Used Lotze Bending Tool, Swivel Bending Machine, Split for sale (67,534)

Condition: used, Year of construction: 1986, tube diameter 4-20 mm wall strength 2 mm Nsdewbi Hcspfx Akuowg bending radius min. 10 mm bending radius max. 75 mm bending speed 35 mm/min pull up length of tube 2000 mm total power requirement 7,5 kW weight of the machine ca. 1,1 t dimensions ca. 3100x1000x1400 mm

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Technical details x-travel 300 mm y-travel 160 mm z-travel 290 mm table surface area 600 x 210 mm tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 830 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a training workshop. Equipment: Nwsdoy Tt I Uspfx Akusg * 3-axis positioning control with active digital display Heidenhain TNC 123 - Manual mode: Manual operation and positioning with manual input - Automatic mode: Single-block programme run, programme storage * Fixed angle table * Movable vertical milling head, swivel range +/- 90 degr., quill stroke 60 mm * Coolant equipment * Central lubrication * Tailstock with counter bearing * Manual

Condition: good (used), Year of construction: 1982, functionality: fully functional, Tool milling machine with 3D control, manual handwheels, and a universal table adjustable in three axes. Control: Deckel Dialog Control 4: 3D contouring control, including drilling and milling cycles Monitor, electronic handheld control panel Terminal for program input and output Technical specifications: Travel range X/Y/Z 300 x 220 x 400 mm Speed 31.5 - 3,150 rpm with 21 gear stages Feed rate 4-2,000 mm/min Rapid traverse 4 m/min Drive power 1.6-2.0 kW SK 40 tool holder Hydraulic tool clamping Universal milling table with digital display: Clamping area 600 mm x 320 mm Table load 180 kg C-axis rotation range 360° A-axis tilt range 15°/45° B-axis swivel range +/- 45° Vertical milling head: Manual quill stroke - horizontally 65 mm, vertically 60 mm Additional equipment: Manual machine handwheels with scale Direct travel measurement of the NC axes Cooling water system Special accessories: Nwodpfxowid Sps Akusg Approx. 33 tool holders (without tools) - see photo High-speed milling spindle Machine data: Machine weight approx. 1,380 kg Space requirement including accessories L approx. 2,940 mm, W approx. 1,900 mm, H approx. 1,960 mm Power supply: 380 V, 50 Hz, 12 kVA The machine is in good, fully functional condition. It can be inspected with power and chippings by appointment.

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details x-travel 620 mm y-travel 420 mm z-travel 400 mm Control Heidenhain TNC 410M table surface area 800 x 400 mm tool taper ISO 40 spindle turning speed - stepless 50 - 4000 U/min main drive motor 5,5 kW weight of the machine ca. 2,1 t Additional information * CNC control HEIDENHAIN TNC 410M * Coolant equipment * Machine lamp Nodpsy Tlx Sofx Akuowg

Condition: used, Year of construction: 1990, x-travel 600 mm y-travel 400 mm z-travel 420 mm control TNC 355 Heidenhain Main spindle: turning speed range - main spindle 20 - 4.000 min/-1 power capacity - main spindel 7 kW transmission ratio 3 tool taper SK 40 distance spindle /table 127 - 567 mm spindle diameter in front bearing 55 mm stroke of quill vertical 75 mm tool clamping 10 kN swivellable +/- 90 ° work table: table surface area 900 x 458 mm T-slots 7x 63 x 14H7 Njdpfx Aetqmm Ajkuewg feeds: feed range 1 - 5.000 mm/min Feed force 5,4 kN rapid traverse ( X / Y / Z ) 7 / 7 / 6 m/min total power requirement 13 kW weight of the machine ca. 3,0 t dimensions of the machine ca. 4,0 x 4,0 x 2,1 m Tool Room Milling Machine - Universal HERMLE - UWF 900 E - Spindle-Head swivable +/- 90°

Condition: used, Year of construction: 1997, turning speeds 3.000 U/min Nwsdpfx Aksup H D Eeuog grinding wheel diameter 150 mm table-size 380 x 220 mm T-slots 1x 0 3~220 / 380 V total power requirement 0,37 kW weight of the machine ca. ca. 150 kg dimensions of the machine ca. 0,7 x 0,6 x 1,25 m Turning Tool Grinding Machine GREIF - DHL K-0

Condition: used, Year of construction: 1966, pressure 10 t table surface area 1.800 x 205 mm ram stroke 150 mm ram head width 50 mm throat 150 mm quantity of oil 75 l connected load 380 V / 50 Hz dimensions of the machine ca. 2,0 x 1,0 x 2,10 m Straightening Press EITEL - RP 10 Nedpfxoymp R Re Akuswg

Condition: ready for operation (used), ERCOLINA TOPBENDER with 2-axis positioning system / 3 meters Nwsdpfoy T Namjx Akusg -CE marking -Pipe capacity 60mm -Bending radius R10-R300 -Bending angle 0-180 degrees -Motor power 1.5 KW -Bending speed 1.25-1.5 revolutions/min -Includes 2-axis positioning system / 3 meters -2 sets of tooling with sliding shoe R100-1-1/4 & R67-25mm -Foot switch -Documentation Dimensions: L x W x H (base machine) 0.7 x 0.9 x 1.4 meters / Total weight 220 kg Errors and omissions excepted.

