx Ajzizpcemvsg Max. negative pressure: 4000 Pa Sound level: approx. 51 dB(A) Weight: approx. 40 kg Multi-stage filter system: - Pre-filter - Particle filter - Activated carbon filter Total weight approx. 900 kg Condition: used Scope of supply: (see photos) - Tekol LAP S4 laser welding system - TRUMPF TruPulse 44 laser unit - TBH GL 230 extraction unit - Documentation / folders / data carriers - Keys and accessories as shown (Specifications and technical details are subject to change and errors!) If you have further questions, please feel free to contact us by phone.

Condition: ready for operation (used), Year of construction: 2014, A Polo slant bed filter with vacuum filter endless belt design and enlarged storage tank is available. Capacity: 5000l, max. operating temperature: 60°C, flow rate per minute emulsion/oils: 650l/200l, dirt chamber capacity: approx. 400l, vacuum chamber capacity: approx. 140l, connected load: 5kW. Filter unit dimensions X/Y/Z: approx. 2450mm/1650mm/1550mm, filter unit weight: approx. 1150kg, total weight: approx. 3000kg. Documentation available. An on-site inspection is possible. Lodpfx Aoy Eg Dyemvsag

Condition: good (used), Clean air extraction system Used machine, in good condition Images to follow Lajdpferb D Nox Amvjg mobil Jet 160, Connection 160, Fan 2.2 kW Air flow rate 1850 m³/h, 400 V

Year of construction: 2016, condition: good (used), machine/vehicle number: 3385, The cost-effective drainage of condensate for your compressor. The oil is separated from the water with a filter set (ATTENTION: filter set is not included in the Ledeqmmkkspfx Amveag scope of delivery) The purified water (only in conjunction with the filter set) is approved for discharge into the sewer. Guarantee and warranty are excluded in this advertisement. Price on request.

Year of construction: 2017, condition: good (used), machine/vehicle number: 4066, The cost-effective drainage of condensate for your compressor. The oil is separated from the water with a filter set. The filter set is included in the scope of delivery. The purified water (only in conjunction with the filter set) is approved for discharge into the sewer. Guarantee and warranty are excluded in this advertisement. Ljdpfxoqmmvcj Amvsag Price on request.

Condition: reconditioned (used), Overhauled and new painted. The pictures are sample photos of similar machines and are intended to show the execution and quality of the overhaul. All wear parts are renewed. Filter cloths new. 1 year warranty on the filter press, excluding wear parts. Plate size: 630 x 630 mm dimensions: approx. 2900 x 1100 x 1500 mm Chamber depth: 25 mm Capacity: 312 liters Operating pressure: 12 / 15 bar Lasdpfenh Nr Iox Amvog Turbidity inlet: flange 2", centered Number of plates: 40 plates Material plates: Polypropylene Material cloths: PP 5009 (white) Design: open filtration Closing pressure: max. 385 bar Painting: primed and painted in RAL 5010, filtrate trough + drip plate in plastic, Motor hydraulics with single acting cylinder. Optional double-acting cylinder that retracts the heavy pressure plates. With the single-acting cylinder, the operator must push back the pressure plates by hand. Optional: Filling pump as piston diaphragm pump or compressed air diaphragm pump.

Year of construction: 1986, condition: refurbished (used), Yeast filter, completely overhauled, with stainless steel lining, 82 food-grade PP filter plates, 30 mm cake thickness, press capacity approx. 1100 liters, filter area 96 m², new filter cloths fitted, max. 15 bar feed pressure possible, closed outlet via 2 diagonal corner holes, automatic plate transport and optional stainless steel filter cloth washing system with 100 bar high-pressure pump, stainless steel height-adjustable base frame, control cabinet Ljdpjn Dw Iqefx Amvsag

Condition: new, Year of construction: 2025, Exhibition model – sold at a special price Sold at a special price Technical data 300-P Intake nozzle: 300 mm Motor rated power: 7.5 kW / 3-phase Voltage: 400 V / 50 Hz Max. volumetric flow: 6,000 m³/h Rated volumetric flow: 5,089 m³/h Negative pressure: 2,280 Pa Filter area: 30 m² Chip collection volume: 3 x 250 L Dimensions (L / W / H) in mm: 2963 x 994 x 2346 Laedpfx Ajcdy I Temvsg Weight: 880 kg Special feature: The unit is equipped with a noise silencer – therefore extremely quiet – can be sold with or without it. Location: Available from stock at 54634 Bitburg.

Condition: as good as new (ex-display), Clean air filter Type: Power Unit 250 P FU Offer type: Demonstration machine Laedpfohfmpxex Amveg Technical data: Motor power: 7.5 kW / 3-phase / 400 V / 50 Hz Intake nozzle diameter: 250 mm Nominal volume flow: 3,534 m3/h Maximum volume flow: 4,900 m3/h Negative pressure at Vnenn: 3,184 Pa Filter area: 22.4 m2 Compressed air cleaning including integrated pre-separator including integrated extinguishing system including inverter for speed control including integrated sound insulation shroud (-4 dB(A)) Chip collection volume: 2 x 250 l Sound pressure level: 71 dB(A) including dust baffle Dimensions L x W x H = 3000 x 1058 x 2361 mm Weight 850 kg

Condition: reconditioned (used), Revised and newly painted. The images are sample photos of similar machines and are intended to show the design and quality of the refurbishment. All wear parts will be replaced. Filter cloths are new. 1-year warranty on the filter press, excluding wear parts. Plate size: 630 x 630 mm Dimensions: approx. 2000 x 1100 x 1500 mm Chamber depth: 25 mm Capacity: 210 liters Operating pressure: 12 / 15 bar Feed inlet: flange 2", centered Number of plates: 25 plates Laedpfji Igi Iex Amveg Plate material: Polypropylene Cloth material: PP 5009 (white) Design: open filtration Closing pressure: max. 385 bar Painting: primed and painted in RAL 5010, filtrate trough + drip tray in plastic. Motor-hydraulic system with single-acting cylinder. Optional: double-acting cylinder, which retracts the heavy pressure plates. With the single-acting cylinder, the operator must manually push the pressure plates back. Optional: filling pump as a piston diaphragm pump or compressed air diaphragm pump.

Condition: new, Year of construction: 2025, A truly reliable and mobile family: AL-KO POWER UNIT® dust extraction systems are available for maximum volume flows between 790 and 10,000 m³. This makes the energy-efficient AL-KO POWER UNIT® models the perfect solution for small to medium dust extraction volumes or an ideal addition to existing stationary systems. Your advantages: • IE 3 motor as standard • approx. 73 m² filter area • Pre-separator as standard • Certified according to GS-HO-07 • H3 residual dust content of 0.1 mg/m³ is reliably maintained (wood dust) • optionally with type-tested rotary valve airlock (FSA) • Tested backflow flap • Integrated automatic extinguishing system Technical data: • Motor rated power: 11.0 kW / 3-phase • Voltage: 400 V / 50 Hz • max. volume flow: up to 8,500 m³/h at the fan • Rated volume flow: 6,927 m³/h • Negative pressure at Vnenn.: 2,543 Pa • Suction nozzle: 350 mm • Noise level: 71 dB (A) at full load (according to DIN EN ISO 11201) • Chip collection volume (net/gross): 3 x 165 L / 3 x 250 • Dimensions (L x W x H) in mm: 3,130 x 1,058 x 2,361 • Net weight without packaging: 977 kg • Dust class H3 Lajdpfx Ashkzt Nsmvjg Location: Available from stock at 54634 Bitburg • immediately available – in stock Subject to prior sale