Condition: as good as new (ex-display), Year of construction: 2026, Hydraulic horizontal bending machine - Model T 200 with stop - feeding machine - stroke length 185 mm - Weight 500 kg Bending capacity up to flat bars ST 37 is 200x12 mm (with appropriate tool) with punch R 5 and die V 100 mm Nwodpfx Aoy T Ranskusg

Condition: excellent (used), You are bidding on: a high-quality plate shear and bending brake from a very good and well-known manufacturer – Schechtl. Features of the machine: Plate shear HT 200 Capacity: 1.25mm steel, aluminum, etc. Cutting length: slightly over 2m (blade in top condition, see photos; original lettering still present, which may fade after frequent cutting) Back gauge Light bar with LED for cut line illumination Adjustable front support Bending brake KS – Capacity: 1mm steel, aluminum, up to approx. 1.5mm Bending length: slightly over 2m Foot pedal Optional: back gauge or beading tool Attachment rail Round dies and other dies According to §25a UStG The machines are in good used condition and are ready for immediate use; they come from a private collection. Important! Optionally, you can find and purchase many machines and machine accessories in our shop, such as various dies, back gauges – everything related to sheet metal and steel processing, including bending brakes, plate shears, drilling machines, slitting and profiling machines, accessories (beading equipment, round dies for gutter production, back stops, etc.), and other hand tools and spare parts from many top manufacturers. I am always available to answer your questions. You will receive an invoice according to §25a UStG, which includes the value-added tax – differential taxation. Nsdpfx Akjy T H Nxsuowg Free loading is possible – weight approx. 750 kg and 650 kg. Inspection and testing are possible and recommended after scheduling an appointment by phone. Payment in cash upon collection. Take advantage of our experience and expertise; we will be happy to advise you. Collection by the buyer (or by a shipping company commissioned by the buyer) should take place within 10 days after the end of the auction. Location: 97249 Eisingen, approx. 3 minutes from the A3 and A81 motorways. Article number: Bending brake KS 260504 & HT 260505

Year of construction: 1995, condition: ready for operation (used), Rated current: 22A, connected load: 15kVA, with extensive accessories, the machine is fully functional. An on-site inspection is possible. Nodey Tx Sxepfx Akujwg

Condition: good (used), Clamping surface of the fixed angle table: 195 x 605 mm Table travel longitudinal/vertical automatic and manual: 290/300 / 330/340 mm Spindle head transverse travel manual: 150 mm Spindle taper: ISA 40 16 spindle speeds: 40 - 2000 rpm 16 feeds: 10 - 500 mm/min Spindle drive motor: 380 V, 1/1.4 kW Nwsdpfx Ajyvgf Rskujg Weight approx.: 660 kg Space requirement: 1200 x 900 x 1570 mm

Condition: like new (used), Technical data: Applications: Nsdpfx Asy S U Umekuswg Straightening and bending of steel beams, steel plates, pipes, welded structures, etc. Electric control Working speed hydraulically adjustable Pressing force: 200 tons Table size: 700 x 700 mm Tool height: 600 mm Straightening ram height: 600 mm Stroke length: 0 - 550 mm Bending speed: 0 – 0.6 m/min. Motor power: 18.5 kW CE marking Weight: approx. 12.5 tons Accessories: Straightening beam with support: 5200 mm Condition: Very good, almost new condition The seller is not liable for typing or data transmission errors. The machine’s appearance, technology, and wear are consistent with its age; used machines are sold without any warranty.

Condition: new, 3-roller round bending machine ORM 2070 x 140 Technical specifications: Special equipment included in the price: motorized bottom roller adjustment Nedofig Apepfx Akuewg hardened rolls motorised rear roller adjustment Digital display Plate width 2070 mm Sheet thickness 5.0 mm max. Bend sheet thickness 4.0 mm Roll length 2070 mm Roller diameter 140 mm Weight 1730 kg Dimensions L-W-H 3230 x 880 x 1100 mm Engine: 2.2 KW Equipment: upper and lower roller electrically driven Upper roller swivels out Conical bending device asymmetrical roller arrangement self-braking main engine sep. control and operating panel Safety leash CE mark

Condition: excellent (used), Table 1,200 x 450mm, X 560 Y 510 Z 450. ISO 40 4,000Rpm, Heidenhain TNC 410 Nwedpsy S T Tnefx Akujg