Condition: new, Year of construction: 2025, Chip extraction unit ASA 7703 mobile, with extraction unit that can be rotated by 180° For milling, planing, and sawing chips (not suitable for dust) Extraction unit can be rotated by 180°, allowing for extraction from below or above Robust metal fan impeller Comes standard with high-quality chassis for improved stability and easy maneuvering Quick-release fasteners for filter and chip bag Fine filter bag, double-woven Ljdpfehk S Stjx Amvoag Dimensions and weights Chip collection volume 2 x 290 l External diameter of extraction nozzle, inlet 260 mm External diameter of extraction nozzle, outlet 3 x 120, 1 x 100 mm Length approx. 1900 mm Width/Depth approx. 670 mm Height approx. 2800 mm Weight approx. 88 kg Electrical data Idle speed 2950 min¯¹ Power consumption 4.8 kW Connection voltage 400 V Mains frequency 50 Hz Filter Filter area 2 x 5.98 m² Noise emission Maximum sound pressure level 98.3 dB(A) Volume flow Nominal volume flow 7700 m³/h Maximum negative pressure 2800 Pa Scope of supply: Two filter bags, two chip bags Location: In stock at warehouse 54634 Bitburg - available for immediate delivery -

Condition: new, Year of construction: 2025, Raw air extraction unit ASA 141 With standard chassis Dimensions and weights Chip collection volume: 175 l Nominal outer diameter of extraction nozzle inlet: 140 mm Length approx.: 1062 mm Width/depth approx.: 648 mm Height approx.: 2300 mm Weight approx.: 40 kg Electrical data Connection voltage: 230 V Mains frequency: 50 Hz Filter Filter area: 1.9 m² Noise emission Maximum sound pressure level: 78 dB(A) Volume flow Nominal volume flow: 1650 m³/h For milling, planing, and sawing chips (no dust) Significantly reduced dust content thanks to BIA-tested filter material with a high separation rate Housing parts and impellers made of high-strength special plastic Quick-release fasteners for filters and chip bags for easy maintenance Robust, high-quality design Easy to move thanks to swivel castors Low power consumption Extraction systems comply with dust class L Scope of delivery: Unit body with mounted fan unit Filter bag / extraction unit Chip bag / extraction unit Lasdpfx Aehk S Swjmveg without extraction hose

Condition: used, Chips center PROMATEC Ljdpfxsuhb Hkj Amvoag

Condition: good (used), Used stainless steel reactor with double jacket Item number: 10271 Last application: Chemical industry Volume: approx. 515 L Operating pressure: +3 bar Operating pressure, double jacket: +6 bar Type: Floor-standing Material (in contact with media): 1.4301 / AISI304 Design: Double jacket Bottom: Klöpper bottom Top: Klöpper bottom Tank dimensions: Ledpfx Asd Eagpjmvsag Tank inner diameter: 900 mm Cylindrical height: 420 mm Overall height: 1660 mm Height of legs: 490 mm Outer diameter: 920 mm Distance from outlet to bottom: 340 mm Materials: Inside: 1.4301 / AISI 304 Outside: 1.4301 / AISI 304 / Painted steel Equipment: Double jacket Various connections on the top Dome cover on the top Filter plate in the tank

Condition: used, The chip conveyor is a single conveyor designed to continuously and reliably transport short, broken metal chips from the machining area of the machine tool to a collection container, while simultaneously separating the metal chips from the coolant. This ensures more efficient production processes, improved dimensional accuracy of the workpieces, and a longer service life of the coolant. The chip conveyor consists of a metal housing with a central chain and carriers. It is driven by a 230 V three-phase geared motor, which can be connected to the machine tool via a plug. Ljdpfsclu H Usx Amvjag Oil return.

Condition: used, Year of construction: 2012, machine/vehicle number: IntNr231316, Technical Data – Used LNS FOX IFS WS 500 Feature Specification Model FOX IFS WS 500 Year of manufacture 2012 Extraction capacity approx. 500 m³/h Motor output approx. 0.37 kW Voltage 400 V / 50 Hz (typical) Weight approx. 35 kg Dimensions approx. 465 × 500 × 1,145 mm (W x D x H) Filter stages 1. Pre-filter F5 2. Centrifugal separator 3. Post-filter F5 (optional: HEPA H13) Filtration efficiency 99 % at ≥ 1–2 µm (F9), optional HEPA 99.95 % at ≥ 0.1 µm Noise level approx. 65 dB (model WS2 similar) Accessories & Features • Compact design for installation directly on or next to CNC machines • Stand for extraction • Three-stage filtration for efficient oil and coolant mist separation • Cartridge filter optionally upgradable with HEPA kit • Easy maintenance, low-noise operation, and durable filter elements Laedjzx Rrrepfx Amveg Technical data and information subject to change and error. Prior sale reserved!

Condition: used, Year of construction: 2009, machine/vehicle number: 4006, functionality: fully functional, year of last overhaul: 2023, Equipment: documentation/manual, We are offering this used Riedex MD-450 stationary dust extraction system, manufactured in 2009, including the air filter unit. Manufacturer: Riedex Lajdozxfrmepfx Amvsg Model: MD-450 Year of manufacture: 2009 Condition: used Category ID: 1413 Type ID: 586 Type: stationary dust extraction system If you have any questions or would like more information, please send us a message or call us. The machine is still in working order. You will be responsible for dismantling it.

Condition: good (used), Code: 0306 Brand: VM Model: 2/18 Suction system with 18 sleeves and 2 collection bags for carpentry workshops, furniture factories, sawmills, woodworking shops and various Technical data: N° 18 filtering sleeves Laodsymfiiepfx Amveg N° 2 collection bags Motor Hp 7,5 Electrical panel Overall dimensions: mm 2800 x 1200 x 3200 h

Condition: used, Year of construction: 2023, Used System Lasdpozlbqrofx Amveg Year of Manufacture: 2023 Condition: Like new, very few operating hours Features and Technical Specifications: ECO JET DUO 6 XL ZRS stationary clean air filtration system for extracting wood dust and chips Fans: 2 x 7.5 kW Airflow: 10,000 m³/h Vacuum pressure: 2,700 Pa (total) / 2,200 Pa (static) 80 filters, each 2.50 m long, BIA Category M, electrically conductive, incl. support baskets Filter area: 77.6 m² Filter loading: 129 m³/(m² x h) Filter cleaning: AL-KO OPTI-JET® Pressure relief areas: 0.84 m² (rupture discs) Base structure with hopper and rotary valve; dry conveying with C-coupling ECO JET DUO 6 ZWR XL, 1,100 mm spacer ring for raising the unit, with 2 intake openings Base unit with feed hopper and ZRS 960/1 FG rotary valve for chip disposal via a customer-supplied transport fan into a silo or similar; transport line DN 200, approx. 1,260 mm, connection to be provided by the customer Rotary valve ZRS 960/1 FG: - ATEX Directive 94/9/EC; CE 0588 Ex II 1D/- (unit for indoor/outdoor use); EX D; FSA 11 ATEX 1614X - Motor: 0.18 kW / 0.78 A, 3-phase / 400 V / 50 Hz - Protection class/enclosure type: IP 54 / B3; Insulation class F - Speed: 41 rpm; Flow rate: 15,744 l/h*; 7 cells - Inlet/Outlet: 960 x 250 / 960 x 208 mm - Dimensions: 1,100 x 605 x 330 mm; Temperature range: up to 50 °C Additional features: - 400 mm suction inlet with check valve in rectangular duct - ECO JET backflow check valve 910 x 346 x 500 mm AL-KO Control System ACS II: - Touchscreen display, ST 1200 controller, Sitop Power power supply, 24 V control voltage, and integrated frequency converter for cascading up to 2 fans up to 37 kW with frequency converter transfer - Plain-text error messages on the display, as well as a collective error message and indicator light; manual start of discharge via display button and cleaning via button; cleaning start via differential pressure; Post-cleaning; external start via potential-free contact; operating hour counter; maintenance interval indicator; control cabinet lighting and ventilation; monitoring/evaluation of fire damper, residual dust sensor, fill level sensor, and maximum filter pressure - 10 individually controlled solenoid valves - Gate valve control in groups of 4 for up to 8 machines: control via potential-free contact (PFC) or induction coil; 24 V DC shut-off valves, motor-driven with single-wire control or electropneumatic; max. 4 plates per conveyor line - ZRS power module up to 0.18 kW; time parameters adjustable via touch display - Rupture disc sensor and evaluation unit; pressure transmitter for frequency converter; pressure cells; strobe light; 2 x PTC thermistor evaluations; rotation monitoring of the rotary valve - 24 V DC supply air/return air switching for summer/winter operation - Filter monitor/residual dust monitoring with evaluation unit in accordance with DIN EN 12779 and H3: If 0.3 mg/m³ is exceeded, a self-holding alarm is triggered and the recirculation damper switches to exhaust air - 10-terminal junction box, 24 V/230 V, fully wired for filter cleaning, including approx. 6 lfm of cable - Ducting system including elbows, branch pipes, reducers, PU hoses, machine connections, small parts, and EP dampers for exhaust from 11 woodworking machines 1 HRS as specified - Return air system in accordance with TRGS 553, with changeover damper and fire damper - Galvanized base frame for container l...