Condition: used, Hydraulic Profile Bending Machine, Pipe Bending Machine LANG Type Ondomat 60 Serial No. 2589 Year of manufacture: 1970 Bending capacity max.: Ø 60 x 2 mm Pressing force: 20 tons Counterforce: 7.5 tons Maximum bending angle: 135° Tool stroke: 250 mm Maximum tool width: 125 mm External width of tool rocker: 90 mm Motor power: 18 kW Power supply: 380 Volt, 50 Hz - Hydraulic bending process with counterpressure cylinder for wrinkle-free bending - Up to 10 different bending angles in sequence via automatic indexing turret - Two-hand control panel - 1 set of bending dies Ø 30 mm, die width rocker = 78 mm, die width counterholder = 50 mm Required space (L x W x H): 2000 x 750 x 1500 mm Weight: approx. 2 tons Good condition Nwsdpfx Ajyi Hrwekuog

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min Nwsdpfstqqllsx Akusg feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Condition: used, Year of construction: 1976, x-travel 350 mm y-travel 150 mm z-travel 340 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 40 - 2000 U/min feeds 5 - 500 mm/min Nodpewwwr Esfx Akuswg rapid traverse 1,2 m/min total power requirement 1,9 kW weight of the machine ca. 0,7 t - machine out of teaching shop - Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, various tool fixtures, various collets, original DECKEL tool cabinet

Condition: used, Year of construction: 1981, x-travel 800 mm y-travel 500 mm z-travel 460 mm table surface area 1000 x 500 mm spindle taper SK 40 control HEIDENHAIN TNC 150 Nwjdpfxotqqplo Akusg spindle turning speed range 31,5 - 3150 U/min feeds longditudinal/cross/vertical 1 - 3000 mm/min rapid traverse longitudinal and cross 6 m/min rapid traverse vertical 4 m/min quill stroke 110 mm distance spindle nose and table max. 559 mm table load capacity max. 500 kg total power requirement 14 kW weight of the machine ca. 3,1 t dimensions of machine L x W x H 2,15 x 1,8 x 2,15 m Accessories: vertical head with hydr. tool clamping and quill retraction, solid table, coolant

Condition: used, grinding wheel diameter 350 mm no. of working stations 2 grinding wheel width max. 125 mm work piece support jeweils 470 x 260 mm dimensions l/w/h 1,32 x 0,78 x 1,3 m - work piece support can be swivelled - Nsdpfx Akotqqmcouowg

Condition: used, Year of construction: 1989, x-travel 350 mm y-travel 200 mm z-travel 350 mm table surface area 700 x 280 mm spindle taper SK 40 150 - 1660 U/min feeds 25 - 285 mm/min rapid traverse 1 m/min Nwedpfxjvzhidj Akujg quill stroke 80 mm milling-head swivable +/- 45 ° total power requirement 3 kW weight of the machine ca. 1,2 t dimensions of machine L x W x H 1,27 x 1,1 x 1,65 m Accessories: vertical head with quill retraction, solid table, univ. table, rotary table 250 mmø, dividing unit with 3-jaw chuck 135 mmø, counter bearing, various tool fixtures, drill chuck, coolant

Condition: used, Year of construction: 1978, x-travel 300 mm y-travel 160 mm z-travel 340 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 40 - 2000 U/min feeds 5 - 500 mm/min rapid traverse 1,2 m/min total power requirement 1,9 kW weight of the machine ca. 0,7 t - machine out of teaching shop - Njdpfx Ajwl N R Nskuowg Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, counter bearing, various tool fixtures, various collets, original DECKEL tool cabinet

Condition: used, Year of construction: 1965, x-travel 700 mm y-travel 350 mm z-travel 450 mm table surface area 940 x 510 mm spindle taper SK 40 spindle turning speed range 32 - 1600 U/min feed - longitudinal/cross 8 - 400 mm/min feeds vertical 4 - 200 mm/min total power requirement 4,5 kW dimensions of machine L x W x H 1,85 x 1,62 x 1,83 m Nwsdpfjvzhh Tjx Akujg Accessories: vertical head with quill retraction, univ. table, counter bearing, coolant

Condition: used, Year of construction: 1973, x-travel 290 mm y-travel 170 mm z-travel 310 mm table surface area 600 x 215 mm spindle taper SK 40 spindle turning speed range 50 - 2500 U/min feeds 9 - 450 mm/min quill stroke 70 mm total power requirement 1,8 kW weight of the machine ca. 860 kg dimensions of machine L x W x H 1,06 x 1,05 x 1,33 m Accessories: vertical head with quill retraction, solid table, counter bearing, Nwedetqqn Rspfx Akueg coolant

Condition: used, Year of construction: 1985, x-travel 710 mm y-travel 600 mm z-travel 500 mm NC-rotary table 630 mm Nwjdpfx Akstqqtboujg spindle taper SK 40 spindle turning speed range 18 - 6300 U/min control DIALOG 4 feed 2 - 3600 mm/min rapid traverse 6 m/min table load max. 485 kg quill stroke 80 mm spindle drive 9,5 kW total power requirement 20 kVA weight of the machine ca. 4,6 t dimensions 3,8 x 2,24 x 2,35 m Accessories: vertical head with hydr. tool clamping and quill retraction, electron. handwheel, coolant