Condition: excellent (used), Year of construction: 2013, radial fan, dust extraction blower, fan, extraction, dust blower -Manufacturer: TEKA, radial fan in soundproof container -Motor: 22 kW -Speed: 1460 rpm -Volume flow rate: 20,000 m³/h -Pressure: 3,000 Pa -Fan wheel: Ø 720 mm Lsdpszunw Refx Amvjag -Inlet connection: Ø 500 mm -Outlet connection: Ø 500 mm -Dimensions: 2150/1770/H2300 mm -Weight: 1051 kg

Condition: used, Year of construction: 2007, functionality: fully functional, power: 100 kW (135.96 HP), heating capacity: 100 kW (135.96 HP), nominal heat output: 100 kW (135.96 HP), nominal power: 100 kW (135.96 HP), tank capacity: 5,000 l, We are offering this used HDG Bavaria 100kW heating system with articulated arm discharge, manufactured in 2007. Ljdjyrhd Topfx Amvsag Manufacturer: HDG Bavaria Model: 100kW with articulated arm discharge Year of manufacture: 2007 If you have any questions or require further information, please feel free to send us a message or give us a call. The system is currently still in operation and can be inspected. The offer includes a 5,000L buffer tank, control unit, and various spare parts (which we have kept in stock as a precaution).

Condition: excellent (used), Year of construction: 1980, functionality: fully functional, power: 0.35 kW (0.48 HP), suction capacity: 400 m³/h, Capacity: 400 m³/h Laedpfx Aozu Th Iomvsg Negative pressure: 1250 Pa Motor: Type B5-71 with 2850 rpm Connection: 380 V Total power consumption: 0.37 kW Machine weight approx.: 35 / 28 kg Machine dimensions approx. L x W x H: Ø 0.5 x 1.3 m

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, power: 3 kW (4.08 HP), input voltage: 400 V, input frequency: 50 Hz, volume flow: 2,500 m³/h, intake vacuum (max.): 22 mbar, intake manifold diameter: 140 mm, filter area: 10 m², total height: 1,940 mm, total length: 1,040 mm, total width: 898 mm, overall weight: 210 kg, Equipment: CE marking, For sale is a used Felder clean air extraction unit RL 140, manufactured in 2023. This compact and powerful extraction system ensures clean air conditions in the workshop and is ideally suited for use with panel saws, planers, milling machines, and other woodworking machines. Thanks to the H3-certified clean air system, a residual dust content of less than 0.1 mg/m³ is achieved. The unit is in good condition and is ready for immediate use. The fan wheel, which is located on the clean air side, prevents dust from escaping and ensures a high level of operational safety. Equipment: Lajdpfx Amszwmxxsvjg • Clean air extraction system with H3 certification • Manual filter shaker • Large 200-liter chip container • Compact design • High extraction performance with minimal space requirements • Ideal for professional woodworking shops • Nominal air flow rate: 1,108 m³/h • Residual dust content: < 0.1 mg/m³ (H3 certified)

Condition: ready for operation (used), Awatech electrostatic system Dimensions approximately 140x60x60cm The system was operational until it was dismantled. No further information is available; however, the price is very attractive. Lasdozwl Dyepfx Amvjg
